GREAT PLAINS BD7600 User manual

Read the operator manual entirely. When you see
this symbol, the subsequent instructions and
warnings are serious - follow without exception.
Your life and the lives of others depend on it!
Illustrations may show optional equipment not
supplied with standard unit.
!
Table of Contents Index
Original Instructions 195-615m
Great Plains
OPERATOR MANUAL
MODEL BD7600 50 Foot 3-Section Drill
DrillCommand Version 02.02.04.00 - 02.03.07.04
Min-Till Drill

Machine Identification
Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new
manual.
If you or the dealer have added options not originally ordered with the machine, or removed options that were
originally ordered, the weights and measurements are no longer accurate for your machine. Update the record by
adding the machine weight and measurements with the option(s) weight and measurements.
Dealer Contact Information
Model Number
Serial Number
Machine Height
Machine Length
Machine Width
Machine Weight
Year of Construction
Delivery Date
First Operation
Accessories
Name:
Street:
City/State:
Telephone:
Email:
Dealer’s Customer
No.:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

To our customer:
Congratulations on the purchase of your Great Plains product. Great Plains welcomes you to its
growing family of new product owners. Your product has been designed and built by skilled
workers using quality materials.
Your dealer has performed the necessary pre-delivery service to your machine, and will advise
you of the proper maintenance and operating practices that will give you long, satisfactory use of
your machine. Do not hesitate to contact your dealer when you have a question related to your
machine.
Your machine has been designed to run efficiently in most operating conditions, and will perform
relative to the service it receives. If you need customer service or repair parts, contact your dealer
who has trained personnel, repair parts, and equipment specially designed for Great Plains
products.
Read this manual carefully before using the machine. It will familiarize you with safety, operation,
adjustments, and maintenance of your new equipment. This manual must always be kept with
your machine.
Great Plains wants you to be satisfied with your product. If for any reason you do not understand
any part of this manual or are otherwise dissatisfied, please take the following actions first:
1. Discuss the matter with your dealership service manager. Make sure he is aware of
any problems so he can assist you.
2. If you are still unsatisfied, seek out the owner or general manager of the dealership.
If your dealer is unable to resolve the problem or the issue is parts related, please contact:
Great Plains Service Department
1525 E. North St.
P.O. Box 5060
Salina, KS, USA 67402-5060
Printed 05/04/2023 | English
Great Plains reserves the right to revise and improve its products at any time. This publication describes the state of this product at the
time of its publication, and may not reflect the product in the future. The content of this publication may be changed without notice.

© 2021 Great Plains | Printed in the United States of America
All rights reserved. No part of this publication may be reproduced, distributed, or transmitted in any form or by any
means, including photocopying, recording, or other electronic or mechanical methods, without the prior written
permission of the publisher, except in the case of brief quotations embodied in critical reviews and certain other
noncommercial uses permitted by copyright law.
Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, DrillCommand, Max-Chisel, Row-Pro, Singulator
Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press.
Registered trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains,
Land Pride, MeterCone, Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max,
Turbo-Trill, Ultra-Till, Whirlfilter, and Yield-Pro.
Brand and product names that appear and are owned by others are trademarks of their respective owners.
For permission requests, write to the publisher at the address below.
Great Plains Mfg.
1525 E. North St.
P.O. Box 5060
Salina, KS 67402
You can also visit our website at www.greatplainsag.com/en/manuals/905/product-manuals for a full catalog of this
and other manuals.
Ordering Information:
Quantity sales. Special discounts are available on quantity purchases by corporations, associations, and others. For
details, contact the publisher at the address above.
Orders for personal, non-commercial use. Please contact our service department by mail or our website
www.greatplainsag.com.

BD7600-50 Cover Index
Great Plains | 195-615m | 05/04/2023 v
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Intended Use Statement . . . . . . . . . . . . . . . . . . . 1
Prohibited Use . . . . . . . . . . . . . . . . . . . . . . . . 1
Machine Identification . . . . . . . . . . . . . . . . . . . . . 1
Directional Information . . . . . . . . . . . . . . . . . . . . . 1
Target Group for Operator Manual. . . . . . . . . . . . 2
Training and Instruction . . . . . . . . . . . . . . . . . 2
Range of Application . . . . . . . . . . . . . . . . . . . . . . 2
Safety Information . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Symbols and Signal Words. . . . . . . . . . . . 3
Observe Safety and Informational Symbols. . 3
Be Aware of Signal Words . . . . . . . . . . . . . . . 3
Before Getting Started . . . . . . . . . . . . . . . . . . . . . 3
Read Machine Information . . . . . . . . . . . . . . . 3
Wear Appropriate Clothing and Equipment . . 3
Inspect Machine Before Use . . . . . . . . . . . . . 3
Machine Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Operate Responsibly . . . . . . . . . . . . . . . . . . . 4
Handle Hydraulics with Care . . . . . . . . . . . . . 4
Avoid Potential Collision Damage . . . . . . . . . 4
Chemicals and Waste . . . . . . . . . . . . . . . . . . . . . 4
Dispose of Waste Properly. . . . . . . . . . . . . . . 4
Machine Maintenance . . . . . . . . . . . . . . . . . . . . . 5
Follow Tire Recommendations. . . . . . . . . . . . 5
Prepare for Performing Maintenance . . . . . . . 5
PTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Machine Transport . . . . . . . . . . . . . . . . . . . . . . . . 5
Use Safety Lights and Devices . . . . . . . . . . . . . . 5
Shutdown and Storage. . . . . . . . . . . . . . . . . . . . . 5
Safety Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Preparation and Setup. . . . . . . . . . . . . . . . . . . 13
Pre-Setup Checklist . . . . . . . . . . . . . . . . . . . . . . 13
Hydraulic Hose Connections . . . . . . . . . . . . . . . 13
Electrical Connections . . . . . . . . . . . . . . . . . . . . 13
Hitch Drill to Tractor . . . . . . . . . . . . . . . . . . . . . . 13
Drill Hitches . . . . . . . . . . . . . . . . . . . . . . . . . 14
Hydraulic System . . . . . . . . . . . . . . . . . . . . . . . . 15
Drill Leveling. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Center Box Frame Leveling . . . . . . . . . . . . . 15
Opener Frame Clearance. . . . . . . . . . . . . . . 15
Wing Box Alignment. . . . . . . . . . . . . . . . . . . 16
Align Transfer Drive Shaft - Ground Drive . . 16
Truss Tube Tension . . . . . . . . . . . . . . . . . . . 17
Hydraulic Manifold Blocks . . . . . . . . . . . . . . . . . 17
Setting Closed-Center Block . . . . . . . . . . . . 17
Ground Drive Setup . . . . . . . . . . . . . . . . . . . . . . 18
Preparation Checklist . . . . . . . . . . . . . . . . . . 18
Set Range. . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Set Gearbox . . . . . . . . . . . . . . . . . . . . . . . . . 19
Hydraulic Drive Setup. . . . . . . . . . . . . . . . . . . . . 19
Preparation Checklist . . . . . . . . . . . . . . . . . . 19
Set Drive Configuration . . . . . . . . . . . . . . . . 19
Adjust for Dry Fertilizer Density . . . . . . . . . . . . . 20
Material Loading. . . . . . . . . . . . . . . . . . . . . . . . . 20
Rear Compartment Loading . . . . . . . . . . . . . 21
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Ground Drive Calibration . . . . . . . . . . . . . . . 21
Hydraulic Drive Calibration . . . . . . . . . . . . . . 23
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Pre-Start Checklist . . . . . . . . . . . . . . . . . . . . . . . 27
Field Operation. . . . . . . . . . . . . . . . . . . . . . . . . . 27
Before Operating Checklist. . . . . . . . . . . . . . 27
Begin Operating . . . . . . . . . . . . . . . . . . . . . . 27
End Operating . . . . . . . . . . . . . . . . . . . . . . . 27
Hydraulic Jack . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Walkboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Walkboard Ladders . . . . . . . . . . . . . . . . . . . . . . 28
Raise and Lower Openers . . . . . . . . . . . . . . . . . 29
Opener Lock-Up . . . . . . . . . . . . . . . . . . . . . . 29
Folding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Unfolding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Transport Lift . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Raise Drill . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Lower Drill. . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Drill Boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Basic Box Components . . . . . . . . . . . . . . . . 32
Two Compartment Box Components . . . . . . 32
Divider Flap . . . . . . . . . . . . . . . . . . . . . . . . . 33
Wing Parking Stands . . . . . . . . . . . . . . . . . . . . . 33
Box Dividers . . . . . . . . . . . . . . . . . . . . . . . . . 34
Rain Flap . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Feed Cups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Feed Cup Components . . . . . . . . . . . . . . . . 36
Feed Cup Funnel . . . . . . . . . . . . . . . . . . . . . 36
Feed Cup Flap . . . . . . . . . . . . . . . . . . . . . . . 36
Slide Gate. . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Openers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Opener Down Pressure . . . . . . . . . . . . . . . . 37
Opener Overview . . . . . . . . . . . . . . . . . . . . . 40
Acremeter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Markers (Option) . . . . . . . . . . . . . . . . . . . . . . . . 41
Single Marker Operation. . . . . . . . . . . . . . . . 41
Dual Markers Operation . . . . . . . . . . . . . . . . 41

BD7600-50 Cover Index
Great Plains | 195-615m | 05/04/2023vi Great Plains l 195-615mvi
Section Control (Option). . . . . . . . . . . . . . . . . . . 41
Shaft Monitor (Option) . . . . . . . . . . . . . . . . . . . . 41
Scale Kit (Option) . . . . . . . . . . . . . . . . . . . . . . . . 41
Point Row Control Box (Option) . . . . . . . . . . . . . 42
Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Parking with Drill Folded. . . . . . . . . . . . . . . . 43
Parking with Drill Unfolded . . . . . . . . . . . . . . 43
Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Opener Adjustments . . . . . . . . . . . . . . . . . . . . . 44
Opener Leveling. . . . . . . . . . . . . . . . . . . . . . 44
Opener Frame Pivot Adjustment . . . . . . . . . 44
Opener Height . . . . . . . . . . . . . . . . . . . . . . . 45
Opener Spring Down Pressure . . . . . . . . . . 46
Opener Depth Adjustment . . . . . . . . . . . . . . 46
Disk Blade Adjustments . . . . . . . . . . . . . . . . 47
Disk Scraper Adjustment (Option) . . . . . . . . 47
Seed Firmer Adjustments. . . . . . . . . . . . . . . . . . 48
Keeton® Seed Firmer (Option) . . . . . . . . . . 48
Seed-Lok® Firming Wheel (Option) . . . . . . . 48
Knock Down Adjustment . . . . . . . . . . . . . . . . . . 48
Tine Pitch Angle . . . . . . . . . . . . . . . . . . . . . . 48
Knock Down Bar/Disk Gap. . . . . . . . . . . . . . 48
Scraper/Disk Gap. . . . . . . . . . . . . . . . . . . . . 49
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Hitches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Hydraulic Block Options . . . . . . . . . . . . . . . . . . . 50
Shaft Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Seed Firmers . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Seed-Lok® Firming Wheel . . . . . . . . . . . . . . 50
Keeton® Seed Firmer . . . . . . . . . . . . . . . . . . 51
HD Narrow Disk Scraper . . . . . . . . . . . . . . . . . . 51
Disk Scraper Installation. . . . . . . . . . . . . . . . 51
Press Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Press Wheel Scraper . . . . . . . . . . . . . . . . . . . . . 51
Seed Hoses/Fertilizer Tubes . . . . . . . . . . . . . . . 52
Rubber Seed Flap . . . . . . . . . . . . . . . . . . . . . . . 52
Blockage Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Box Divider Insert. . . . . . . . . . . . . . . . . . . . . . . . 53
Scale Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Touch800® Console Kits . . . . . . . . . . . . . . . . . . 53
Work Light Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Knock Downs . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Camera Package . . . . . . . . . . . . . . . . . . . . . . . . 54
Fertilizer Tank . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Topcon Console System . . . . . . . . . . . . . . . . . . 55
Low Speed Sprocket Kits . . . . . . . . . . . . . . . . . . 55
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Maintenance Schedule. . . . . . . . . . . . . . . . . . . . 56
Regular Maintenance . . . . . . . . . . . . . . . . . . . . . 56
Hydraulic Maintenance. . . . . . . . . . . . . . . . . . . . 57
In-Line Filter . . . . . . . . . . . . . . . . . . . . . . . . . 57
Material Clean-Out . . . . . . . . . . . . . . . . . . . . . . . 57
Flow Tent Replacement . . . . . . . . . . . . . . . . . . . 58
Feed Cup Maintenance . . . . . . . . . . . . . . . . . . . 58
Feed Cup Removal. . . . . . . . . . . . . . . . . . . . 58
Feed Cup Installation . . . . . . . . . . . . . . . . . . 59
Seed Wheel . . . . . . . . . . . . . . . . . . . . . . . . . 59
Feed Cup Flap . . . . . . . . . . . . . . . . . . . . . . . 60
Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Chain Clips . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Markers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Marker Shear Bolt. . . . . . . . . . . . . . . . . . . . . 61
Marker Disk Lubrication . . . . . . . . . . . . . . . . 61
Ground Drive Gearbox . . . . . . . . . . . . . . . . . . . . 61
Hydraulic Drive . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Knock Down Maintenance . . . . . . . . . . . . . . . . . 62
Seed Flap Replacement. . . . . . . . . . . . . . . . . . . 62
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Grease Fittings . . . . . . . . . . . . . . . . . . . . . . . 63
Wheel Bearings . . . . . . . . . . . . . . . . . . . . . . 63
Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 64
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Torque Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Tire Information . . . . . . . . . . . . . . . . . . . . . . . . . 68
Electrical Harness Routing . . . . . . . . . . . . . . . . . 69
Lighting Harness. . . . . . . . . . . . . . . . . . . . . . 69
Hydraulic Diagrams . . . . . . . . . . . . . . . . . . . . . . 69
Fold. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Lift, Hook, and Hydraulic Jack . . . . . . . . . . . 70
Split Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Section Control with Closed Center . . . . . . . 74
Non-Section Control with Closed Center . . . 77
Hydraulic Drive Configuration. . . . . . . . . . . . 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

BD7600-50 Table of Contents Index Introduction
Great Plains | 195-615m | 05/04/2023 1
Introduction
The BD7600-50 Drill is a towed seeding/fertilizing
implement. This two section min-till drill has a working
width of 50 feet (15 m) and folds to a width of 16 feet (4.9
m) for transport.
The seed metering system is ground drive or hydraulic
drive.
Intended Use Statement
The BD7600-50 Drill with standard equipment and/or
authorized attachments and options is intended to be used
as a seeding/fertilizing implement when operated
according to instructions and safety precautions in this
manual, machine decals, or other information provided
with the machine.
The drill has straight arm, double disk openers. The
opener disks make a seed furrow, and seed tubes mounted
between the disks place seed in the furrow. Press wheels
following the opener disks, close the furrow and gauge the
opener seeding depth.
The drill features active hydraulic down pressure on the
opener frames. Constant down pressure ensures even
opener penetration in uneven ground. Hydraulic down
pressure is adjustable at a single point.
A drill equipped with one-compartment boxes can be used
to drill either seed or small seed.
A drill equipped with two-compartment boxes allow two
different materials to be put down in the same field pass.
Dividers separate each drill box into two compartments
with an equal amount of feed cups for each compartment.
The two-compartment boxes can be used for
combinations, such as seed and fertilizer, small seed and
fertilizer, seed and small seed, or small seed and small
seed.
Use this implement to seed production-agriculture crops in
conventional or minimum tillage applications. Do not
modify the drill for use with attachments other than Great
Plains options and accessories specified for use with the
BD7600-50 Drill.
Prohibited Use
Do not use this machine for any purpose or in any way
other than what is described in this manual, machine
decals, or any other information provided with the
machine by the manufacturer. These materials define the
intended use of the machine.
Unauthorized modifications to the machine will relieve
the manufacturer of all liability for any resulting injury or
damage.
Machine Identification
The machine identification plate is located on the left end
of the drill frame under the box.
Your machine’s parts were specially designed and should
only be replaced with Great Plains parts. Always use the
serial and model number when ordering parts from your
dealer. Record your drill model and serial number on the
inside cover of this manual for quick reference.
Directional Information
All directional information in this manual, such as left,
right, front, rear, forward, or backward, is determined by
facing the direction of forward travel of the machine.
71502

Great Plains | 195-615m | 05/04/20232 2Great Plains l 195-615m
BD7600-50 Table of Contents Index Introduction
Target Group for Operator Manual
Simplified Illustrations
Illustrations of the machine in the operator
manual are shown without protective equipment - or
with the protective equipment open - for better
understanding. Be sure to observe the safety
information and follow the handling instructions
in the operator manual. Serious or fatal injury
may be caused as a result.
This operator manual is aimed at trained
agriculturists and persons who are otherwise qualified for
agricultural activities and have received instruction in
working with this machine.
For your safety - You must familiarize yourself with the
contents of this operator manual before assembly or initial
operation of the machine. In this way, you will achieve
optimum work results and operational safety. The operator
manual forms an integral part of the machine and must
always be kept at hand. This will ensure that you:
avoid accidents.
comply with warranty conditions.
have a fully functional machine in good working order
at all times.
Training and Instruction
Your dealer will provide instruction on operation and care
of the machine.
Information for the employer - All personnel are to be
regularly, at least once a year, instructed on the use of the
machine, in accordance with the regulations of the
national organization for Health and Safety at Work.
Untrained or unauthorized persons are not permitted to use
the machine.
You are responsible for ensuring that the machine is
operated and maintained safely. Make sure that you and all
other persons that operate, maintain, or work in close
proximity with the machine are familiar with the operating
and maintenance regulations, as well as the corresponding
safety instructions in this operator manual.
Range of Application
This product is classified as replaceable equipment in
accordance with EC directive 2006/42/EC and agricultural
implement in accordance with ASABE S390.
!

BD7600-50 Table of Contents Index Safety Information
Great Plains | 195-615m | 05/04/2023 3
Safety Information
Safety Symbols and Signal Words
Observe Safety and Informational Symbols
Throughout this manual you will see the following safety
and informational symbols. They indicate safety hazards,
machine hazards, or information to improve operation.
Read the instructions carefully whenever you see any of
these symbols:
The safety symbol indicates a potential safety hazard
to persons operating or near the machine and advises
on how to avoid it.
The notice symbol indicates a potential for machine
or property damage from operator error and advises
on how to avoid misuse.
The information symbol indicates useful - but not
crucial - information for machine operation,
assembly, or adjustment.
Be Aware of Signal Words
Some decals are accompanied by a signal word. Signal
words indicate the seriousness of a potential hazard. These
signal words are:
DANGER indicates an imminent hazard which, if not
avoided, will result in death or serious injury. This signal
word is limited to the most serious situations, typically for
unguarded machine components.
WARNING indicates a potential hazard which, if not
avoided, could result in death or serious injury including
hazards that are exposed when guards are removed. It also
alerts against unsafe practices.
CAUTION indicates a potential hazard, which if not
avoided, may result in minor or moderate injury. It also
alerts against unsafe practices.
Before Getting Started
Read Machine Information
Read this manual in its entirety before attempting to start
and operate the machine. Do not let anyone operate
machine without proper instruction.
Non-Great Plains components on this machine may
contain additional safety information not found in this
manual. Consult the manufacturer’s safety
information and product decals to safely use products
from third-parties.
Wear Appropriate Clothing and Equipment
Never wear loose clothing around machine. Always
wear appropriate clothing and equipment such as hard
hats, gloves, face masks, eye protection, and work or
steel-toed boots as needed.
Prolonged exposure to machine noise during
operation can cause hearing impairment or loss. Use
proper hearing protection like earmuffs or earplugs
while working.
Inspect Machine Before Use
Inspect brakes, link pins, and other mechanical parts
for wear and dirt buildup, and check that all guards
and shields are undamaged, installed, and secure
before operating machine.
Check that hydraulic fittings are tight and all
hydraulic hoses and lines are in good working
condition before applying pressure to the system.
Do not modify the machine. Unauthorized
modification can result in unsafe conditions that lead
to machine damage or personal injury.
!
!
i

Great Plains | 195-615m | 05/04/2023 4 4Great Plains l 195-615m
BD7600-50 Table of Contents Index Safety Information
Machine Use
Operate Responsibly
Maintain attention on operation at all times to avoid
injury to yourself or others.
Do not operate machine while distracted by a smart
phone, tablet, or similar electronic device, or while
impaired by alcohol, medication, any controlled
substance, or while fatigued.
Do not ever allow passengers to ride on any part of the
machine at any time, for any reason.
Handle Hydraulics with Care
Keep clear of machine while hydraulics are in use.
Any failure in the hydraulic system can cause machine
parts to move or fall rapidly with a great deal of force.
Anyone struck, caught between, or crushed beneath
these parts can suffer serious injury or even death.
A raised planter without cylinder locks installed or
without active hydraulic pressure will slowly lower
over time. Use tractor hydraulics to raise planter only
for brief periods, such as field turns and cylinder lock
installation.
Relieve hydraulic pressure and wait for all parts to
come to a complete stop before disconnecting any
hydraulic lines or performing any work on the
hydraulic system.
Do not have skin exposed when searching for leaks in
hydraulic lines. Use a piece of cardboard or wood to
locate leaks. If injured by escaping hydraulic fluid, seek
immediate medical attention.
Wear protective gloves and eye protection when
working on the machine’s hydraulic system.
Avoid Potential Collision Damage
Watch your surroundings at all times. Do not operate
with nearby bystanders or while anyone makes
adjustments or fills the machine.
Avoid contacting overhead obstructions such as low
bridges, overpasses, and power lines.
Do not operate near ditches, holes, steep slopes,
embankments, or other surfaces which may collapse
under the machine’s weight or tip the machine over.
Chemicals and Waste
Agricultural chemicals can be dangerous. Improper use can
seriously injure persons, animals, plants, soil and property.
Read chemical manufacturer’s instructions carefully,
and then take appropriate precautions before use. In
the absence of manufacturer instructions, chemical
labels will inform you of any potential hazards and
their severity.
Wear protective clothing and as well as any other
personal protective equipment.
Wash hands and face before eating after working with
chemicals. Shower as soon as application is
completed for the day.
Apply only with acceptable wind conditions. Make
sure wind drift of chemicals will not affect any
surrounding land, people or animals.
Dispose of unused chemicals and chemical waste as
specified by the manufacturer. Observe all the local
ordinances and regulations in your area.
Dispose of Waste Properly
Dispose of waste properly to avoid threatening the
environment and ecology. Potential harmful waste
includes oil, fuel, filters, and batteries.
Use a leak-proof container for draining fluids. Do not
use a food or beverage container that may be mistaken
for a consumable product.
Do not drain or pour waste onto the ground, down a
drain, or into any water source.
Contact your local environmental or recycling center
for the proper way to recycle or dispose of waste.

BD7600-50 Table of Contents Index Safety Information
Great Plains | 195-615m | 05/04/2023 5
Machine Maintenance
Follow Tire Recommendations
Consult the tire manufacturer’s recommendations for
maintenance and replacement of your machine’s tires.
Only use prescribed tire sizes with correct ratings and
tire pressure.
Replacing tires is potentially hazardous. Have a
trained professional change the machine’s tires with
the proper tools and equipment.
Avoid over inflation of tires and over torquing wheel
bolts. Review the machine specifications and tire
information in this manual first before doing any work
on the tires of your machine.
Prepare for Performing Maintenance
Understand procedure before performing any work.
Always use proper tools and equipment.
Only work on or around the machine if frame is
lowered, or raised with the cylinder locks in place.
Lower the implement. Put tractor in Park, turn off engine.
To prevent unauthorized starting, remove key before
performing maintenance or service work.
If work must be performed with wings raised, set the
wing tilt locks to the road position.
Disconnect electronic monitor and lighting harness
from the tractor before servicing or adjusting
electrical systems.
Check and replace worn brake lines as needed.
Remove all tools and unused parts from implement
before operation.
PTO
Wait until all moving components have completely
stopped before adjusting, cleaning, or servicing any
PTO driven equipment.
When operating stationary PTO driven equipment,
always apply the parking brake and place chocks
behind wheels.
Stay clear of and never step over any rotating parts.
Machine Transport
This machine does not meet all local, regional, or
national regulations for transport on a public road.
Know and comply with your local laws and
regulations before transporting your machine.
Transport only at recommended transport speed.
Further reduce speed when turning.
Before towing implement on roads, empty out all
material from hoppers or boxes. Implement should
never weigh more than 1.5 times the weight of towing
vehicle.
Know transport height and width of implement to
avoid collision.
Do not engage any hydraulic functions while machine
is in transport.
Use Safety Lights and Devices
Inspect safety chain and chain load rating before use with
machine. Never use the safety chain for towing. Replace
chain if any links or end fittings are broken, stretched, or
otherwise damaged.
Always use safety lights and devices when
transporting and operating the machine. If equipped,
use flashing warning lights and turn signals whenever
driving on public roads.
Regularly inspect safety lights, signs, and devices to
ensure that they are clean and visible from either end
of the machine.
Shutdown and Storage
Park the tractor and implement on a solid, level
surface devoid of bystanders.
Fold and tilt wings up.
Put tractor in park or set the parking brake. Turn off
engine and remove key from ignition.
Turn lockout valve and wing lock levers to locked
position to prevent the wings from lowering.
Detach the tractor. Secure the implement using blocks.

Great Plains | 195-615m | 05/04/20236 Great Plains l 195-615m 6
BD7600-50 Table of Contents Index Safety Decals
Safety Decals
Your implement comes equipped with safety reflectors
and decals in place.
Read and follow decal directions. Keep all safety decals
clean and legible. Replace all damaged, faded, or missing
decals.
Order new decals from your Great Plains dealer. Refer to
this section for proper decal placement.
When ordering new parts or components, also request
corresponding safety decals.
To install new decals:
Clean the area on which the decal is to be placed.
Peel backing from decal. Press firmly on surface, being
careful not to cause air bubbles under decal.
Slow Moving Vehicle Reflector
818-055C
One reflector at rear of center box. Two compartment
boxes, reflector is on rain flap (shown).
One reflector under center walkboard.
Red Reflectors
838-266C
One reflector on the inside end of each wing walkboard,
and two reflectors on the rear of center walkboard.
Two reflectors under center walkboard.
71490
71490A
71490B
71490A

BD7600-50 Table of Contents Index Safety Decals
Great Plains | 195-615m | 05/04/2023 7
Amber Reflectors
838-265C
One reflector on the outside end of each wing walkboard,
two on the rear of each wing walkboard, and one on each
end of center walkboard.
Two reflectors under each wing walkboard.
Daytime Reflectors
838-267C
Two reflectors on the rear of center walkboard.
Two reflectors under center walkboard.
71490C
71490D
71490B
71490A

Great Plains | 195-615m | 05/04/20238 Great Plains l 195-615m 8
BD7600-50 Table of Contents Index Safety Decals
Negative Tongue Weight Hazard
818-019C
One decal on the tongue near the hitch.
Pinch/Crush Hazard
818-045C
One decal on each side of the tongue near the transport
hooks
One decal on each end of the center section.
Excessive Speed Hazard
818-337C
One decal on the tongue near the hitch.
WARNING
NEGATIVE TONGUE WEIGHT
HAZARD
Negative tongue weight can cause immediate
elevation of tongue when unhitching implement
To prevent serious injury or death:
Always be certain implement is hitched securely
to tractor drawbar before raising.
Lower implement BEFORE unhitching.
818-019C Rev. D
71491
71491
71520
WARNING
EXCESSIVE SPEED
HAZARD
To Prevent Serious Injury or Death:
Do NOT exceed 20 mph maximum
transport speed. Loss of vehicle
control and/or machine damage
can result.
818-337C Rev. B
71491

BD7600-50 Table of Contents Index Safety Decals
Great Plains | 195-615m | 05/04/2023 9
High Pressure Fluid Hazard
818-339C
One decal on the tongue near the hitch.
Falling Hazard
818-398C
Two decals - One decal on each end of rockshaft.
Two decals - One decal on outside of each gauge wheel
mount.
Pinch Point Hazard
818-579C
One decal on the front of each marker.
71491
To Avoid Injury for Unsecured
Transport Tires:
Never stand on or use transport
tires as a step.
Tires not in contact with the
ground will rotate easily.
818-398C
CAUTION
71492
71492A
71474

Great Plains | 195-615m | 05/04/202310 Great Plains l 195-615m 10
BD7600-50 Table of Contents Index Safety Decals
Overhead Hazard
818-580C
One decal on the front of each marker.
General Instructions
818-587C
One decal on the tongue near the hitch.
Falling Hazard
838-102C
One decal on the end of each wing near the ladder.
Hydraulic Failure Hazard
844-146C
One decal on left end of rockshaft near transport lock.
71474
WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Read Owner’s Manual before using machine.
Stand clear when folding and unfolding markers.
Stand clear when raising and lowering machine.
Keep all safety shields and devices in place.
Keep hands, feet, and clothing away from
Never ride on machine.
Always lower or properly support machine
Escaping hydraulic fluid can cause serious
Review safety instructions with all operators
moving chains and sprockets.
BEFORE servicing.
818-587C Rev. B
injury.
annually.
CAUTION
71491
WARNING
To avoid serious injury or death:
Watch your step when climbing ladder or
walking on walkboard.
838-102C
71502
71492

BD7600-50 Table of Contents Index Safety Decals
Great Plains | 195-615m | 05/04/2023 11
Tire Inflation and Wheel Bolt Torque
844-421C
One decal on each gauge wheel mount.
General Hazard
848-512C
One decal on the tongue near the hitch.
Radar Hazard
848-577C
One decal on the left side of the tongue above the transport
tires.
Tire Inflation and Wheel Bolt Torque
858-861C
One decal on each transport wheel mount.
71492A
848-512C
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
71491
71492
To Avoid Injury or Machine Damage from Improper Tire
Inflation or Torquing of Wheel Bolts:
Maximum inflation pressure of tires is 73 psi.
Torque wheel bolts to 295 ft-lb.
858-861C
CAUTION
71492

Great Plains | 195-615m | 05/04/202312 Great Plains l 195-615m 12
BD7600-50 Table of Contents Index Safety Decals
Pinching/Crushing Hazard
858-950C
One decal on the tongue near the hitch.
71491

BD7600-50 Table of Contents Index Preparation and Setup
Great Plains | 195-615m | 05/04/2023 13
Preparation and Setup
This section helps you prepare your tractor and drill for
use. Before using the drill in the field, hitch the drill to a
suitable tractor to inspect the systems and setup the drill.
Pre-Setup Checklist
Read and understand “Safety Information”
beginning on page 3.
Check that all working parts are moving freely, bolts
are tight, and cotter pins are spread.
Check that all grease fittings are in place and
lubricated. See “Lubrication” on page 62.
Check that all safety decals and reflectors are
correctly located and legible. Replace if damaged. See
“Safety Decals” on page 6.
Inflate tires to the pressure recommended and tighten
wheel bolts as specified. See “Specifications” on
page 67.
Hydraulic Hose Connections
High Pressure Fluid Hazard
Escaping fluid under pressure can have
sufficient pressure to penetrate the skin. Check
all hydraulic lines and fittings before applying
pressure. Use paper or cardboard, not body
parts, and wear heavy gloves to check for
suspected leaks. If injured, seek immediate
medical attention from a physician familiar with
this type of injury.
Equipment Damage Risk
Use the proper hydraulic block to operate
openers, which depends on the type of tractor
hydraulics. If you are not familiar with your
tractor hydraulics, ask your dealer.
Hydraulic hoses have color coded handle grips to help
when connecting the hoses to the tractor outlets.
To distinguish hoses on the same hydraulic circuit, refer to
the symbol on the handle grip. Hoses with an
extended-cylinder symbol feed the cylinder base ends.
Hoses with a retracted-cylinder symbol feed the cylinder
rod ends.
Electrical Connections
Make sure the tractor is shut down with accessory power
off before making the following connections:
lighting connector to tractor outlet
console connector to tractor harness
any optional or after-market electrical connectors.
These connections can be made in any order, and must be
made before moving the drill.
Hitch Drill to Tractor
Crushing Hazard
Serious injury or death can result when standing
between drill and moving tractor. Do not stand
or place any body part between drill and moving
tractor when hitching drill. Keep others away.
Stop tractor engine and set parking brake before
installing hitch pins, and attaching harnesses
and hoses.
Negative Tongue Weight Hazard
This drill can have positive and negative tongue
weight, which can work the hitch pin loose
during transport. To avoid serious injury, always
use a clevis hitch or clevis draw bar with
locking-style hitch pin.
Color Hydraulic Function
Red Opener lift
Blue Transport lift/Jack
Green Marker
Gray Fold
Yellow Hydraulic Drive
!
!
21
31733
!
!

Great Plains | 195-615m | 05/04/202314 Great Plains l 195-615m 14
BD7600-50 Table of Contents Index Preparation and Setup
Drill Hitches
The drill has the following hitch options:
Single-tang, large hole
CAT IV swivel hitch
CAT V swivel hitch
Use the single-tang hitch for tractors with clevis draw
bars. Always use a locking-style hitch pin sized to match
the holes in the hitch and draw bar.
Hitch Height
Adjust the drill hitch to match the tractor draw bar height.
1. With the drill lowered to field position, extend the
jack so the lowest hitch hole is 18 inches (45.7 cm)
above ground level (A).
2. Install the drill hitch onto the tongue to match the
tractor draw bar height. The hitch can be turned over
for six different hitch heights.
Always have two bolts in two holes of both the tongue
and hitch.
When hitching the drill to a different tractor,
check for a difference in draw bar heights.
Adjust hitch height as necessary.
(B) 32.0 in (81.3 cm)
(C) 29.0 in (73.7 cm)
(D) 26.0 in (66.0 cm)
(E) 21.5 in (54.6 cm)
(F) 18.5 in (47.0 cm)
(G) 15.5 in (39.4 cm)
3. Securely attach the safety chain to an anchor on the
tractor capable of pulling the drill.
4. Raise the jack.
Hitch Installation
Install the hitch (1) onto the tongue and secure with the
bolt (2), lock washer, and nut. Assemble the safety chain
(3) and washer (4), and secure with the longer bolt (5),
lock washer, and nut.
i
15
4
3
2
71337
71445
A
BCDEFG
