GREAT PLAINS 3P606NT User manual

Manufacturing, Inc.
www.greatplainsmfg.com
© Copyright 2018 Printed 2018-06-06 151-061M
EN
Table of Contents Index
Table of Contents Index
ORIGINAL INSTRUCTIONS
Operator Manual
3P606NT, 606NT
2007+ 3P605NT and 605NT
6-Foot No-Till Drills
Read the operation manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit.
25105
25106

Machine Identification
Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new
manual.
If you or the dealer have added options not originally ordered with the machine, or removed options that were originally
ordered, the weights and measurements are no longer accurate for your machine. Update the record by adding the
machine weight and measurements with the option(s) weight and measurements.
Dealer Contact Information
Model Number
Serial Number
Machine Height
Machine Length
Machine Width
Machine Weight
Year of Construction
Delivery Date
First Operation
Accessories
Name:
Street:
City/State:
Telephone:
Email:
Dealer’s Customer
No.:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

3P605NT, 3P606NT, 605NT & 606NT Cover Index Table of Contents iii
2018-06-06 Cover Index 151-061M
© Copyright 2006, 2007, 2008, 2009, 2011, 2012, 2014, 2017, 2018 All rights Reserved
Great Plains Manufacturing, Inc. provides this publication “as is” without warranty of any kind, either expressed or implied. While every precaution has been
taken in the preparation of this manual, Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed for
damages resulting from the use of the information contained herein. Great Plains Manufacturing, Inc. reserves the right to revise and improve its products as
it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, Max-Chisel, Row-Pro,
Singulator Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press.
Registered Trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains, Land Pride, MeterCone,
Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo-Till, Ultra-Till, Whirlfilter, and Yield-Pro.
Brand and Product Names that appear and are owned by others are trademarks of their respective owners.
Printed in the United States of America
Table of Contents
Important Safety Information.................................................1
Safety Decals ....................................................................6
Introduction...........................................................................12
Description of Unit ...........................................................12
Intended Usage ........................................................12
Models Covered .......................................................12
Document Family .....................................................12
Using This Manual...........................................................13
Owner Assistance............................................................13
Preparation and Setup .........................................................14
Pre-Setup Checklist.........................................................14
Hitching Tractor to Drill....................................................14
Hitching Model 3P605NT or 3P606NT .....................14
Hitching Model 605NT or 606NT..............................15
Electrical Connections .....................................................16
Height and Leveling the Drill............................................17
Height Setup: Model 3P605NT or 3P606NT ............17
Height Setup: Model 605NT or 606NT .....................18
Operation Instructions .........................................................19
Pre-Start Checklist...........................................................19
Transporting 3P605NT or 3P606NT................................20
Use an Adequate Tractor (3-Point) ..........................20
3P605NT or 3P606NT Example Weights.................20
Transporting 605NT or 606NT.........................................21
Use an Adequate Tractor (Pull-Type).......................21
605NT or 606NT Example Weights..........................22
Use Transport Locks ................................................22
Loading Seed ..................................................................25
Main Seed Box Loading ..........................................25
Loading Native Grass Box.......................................25
Loading Small Seeds Box .......................................25
Field Operation ................................................................26
Re-Phasing Cylinders...............................................26
Acremeter Operation .......................................................27
Parking ............................................................................28
Storage ............................................................................29
Adjustments ..........................................................................30
Frame Weight Adjustment ...............................................31
Coulter Adjustments ........................................................32
Coulter Depth ...........................................................32
Coulter Down-Force .................................................33
Drive Clutch Adjustment..................................................33
05/06 Series Row Unit Adjustments................................34
Opener Spring..........................................................35
Disc Blade Adjustments ...........................................36
Disc Scraper Adjustment..........................................37
Seed Firmer Adjustments.........................................38
Small Seeds Tube Adjustment (Option)...................39
Opener Depth (Press Wheel Height) .......................39
Troubleshooting ...................................................................40
Maintenance and Lubrication..............................................42
Maintenance....................................................................42
Drive Idler Adjustment (605NT or 606NT)................43
Seed Clean-Out .......................................................43
Seed Flap Replacement..................................................44
Current Drill Model Flap ...........................................44
Older Drill Model Flap ..............................................45
Bleeding Hydraulics .................................................46
Chain Maintenance ..................................................47
Gearbox Maintenance..............................................47
Lubrication and Scheduled Maintenance ........................48
Options ..................................................................................53
Seed-Lok®Seed Firmer...........................................59
Appendix A - Reference Information ..................................60
Specifications and Capacities .........................................60
Tire Information ...............................................................60
Torque Values Chart .......................................................61
Hydraulic Diagram...........................................................62
Drive System Diagrams...................................................63
Native Grass Drive Chain Routing ..................................67
Small Seeds Drive Chain Routing ...................................68
Agitator Drive Chain Routing...........................................69
Seed Box Chain Routing .................................................70
Drive Chain Routing ........................................................71
Gauge Wheel Drive Chain Routing .................................72
Appendix B - Pre-Delivery ...................................................73
Appendix C - Accessory Installation ..................................74
Carbide Disc Scraper Installation ....................................74
Weight Bracket Installation..............................................75
Warranty..........................................................................76

Table of Contents Index
Table of Contents Index

2018-06-06 Table of Contents Index 151-061M
3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Important Safety Information 1
Important Safety Information
Look for Safety Symbol
The SAFETY ALERT SYMBOL indicates there is a
potential hazard to personal safety involved and extra
safety precaution must be taken. When you see this
symbol, be alert and carefully read the message that
follows it. In addition to design and configuration of
equipment, hazard control and accident prevention are
dependent upon the awareness, concern, prudence and
proper training of personnel involved in the operation,
transport, maintenance and storage of equipment.
Be Aware of Signal Words
Signal words designate a degree or level of hazard
seriousness.
DANGER, and the color Safety Red, indicate an
imminent hazard which, if not avoided, will result in death
or serious injury. This signal word is limited to the most
extreme situations, typically for machine components
that, for functional purposes, cannot be guarded.
WARNING, and the color Safety Orange, indicate a
potential hazard which, if not avoided, could result in
death or serious injury, and includes hazards that are
exposed when guards are removed. It may also be used
to alert against unsafe practices.
CAUTION, and the color Safety Yellow, indicate a
potential hazard which, if not avoided, may result in
minor or moderate injury. It may also be used to alert
against unsafe practices.
Prepare for Emergencies
Be prepared if a fire starts
Keep a first aid kit and fire extinguisher handy.
Keep emergency numbers for doctor, ambulance, hospital
and fire department near phone.
Be Familiar with Safety Decals
Read and understand “Safety Decals” on page 6,
thoroughly.
Read all instructions noted on the decals.
Keep decals clean. Replace damaged, faded and illegible
decals.

2018-06-06 Table of Contents Index 151-061M
3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Important Safety Information 2
Wear Protective Equipment
Wear protective clothing and equipment.
Wear clothing and equipment appropriate for the job.
Avoid loose-fitting clothing.
Because prolonged exposure to loud noise can cause
hearing impairment or hearing loss, wear suitable
hearing protection such as earmuffs or earplugs.
Because operating equipment safely requires your full
attention, avoid wearing entertainment headphones while
operating machinery.
Handle Chemicals Properly
Agricultural chemicals can be dangerous. Improper use
can seriously injure persons, animals, plants, soil and
property.
Do not use liquid seed treatments with the 3P606NT or
606NT.
Read and follow chemical manufacturer’s instructions.
Wear protective clothing.
Handle all chemicals with care.
Avoid inhaling smoke from any type of chemical fire.
Never drain, rinse or wash dispensers within 100 feet
(30 m) of a freshwater source, nor at a car wash.
Store or dispose of unused chemicals as specified by
chemical manufacturer.
Dispose of empty chemical containers properly. Laws
generally require power rinsing or rinsing three times,
followed by perforation of the container to prevent re-use.
Avoid High Pressure Fluids
(Model 605NT or 606NT only)
Escaping fluid under pressure can penetrate the skin,
causing serious injury.
Avoid the hazard by relieving pressure before
disconnecting hydraulic lines.
Use a piece of paper or cardboard, NOT BODY PARTS, to
check for suspected leaks.
Wear protective gloves and safety glasses or goggles when
working with hydraulic systems.
If an accident occurs, seek immediate medical attention
from a physician familiar with this type of injury.

3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Important Safety Information 3
2018-06-06 Table of Contents Index 151-061M
Use an Adequate Tractor
Model 3P605NT or 3P606NT only:
Ensure that the tractor is rated for, and correctly ballasted
for the drill’s 3-point loading. Check that drill plus ballast
does not exceed the tractor’s capability.
Avoid transport with material loaded in boxes.
Model 605NT or 606NT only:
Ensure that the tractor weighs at least 2/3(67%) of the
drill (including the weight of any Options and materials).
Avoid transport with material loaded in boxes.
Use A Safety Chain
(Model 605NT or 606NT only)
Use a safety chain to help control drawn machinery
should it separate from tractor drawbar.
Use a chain with a strength rating equal to or greater than
the gross weight of towed machinery.
Attach chain to tractor drawbar support or other specified
anchor location. Allow only enough slack in chain to
permit turning.
Replace chain if any links or end fittings are broken,
stretched or damaged.
Do not use safety chain for towing.
Keep Riders Off Machinery
Riders obstruct the operator’s view. Riders could be
struck by foreign objects or thrown from the machine.
Never allow children to operate equipment.
Keep all bystanders away from machine during operation.
Use Safety Lights and Devices
Slow-moving tractors and towed implements can create
a hazard when driven on public roads. They are difficult
to see, especially at night.
Use flashing warning lights and turn signals whenever
driving on public roads.
Use lights and devices provided with implement

2018-06-06 Table of Contents Index 151-061M
3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Important Safety Information 4
Transport Machinery Safely
Maximum transport speed for the implement on its own
tires is 20 mph (30 kph). Rough terrain may require a
slower speed. Sudden braking can cause a towed load to
swerve and upset.
Do not exceed 20 mph (30 kph). Travel only at a speed
which allows adequate control of steering and stopping.
Comply with state and local laws.
Carry reflectors or flags to mark drill in case of
breakdown on the road.
3-point implements reduce weight on steering tires. Verify
that tractor is correctly ballasted. Watch for signs of poor
steering traction.
Shutdown and Storage
Park on level ground.
Unhitch and store the drill in an area where children
normally do not play.
Tire Safety
Tire changing can be dangerous and should be
performed by trained personnel using correct tools and
equipment.
When inflating tires, use a clip-on chuck and extension
hose long enough for you to stand to one side–not in front
of or over tire assembly. Use a safety cage if available.
When removing and installing wheels, use wheel-handling
equipment adequate for weight involved.
Practice Safe Maintenance
Understand procedure before doing work. Use proper
tools and equipment. Refer to this manual.
Work in a clean, dry area.
Lower the drill, put tractor in park, turn off engine, and
remove key before performing maintenance. If work must
be performed with implement raised, use blocks or
jackstands rated for the drill weight.
Make sure all moving parts have stopped and all system
pressure is relieved.
Allow drill to cool completely.
Disconnect battery ground cable (-) before servicing or
adjusting electrical systems.
Welding: Disconnect battery ground. Avoid fumes from
heated paint.
Inspect all parts. Make sure parts are in good condition
and installed properly.
Remove buildup of grease, oil or debris.
Remove all tools and unused parts from drill before
operation.

3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Important Safety Information 5
2018-06-06 Table of Contents Index 151-061M
Safety At All Times
Thoroughly read and understand the instructions in this
manual before operation. Read all instructions noted on
the safety decals.
Be familiar with all drill functions.
Operate machinery from the driver’s seat only.
Do not leave drill unattended with tractor engine running.
Do not stand between the moving tractor and drill during
hitching.
Keep hands, feet and clothing away from power-driven
parts.
Wear snug-fitting clothing to avoid entanglement with
moving parts.
Make sure all persons are clear of working area.

2018-06-06 Table of Contents Index 151-061M
3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Important Safety Information 6
Safety Decals
Safety Reflectors and Decals
Your implement comes equipped with all lights, safety
reflectors and decals in place. They were designed to
help you safely operate your implement.
Read and follow decal directions.
Keep lights in operating condition.
Keep all safety decals clean and legible.
Replace all damaged or missing decals. Order new decals
from your Great Plains dealer. Refer to this section for
proper decal placement.
When ordering new parts or components, also request
corresponding safety decals.
To install new decals:
1. Clean the area on which the decal is to be placed.
2. Peel backing from decal. Press firmly on surface,
being careful not to cause air bubbles under decal.
Reflector: Slow Moving Vehicle (SMV)
At center of walkboard;
1 total
See transport topic on page 20 or page 21.
Reflectors: Red
On rear face of walkboard, left and right ends;
2 total
See transport topic on page 20 or page 21.
Reflectors: Amber
On side frames at walkboard ends;
2 total
See transport topic on page 20 or page 21.
818-055C
32693
838-266C
32693
838-266C
32693

3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Important Safety Information 7
2018-06-06 Table of Contents Index 151-061M
Reflectors: Amber (With Weights Option)
838-266C
On decal mounts attached to top front tool bar;
2 total
See transport topic on page 20 or page 21.
Danger: Hitch Crush
(3P605NT and 3P606NT only)
Front face, each end of top front tool bar;
2 total
Danger: Moving Chain (Option)
(optional Native Grass box)
On chain guard of Native Grass option box (left end);
1 total
Danger: Possible Chemical Hazard (Option)
(with Small Seeds Option only)
Under lid;
1 total
18621A
818-590C
32695
818-518C
818-518C
DONOT operate with inclosure missing
Toprevent seriousinjury from movingchain:
MOVING CHAIN HAZARD
DANGER
32700
818-518C REV. B
DO NOT operate with enclosure missing
CAUTION
MOVING CHAIN HAZARD
To prevent serious injury from moving chain:
838-467C
32696

2018-06-06 Table of Contents Index 151-061M
3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Important Safety Information 8
Warning: Speed
On front face, upper front frame tube, left of center;
1 total
See transport topic on page 20 or page 21.
Warning: Moving Parts (standard)
On front face, upper front frame tube, below gearbox;
1 total
Warning: Moving Parts (Option)
(with Small Seeds Option only)
On front face, upper front frame tube, below gearbox;
1 total
Warning: High Pressure Fluid
(605NT and 606NT only)
On side frames, near cylinder;
2 total
818-337C
32695
WARNING
EXCESSIVE SPEED
HAZARD
To Prevent Serious Injury or Death:
Do NOT exceed 20 mph maximum
transport speed. Loss of vehicle
control and/or machine damage
can result.
818-337C Rev. B
818-860C
32695
818-860C
32696
838-094C
32693

3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Important Safety Information 9
2018-06-06 Table of Contents Index 151-061M
Warning: Falling Hazard
On side frames at walkboard ends;
2 total
See “Loading Seed” on page 25.
Warning: Clevis Adjustment
(605NT and 606NT only)
On tongue cross-tube near turnbuckle;
2 total
See “Height and Leveling the Drill” on page 17.
Warning: Crushing (Option)
(optional Native Grass box)
On underside of lid;
1 total
Caution: Tires Not A Step
(605NT and 606NT only)
On side frames above tires;
2 total
Tires may be in light contact with ground, or off the
ground, when the drill is lowered.
838-102C
32693
WARNING
To avoid serious injury or death:
Watch your step when climbing ladder or
walking on walkboard.
838-102C
838-406C
32693
WARNING
838-611C
32700
818-398C
32693

2018-06-06 Table of Contents Index 151-061M
3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Important Safety Information 10
Caution: General
3P605NT and 3P606NT:
On front face, upper front frame tube, right of center;
1 total
605NT and 606NT:
On front face, upper front frame tube, right end;
See “Important Safety Information” on page 1.
Caution: Tire Pressure and Torque
(605NT only, 2006- only)
On rim of each end wheel with 9.5L 8-ply tires;
2 total
Caution: Tire Pressure and Torque
(605NT 2007+, 606NT only)
On rim of each end wheel with 700-15 LT tires;
2 total
818-719C
32695
32693
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
To prevent injury or death:
Read and understand Operator’s Manual before using.
Lower implement, stop tractor engine, set park brake and remove ignition
Do now allow riders.
Keep othersaway during operation.
Safely support and secure implement before repairsare made.
key before servicing, adjusting, repairing or unplugging.
CAUTION
818-719C
838-258C
32693
848-021C
32693
CAUTION
To Avoid Injury or Machine Damage from Improper Tire
Inflation or Torquingof Wheel Bolts:
Maximum inflation pressure for tiresis60 psi.
Torque wheel boltsto 85 lb-ft.
•
•
848-021C REV. B

3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Important Safety Information 11
2018-06-06 Table of Contents Index 151-061M
NOTICE: Petroleum Products
858-679C
(3P6006NT and 606NT only) On the left-hand ends of
each seed box;
1 per seed box
xxx

2018-06-06 Table of Contents Index 151-061M
3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Introduction 12
Introduction
Great Plains welcomes you to its growing family of new
product owners. Your 6-Foot No-Till Drill has been
designed with care and built by skilled workers using
quality materials. Proper setup, maintenance, and safe
operating practices will help you get years of satisfactory
use from the machine.
Description of Unit
The 605NT and 606NT are towed seeding implements.
This drill has a working width of 7.5 feet (1.9 m). The drill
has straight arm, double disc 05 or 06 Series openers.
The opener discs make a seed bed, and seed tubes
mounted between the discs place seed in the furrow.
Press wheels following the opener discs close the furrow
and gauge opener seeding depth. A T-handle on the
opener body makes seeding depth adjustments.
The metering system is driven from the gauge wheel
(3-point), or from the left end wheel (pull-type). Seeding
rates are set by rate adjustment handles and a Drive
Type gearbox for the main seed box.
Intended Usage
Use this implement to seed production-agriculture crops
in conventional or minimum tillage applications.
Models Covered
This manual applies to Great Plains drill models:
Standard 3P605NT, 3P606NT, 605NT or 606NT Models
have a main seed box. Native Grass and/or Small Seeds
capability may be added.
Document Family
3P605NT-0975 9-row 7.5-inch (19.1 cm)
3P606NT-0975 9-row 7.5-inch (19.1 cm)
605NT-0975 9-row 7.5-inch (19.1 cm)
606NT-0975 9-row 7.5-inch (19.1 cm)
151-061M Operator Manual (this document)
151-061P 3P606NT, 606NT Parts Manual
151-122B Seed Rate Manual
Figure 1
3P606NT No-Till Drill
32704
Figure 2
606NT No-Till Drill
32703
Dealer QRC
The QR Code (Quick Reference) to the
left will take you to available dealers for
Great Plains products. Refer to the
Parts Manual QR Locater for detailed
instructions.
Manual Family QRC
The QR Code (Quick Response) to the
left will take you to this machine’s family
of manuals. Use your smart phone or
tablet to scan the QR Code with an
appropriate App to begin viewing.

3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Introduction 13
2018-06-06 Table of Contents Index 151-061M
Using This Manual
This manual familiarizes you with safety, assembly,
operation, adjustments, troubleshooting, and
maintenance. Read this manual and follow the
recommendations to help ensure safe and efficient
operation.
Right-hand and left-hand as used in
this manual are determined by facing
the direction the machine will travel
while in use unless otherwise stated.
An orientation rose in some line art
illustrations shows the directions of: Up, Back, Left,
Down, Front, Right.
Identifies an Economic (not a Safety) Risk:
NOTICE provides a crucial point of information related to the
current topic. Read and follow the instructions to avoid damage
to equipment and ensure desired field results.
This form sets off useful information related to the
current topic, or forestalls possible
misunderstanding.
The information in this manual is current at printing.
Some parts may change to assure top performance.
Owner Assistance
If you need customer service or repair parts, contact a
Great Plains dealer. They have trained personnel, repair
parts and equipment specially designed for Great Plains
products.
Refer to Figure 3
Your machine’s parts were specially designed and
should only be replaced with Great Plains parts. Always
use the serial and model number when ordering parts
from your Great Plains dealer. The serial-number plate is
located on the upper front frame tube, just left of center.
Record your drill model and serial number here for quick
reference:
Model Number:__________________________
Serial Number: __________________________
Your Great Plains dealer wants you to be satisfied with
your new machine. If you do not understand any part of
this manual or are not satisfied with the service received,
please take the following actions.
1. Discuss the matter with your dealership service
manager. Make sure they are aware of any problems
so they can assist you.
2. If you are still unsatisfied, seek out the owner or
general manager of the dealership.
For further assistance write to:
Product Support
Great Plains Mfg. Inc., Service Department
PO Box 5060
Salina, KS 67402-5060
GP Contact URL
[e-mail]
785-823-3276
U
D
F
B
L
R
Figure 3
Serial Number Location, 606NT
32703

2018-06-06 Table of Contents Index 151-061M
3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Preparation and Setup 14
Preparation and Setup
This section helps you prepare your tractor and drill for
use. Before using the drill in the field, you must hitch the
drill to a suitable tractor and also setup the drill.
Pre-Setup Checklist
1. Verify that dealer pre-delivery is complete (page 73)
and optional accessories are installed (page 74).
2. Read and understand “Important Safety
Information” on page 1.
3. Check that all working parts are moving freely, bolts
are tight, and cotter pins are spread.
4. Check that all grease fittings are in place and
lubricated. See “Lubrication and Scheduled
Maintenance” on page 48.
5. Check that all safety decals and reflectors are
correctly located and legible. Replace if damaged.
See “Safety Decals” on page 6.
6. Inflate tires and tighten wheel bolts as at “Tire
Pressures” on page 60.
Hitching Tractor to Drill
Hitching Model 3P605NT or 3P606NT
Crushing Hazard:
You may be severely injured or killed by being crushed
between the tractor and drill. Do not stand or place any part of
your body between drill and moving tractor. Stop tractor
engine and set park brake before installing the hitch pin.
Certain Machine Damage:
Remove tractor draw bar before hitching the 3P605NT or
3P606NT. The drill drive wheel will be damaged if drawbar is
not removed.
1. Raise or lower tractor 3-point arms as needed and
pin lower arms to drill.
2. Pin upper arm to drill.
3. Slowly raise drill. Watch for cab interference.
4. Adjust top 3-point link so the top edge of drill box is
parallel with the ground when drilling.
Do not use link to adjust opener depth. For opener
adjustments, refer to “Opener Depth (Press Wheel
Height)” on page 39. Set your tractor 3-point draft
control to Float position for planting.
Equipment Damage Risk:
Due to interference with the gauge wheel assembly, drill
models 3P605NT and 3P606NT are not compatible with
Great Plains accessory hitches CPH, PFH and SSH, nor with
the Great Plains hitch set-back kit.

3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Preparation and Setup 15
2018-06-06 Table of Contents Index 151-061M
Hitching Model 605NT or 606NT
Crushing Hazard:
You may be severely injured or killed by being crushed
between the tractor and drill. Do not stand or place any part of
your body between drill and moving tractor. Stop tractor
engine and set park brake before installing the hitch pin.
1. With drill lowered in field position and tongue jack
mounted as shown in Figure 4, raise or lower tongue
jack to level drill tongue.
Refer to Figure 5
2. With drill tongue level, adjust drill hitch on drill tongue
to match your tractor-drawbar height. You can move
the hitch up or down or turn it over for a total of four
different hitch heights.
3. When drill hitch matches tractor-drawbar height,
hitch drill to tractor.
4. Securely attach drill safety chain to an anchor on
tractor capable of pulling drill.
anchor-only
anchor-only
When hitching drill to a different tractor, check for a
difference in drawbar heights. If heights are different,
readjust hitch height accordingly.
Figure 4
Jack in Parking Position
18473
Figure 5
Clevis Hitch Height Adjustment
18544
159/32 in.
38.8 cm
189/32 in.
46.4 cm
1917/32 in.
49.6 cm
2217/32 in.
57.2 cm
Figure 6
Pintle Hitch Height Adjustment
27216
1525/32 in.
40.1 cm
1825/32 in.
47.7 cm
201/32 in.
50.9 cm
231/32 in.
58.5 cm

2018-06-06 Table of Contents Index 151-061M
3P605NT, 3P606NT, 605NT & 606NT Table of Contents Index Preparation and Setup 16
Hydraulic Hose Hookup (605NT or 606NT)
High Pressure Fluid Hazard:
Shut down tractor before making hydraulic connections. Only
trained personnel should work with system hydraulics.
Escaping fluid under pressure can have sufficient pressure to
penetrate the skin causing serious injury. Use paper or
cardboard, NOT BODY PARTS, to check for leaks. Wear
protective gloves and safety glasses or goggles when working
with hydraulic systems. If an accident occurs, seek immediate
medical assistance from a physician familiar with this type of
injury.
Refer to Figure 7
Hydraulic hoses have directional handles and are color
coded to help you hookup hoses to your tractor outlets.
Hoses that go to the same remote valve pair are marked
with the same color.
To distinguish hoses on the same hydraulic circuit, refer
to the symbols on the handles. Hose under
extended-cylinder symbol feeds cylinder base ends.
Hose under retracted-cylinder symbol feeds cylinder rod
ends.
Electrical Connections
Refer to Figure 8
5. Plug drill electrical lead into tractor seven-pin
connector. If your tractor is not equipped with a
seven-pin connector, contact your dealer for
installation.
Color Hydraulic Function
Blue Transport Lift Cylinders
Figure 7
Hose Handles
31733
Figure 8
Lighting Connector
26467
