GREAT PLAINS PL5700 User manual

Read the operator manual entirely. When you see
this symbol, the subsequent instructions and
warnings are serious - follow without exception.
Your life and the lives of others depend on it!
Illustrations may show optional equipment not
supplied with standard unit.
!
Table of Contents Index
Original Instructions 411-681Q
Great Plains
PRE-DELIVERY MANUAL
MODEL PL5700 3-Section Planter
PLANTER

© 2021 Great Plains | Printed in the United States of America
All rights reserved. No part of this publication may be reproduced, distributed, or transmitted in any form or by any
means, including photocopying, recording, or other electronic or mechanical methods, without the prior written
permission of the publisher, except in the case of brief quotations embodied in critical reviews and certain other
noncommercial uses permitted by copyright law.
Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, DrillCommand, Max-Chisel, Row-Pro, Singulator
Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press.
Registered trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains, Land
Pride, MeterCone, Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo-
Trill, Ultra-Till, Whirlfilter, and Yield-Pro.
Brand and product names that appear and are owned by others are trademarks of their respective owners.
For permission requests, write to the publisher at the address below.
Great Plains Mfg.
1525 E. North St.
P.O. Box 5060
Salina, KS 67402
You can also visit our website at www.greatplainsag.com/en/manuals/905/product-manuals for a full catalog of this
and other manuals.
Ordering Information:
Quantity sales. Special discounts are available on quantity purchases by corporations, associations, and others. For
details, contact the publisher at the address above.
Orders for personal, non-commercial use. Please contact our service department by mail or our website
www.greatplainsag.com.

PL5700 Planter Cover Index
Great Plains | 411-681Q | 02/18/2021 iii
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Description of Unit . . . . . . . . . . . . . . . . . . . . . . . . 1
Intended Use Statement . . . . . . . . . . . . . . . . . . . 1
Using This Manual . . . . . . . . . . . . . . . . . . . . . . . . 1
Document Family . . . . . . . . . . . . . . . . . . . . . . . . . 1
Directional Information . . . . . . . . . . . . . . . . . . . . . 1
Product Support . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Information . . . . . . . . . . . . . . . . . . . . . . . 2
Before Getting Started . . . . . . . . . . . . . . . . . . . . . 2
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Operation Noise Hazard. . . . . . . . . . . . . . . . . 2
Handling and Disposing of Chemicals . . . . . . 3
PTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hydraulic System . . . . . . . . . . . . . . . . . . . . . . 3
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Tire Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
High Pressure Fluids . . . . . . . . . . . . . . . . . . . 4
Transporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Chain. . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Lights and Devices . . . . . . . . . . . . . . . 4
Trailer Transport. . . . . . . . . . . . . . . . . . . . . . . 4
Shutdown and Storage. . . . . . . . . . . . . . . . . . . . . 4
Proper Waste Disposal . . . . . . . . . . . . . . . . . . . . 4
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Tools Required. . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Before Beginning . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unloading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Hose Holder . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Shipping Zip Ties . . . . . . . . . . . . . . . . . . . . . . 6
Tire Hub Assemblies . . . . . . . . . . . . . . . . . . . . . . 6
Hitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Center Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Main Transport Wheel Assemblies . . . . . . . . . . . 8
Shifting Wheel Assembly Mounts. . . . . . . . . . 9
Wheel Swing Arm Mount . . . . . . . . . . . . . . . . 9
Main Transport Tires . . . . . . . . . . . . . . . . . . 10
Main Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Join Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Wing Gauge Wheel Assemblies. . . . . . . . . . . . . 11
Shifting Wheel Assembly Mounts. . . . . . . . . 12
Gauge Wheel Swing Arm Mounts . . . . . . . . 12
Wing Gauge Tires . . . . . . . . . . . . . . . . . . . . 12
Fertilizer Tank (Option) . . . . . . . . . . . . . . . . . . . 13
Hose Connections . . . . . . . . . . . . . . . . . . . . . . . 14
Hydraulics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Lift Hydraulic Cylinders. . . . . . . . . . . . . . . . . 15
Wing Gauge Wheel Hydraulic Cylinders . . . 15
Cylinder Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Row Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Hose Holder . . . . . . . . . . . . . . . . . . . . . . . . . 17
Openers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Ground Speed Sensor . . . . . . . . . . . . . . . . . . . . 17
Air Hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Press Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Markers (Option) . . . . . . . . . . . . . . . . . . . . . . . . 19
Marker Hydraulic Cylinders . . . . . . . . . . . . . 19
Slow Moving Vehicle Reflector . . . . . . . . . . . . . . 20
AccuShot Precision Fertilizer System. . . . . . . . . 20
Fertilizer Valve . . . . . . . . . . . . . . . . . . . . . . . 21
Ground Drive Liquid Fertilizer. . . . . . . . . . . . 21
Assembly Close-Out . . . . . . . . . . . . . . . . . . . . 22
Trailer Shipping . . . . . . . . . . . . . . . . . . . . . . . . 23
Shipping Chain Installation. . . . . . . . . . . . . . . . . 23
With IntelliAg ISO6 . . . . . . . . . . . . . . . . . . . . 23
With Switch Box . . . . . . . . . . . . . . . . . . . . . . 24
Check Valve Shipping Kit Installation. . . . . . . . . 25
With IntelliAg ISO6 . . . . . . . . . . . . . . . . . . . . 26
With Switch Box . . . . . . . . . . . . . . . . . . . . . . 27
Close-Out . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Loading on Trailer . . . . . . . . . . . . . . . . . . . . . . . 29
With IntelliAg ISO6 . . . . . . . . . . . . . . . . . . . . 29
With Switch Box . . . . . . . . . . . . . . . . . . . . . . 29
Unloading from Trailer . . . . . . . . . . . . . . . . . . . . 30
With IntelliAg ISO6 . . . . . . . . . . . . . . . . . . . . 30
With Switch Box . . . . . . . . . . . . . . . . . . . . . . 31
Shipping Check Valve Removal . . . . . . . . . . . . . 32
With IntelliAg ISO6 . . . . . . . . . . . . . . . . . . . . 33
With Switch Box . . . . . . . . . . . . . . . . . . . . . . 34
Shipping Chain Removal . . . . . . . . . . . . . . . . . . 35
Close-Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Torque Value Chart . . . . . . . . . . . . . . . . . . . . . . 37
Tire Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Tire Warranty Information. . . . . . . . . . . . . . . . . . 37
Wheel Assembly Mount Position Charts . . . . . . 38
Hydraulic Schematics. . . . . . . . . . . . . . . . . . . . . 39
Lift Hydraulics . . . . . . . . . . . . . . . . . . . . . . . . 39
Fold Hydraulics. . . . . . . . . . . . . . . . . . . . . . . 40
Single Fan Hydraulics (Option). . . . . . . . . . . 41
Dual Fan Hydraulics (Option) . . . . . . . . . . . . 41
Weight Transfer Hydraulics (Option) . . . . . . 42
Marker Hydraulics (Option). . . . . . . . . . . . . . 43
Plumbing Schematics. . . . . . . . . . . . . . . . . . . . . 44

Cover Index

PL5700 Planter Table of Contents Index Introduction
Great Plains | 411-681Q | 02/18/2021 1
Introduction
Great Plains wants you to be satisfied with any new
planter delivered. To ease assembly and produce a
properly working machine, read this entire manual
before beginning assembly.
All information in this manual is current as of
publication. Information contained within this manual
is subject to change to ensure top performance.
Illustrations in this manual were not done during an
actual assembly. For clarity, some illustrations may or
may not include parts, assemblies, and other
components at the same point in an actual assembly.
In some cases, illustrations and images may show
optional equipment or parts with a similar
appearance than what is used on the planter.
Description of Unit
The Great Plains PL5700 Planter is a pull-type
implement with optional mounted fertilizer capability.
The planter is front-fold for transport.
The PL5700 planter includes 5000 Series openers
with Air-Pro® meters. Optional unit-mounted coulters
are available for light to moderate no-till conditions.
The PL5700 planter may be configured with 12 or 16
rows with 30 inch or 70 cm row spacing.
The seed metering system is ground drive, hydraulic
drive, or electric drive. Hydraulic drive is not available
on 70cm row spacing.
Intended Use Statement
Use this planter to seed and fertilize production-agriculture
crops only. It is suitable for conventional till, min-till,
and moderate no-till conditions.
Using This Manual
This manual was written to help you assemble and
prepare the new PL5700 Planter for the customer. The
manual includes instructions for assembly and setup.
Read this manual and follow the recommendations for
safe, efficient, and proper assembly and setup.
An operator manual and parts manual are also
included with the new planter. Read and understand
Safety Information, Preparation and Setup, and
Operation sections in the operator manual before
assembling the planter. As a reference, it is a good
idea to keep the operator and part manuals on hand
during assembly.
Models Covered
PL5700 export models with 12 rows and 16 rows on
70 cm row spacing.
Document Family
Directional Information
All directional information in this manual, such as left,
right, front, rear, forward, or backward, is determined
by facing the direction of forward travel of the planter.
Product Support
If you do not understand any part of this manual, or
have other assembly or setup questions, assistance
is available. Contact our service department at:
Great Plains Manufacturing, Inc
Service Department
P. O. Box 5060
Salina, Kansas 67402-5060
Or call us at [phone] to speak with a service
representative by phone.
Additional copies of the pre-delivery, operator, and
parts manuals, are available by mail or online.
Please visit www.greatplainsag.com and follow the
product links for the PL5700 planter. If writing, please
include the serial number in all correspondence.
411-681M Operator Manual
411-681P Parts Manual
411-681B Material Rate Manual
411-481Q Pre-Delivery Manual (Export Models)

Great Plains | 411-681Q | 02/18/2021 2
PL5700 Planter Table of Contents Index Safety Information
Safety Information
The safety symbol indicates a potential safety
hazard to persons operating or near the
machine and advises on how to avoid it.
The notice symbol indicates a potential for
machine or property damage from operator
error and advises on how to avoid misuse.
The information symbol indicates useful - but
not crucial - information for machine operation,
assembly, or adjustment.
Before Getting Started
1. Read the operator manual in its entirety before
attempting to start and operate the machine.
2. Only use operators who are thoroughly trained by
the owner or trained by someone with the
owner’s consent. The operator must be familiar
with all functions of the tractor and attachments,
and be able to handle emergencies quickly.
3. Maintain attention on operation at all times. Do
not operate if using a smart phone, tablet, or
similar electronic device, and never operate
machine while impaired by alcohol, medication,
any controlled substance, or while fatigued.
4. Do not ever allow passengers to ride the machine
at any time, for any reason.
5. Before operation, ensure all tractor cab levers are
in their “Neutral” positions and the parking brake
is engaged.
6. Check brakes, link pins, and other mechanical
parts for wear before using planter.
7. Never wear loose or bulky clothing around
machine. Use additional safety equipment, such
as hard hats, eye and ear protection, safety
boots, etc., as needed.
8. Do not modify the machine. Unauthorized
modification can result in unsafe conditions that
lead to machine damage or personal injury.
Operation
1. Always stop the tractor, set the gear in Park,
engage the parking brake, and turn off engine
before leaving the cab. Dismounting from a
moving tractor can cause serious injury or death.
2. Consider turning radius of tractor and implement
in the field. Turning tractor too tight can cause
hitched implement to ride up on wheels which can
result in injury or equipment damage.
3. Pull machine only from the hitch at the end of the
tongue. Never pull from jack stand, safety chain,
or any point other than the hitch.
4. Never leave the tractor cab unattended while the
implement is running. Set parking brake, turn off
tractor, and remove key before exiting the tractor
cab.
5. Watch your surroundings at all times. Do not
operate with bystanders nearby, and avoid
contacting overhead obstructions.
6. Ensure all guards and shields are undamaged,
installed, and secure before operating planter.
7. Keep children out of the work area. Do not
operate or turn on machine while children are in
the area.
8. Do not operate near ditches, holes, steep slopes,
embankments, or other surfaces which may
collapse under the machine’s weight or tip the
machine over.
9. Never stand between tractor and planter unless
parking brake is applied. Use care as being
crushed between tractor and planter can cause
serious injury or death.
Operation Noise Hazard
1. Use proper ear protection like earmuffs or
earplugs while working.
!
!
i

PL5700 Planter Table of Contents Index Safety Information
Great Plains | 411-681Q | 02/18/2021 3
Handling and Disposing of Chemicals
Agricultural chemicals can be dangerous. Improper
use can seriously injure persons, animals, plants, soil,
and property.
1. Read chemical manufacturer’s instructions
carefully, and then take appropriate precautions
before use.
2. Wear protective clothing.
3. Wash hands and face before eating after working
with chemicals. Shower as soon as application is
completed for the day.
4. Apply only with acceptable wind conditions. Make
sure wind drift of chemicals will not affect any
surrounding land, people, or animals.
5. Dispose of unused chemicals and chemical waste
as specified by the manufacturer. Observe all the
local ordinances and regulations in your area.
PTO
1. Wait until all moving components have completely
stopped before adjusting, cleaning, or servicing
any PTO driven equipment.
2. Before installing or using PTO driven equipment,
read the tractor manual and review the safety
labels attached to the equipment.
3. When operating stationary PTO driven equipment,
always apply the parking brake and place chocks
behind wheels.
4. Stay clear of and never step over any rotating
parts.
Hydraulic System
1. Compromising a pressurized system can cause
significant injury or death. Only trained personnel
should complete work.
2. Routinely inspect hydraulic lines, valves, fittings,
and cylinders for any signs of damaged or worn
parts, and the presence of hydraulic fluid.
3. Marker hydraulics are active any time the fold
hydraulics are not active. Use care to only
operate markers when intended.
Maintenance
1. Understand procedure before doing work. Use
proper tools and equipment.
2. Work in a clean, dry area.
3. Lower the implement. Set tractor gear in Park,
engage parking brake, and turn off engine. To
prevent unauthorized starting, remove key before
performing maintenance or service work.
4. Make sure all moving parts have stopped and all
system pressure is relieved.
5. Relieve hydraulic pressure before disconnecting
hydraulic lines or performing any work on the system.
6. Do not work underneath any hydraulically supported
components. Hydraulics can settle, leak, or be
accidentally lowered. If working underneath
hydraulically supported components is necessary,
secure implement with stands or suitable blocking
beforehand.
7. Disconnect electronic console and lighting
harness from the tractor before servicing or
adjusting electrical systems.
8. Before welding, disconnect electronic console and
lighting harness from the tractor. Protect hydraulic
lines. Avoid fumes from heated paint.
9. Remove buildup of grease, oil, and debris.
10. Check and replace worn brake lines as needed.
11. Remove all tools and unused parts from planter
before operation.
Tire Safety
1. Inspect tires for cuts, bulges, and correct
pressure. Replace worn or damaged tires.
2. Tire services can be hazardous and must be
performed by trained personnel using correct
tools and equipment.
3. Tire explosion and/or serious injury can result from
over inflation. Do not exceed tire inflation
pressures.
4. When removing and installing wheels, use wheel-
handling equipment adequate for weight involved.
5. Tighten wheel bolts only to the specified torque.

Great Plains | 411-681Q | 02/18/2021 4
PL5700 Planter Table of Contents Index Safety Information
High Pressure Fluids
1. Escaping fluid from holes in hydraulic lines is
difficult to spot. Do not use your hands or bare
skin to search for suspected leaks; instead, use a
piece of cardboard or wood. If injured by
escaping hydraulic fluid, see a medical
professional immediately. Exposure can result in
gangrene or severe allergic reaction.
2. Check that hydraulic fittings are tight and all
hydraulic hoses and lines are in good condition
before applying pressure to the system.
3. Wear protective gloves and safety glasses or
goggles when working with hydraulic systems.
Transporting
1. As with transporting any piece of heavy
machinery, comply with all local laws and
regulations before and during transport process.
2. Transport only at recommended transport speed
for implement. Some rough terrains require a
slower speed. Sudden braking can cause a
towed load to swerve and upset.
3. Know transport height and width of implement.
4. Do not tow a planter, when fully loaded, weighs
more than 1.5 times the weight of towing vehicle.
5. Keep clear of overhead power lines and other
obstructions when transporting.
6. Do not fold or unfold the planter while the tractor is
moving.
7. Reduce speed when turning, and make as wide a
turn as possible. Turning tractor too tight can
cause implement to tip over.
8. When towing on a trailer, secure planter with tie
downs and chains. Refer to special instructions for
trailer transport.
9. When towing on a trailer, sudden braking can
cause a trailer to swerve and upset. Reduce
speed if trailer is not equipped with brakes.
Safety Chain
1. Use a chain with a strength rating equal to or
greater than the gross weight of towed machinery.
2. Replace chain if any links or end fittings are
broken, stretched, or damaged.
3. Do not use safety chain for towing.
Safety Lights and Devices
1. Always use safety lighting. Slow-moving tractors
and towed machinery can create a hazard when
driven on public roads. They are difficult to see,
especially at night.
2. If equipped, use flashing warning lights and turn
signals whenever driving on public roads.
3. Use safety devices provided with implement.
4. Keep safety lights and signs clean and visible from
front and rear of machine.
5. Keep lights in operating condition.
Trailer Transport
1. Install shipping check valve kit before loading
planter on trailer bed for trailer transport.
2. Secure left-and-right wings to tongue with
properly rated shipping chain or strap before
loading.
Shutdown and Storage
1. Park the tractor and planter on a solid, level
surface where children normally do not play.
2. Lock up toolbars, fold wings, and engage transport
hook.
3. Set tractor in park, set the parking brake, turn off
engine, and remove switch key to prevent
unauthorized starting.
4. Wait for all components to come to a complete
stop before leaving the operator’s seat.
5. Detach the tractor. Secure the planter using
chocks.
Proper Waste Disposal
1. Dispose of waste properly to avoid threatening
the environment and ecology. Potential harmful
waste includes oil, fuel, filters, and batteries.
2. Use a leak-proof container for draining fluids. Do
not use a food or beverage container that may be
mistaken for a consumable product.
3. Do not drain or pour waste onto the ground,
down a drain, or into any water source.
4. Contact your local environmental or recycling center
for the proper way to recycle or dispose of waste.

PL5700 Planter Table of Contents Index Assembly
Great Plains | 411-681Q | 02/18/2021 5
Assembly
High Pressure Fluid Hazard
Escaping fluid under pressure can have sufficient
pressure to penetrate the skin. Check all hydraulic
lines and fittings before applying pressure. Use
paper or cardboard, not body parts, and wear heavy
gloves to check for suspected leaks. If injured, seek
immediate medical attention from a physician familiar
with this type of injury.
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
This section will provide step-by-step instructions for
assembling the PL5700 Planter. Read and understand
this manual before beginning work. Ensure you have all
the necessary tools and equipment before beginning.
Follow each set of instructions to make the job as
timely and safe as possible and to assemble a
properly working planter. Given the variety of
possible planter configurations, some sections may
not be needed for the planter being assembled.
It is the dealer’s responsibility to unload the PL5700
planter. Unload all equipment before beginning
assembly. Do not attempt any work with the PL5700
on the truck. It may be necessary to move additional
parts or assemblies not specifically listed in this
manual to allow for clearance to unload the planter.
These instructions provide a general guide of
instructions, however, at times, it will be necessary to
identify when other parts or assemblies may block
the removal of a part or section of the planter.
Tools Required
Three forklifts
General hand tools
Jack stands or blocks and safety chains
Hoist straps with proper load rating
At least three people to assist
Before Beginning
Read and understand “Safety Information” before
beginning to assemble the planter.
Have at least three people on hand while assembling.
Ensure the assembly location is level and free of
obstructions and debris. Great Plains recommends an
open, concrete area.
Create a plan for assembly, and ensure all workers
understand the plan, their responsibilities, and what to
do in the event of an accident or other emergency.
Have all major components and required tools. Test to
ensure all are properly working.
Have all loose components, fasteners, and pins
shipped with the PL5700 Planter.
Use a tractor of sufficient size and horsepower
with at least three remote hydraulic circuits. Refer
to Specifications in the operator manual for
tractor requirements.
Ensure safety decals and reflectors are located
correctly and legible. Replace if improperly located or
damaged. Refer to Safety Decals in operator manual.
Have a copy of the parts manual on hand. If unsure of
proper placement or use of any part or fastener, refer
to the parts manual.
Ensure all moving parts are moving freely, bolts are
tighten to torque, and cotter pins are spread.
Unloading
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist and/or lifting
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached to planter part before moving or unloading
parts.
Tire Weight
Tires are extremely heavy. It may take more than one
or two people to safely move each tire. Use extreme
caution to prevent injury.
Remove all loose components from the truck. Set
aside.
Remove all tires. Some may be bolted to the shipping
rack and shipping plates. Loosen the bolts, washers,
and nuts to remove from rack and shipping plates. Set
aside shipping plates, bolts, washers, and nuts.
Closely inspect the unit shipping rack. It may be
necessary to move additional parts or assemblies not
!
!
!
!
!

Great Plains | 411-681Q | 02/18/2021 6
PL5700 Planter Table of Contents Index Assembly
specifically listed in this manual to allow for clearance
to unload the planter to prevent damages.. See
below for an example of a part which may need
to e removed.
Hose Holder
Machine Damage Risk
You must remove the hose holder and set aside
before removing any more parts from the rack or
machine damage will occur.
The hose holder will need to be removed from row
unit number 4, as well as any others that may block
sufficient clearance of unloading any more parts.
Sometimes, row units are marked with a tag (shown)
or with a marker (not shown).
Row unit number 4 can be located in the general
area as indicated below. Verify the row unit with the
tag or mark.
To remove hose holder:
1. Locate the hose holder (1) attached to row unit
number 4, or other relevant row. It is located at
the row unit mount and near the u-bolt assembly
securing the row unit to the rack.
2. Loosen the nut and washer holding the hose
holder (1).
3. Remove the hose holder (1), nut, and washer.
Set aside.
Shipping Zip Ties
For shipping purposes hydraulic hoses, air hoses,
wires, and lines may have been tied back and bundled
with zip ties. Shipping zip ties have not been trimmed.
Zip ties that have been trimmed should remain intact to
help keep parts in place or bundled together while
operating the planter. Carefully release shipping zip ties
while assembling planter using care to avoid damages to
nearby parts, hoses, wires, etc.
Tire Hub Assemblies
Weight and Crushing Hazards
Tires are extremely heavy and can crush body parts
between the tire and another surface. It may take
more than one or two people to move each tire, even
when aided by a hoist. Use extreme caution when
unloading or moving the tires. Thoroughly secure
tires in safe place after unloading to prevent a
falling or loose tire.
TP-75212
!
TP-71848
TP-71846
TP-71847
1
TP-71881
Trimmed
TP-71882
Untrimmed
!

PL5700 Planter Table of Contents Index Assembly
Great Plains | 411-681Q | 02/18/2021 7
To install tire hub assembly:
1. Locate the tire hub assembly.
2. Loosen all of the nut lugs (1) from the hub studs
(2) from the tire hub (3).
3. Use one or two people to support the wheel,
carefully thread the hub studs (2) on the tire hub
(3) through the mounting holes (A) on the wheel
(4).
4. Secure the tire hub (3) with nut lugs (1) on the
hub studs (2). Tighten to torque, see “Torque
Value Chart” on page 37.
5. Repeat steps for each wheel. Carefully set aside
each wheel.
Hitch
Secure Load
Obey all safety instructions from hoist equipment
manufacturer. Be sure hoist chains and lift straps
are properly rated for load and securely attached
before moving or unloading parts.
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
High Pressure Fluid Hazard
Escaping fluid under pressure can have sufficient
pressure to penetrate the skin. Check all hydraulic
line and fittings before applying pressure. Use
paper or cardboard, not body parts, and wear heavy
gloves to check for suspected leaks. If injured, seek
immediate medical attention from a physician
familiar with this type of injury. Pinching or
crushing a hydraulic line during assembly can
cause a high pressure leak resulting in severe
injuries. Use care to when working around
hydraulic lines, especially when the system is
pressurized.
Hydraulic Hose Damage Risk
Use care when assembling parts near hydraulic
hoses. Pinching or crushing hydraulic lines can
cause hose damage and will leak hydraulic fluid.
1. Prepare to unload the hitch from the rack using a
hoist by placing a strap (A). Make sure the strap
is placed in a way that does not pinch, bend, or
damage any parts.
2. Remove the parking stands (1) from each side of
the hitch by removing the pin assembly on each
parking stand. Set aside.
In some cases, the parking stands have been
inverted for shipping purposes and will need to
be repositioned for operation. If the parking
stands have not been inverted (as shown
above) skip step 5.
3. Remove the hitch bolts, washers, and nuts (2)
securing the hitch to the rack. Set aside.
TP-75210
TP-75211
2
1
3
4
A
!
!
!
!
TP-71853
A2
2
1
1
i

Great Plains | 411-681Q | 02/18/2021 8
PL5700 Planter Table of Contents Index Assembly
4. Using care with the strap (A), guide the hitch near
the tongue. The main frame with tonue is still
secured on the shipping racking.
5. With the hitch suspended at a comfortable
working height, and with enough clearance from
the ground, install both parking stands onto the
hitch. Do not place parking stands back into the
inverted shipping position.
6. Join hitch to tongue on main frame and secure
with hitch bolts, washers, and nuts at the top and
bottom mounting holes. Tighten to torque. See
“Torque Value Chart” on page 37.
Center Frame
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist and/or lifting
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached to planter part before moving or unloading
parts.
1. Prepare to unload the center frame from the rack
using a hoist by placing two straps (1). Make
sure the straps are placed in a way that does not
pinch or damage any parts.
2. Loosen and remove the u-bolt assemblies (2) to
release the center frame from the rack.
3. Using a hoist, and at least two assistants to guide
and balance the center frame, move the center
frame into an area with enough clearance to
assemble to the planter.
4. Temporarily stabilize the suspended center frame
with jack stands, blocking, hoist, forklift, etc. to
prepare to install the tire hub assemblies and the
main transport tires. The center frame will remain
in the hoist.
Main Transport Wheel Assemblies
Falling and Flailing Equipment Hazards
An improperly positioned wheel assembly can cause
severe injury or death by falling and flailing
equipment if the hydraulic system is compromised
or damaged, and there is a lost of pressure. Do not
operate the planter until the wheel assembly mounts
have been measured and any necessary adjustments
have been made.
TP-71855
A
TP-71856
TP-71857
!
!
TP-71846
2
2
1
1
!

PL5700 Planter Table of Contents Index Assembly
Great Plains | 411-681Q | 02/18/2021 9
Secure Load
Obey all safety instructions from hoist equipment
manufacturer. Be sure hoist chains and lift straps
are properly rated for load and securely attached
before moving or unloading parts.
Planter Damage Risk
An improperly positioned wheel assembly can cause
significant damage to the planter including
pinching and crushing hoses, wiring, or lines.
Measure the position of the wheel assembly mounts
and any necessary adjustments have been made.
It is necessary to verify the wheel mount assemblies
are in the correct position. The planter is configured
with four main transport wheel assemblies (1). For
shipping purposes, any of the wheel mount
assemblies may have been removed or shifted out of
the proper position on your planter. Utilize a tape
measure for accuracy.
Shifting Wheel Assembly Mounts
If it is necessary to shift the wheel assembly mount, it
must be completed before installing the swing arm
1. With a measuring tape, carefully determine the
correct position for the wheel assembly mount.
Refer to See “Wheel Assembly Mount
Position Charts” on page 38. Place a mark (3)
for reference.
1. Loosen the u-bolts (1), washers (2), and nuts (2).
2. Slide the entire gauge wheel mount until the
wheel assembly mount is centered on mark (3).
3. Tighten the u-bolts, washers, and nuts once in
position. Tighten to torque. See “Torque Value
Chart” on page 37. Wing gauge wheel assembly
mount shown.
Wheel Swing Arm Mount
In some cases, it is necessary for the wheel swing
arm mount to be removed for shipping. If necessary,
use the following steps to install the four wheel swing
arm mounts to the center frame.
1. Remove wheel swing arm mount from rack using
a hoist strap.
2. Align wheel swing arm mount into the main
transport wheel assembly on the center frame.
Secure with pin roll, pin (1), washer, and snap
ring (2).
3. Repeat for all four wheel swing arm mounts on
the center frame.
!
!
TP-75209
12 Row Configuration
1
1
L
R
1
1
TP-75208
16 Row Configuration L
R
TP-71868
2
1
3
TP-71869
TP-71870
2
1

Great Plains | 411-681Q | 02/18/2021 10
PL5700 Planter Table of Contents Index Assembly
Main Transport Tires
To install a tire:
1. With the center frame blocked or supported by
jack stands, move the tire into place on the swing
arm wheel mount (1) to be able to secure the
wheel assembly into the center hole (A) in the
swing arm wheel mount with a bolt and locking
washer on each side.
2. Secure the wheel assembly on each side with the
bolt and locking washer. Tighten to torque. See
“Torque Value Chart” on page 37.
3. Repeat for each of the four main transport tires
on the center frame.
Main Frame
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist equipment
manufacturer. Be sure hoist chains and lift straps are
properly rated for load and securely attached before
moving or unloading parts.
Hoist Chains and/or Lift Straps Placement
To prevent uneven load or flailing parts, ensure
hoist chains and/or lift straps are placed on the
main frame and not on either or both wings.
1. Prepare to unload the main frame from the rack
using a hoist by placing two straps. Do not
secure the strap to any section of either or both
wings. Make sure the straps are placed in a way
that does not pinch or damage any parts.
2. Loosen and remove the shipping plate, bolts,
washers, and nuts from the main frame and rack.
3. Loosen and remove the u-bolts, washers, and
nuts from the main frame located below the fan
on the rack.
4. Move the main frame off of the rack so that the
rear of the main frame is near the center frame.
TP-75213
1
A
TP-71850
TP-71849
!
!
!
TP-71858
TP-75160
TP-75162
TP-71863

PL5700 Planter Table of Contents Index Assembly
Great Plains | 411-681Q | 02/18/2021 11
Join Frames
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist and
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached before moving or unloading parts.
Planter Damage Risk
Use care when assembling parts near electrical
wiring, lines, and hydraulic hoses. Pinching or
crushing hydraulic lines can cause hose damage
and will leak hydraulic fluid. Pinching or crushing
hoses, wiring, or lines can cause damage.
1. Using a hoist, move the center frame to join at
the mount plate to the main frame.
2. Bring the center and main frames together until
the mount plates are flush with one another.
3. Secure the center and main frames with bolts,
washers, and nuts. There are ten mounting holes
around the mount plates. Tighten to torque. See
“Torque Value Chart” on page 37.
4. Install two 3/4-10 x 8 1/32 x 14 u-bolts with
washers and nuts on the rear of the mount on the
center frame. Tighten to torque. See “Torque
Value Chart” on page 37.
Wing Gauge Wheel Assemblies
Secure Load
Obey all safety instructions from hoist equipment
manufacturer. Be sure hoist chains and lift straps
are properly rated for load and securely attached
before moving or unloading parts.
Falling and Flailing Equipment Hazards
An improperly positioned wheel assembly can cause
severe injury or death by falling and flailing
equipment if the hydraulic system is compromised
or damaged, and there is a lost of pressure. Do not
operate the planter until the wheel assembly mounts
have been measured and any necessary adjustments
have been made.
Planter Damage Risk
Improperly positioned wheel assembly mounts can
cause significant damage to the planter including
pinching and crushing hoses, wiring, or lines.
Measure the position of the wheel assembly mounts
and any necessary adjustments have been made.
It is necessary to verify the wheel assemblies are in
the correct position. The planter is configured with up
!
!
!
TP-71864
TP-71865
TP-71866
TP-71867
!
!
!

Great Plains | 411-681Q | 02/18/2021 12
PL5700 Planter Table of Contents Index Assembly
to four wing gauge wheel assemblies (1). For
shipping purposes, any of the wing gauge wheel
assemblies may have been removed or shifted out of
the proper position on your planter. Utilize a tape
measure for accuracy.
Shifting Wheel Assembly Mounts
1. With a measuring tape, carefully determine the
correct position for the wheel assembly mount.
Place an indelible mark for future reference, if
preferred. See “Wheel Assembly Mount
Position Charts” on page 38.
1. Loosen the u-bolts (1), washers (2), and nuts (2).
2. Slide the entire gauge wheel mount until the
wheel assembly mount is centered on mark (3).
3. Tighten the u-bolts, washers, and nuts once in
position. Tighten to torque. See “Torque Value
Chart” on page 37.
Gauge Wheel Swing Arm Mounts
1. Remove wing gauge wheel swing arm mount
from rack using a hoist strap.
2. Align wheel swing arm mount into the gauge
wheel mount on the wing. Secure with pin roll, pin
(1), washer, and snap ring (2).
3. Repeat for two or four wheel swing arm mounts.
Wing Gauge Tires
Two of the tire hub assemblies will have a
speed wheel (1) included on the hub. These
two speed wheels will be mounted on each
outer wing gauge wheel.
TP-75209
12 Row Configuration
1
1
L
R
1 1
TP-75208
16 Row Configuration L
R
TP-71868
2
1
3
TP-71869
TP-71870
2
1
i
TP-71872
1

PL5700 Planter Table of Contents Index Assembly
Great Plains | 411-681Q | 02/18/2021 13
To install wheel assembly:
1. Move the tire into place on the wheel mount (2) to
be able to secure the wheel assembly into the
center hole (A) in the wheel mount with a bolt and
locking washer on each side.
2. Secure the wheel assembly on each side with the
bolt and locking washer. Tighten to torque. See
“Torque Value Chart” on page 37.
3. Repeat for each of the two or four wing gauge
tires on the wings.
Fertilizer Tank (Option)
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist equipment
manufacturer. Be sure hoist chains and lift straps
are properly rated for load and securely attached
before moving or unloading parts.
1. Prepare to unload the fertilizer tank from the rack
using a hoist by placing a strap. Ensure the strap
is placed in a way that does not pinch, bend, or
damage any parts.
2. Remove the bolts, washers, and nuts securing
the fertilizer tank to the rack. Set aside.
3. Guide the fertilizer tank to the main frame and
secure with u-bolts, bolts, washers, and nuts on
the fertilizer tank mounting plates.
4. On the front fertilizer tank mount (1), secure the
fertilizer tank with spacer plate (2), u-bolts (3),
washers (4), and nuts (5). Do not pinch or crush
hoses, lines, or wires.
TP-71871
2
TP-71850
A
!
!
TP-71869
TP-71873
TP-71874
3
4
5
1
2

Great Plains | 411-681Q | 02/18/2021 14
PL5700 Planter Table of Contents Index Assembly
5. On the rear fertilizer tank mount (6), secure the
fertilizer tanks with bolts (7), washers (8), and
nuts (9). Do not pinch or crush hoses, lines, or
wires.
Hose Connections
This section will provide instructions for some, but not
all, of the hoses on the planter. If unsure of proper
placement or use of any part or fastener, refer to the
parts manual. For more information about the parts,
and their placement, for the AccuShot Precision
Fertilizer System refer to the accompanying
manufacturer’s manuals.
1. On the right-side of the center frame, flip the
hose (1) from the shipping position. Insert o-ring
and make connection later.
2. Underneath the fertilizer tank, at the valve, install
one o-ring in each hose ends and tightly secure
each of the two hoses with clamps.
For shipping, hoses may have been tied back
with zip ties. These shipping zip ties have
been left untrimmed and will need to removed
to be able to position hoses for use.
3. Near the fan assembly, secure the rear pump
mount bracket (2) with a u-bolt (3), washers, and
nuts.
4. Secure the front pump mount bracket (2) with a
bolt plate (4) with bolts, washers, and nuts.
5. Secure the AccuShot pump rear mount plate (5)
to the mount plate on the fan with a bolt, washer,
and nut.
6. On the pump assembly install one o-ring in each
hose ends and tightly secure each of the three
hoses with clamps.
Refer to the parts manual if unsure of proper
placement or use of any part or fastener.
Hydraulics
High Pressure Fluid Hazard
Escaping fluid under pressure can have sufficient
pressure to penetrate the skin. Check all hydraulic
lines and fittings before applying pressure. Use
paper or cardboard, not body parts, and wear heavy
gloves to check for suspected leaks. If injured, seek
immediate medical attention from a physician
familiar with this type of injury.
TP-71875
7
8
6
9
TP-71894
1
TP-71876
i
TP-71877
4
3
2
5
TP-71878
5
i
!

PL5700 Planter Table of Contents Index Assembly
Great Plains | 411-681Q | 02/18/2021 15
1. Release the hydraulic hoses, hoses, wires, and
lines that have been bundled together with zip
ties near the rear for shipping.
2. Starting from the left side, remove the hydraulic
caps (1) and connect the hydraulic hoses (2) to
each corresponding hydraulic cylinder port (3).
For ease, the hydraulic ports are marked with
colored zip ties and the hoses have been
temporarily marked with colored tape. Set aside
caps.
Lift Hydraulic Cylinders
Hydraulic hose connection information is provided
from left-to-right for the hydraulic cylinders (4) on the
center frame above the main transport tires. Refer to
the following chart for connection information. When
these zip ties and other color coded information is
not available, refer to the parts manual and
hydraulic layouts for assistance.
Wing Gauge Wheel Hydraulic Cylinders
Pinch and Crushing Hazards
Use care when moving and aligning parts into their
correct positions; avoid pinching or crushing body
parts to prevent injury.
1. At each wing gauge wheel the hydraulic cylinder
may have been wired up or secured with a zip tie for
shipping. Remove the wire, or the zip ties, using
care not to damage the cylinder rod.
2. Secure the cylinder rod with the clevis pin, cotter
pin, and washer on the swing arm mount.
3. Repeat for each of the two or four wing gauge
wheels.
TP-71880
TP-71879
3
3
1
1
2
4
Cylinder
Location Top Connection Bottom Connection
Outer-left Orange Orange/Blue
Left-center White White
Right-center Yellow Yellow
Outer-right Orange/Blue Blue
!
TP-71883
TP-71884

Great Plains | 411-681Q | 02/18/2021 16
PL5700 Planter Table of Contents Index Assembly
Cylinder Locks
It is necessary to install the cylinder locks (1) on the
four cylinders on the center frame above the main
transport tires before the row units are installed on
the planter. They are in the storage position.
1. Connect the lift hydraulics to the tractor. Lift
hydraulics are identified by the blue color coded
hydraulic handles.
2. Use the lift circuit lever to fully raise the planter.
3. Set the lift circuit circuit lever to “Neutral” to hold.
4. Install cylinder locks (1) on the cylinder rods
above the main transport tires and secure with
pin(2).
5. Relieve hydraulic pressure.
6. Disconnect hydraulics before continuing with
assembly.
7. Place tractor gear in Park, set parking brake, turn
off tractor, and remove key.
Row Units
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist equipment
manufacturer. Be sure hoist chains and lift straps
are properly rated for load and securely attached to
before moving or unloading parts.
Machine Damage Risk
The planter must be fully raised with cylinder locks
installed before openers are installed or machine
damage will occur.
1. Prepare the area for the row unit by removing any
hoses, wires, and lines.
2. Prepare to unload the row unit from the rack
using a hoist by placing a strap. Make sure the
strap is placed in a way that does not pinch,
bend, or damage any parts.
3. Remove shipping u-bolt (1), washers, and nuts.
4. Place the row unit in its proper position. Each row
unit has a numbered tag (2) or numbered mark
(not shown). Rows are numbered 1-16 from left to
right on the planter.
On planters with 12 rows: 1-4 are on the left
wing, rows 5-8 are on the center frame, and
rows 9-12 on the right wing. On planters with
16 rows: 1-6 are on the left wing, rows 7-10
are on the center frame, and rows 11-16 on
the right wing.
5. Secure into proper position with two u-bolts,
washers, and nuts.
TP-71885
1
TP-71886
1
2
!
!
!
TP-71887
1
2
