Grouser Products 770 - Plus User manual

Date 9-11-16PN: 63-19653
770 - Plus
Owner’s Manual
&
Parts Book
Purchase Date
Serial Number
Model Number
Tractor Model
Dealer

2
Description Page
To The Owner & Maintenance 2
Torque Specications & Safety Precautions 3
Unpacking Components & Undercarriage Installation Instructions 4
Assembling Lift Components & Installing Hydraulic Coupler Components 4
Lift System 5
Tractor Side Hydraulic Hose Routing 6
Initial Startup Instructions 7
Connecting & Disconnecting the Blade, Skid Shoe and Tilt Plate Adjustment 8-9
Angle / Tilt Function Abbreviation Key 9
Blade Assembly & NANT Blade Assembly 10
Electric Hydraulic Angle & 2-Lever Angle System Operating Instructions 11
Angle Position Sensor Adjustment 11
End Extensions 12
No Angle - Hydraulic Tilt System & Hydraulics 12-13
Angle Hydraulic Components 13
Quick Attach System 14-15
Hydraulic Angle - Hydraulic Tilt & Hydraulic Angle - No Tilt System 16-17
Hydraulic Angle - Hydraulic Tilt & Hydraulic Angle - No Tilt Hose Routing (Blade Side) 18-19
Electric System Wire Harness Schematic and Hydraulic Schematic 20-21
Angle Wire Harness 22
Notes 23
Contact Us, Improvements, & Warranty 24
Contents
To The Owner
This manual contains information concerning the operation, adjustment, and maintenance of the 770 blade
assembly. You have purchased dependable, long lasting equipment, but only by proper care and operation
can you expect to receive the performance and long service built into our products. Please have all operators
read this manual carefully and keep the manual available for ready reference. If you have any questions or
concerns, contact Grouser Products.
Maintenance
Due to the harsh environment many of our equipment operates in, the following tasks
should be performed every 10 hours or less.
• Inspect all equipment before operation for existing or potential damages.
• Lubricate all joints with high quality grease.
• Inspect and tighten all bolts to torque specications on page 3.
• Check replaceable cutting edge for wear ensuring there is enough material to prevent permanent damage
to the blade.
• Make sure all non-rotating pins are secured properly.
• Check hydraulic cylinders and hoses for damage or leaks. For replacement parts, see hydraulic pages for
your specic system.
• Check skid shoes for wear and replace if necessary. For adjustment, see page 9.
• Inspect all tilt-ways for aggressive wear. See page 9 for tilt plate adjustment.

3
Torque Specications
All bolts should be tightened to the specications that are stated. If specications are not stated, follow torque
charts below.
Torque - Dry (ft–lbs)
SAE Grade 5 SAE Grade 8
Size UNC UNF UNC UNF
5/16 17 19 24 27
3/8 30 35 45 50
7/16 50 55 70 80
1/2 75 85 110 120
9/16 110 120 150 170
5/8 150 170 210 240
3/4 260 300 380 420
7/8 430 470 600 670
1 640 720 910 1020
Torque - Dry (ft-lbs)
Size Grade 10.9
M18 x 2.50 284
M20 x 2.50 401
M22 x 2.50 547
M24 x 3.00 694
Safety Precautions
A careful operator is the best operator. Most accidents can be avoided by observing certain precautions. To
help prevent accidents, read and take the following precautions before operating this equipment. In addition
to these precautions, please follow all safety and operational instructions of your tractor manufacturer.
The Dozer:
1. The 770 Dozer should be operated only by those who are responsible and instructed to do so.
2. Read the owner’s manual carefully before using this equipment. Lack of operating knowledge can lead to
accidents.
3. Keep the dozer maintained in reliable and satisfactory condition to ensure your safety.
4. Make sure the area is clear of people before moving any equipment.
5. Do not modify or permit anyone else to modify or alter the equipment and its components without rst
consulting Grouser Products.
Servicing the Dozer:
1. Read and follow all safety instructions provided by the tractor manufacturer.
2. Always use proper personal safety gear when performing maintenance on equipment.
3. Before servicing, relieve hydraulic pressure, stop engine and fully engage parking brake.
4. Escaping hydraulic uid under pressure can penetrate skin causing serious injury. If uid is injected into
skin, obtain medical attention immediately.
– DO NOT use your hand to check for leaks. Use a piece of cardboard or paper to search for leaks.
– Stop the engine and relieve pressure before connecting or disconnecting lines.
– Tighten all connections before starting the engine or pressurizing lines.
Storing the Dozer:
1. Thoroughly clean the inside and outside of the dozer before storage. Use paint where necessary to
prevent rust.
2. Check the dozer for worn or damaged parts. Install new parts as required.
3. Lubricate all pins and joints.

4
Assembling Lift Components
Some assembly of Lift system components is necessary. Follow the steps listed below. Refer to Page 5 for the correct
hardware and orientation of parts.
Remove all pins and fasteners on each side of the undercarriage and set aside for later installation.
Position the lift frame between the two plates on both sides of the undercarriage and align to the bottom holes.
Attach the lift frame, the base end of the lift cylinders, and the top arms to the undercarriage. Refer to Page 5 for
proper components and orientation.
Attach the male quick attaches to the lift frame, and to the top arms. See Page 5 for proper orientation.
Tighten all fasteners.
Connect the lift hoses to the lift cylinders. The hoses are marked with 2 Orange Bands for the base end and 1
Orange Band for the rod end.
Verify that hoses are not twisted and protected from rubbing on any sharp edges. See picture below for proper
hose routing.
1.
2.
3.
4.
5.
6.
7.
Unpacking Components
Unstrap and remove the lift frame, hoses, top arms, and any boxes of hardware from the undercarriage. If any components
are missing, call Grouser.
Undercarriage Installation
Install undercarriage per the tractor specic mounting instructions.
Installing Hydraulic Coupler Components
Note: Refer to Diagram on Page 6 for further information on hose routing and hose positions. The quantity
and location of the female couplers is determined by blade functionality.
Attach the coupler mounts to the left top arm and install the female quick couplers and 90° ttings.
Install each coupler into the designated hole on the coupler mount and fasten them in place with the coupler retainer
plate, 3/8” x 3/4” bolts and 3/8” ange nuts.
Identify each remaining hose at the front of the undercarriage by the colored bands on the end of the hose and
connect the hose to the corresponding 90° tting and female coupler in the coupler mount.
If applicable, attach the wire harness to the coupler mount. Hold in place with a zip tie. Run the other end of the wire
harness up into the cab of the tractor.
Locate the keyed and fused power supply. Connect the red wire to the power and the black to the ground. Install
provided switch into an open switch hole in the right overhead console or another convenient place in the tractor.
Connect the wire harness to the switch.
Continue on Page 7 for instructions on how to remove the air from the system.
8.
9.
10.
11.
12.
13.
14.

5
Lift System
Cylinder Part No. Description
26-34745 49-12278 Seal Kit 4.5” Bore x 2” Rod (658366) Nitrided Rod
* Parts Not Shown
Item #A for Claas Tractors (24-18239)
Item #B for Steiger (24-18238), New Holland (24-18238), and JD 9R Tractors (24-18843, 24-18269 or 24-19441)
Item #C for JD 9RX (24-18951), Versatile (24-18262) and Challenger Tractors (24-18255)
Detail A:
Scale 1:10
NO. QTY. PART NO. DESCRIPTION
1 1 11-18165-L R3 Top Arm, Ag Pro +
2 1 11-18165-R R3 Top Arm, Ag Pro +
3 2 16-20002 1/4" x 3/4 " Hex Bolt Gr 5 NC
4 4 16-20216 3/4" x 1-1/2" Hex Bolt Gr 5 NC
5 4 16-20217 3/4" x 1-3/4" Hex Bolt Gr 5 NC
6 4 16-20220 3/4" x 2-1/2" Hex Bolt Gr 5 NC
7 8 19-13515 Spacer, NR Pin
8 2 25-34342 Tappet Quick Coupler Male - Poppet Style
9 2 25-3457 Pioneer Dust Cap Lift (Orange)
10 2 26-34745 4.5 x 18 Hydraulic Cylinder
11 2 27-9504 Decal, Grouser Horizontal
12 12 27-9507 Decal, Grease
13 2 31-11699-10-8 JIC Union
14 2 31-34030 Bulkhead Run Tee JIC
15 2 31-34040 Straight JIC x O-Ring
16A* 2 31-6802-8-10 Straight Thread Elbow 45° JIC x O-Ring
16B,C 2 31-34051 Straight Thread Elbow 90° JIC x O-Ring
17 2 31-6400-10-8 Straight JIC x O-Ring
18 1 32-18630 Lift Frame, Ag Pro Plus
19 2 34-12932 Cylinder Saddle
20 1 34-14961 Manual Canister Small
21 2 34-16578 Hose Clamp (worm drive - 4.5)
22 15 34-18888-OR -12 Orange - Spiral Band
NO. QTY. PART NO. DESCRIPTION
23 1 35-12633-0515 51.5” x 1/2" -8JIC/-8JIC Hose
24 1 35-12633-0535 53.5” x 1/2" -8JIC/-8JIC Hose
25 1 35-12633-0665 66.5” x 1/2" -8JIC/-8JIC Hose
26 1 35-12633-0670 67” x 1/2" -8JIC/-8JIC Hose
27 2 35-18240 Lift Cylinder Steel Line
28A,B 2 35-30183 293” (24.42”) x 1/2" -8JIC/-8JIC Hose
28C 2 35-18953-320 320” (26.67”) x 1/2" -8JIC/-8JIC Hose
29 2 43-14725 Lift Frame / UC Pin
30 4 43-18120 Top Pin Weld
31 2 43-18127 Top Arm Pin Weld
32 2 43-18175 Lift Cyl Pin Weld
33 2 43-18635 Ag Pro Plus QA Pin
34 1 45-18130-L R5 Ag Pro + Male QA
35 1 45-18130-R R5 Ag Pro + Male QA
36 2 57-1530 3" OD X .75 ID X .25" HD Flat Washer
37 6 57-1811 2” Washer
38 2 57-20740 1/4" Flat Washer
39 10 57-20747 3/4" Flat Washer
40 12 58-9369 Straight 1/8" NPT Grease Zerk
41 2 70-20607 3/4" Hex Center Lock Nut NC
42 2 70-20807 3/4" Hex Jam Nut NF
22
17 27
23
24
21 19
10 22 13
15
4
3637
31
40
11
34
1
2
18
32
40
739
5
33
29
39
4
40
739
40
6
9
8
20
38
3
41
23
27
24
16
30
25
35
14
12
42
10
28
26
A

6
Conguration HAHT HANT NAHT NANT
Item
No. Part No. Description Qty. Qty. Qty. Qty.
1 16-35C612 3/8” x 3/4” Flanged Bolt 4 2 2 -
2 16-21127 1/2” x 1-3/4” Carriage Bolt Gr 5 NC 2 2 2 -
3 25-34342 Tappet Quick Coupler Male 4 2 2 -
4 25-34321 Tappet Quick Coupler Female 4 2 2 -
5* 25-3453 Pioneer Dust Cap Tilt (Green) 2 - 2 -
6* 25-3455 Pioneer Dust Cap Right Angle (Red) 2 2 - -
7 31-15199-8-8 JIC Union Elbow 90° (2500-8-8) 4 2 2 -
8 31-34051 Straight Thread Elbow 90° JIC x O-Ring (6801-8-10) 8 4 4 -
8A 31-34051 Straight Thread Elbow 90° JIC x O-Ring (6801-8-10) 4 2 2 -
8B 31-6802-08-10 Straight Thread Elbow 45° JIC x O-Ring (6802-08-10) 4 2 2 -
9 35-31133 72” x 1/2” -8JIC/-8JIC Hose W/Cordura 2 2 - -
10 35-31134 75” x 1/2” -8JIC/-8JIC Hose W/Cordura 2 - 2 -
11D 35-18953-3200 320” (26.67”) x 1/2” -8JIC/-8JIC Hose w/180” Cordura 4 2 2 -
11C 35-30183 293” (24.42”) x 1/2” -8JIC/-8JIC Hose w/165” Cordura 4 2 2 -
12 44-14734 Female Coupler Retainer 2 1 1 -
13 44-18180 Female Coupler Mount Bracket 1 1 1 -
14 44-8490 Spacer Bushing 4 4 4 -
15* 69-14681 Wire Harness 1 1 - -
16* 69-14679 Electric Angle Switch 1 1 - -
17 70-20604 1/2” Hex Center Lock Nut NC 2 2 2 -
18 70-20622 3/8” Flange Hex Nut NC 4 2 2 -
Tractor Side - Hydraulic Hose Routing
* Parts Not Shown
Hoses Not Drawn To Scale
See Pages 23 for hydraulic schematic.
Top View - Some
Parts Not Shown
For Clarity
4
10
9
3
8
7
11
All Hoses Should Be Routed
Thru Hose Loop. Hoses Are
Shown Outside Of The Hose
Loop For Clarity.
1,18
Tilt Rod
13
12
2,14,17
Tilt Base
Angle Rod
Angle Base
Item #C for Steiger, New Holland, Claas and JD 9R Tractors and Item #D for JD 9RX, Versatile and Challenger Tractors.
Item #A & B for Claas Tractors.
NOTE: 4 Spacers (#14) goes between plate on Top Arm
and Coupler Bracket #14.

7
Initial Startup Instructions
Prior to operating the blade system, all air must be purged from the hydraulic system. Follow the steps below for each
function on your blade.
Lift Function:
1. With the lift frame down and blocked, loosen the ttings on both ends of the lift cylinders.
2. Actuate the raise function to supply oil to the rod end of the cylinders.
3. When oil starts to ow from the ttings, stop oil ow, and tighten the tting on the rod end of the lift cylinders.
4. Continue to ow oil until the system is fully raised and then block the lift frame.
5. Actuate the function in the opposite direction to supply oil to the base end of the lift cylinders.
6. When all air is removed from the lift system, stop oil ow and tighten the ttings on the base end of the lift cylinders.
7. Raise lift system and remove blocks. Cycle up and down 5 more times.
8. Check tractor oil level and ll if necessary.
9. Continue with connecting the blade on Page 8.
Tilt Function:
1. Use a lift or jack to tilt the blade system until the left side is fully up, loosen the ttings on the rod and base end of
both tilt cylinders.
2. Actuate the tilt function to extend the right tilt cylinder and supply oil to the base end of the right cylinder and to the
rod end of the left cylinder.
3. When oil starts to ow from the ttings, stop oil ow, and tighten the tting on the base end of the right cylinder and
rod end of the left cylinder.
4. Remove the lift or jack.
5. Continue to actuate the tilt function until oil ows out of the remaining open ports.
6. Actuate the tilt function in the opposite direction.
7. When all air is removed from the tilt system, stop oil ow, and tighten the remaining ttings on the cylinders.
8. Cycle both cylinders in and out 5 more times.
9. Check tractor oil level and ll if necessary.
Angle Function:
1. Loosen the ttings on the rod and base end of the left angle cylinder.
2. Actuate the angle function to extend the left angle cylinder and supply oil to the base end of the left cylinder.
3. When oil starts to ow from the ttings, stop oil ow, and tighten the tting on the base end of the left cylinder.
4. Continue to actuate the left angle function until oil ows out of the remaining open ports on the left cylinder.
5. Actuate the left angle function in the opposite direction.
6. When all air is removed from the left angle system, stop oil ow, and tighten the remaining ttings on the left angle
cylinder.
7. Loosen the ttings on the rod and base end of the right angle cylinder.
8. Actuate the angle function to extend the right angle cylinder and supply oil to the base end of the right cylinder.
9. When oil starts to ow from the ttings, stop oil ow, and tighten the tting on the base end of the right cylinder.
10. Continue to actuate the right angle function until oil ows out of the remaining open ports on the right cylinder.
11. Actuate the right angle function in the opposite direction.
12. When all air is removed from the right angle system, stop oil ow, and tighten the remaining ttings on the right
angle cylinder.
13. Cycle the left cylinder in and out 5 more times and then the right cylinder in and out 5 more times.
14. Check tractor oil level and ll if necessary.
Run the blade through all the functions. If any function does not operate correctly, refer to corresponding section above
and re-bleed. If problem still persists, call Grouser Products.
NOTE: If blade does not function to the operator’s liking or preferred direction, swap the couplers at the rear
of the tractor or control the function location in the cab.

8
Connecting and Disconnecting the Blade
To Connect:
1. Remove the 3/4” pin (#18 on Page 10) so the skid shoes can move freely. The blade will lean back further
for easier connection onto the male quick attaches. Store the pin in the empty hole right behind the hole you
just took the pin out of.
2. Lift the locking latch and pull the quick attach lock handle on the left side of the angle system to open the
quick attach system. Refer to Page #14-15 for further clarication on the quick attach system.
3. Drive the tractor forward slowly until the top edge of the male quick attach is under the top hook of the
female quick attach already on the blade assembly.
4. Raise the lift system until the male quick attach engages the female. Continue to raise the lift system until
the blade is off the ground and the female quick attaches are against the front of the male quick attaches.
5. Shut off the tractor engine and set the parking brake.
6. Push the quick attach lock handle and lift the locking latch to the lock the handle in place.
7. Connect hydraulics couplers on the top arm. Refer to Page #6 for proper locations of all functions.
8. If applicable, plug the male blade break away end of the wire harness into the female blade break away
end of the wire harness on the top arm.
9. Lock the mushroom skid shoe link back in place with the 3/4” pin you moved in in Step #1.
10. Refer to the Initial Startup Instructions on Page 7 before operating any function on the blade.
To Disconnect:
1. Set the blade on the ground.
2. Unhook all of the couplers on the top arm.
3. Lift the locking latch and pull the quick attach lock handle to unlock the quick attach system.
4. Remove the 3/4” pin so the skid shoes can move freely and the blade can lean back. Store the pin.
5. Slowly lower the lift system to disengage the blade.
6. Slowly back away from the blade. When lift system is clear from the blade, raise the lift system.

9
Skid Shoe and Tilt Plate Adjustment
Skid Shoe Adjustment:
1. Remove the handle from the ratchet keeper
by pulling the hitch clip pin and insert into the
handle on the ratchet jack.
2. Loosen the locking nut on the ratchet jack.
3. Hold the body of the ratchet jack and rotate the
ratchet jack handle to raise or lower the skid
shoes.
4. If the skid shoe is not moving in the proper
direction, move the forward/reverse lever on
the handle (see Figure 2). Rotate the ratchet
jack handle again to move the skid shoe in the
direction needed.
5. After skid shoe is adjusted, rotate the ratchet
jack handle until it rests up against the ratchet
keeper. Return the removable handle to the
ratchet keeper ensuring that the ratchet jack
handle is captured by the removable handle
and the ratchet keeper. Secure the handle to
the ratchet keeper with a hitch clip pin.
6. Tighten the locking nut against the ratchet jack
body to keep it from moving.
7. When skid shoes are worn, replace with new
skid shoes.
Tilt Plate Adjustment:
1. Remove bolts and tilt plates.
Note: Don’t remove all of the bolts at the same
time.
2. Add or remove washers as needed to adjust
tilt-way clearance to have 1/16” - 1/8” of
clearance.
3. Once the tilt-way clearance is set, tighten bolts
to 640 ft-lbs.
Skid Shoe
Figure 2
Lever
Handle
Removable
Handle
Figure 1
Handle
HAHT Hydraulic Angle - Hydraulic Tilt 6-Way
HANT Hydraulic Angle - No Tilt 4-Way
NAHT No Angle - Hydraulic Tilt 4-Way
NANT No Angle - No Tilt 2-Way
Angle / Tilt Function Abbreviation Key

10
Blade Assembly & NANT Blade Assembly
Blade Length 14’ 16’ 18’ 20’
Item
No. Part No. Description Qty. Qty. Qty. Qty.
17 43-7767 Hitch Clip Pin 2222
18 43-15712 3/4” x 3-1/4” Safety Hitch Pin w/ Clip Pin 2222
19 43-18463 1” x 2.75” Pin 4444
20 43-18943 3/16” x 1-1/2” Cotter Pin 4 4 4 4
21 44-3749 Backdrag Brace Plate 1 1 1 1
22A 44-14830 Custom Name Plate 1 1 1 1
22B 44-18285 Ag Pro Plus Name Plate 1 1 1 1
23 50-15458 12” Round Mushroom Skid Shoe 2222
24 50-18470 Mushroom Skid Shoe Mount 2 2 2 2
25 52-8204 Tilt Plate 4 4 4 4
26 57-20749 1” Flat Washer 12 12 12 12
27 57-20818 7/8” Flat Washer Heavy Duty Gr. 8 (USS) 28 36 36 44
28 70-20999 1” Hex Top Lock Nut Gr 8 NC (Yellow Zinc) 2222
29 70-20598 7/8” Hex Nut Gr 8 NC 14 18 18 22
30 70-20646 5/8” Hex Top Lock Nut Gr 5 NC 32 36 40 44
31 70-20622 3/8” Flange Nut 8 8 8 8
32 75-18479 Mushroom Skid Shoe Link 2 2 2 2
Item #A for Custom Name Plate and Item #B for AG Pro Plus Name Plate
2
Refer to Pages 12-13 for
Quick Attach System
Detail View A
Blade Length 14’ 16’ 18’ 20’
Item
No. Part No. Description Qty. Qty. Qty. Qty.
115-18465-XX AG Pro Blade XX’ - Slant Top 1111
215-18475-XX AG Pro NANT Blade XX’ - Slant Top 1111
315-14730-XX XX’ x 24” Bolt on Top Extension 1111
315-18520-XX XX’ x 24” Bolt on Top Extension 1111
4 16-18945 1” X 3” Hex Bolt Gr 5 NC - Short Thread 2222
5 16-20538 7/8” x 2” Hex Bolt Gr 8 NC 14 18 18 22
6 16-20558 1” x 2” Hex Bolt Gr 8 NC 3333
7 16-20562 1” x 3” Hex Bolt Gr 8 NC 12 12 12 12
8 16-21064 3/8” x 1” Carriage Bolt Gr 5 NC 8 8 8 8
9 16-21666 5/8” x 1-3/4” Plow Bolt Gr 5 NC 32 36 40 44
10 18-18498-L Ratchet Keeper - Left 1111
11* 18-18498-R Ratchet Keeper - Right 1111
12 19-7774 1” x 1” Spring Bushing 2 2 2 2
13 27-9506 Grouser Dozer Serial Tag 1 1 1 1
14 29-7950-6 6’- 5/8” x 6” Double Bevel Cutting Edge - - 3 2
14 29-7950-7 7’- 5/8” x 6” Double Bevel Cutting Edge 2 - - -
14 29-7950-8 8’- 5/8” x 6” Double Bevel Cutting Edge - 2 - 1
15 34-17565 Ratchet Jack with Pins 2222
16 34-17567 Ratchet Jack - Handle 2222
24
19
10
23
30
28
15
18
20
18
4
19
17
20
16
9
32
14
7
30
27
27
1
22
29
3
21
25
9
5
26
6
12
8
30
13
A
Refer to Pages 16-17 for
Quick Attach System

11
Electric Hydraulic Angle System Operating Instructions
If your Grouser blade was purchased with the Electric Hydraulic Angle Option, you will have the ability to
angle the blade 30 degrees left or right. To achieve these angles, the two cylinders are designed to operate
independently of each other through an electric diverter valve. To angle the blade to the left, actuate the tractor
hydraulic control lever in the cab with the diverter valve un-powered. Then fully retract. To angle the blade to
the right, apply power to the diverter valve and then actuate the tractor hydraulic control lever. Always retract
cylinders fully prior to switching functions. If a cylinder fails to retract fully, clear any possible obstruction.
CAUTION: Do not bypass the hydraulic valve and plumb each cylinder to separate valves on the
tractor.
To ensure proper use and life of equipment, it is recommended to have both cylinders closed for straight ahead
dozing and only one cylinder partially or fully extended for angled dozing as shown in the diagrams below. If
the angle system is not used correctly, damage may occur.
Please contact Grouser Products with any questions by:
Phone - 701-282-7710 or 800-747-6182; Fax - 701-282-8131
CORRECT
(Left or RIght)
INCORRECT
2-Lever Angle System Operating Instructions
If your Grouser blade was purchased with the 2-Lever Hydraulic Angle Option, you will have the ability to
angle the blade 30 degrees left or right. To achieve these angles, the two cylinders are designed to operate
independently of each other with the use of 2 tractor hydraulic control levers and a 2-lever angle valve. To
angle the blade to the left or right, actuate the tractor hydraulic control lever corresponding to the left or right
cylinder. Only one cylinder can be extended at a time.
Angle Position Sensor Adjustment
The angle position sensor is set from the factory. If the system does not function correctly, verify the gap
between the sensor and the plate and the position of the sensor. If any adjustments are necessary, follow the
instructions below.
With cylinder retracted, verify that the proximity sensor is in the center of the plate that is on the cylinder end.
To adjust the spacing between the plate and the sensor, loosen one of the nuts and turn the other nut till the
spacing between the plate and the sensor is between 3/16” and 3/8”. Once the correct spacing is achieved,
tighten the locking nut.
24
19
10
23
30
28
15
18
20
18
4
19
17
20
16
9
32

12
End Extension Length 1’ 2’
Item No. Part No. Description Qty. Qty.
1 15-13990-1-L Slant Top 1’ End Extension cmb - Left 1 -
2* 15-13990-1-R Slant Top 1’ End Extension cmb - Right 1 -
3* 15-13990-2-L Slant Top 2’ End Extension cmb - Left - 1
4* 15-13990-2-R Slant Top 2’ End Extension cmb - Right - 1
5 16-20538 7/8” x 2” Hex Bolt Gr 8 NC 12 12
6 16-20540 7/8” x 2-1/2” Hex Bolt Gr 8 NC 4 4
7 16-21666 5/8” x 1-3/4” Plow Bolt Gr 5 NC 4 8
8 29-7950-1 1’- 5/8” x 6” Double Bevel Cutting Edge 2 -
9* 29-7950-2 2’- 5/8” x 6” Double Bevel Cutting Edge - 2
10 57-20816 5/8” Flat Washer Grade 8 (USS) 4 8
11 57-20818 7/8” Flat Washer Heavy Duty Grade 8 (USS) 20 20
12 70-20598 7/8” Hex Nut Gr 8 NC 16 16
13 70-20646 5/8” Hex Top Lock Nut Gr 5 NC 4 8
End Extensions
* Parts Not Shown
Only Left Side Shown
11
6
8
12
5
12
13
7
1
10
11
11
Item
No. Qty. Part No. Description
1 4 16-20128 1/2” x 2” Hex Bolt Gr 5 NC
2 4 16-35C612 3/8” x 3/4” Flanged Bolt
3 1 18-14658 NAXT Center Bracket
4 4 19-13577 NR Pin Spacer Clevis End
5 2 19-7774 1” x 1” Spring Bushing
6 2 26-34711 4 x 8 Cylinder w/ Cast Clevis Ends
7 1 32-14560 NAHT Tilt Frame
8 4 43-13580 1” Clevis Bolt In Pin
9 8 57-20744 1/2” Flat Washer
10 4 70-20604 1/2” Hex Center Lock Nut Gr 2 NC
No Angle - Hydraulic Tilt
Quick Attach (See Pages 12-13)
Quick Attach Lever System
1
2
3
4
5
6
7
8
9
10
9
(See Pages 12-13)
Refer to Page 7 for
Skid Shoe Parts
Quick Attach (See Pages 14-15)
Quick Attach Lever System
(See Pages 14-15)
Refer to Page 10 for
Skid Shoe Parts

13
Item
No. Qty. Part No. Description
1 16 16-21218 3/4” x 2” Carriage Bolt Gr 5 NC
2 3 16-35C612 3/8” x 3/4” Flanged Bolt
3 4 18-14670 770- Trunnion Mount Bracket
4 1 18-1701 AG Pro Hydraulic Valve Cover
5 1 56-14680 Logic Hydraulic Angle Valve
6 4 57-20744 1/2” Flat Washer
7 4 58-9369 Grease Zerk 1/8” NPT Straight
8 4 70-20604 1/2” Hex Center Lock Nut Gr 2 NC
9 16 70-20607 3/4” Hex Center Lock Nut Gr 2 NC
Angle Hydraulic Components
3
6
1
2
5
4
9
8
7
Item No. Qty. Part No. Description
1 2 25-34342 Tappet Quick Coupler Male
2* 2 25-3453 Pioneer Dust Cap Tilt (Green)
3* 2 25-3454 Pioneer Dust Plug Tilt (Green)
4 2 26-34711 4 x 8 Cylinder W/ Cast Clevis Ends
5 2 31-34050 Straight Thread Elbow 90° JIC x O-Ring (6801-8-8)
6 2 31-34051 Straight Thread Elbow 90° JIC x O-Ring (6801-8-10)
7 2 31-34060 Branch Tee JIC x O-Ring (6803-8-8-8)
8 2 35-30022 39” x 3/8” -8JIC/-8JIC Hose
9 1 35-31184 37” x 1/2” -8JIC/-8JIC Hose w/ Cordura (3.5M)
10 1 35-31185 47” x 1/2” -8JIC/-8JIC Hose w/ Cordura (3.5M)
No Angle - Hydraulic Tilt Hydraulics
* Parts Not Shown
NOTE: When ordering cylinder seal kits, the part number
on the cylinder is needed. The number is stamped on the
base end of the cylinder opposite of the hydraulic ports.
No. On
Cylinder Part No. Description
26-34711 49-12271 Seal Kit 4 x 8 (647135) Nitrided Rod, Clevis Ends
Hoses Not Drawn To Scale
8
6
4
5
4
7
9
10
8
1
See Page 20 for the remaining hydraulics.
See Page 6 for the remaining hydraulics

14
Quick Attach System
Item No. Qty. Part No. Description
1 1 11-3049 Bell Crank Weld
2 1 16-20011 1/4” x 2-3/4” Hex Bolt Gr 5 NC
3 3 16-20125 1/2” x 1-1/4” Hex Bolt Gr 5 NC
4 2 16-20130 1/2” x 2-1/2” Hex Bolt Gr 5 NC
5 8 16-20560 1” x 2-1/2” Hex Bolt Gr 8 NC
6 2 16-21064 3/8” x 1” Carriage Bolt
7 1 16-21125 1/2” x 1-1/4” Carriage Bolt
8 2 19-13577 NR Pin Spacer Clevis End
9 1 34-17799 Pin Pulling Latch Spring
10 1 39-14663 AG Pro Pin Puller Latch
11 1 39-14665 AG Pro Pin Puller Handle Weld
12 1 39-3072 Handle Cover (Orange)
13 2 43-18965 QA Lock Pin
14 1 44-14662 Pin Puller Link Plate
15 2 44-18970 AG Pro Pin Puller Arm
16 1 45-14710-R Female Bolt On Quick Attach, Right
17 1 45-14710-L Female Bolt On Quick Attach, Left
18 2 57-20742 3/8” Flat Washer
19 16 57-20819 1” Flat Washer Heavy Duty Gr 8 (USS)
20 6 70-20604 1/2” Hex Center Lock Nut Gr 2 NC
21 2 70-20607 3/4” Hex Center Lock Nut Gr 2 NC
22 1 70-20610 1/4” Nyloc Hex Nut Gr 5 NC
23 2 70-20622 3/8” Flange Nut
24 8 70-20999 1” Hex Top Lock Nut Gr 8 NC (Yellow Zinc)
Some Parts Hidden For Clarity
3
9
2
1
3
4
6
7
5
10
22
11
20
17
21
24
19
19
8
20
16
23
14
3
13
21
20
12 18
15
20
Qty 2.
Note: Angle frame may look
slightly different than what is
on your system.

15
Quick Attach System
3
9
2
1
3
4
6
7
5
10
22
11
20
17
21
24
19
19
8
20
16
23
14
3
13
21
20
12 18
15
20
Qty 2.

16
Hydraulic Angle - Hydraulic Tilt Or Hydraulic Angle - No Tilt
Item
No. Qty. Part No. Description
1 1 11-14640-L 770 Series Angle Arm Left
2 1 11-14640-R 770 Series Angle Arm Right
3 1 11-14650 770 Series Stabilizer Arm
4 1 14-9366 Non Tilt Bar
5 5 16-20036 5/16” x 1-1/2” Hex Bolt Gr 5 NC
6 1 16-20043 5/16” x 3-1/4” Hex Bolt Gr 5 NC
7 2 16-20220 3/4” x 2-1/2” Hex Bolt Gr 5 NC
8 2 16-20424 1/2” x 3-1/2” Hex Bolt Gr 8 NC
9 3 16-20427 1/2” x 4-1/2” Hex Bolt Gr 8 NC
10 2 16-20564 1” x 3-1/2” Hex Bolt Gr 8 NC
11 4 16-35C612 3/8” x 3/4” Flanged Bolt
12 5 18-3074 Hose Hold Down Clamp
13 6 18-3075 Hose Hold Down Clamp Plate
14 2 19-7774 1” x 1” Spring Bushing
15 2 19-13515 3/4” ID - Non Rotating Pin Spacer Bushing
16 4 19-13577 NR Pin Spacer Clevis End
17 2 26-34711 4 x 8 Cylinder W/ Cast Clevis Ends
18 2 26-34739 4 x 55 Trunnion Mounted Tube End Cylinder
19 1 32-14610 770 Angle Frame
20 1 32-14620 770 HA Tilt Frame
21 1 43-8130 1-15/16” x 23-1/4” Pin
22 2 43-8131 1-15/16” x 31” Pin
23 1 43-8132 1-15/16” x 35-1/2” Pin
24 1 43-8133 1-15/16” x 7-1/8” Stabilizer Arm Pin
Item
No. Qty. Part No. Description
25 4 43-13580 1” Clevis Bolt In Pin
26 2 43-8466 Angle Cylinder Pin - 1-1/2” x 6-1/4”
27 2 57-20747 3/4” Flat Washer
28 4 57-20749 1” Flat Washer
29 1 58-9373 Grease Zerk 1/8” NPT 65°
30 7 58-9372 Grease Zerk 1/8” NPT 90°
31 5 70-20604 1/2” Hex Center Lock Nut Gr 2 NC
32 2 70-20607 3/4” Hex Center Lock Nut Gr 2 NC
33 2 70-20609 1” Hex Center Lock Nut Gr 2 NC
HANT - Replace item # 11, 16, 17 & 25 with item # 4, 10, 28 & 33.
10
28
28
4
33
30
21
1
2
18
5
6
13
12
8
31
19
22
22
5
13
12
3
31
24
30
32
26
15
27
7
31
9
29
23
20
11
16 25
17
14
29
9
30

17
Hydraulic Angle - Hydraulic Tilt Or Hydraulic Angle - No Tilt
30
21
1
2
18
5
6
13
12
8
31
19
22
22
5
13
12
3
31
24
30
32
26
15
27
7
31
9
29
23
20
11
16 25
17
14
29
9
30
30

18
Hydraulic Angle - Hydraulic Tilt Or Hydraulic Angle - No Tilt Hose Routing
Hoses Not Drawn To Scale
6
19
14
21
14
29
28
1
6
6
5
5
1
6
33
22
25
2
31
4
8
34
15
17
24
#3 for HAHT
16
18
20
20
9
26
30
27
19
7
#1 for HANT 26
23

19
6
19
14
21
14
29
28
1
6
6
5
5
1
6
33
22
25
2
31
4
8
34
15
17
24
#3 for HAHT
16
18
20
20
9
26
30
27
19
7
#1 for HANT 26
23
Hydraulic Angle - Hydraulic Tilt Or Hydraulic Angle - No Tilt Hose Routing
Conguration HAHT HANT
Item No. Part No. Description Qty. Qty.
1 16-20036 5/16” x 1-1/2” Hex Bolt Gr 5 NC 5 1
2 16-20040 5/16” x 2-1/2” Hex Bolt Gr 5 NC 4 4
3 16-20043 5/16” x 3-1/4” Hex Bolt Gr 5 NC 1 -
4 16-35C616 3/8” x 1” Flanged Bolt 4 4
5 18-3074 Hose Hold Down Clamp 9 5
6 18-3075 Hose Hold Down Clamp Plate 10 5
718-14684-R Switch Mount Bracket - Right 1 1
8 18-14684-L Switch Mount Bracket - Left 1 1
9 25-34322 Tappet Quick Coupler Male 4 2
10* 25-3453 Pioneer Dust Cap Tilt (Green) 2 -
11* 25-3454 Pioneer Dust Plug Tilt (Green) 2 -
12* 25-3455 Pioneer Dust Cap Angle (Red) 2 2
13* 25-3456 Pioneer Dust Plug Angle (Red) 2 2
14 26-34711 4 x 8 Cylinder W/ Cast Clevis Ends 2 -
15 26-34739 4 x 55 Trunnion Mounted Tube End Cylinder 2 2
16 31-11699-8-8 JIC Union (2403-8-8) 2 2
Conguration HAHT HANT
Item No. Part No. Description Qty. Qty.
17 31-34040 Straight JIC x O-Ring (6400-8-8) 2 2
18 31-34041 Straight JIC x O-Ring (6400-8-10) 4 4
19 31-34050 Straight Thread Elbow 90° JIC x O-Ring (6801-8-8) 4 2
20 31-34051 Straight Thread Elbow 90° JIC x O-Ring (6801-8-10) 6 4
21 31-34060 Branch Tee JIC x O-Ring (6803-8-8-8) 2 -
22 34-12932 Cylinder Saddle 4 4
23 34-12994 Cylinder Hose Clamp 4 4
24 35-14674 45” -8 Formed Steel Line - Tier 4 Angle 2 2
25 35-30022 39” x 3/8” -8JIC/-8JIC Hose 2 -
26 35-30131 66” x 1/2” -8JIC/-8JIC Hose 4 4
27 35-30132 69” x 1/2” -8JIC/-8JIC Hose 2 2
28 35-30173 230” (19.17’) x 1/2” -8JIC/-8JIC Hose 1 -
29 35-30174 240” (20’) x 1/2” -8JIC/-8JIC Hose 1 -
30 56-14680 Logic Hydraulic Angle Valve 1 1
31 57-20741 5/16” Flat Washer 4 4
32* 59-34952 Stud Mounted Zip Tie 10 10
33 70-20581 5/16” Hex Nut NC 4 4
34 70-20622 3/8” Flange Hex Nut NC 4 4
* Parts Not Shown
NOTE: When ordering cylinder seal kits, the part number on the
cylinder is needed. The number is stamped on the base end of the
cylinder opposite of the hydraulic ports.
No. On
Cylinder Part No. Description
26-34711 49-12271 Seal Kit 4 x 8 (647135) Nitrided Rod, Clevis Ends
26-34739 49-12274 Seal Kit 4 x 55 (647210) Nitrided Rod

20
Angle Wire Harness
B-BLK
PPU
C-BLU
A-BRN
B-BLK
PPU
C-BLU
A-BRN
87
85 86
30
87
85 86
30
2 1
2 1
C B A
C
DEUTSCH PLUG
DEUTSCH PLUG DEUTSCH PLUG
4 PIN TRAILER PLUG
DEUTSCH PLUG
B A
Part Number 69-14675
Part Number 69-14677
C9: B1 COIL C8: B2 COIL C7: RIGHT RELAY
C
DEUTSCH PLUG
4 PIN TRAILER RECEPTICLE
C3
C1
C2
C3
C4
C5
C6
C7
C8
C9
85 30
86 87
B A
C6: LEFT RELAY
GROUND
RED 16GA. BLACK 16GA.
RIGHT PROX LEFT PROX POWER
GROUND RIGHT PROX LEFT PROX
A C B
C5: RIGHT PROX.
Part Number 69-14676
POWER
CONNECTIONS: C1: POWER SUPPLY C2: SELECTOR SWITCH C3: BLADE BREAK AWAY C4: LEFT PROX.
Part Number 69-14682
Part Number 69-14679
A2
BA
LEFT CYL
RIGHT CYL
B1 B2 A1
22
11
5 Amp Fuse
