Grozone Control CY1 User manual

www.grozonecontrol.com
USER GUIDE
CY1
Periodic mer

SAFETY NOTICE 3
INSTALLATION & OPERATION 4
OPTIONAL SETTINGS/24-HOUR CONTROL 5
OPTIONAL SETTINGS/DAY CONTROL ONLY 6
OPTIONAL SETTINGS/NIGHT CONTROL ONLY 7
QUICK TROUBLESHOOTING GUIDE 8-9
COMPLETE TROUBLESHOOTING GUIDE 10-11
WARRANTY & CUSTOMER SERVICE 12-13
PRODUCT DETAILS 14
TABLE OF CONTENTS

3
SAFETY NOTICE
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
DANGER
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
CAREFULLY FOLLOW THESE INSTRUCTIONS.
To reduce the risk of electric shock, disconnect power to the 120V
electrical outlet before installing or removing the unit. When removing the
electrical wall plate, it may fall across plug pins or become displaced.
To reduce the risk of electric shock, this product has a grounding type plug
that has a third (grounding) pin. This plug will only fit into a grounding
type power outlet. If the plug does not fit into the outlet, contact a
qualified electrician to install the proper outlet. Do not change the plug in
any way.

4
INSTALLATION & OPERATION
Note: This unit has been set to perform in Day control only. For Night
control only or 24-hour control, refer to Oponal sengs.
Set Values
Plug into 120 VAC outlet (see security noce on page 1).
Connect your equipment into the front panel outlet (MAX 15A).
OFF Time: 1 min to
12 hours.
Duraon in between
ON cycles.
ON Time: 10 sec to 20
min.
Duraon for which
equipment will run.
Installaon is now complete
Light sensor (photocell)

5
A. Unplug the unit.
Set both values to minimum.
OPTIONAL SETTINGS/24-HOUR CONTROL
B. Within 5 seconds, plug in the unit
then set both values to maximum.
C. "Output On" light turns ON or
OFF according to actual seng.
CY1 is now in "24-hour control" mode

6
A. Unplug the unit.
Set both values to maximum.
B. Within 5 seconds, plug in the unit
then set top value to minimum
followed by boom value to
minimum.
C. "Output On" light turns ON or OFF
according to actual seng.
CY1 is now in "Day control only" mode
OPTIONAL SETTINGS/DAY CONTROL ONLY

7
OPTIONAL SETTINGS/NIGHT CONTROL ONLY
A. Unplug the unit.
Set both values to maximum.
B. Within 5 seconds, plug in the
unit then set boom value to
minimum followed by top value
to minimum.
C. "Output On" light turns ON or
OFF according to actual seng.
CY1 is now in "Night control only" mode

8
Aer 10 sec,
Indicator and
load remain On
QUICK TROUBLESHOOTING GUIDE
Relay has
clicked and
Indicator is ON
Power applied
to load
Plug load into UNIT*
Plug UNIT
Unplug UNIT
SET DAY CONTROL
A
Quick Troubleshoong Chart Product Models : CY1
HOW TO SET DAY CONTROL • Unplug UNIT • Turn both knobs to MAX value • Within 5 sec, plug UNIT and rotate
knobs in this order :
• Top knob to Min • Boom knob to Min
DEFINITIONS
Min : knob rotated to minimum value (fully counter clockwise). Max : knob rotated to maximum value (fully clockwise). Indicator : Output ON light indicator
B
C
D E
F G H
Both knobs to Max value
Product
Good
Product
Defecve
Hide photocell
with hand palm
& wait 10 sec.
Aer 10 sec,
Indicator and
load are Off
No Yes
No
Yes

9
QUICK TROUBLESHOOTING GUIDE
= Steps
Relay has
clicked and
indicator is
ON
Power
applied to
load
Hide photocell
with hand palm
& wait 10 sec.
Aer 10 sec,
Indicator and
load remain Off
Aer 10 sec,
Indicator and
load are On
Plug load into UNIT*
Plug UNIT
Both knobs to Max value
Unplug UNIT
SET NIGHT CONTROL
I HOW TO SET NIGHT CONTROL
•Unplug UNIT •Turn both knobs to MAX value •Within 5 sec, plug UNIT and rotate knobs in this order :
•Boom knob to Min •Top knob to Min
J
K
L
M
N O P
*Before test, check if load is working properly.
Product
Good
Product
Defecve
No Yes
No
Yes

10
COMPLETE TROUBLESHOOTING GUIDE
Periodic mer
CY1
1 – Before you start
2 – Test
*IMPORTANT: READ AND FOLLOW THESE INSTRUCTIONS BEFORE
STARTING THE TEST.
· DO NOT CONNECT UNIT BEFORE STEP 1 OF THE TEST.
· DO NOT CONNECT A LOAD INTO THE UNIT BEFORE STEP 4 OF THE TEST.
· LIGHTHING CONDITION: perform this test in a room with enough light
for the controller to detect a DAY condion.
· Definions : CW : Clockwise.
CCW : Counter clockwise.
· Turn BOTH knobs fully CW before going to STEP 1.
STEP HANDLING AND TEST DESCRIPTIONS EXPECTED RESULTS
1
Within 5 seconds:
· Plug the unit into the power outlet.
· Turn UPPER knob fully CCW.
· Turn LOWER knob fully CCW.
· Turn BOTH knobs fully CW (order
DOES NOT MATTER).
Output On indicator
will turn ON.

11
COMPLETE TROUBLESHOOTING GUIDE
STEPS HANDLING AND TEST DESCRIPTIONS EXPECTED RESULTS
2
· Cover the Light Sensor completely
with the palm of your hand or black
electrical tape (a single finger will
NOT cover the sensor appropriately).
Output On indicator
will turn OFF aer 6-8
seconds.
3 · Uncover the light sensor.
Output On indicator
will turn ON aer 6-8
seconds.
4 · Plug a load into the CY1 front outlet. Load will be ON.
5 · Turn UPPER knob fully CCW (ON
Time at 10 seconds).
Output On indicator
and load will turn OFF
aer 10 SECONDS.
6
· Turn LOWER knob fully CCW (OFF
me at 1 minute) AND WAIT FOR
ONE MINUTE.
Output On indicator
and load will turn back
ON IN APPROXIMATELY
ONE MINUTE.

12
WARRANTY & CUSTOMER SERVICE
DO YOU HAVE A PROBLEM WITH YOUR CONTROLLER ? PLEASE READ
THESE INSTRUCTIONS CAREFULLY AND SAVE THEM FOR FUTURE
REFERENCE.
1. I think my controller is damaged, or it simply does not work as
indicated in the user guide, what should I do?
· Please refer to the troubleshoong steps. Follow these instrucons
carefully, step by step. The controller should work as described in the
“Expected results” column of the Complete Troubleshoong Guide.
Do you need assistance on execung the Troubleshoong steps?
1. Contact us at 1-855-262-1800
2. Send us an EMAIL at ser[email protected]
3. VISIT our Technical Support Center at
www.grozonecontrol.com/techsupport.html
Technical Support is available Monday through Friday, from 8:00 AM to
8:00 PM, Eastern Time.

13
2. I’ve been through the troubleshoong steps. What do I do if I meet a
problem at any of these steps? Is my product covered by the
WARRANTY?
· Grozone controllers are covered by a 3-year warranty (*). We will
replace any DAMAGED PRODUCT WITH A BRAND NEW PRODUCT.
· Covered or not covered? We do not authorize the replacement of fully
working products nor altered (tampered) products. The Troubleshoong
steps will help you idenfy a damaged product. Do not hesitate to
contact us or contact your retailer to make sure the controller is not fully
working or damaged before returning it to the store.
· My product is not fully working or damaged, I want a replacement unit:
in order to get a replacement product, you MUST return all modules
and applicable accessories to the retailer. To avoid being charged for
the accessories, be sure to include all pieces. Thanks for your
cooperaon.
· Any Grozone Control product that is returned with obvious signs of user
neglect will not be covered by the warranty. Grozone Control exercises
the right to make final decisions in these maers.
(*)The warranty period begins from the date of purchase at the retail level. The
retailer/consumer must keep their proof of sale/purchase. Otherwise, Grozone
Control will consider the manufacturing date to apply the warranty coverage.
IMPORTANT MESSAGE TO RETAILERS
Retailers must call Grozone Control to get authorisaon to replace the
defecve product and a RMA number.
1-855-262-1800
WARRANTY & CUSTOMER SERVICE

14
PRODUCT DETAILS
Operaon and Specificaons
ON me: 10 seconds to 20 minutes.
OFF me: 1 minute to 12 hours.
Starts with ON me when the controller is plugged into a power outlet.
Timing precision +/- 1%.
Electrical Specificaons: See the rang label on your product.
