Guldmann GH3 Twin User manual

1
© Guldmann GB/US-12/2016 • # 550216_10
GB/US ....GH3/GH3+ Ceiling Hoist
Manual – vers. 10.00
23W1

GH3 Lifting modules, version type nomenclature
Guldmann
hoist type
Product
line
Load in
kg
Number
of lifting
straps
Number
of lifting
motors
Number of
horizontal
drive
motors
Scale
module
CLM
module
Service
module
User
interface
GH3 (x) xxx x x x x x x x
GH3 200 1 1 1
250 1 1 1
+ 200 1 1 1 None : 0
Scale : 1
None : 0
CLM : 1
None : 0
Service: 1
Hand
control: 0
IR : 1
250 1 1 1
300 1 2 2
350 1 2 2
375 1 2 2
Twin 250 2 2 0
500 2 2 0
GH3 X Y Z Z Z Q Q Q Q
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10

3
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
GH3/GH3+ Ceiling Hoist
Item nos:
552xxx
1.00 .........GH3 use .....................................................5
1.01 .........Manufacturer ..................................................5
1.02 .........Intended use ..................................................5
1.03 .........Conditions for use ..............................................5
1.04 .........Important/Precautions ...........................................5
1.05 .........Load limits on GH3 system .......................................6
1.06 .........Unpacking and Preparation .......................................6
1.07 .........Placing a new GH3 Hoist in an existing rail system ....................6
1.08 .........Power supply ..................................................7
1.09 .........Installation of the lifting hanger before use ...........................8
1.10 .........Lifting sling....................................................9
1.11 .........Swing kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.12 .........Using swing kit in doorway ......................................13
1.13 .........GH3 with horizontal drive motor ..................................14
1.14 .........GH3 with horizontal drive motor and infrared remote (IR) control. . . . . . . . . 14
2.00 .........Description of functions .......................................14
2.01 .........Pictograms ...................................................15
2.02 .........Indicator lamps and audio signals .................................15
2.03 .........Operation ....................................................16
2.04 .........Supplementary modules, GH3+. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
. . . . . . . . . . . . . Menu structure, Supplementary modules GH3+ ......................18
2.05 .........Conguration of supplementary modules, GH3+. . . . . . . . . . . . . . . . . . . . . . 20
2.06 .........Scale module (GH3+ with integrated scale module) ..................21
2.07 .........CLM module (GH3+ with statistical function for management use) .......24
2.08 .........Service module (GH3+ with service module) ........................26
2.09 .........Safety functions ...............................................28
2.10 .........Charging/connection ...........................................30
2.11 .........Accessories ..................................................30
3.00 .........Transport and storage.........................................32
4.00 .........Maintenance and storage ......................................33
4.01 ........Cleaning.....................................................33
4.02 .........Storage .....................................................34
4.03 .........How to prevent/avoid corrosion? ..................................34
4.04 .........The owner’s daily maintenance duty ...............................34
4.05 ........Disposal of the GH3 including batteries ............................35
5.00 ........Service and lifetime ...........................................35
5.01 .........Lifetime .....................................................35
5.02 .........Safety/service inspections .......................................35
5.03 .........Troubleshooting ...............................................36

4
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
6.00 .........Classication ................................................36
7.00 .........Certicates ..................................................38
8.00 .........Technical specications .......................................38
9.00 .........EC-Declaration of conformity ...................................41
10.00 ........Environmental policy statement - V. Guldmann A/S ................42
. . . . . . . . . . . . . USA and countries outside the EU ..............................43
. . . . . . . . . . . . . A. Users guide ...............................................43
. . . . . . . . . . . . . B. WARRANTY ...............................................43

5
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
1.00 GH3 use
1.01 Manufacturer
V. Guldmann A/S
Graham Bells Vej 21-23A
DK-8200 Aarhus N
Tel. + 45 8741 3100
Fax + 45 8741 3131
www.guldmann.com
1.02 Intended use
GH3 is a lifting module that covers the need for lifting and moving a person
with disabilities and for walking training.
GH3 is intended for use in hospitals, nursing homes, rehabilitation centres
and in private homes and buildings.
1.03 Conditions for use
The use of the GH3 is subject to the following:
• The GH3 should only be used by trained personnel.
• The maximum nominal load, 200 kg (440 lbs), 250 kg (550 lbs), 300 kg
(660 lbs), 350 kg (770 lbs), 375 kg (825 lbs) respectively, must not be
exceeded.
• The instruction offered by Guldmann to all customer groups in connection
with the purchase of a ceiling-mounted hoist has been received.
• The helper pays attention to the well-being of the user when using the
hoist.
• The hoist is used in rail systems which are installed, tested and approved
according to Guldmann’s stipulation.
• Only technicians who have been certied by Guldmann may install and
test the rail systems.
• The hoist is used with the Guldmann lifting hanger or with other suitable
hanger (section 1.09).
• The hoist is used with a Guldmann lifting sling or with other suitable slings
(section 1.10).
1.04 Important/Precautions
• Read the instructions carefully before using the GH3 and in connection
with cleaning and service of the hoist.
• The GH3’s maximum load must never be exceeded.
• The GH3 may only be used to lift a person.
• The red strap for the emergency stop and the emergency lowering must
be adjutsed to the helpers reach, and must not be removed.
• The GH3 must not be used where there is a risk of it being splashed with
water.
• If a defect appears during use of the GH3, stop using the hoist and contact
the Guldmann Service Team for repairs.

6
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
• The GH3 is controlled by a microprocessor PCB, which can be damaged by
static electricity if touched without the necessary precautions, (see point 1.08)
• The electronics may only be serviced by Guldmann approved service
technicians.
• The lifting hanger must not be mounted or replaced when the GH3 hoist is
positioned over the patient.
Re: EMC
If electromagnetic or other inuences occur between this product and other
products, these products must not be used together.
1.05 Load limits on GH3 system
Read the label which indicate the maximum load limits for each component.
The components, e.g. lifting hanger, lifting sling, etc. labelled with the lowest
load limit determines the maximum load limit for the entire system.
This maximum load limit must not be exceeded.
Please note that the max load may change when different components are
used, such as lifting hangers, lifting slings, etc.
1.06 Unpacking and Preparation
Visual check of the GH3.
If the GH3 is thought to be damaged upon reception, the GH3 must not be
used before it has been checked and approved by a qualied person or the
Guldmann Service Team.
1.
2.
3.
4.
5.
Contents of the box
GH3 hoist
Hand control
Transformer
Manual
Label for rail system
1
3
2
1.07 Placing a new GH3 Hoist in an existing rail system
Please notice, placing a new GH3 hoist in an existing rail system it must
be ensured that:
• The rated max load of the rail system, must be equal or higher than the
max load of the new hoist.

7
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
– If there is no max load mentioned on the rail system, the rail system
must then be checked according to the guideline in the installation
manual (distance between bracket according to max load)
– If the brackets are not visible, then a load test with 1,5 x max load of
the hoist must be performed minimum 20 min. The deection of rails must
not be higher than 1/200 of the length of the rail.
– If it is not possible to do any of the above mentioned, please contact
Guldmann or their representative
• If the rail system can not be rated to the same max load as the hoist,
then extra brackets must be installed according to the installation
manual (distance between bracket according to max load).
Class I equipment
Fixed rail systems are class I equipment and must be installed by a qualied
technician or by Guldmann Service Team.
Equipment is disconnected from Supply Mains by breaking the mains breaker
switch.
Class II equipment
Mobile equipment is class II epuipment (marked with double-encassed
symbol) and can be connected to the mains direct by the user.
Equipment is disconnected from Supply Mains by detaching the mains plug
from the wall outlet.
Emergency stop device
The emergency stop device must be reset in order to connect power to the
product. To do this, push the yellow reset button (see point 2.09).
1.08 Power supply
GH3 is equipped with batteries that require regular recharging. The power
supply for charging and the battery charging point must be connected by a
qualied engineer or by Guldmann Service Team.
The transformer supplied must always be used.
Safety concerning static electricity (ESD)
Service technicians and installers must use an ESD-safety package
consisting of a mat, a ground wire, and a bracelet. The technician/installer
connects the mat to a grounding point, for instance a radiator or a water pipe.
The technician/installer must then put on the bracelet and connect it to the
mat. If it is not possible to nd a grounding point, the mat and the bracelet
must be used as a minimum.
Only then is it allowed to work with the PC Board or components where it
is possible to come into contact with the PC Board.

Fig. 1
Fig. 3
Fig. 2c
Fig. 2b
Fig. 2a
8
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
1.09 Installation of the lifting hanger before use
Lifting hangers from other
manufacturers
Guldmann shall not be liable for faults
or accidents that may occur as a result
of using lifting hangers made by other
manufacturers.
If there is any doubt about the
selection or use of a lifting hanger,
please contact your supplier.
The lifting hanger can be installed to
the lifting strap without the use of any
tools.
1. Hold the lifting hanger in the right hand
and press the yellow button using the
thumb as shown (Fig. 1)
2. Insert the strap attachment in
the slot on the lifting hanger top cover
with the open side facing down
(Fig. 2a, 2b) and release the yellow
button (Fig. 2c)
3. Rotate the strap attachment to a
vertical position (Fig. 3)
4. Check that the yellow button has returned
to its locked position by checking that it is
ush with the cover of the lifting hanger
and that the strap attachment can rotate
freely.

9
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
1.10 Lifting sling
A lifting sling with four to six lifting straps designed for mounting on hooks
should be used when using a Guldmann lifting hanger. Place the straps on
the hooks. Make sure that the rubber safety catch returns to its start position,
so the straps can not unintentionally fall off.
Slings made by other manufacturers
Guldmann shall not be liable for faults or accidents that may occur as a
result of using lifting slings made by other manufacturers.
If there is any doubt about the selection or use of a lifting sling,
please contact your supplier.
Guldmann shall not be liable for faults or accidents due to incorrect use of
the lifting sling, or for reasons of inadequate attention on the part of the carer
or user.
Working with the GH3
The GH3 runs easily in the rail system and does not have any special
requirements for space or power in connection with moving. Attention can
thus be fully focused on the user’s functional level and the helper’s technique.
If the hoist is used correctly, the user should only be lifted to the extent that
she/he is clear of the surface and should be moved at this height.
Attaching the lifting sling
Place the straps from the lifting sling on the hooks on the lifting hanger. Start
with the uppermost set of straps (from the back) and then take the lowest set
of straps (from the legs).

10
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
GH lifting hanger, 4 attachment points
Caution!
Be careful when attaching the lifting sling’s straps on the hooks. Check
that the straps have been correctly placed in the lifting hanger’s hooks.
When pressing the up button on the hand control to lift the user, check
again that all straps remain correctly placed in the lifting hanger’s
hooks (Fig. 1).
Fig. 1
GH lifting hanger
Caution!
Be careful when attaching the lifting sling on the hooks. Check that the
straps have been pulled completely through the rubber safety catch
(A) and into place in the lifting hanger’s hooks. When pressing the up
button to lift the user, check again that all the straps remain correctly
placed in the lifting hanger’s hooks (g. 1a and g. 1b).
Fig. 1a Fig. 1b
AA

11
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
Lifting to and from a seated position
When lifting a user from e.g. a wheelchair, move the GH3 towards the person
to be lifted.
The lifting hanger should be at the same height as the user’s chest and
should not be moved further in over the user than to approximately mid-thigh
position.
Place the lifting hanger parallel to the user’s shoulders.
Place the lifting sling behind the user’s back between the back of the chair
and the user’s back.
The centre band of the lifting sling should follow the user’s spine. As for the
slings type Active the strap showing the size of the sling should be opposite
the spine. Lead the leg straps along the outer sides of the user’s shins and
beneath the thighs between the hollow of the knees and the hip joints. Cross
the leg straps in front of the user.
All four lifting straps are now ready to be attached. The lifting sling can now
be mounted on the lifting hanger.
Lifting to and from lying position in bed
Bring the lifting hanger over the centre of the person to be lifted.
Place the lifting hanger parallel to the user’s shoulders.
Turn the user onto his or her side. The Basic High sling should be placed so
that its top is at the same height as the top of the user’s head. Now position
the sling over the user so that the centre band follows the user’s spine. Turn
the user onto his or her back and pull out the remaining part of the lifting
sling. Place the leg straps beneath the user’s thighs and cross them. All four
lifting straps are now ready to be attached and the lifting sling can now be
mounted on the lifting hanger. It is an advantage to elevate the head of the
bed so that the user is sitting up.
Important!
Only persons who have received competent instruction regarding the use of
lifting equipment and tting of slings should use the hoist.
Plan the move. Avoid leaving the user in the lifting sling unattended.
The hoist lifts quickly and powerfully. Before lifting, check that the user is
completely free of his/her surroundings. The user’s head, arms, hands and
feet must not be in danger of becoming trapped. Be careful with any tubes
and wires that are attached to the user. The user should not hold the lifting
strap during the moving procedure as there is a risk of crushing between
the strap’s hook and the hoist. Check that the hand control and hand control
cable is free of hanger, patient and other object before the hoist is activated
up or down moved.
If the hoist is used correctly, the user should only be lifted to the extent that
she/he is clear of the surface and should be moved at this height.

Fig. 3a
Fig. 6
Fig. 5
Fig. 4
Fig. 3b
Fig. 2
Fig. 1
12
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
1.11 Swing kit
The swing function is used in conjunction
with a transfer e.g. through a door from
one lifting module to another.
Note: The swing adapter must be ordered
separately.
Installation of swing adapter
1. Before starting a lift involving a swing
transfer the swing adapter (Fig. 1)
must be installed on the lifting hanger.
(Fig. 2 to 5)
2. Hold the lifting hanger in the right hand
and press the yellow button using the
thumb (Fig. 2)
3. Insert the swing adapter in the slot on the
lifting hanger top cover with the open side
facing down (Fig. 3a, 3b) and release the
yellow button.
4. Rotate the swing adapter to a vertical
position (Fig. 4)
5. Check that the yellow button has returned
to its locked position by checking that it is
ush with the cover of the lifting hanger
and that the swing adapter can rotate
freely.
6. Install the strap attachment to the swing
adapter by sliding the open side of the
strap attachment over the at area of the
swing adapter (Fig. 5)
7. Rotate the strap attachment and ensure
that it moves up on the circular portion of
the swing adapter (Fig. 6)

A B
A B
A B
A B
A B
13
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
1.12 Using swing kit in doorway
1. Bring the two hoist as close together as
possible. Adjust the height of the lifting
hanger on hoist B so that the transfer can
be done without the user touching the
oor during the transfer from one hoist to
another.
2. Take the free lifting strap from hoist A
and secure it to the swing adapter on the
lifting hanger (see 1.10 gures 5 and 6).
In order to lower the free lifting strap on
hoist A a slight pull must be applied to the
strap.
3. Lower the lifting hanger using hoist B
while lifting the strap on hoist A to perform
the swing transfer. The transfer has been
completed when there is no load on the
lifting strap on hoist B
4. Disconnect the lifting strap on hoist B
from the lifting hanger and raise the strap
on hoist B out of the way.
5. Move the lifting hanger from hoist A to
operating height and the doorway transfer
is complete.

14
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
1.13 GH3 with horizontal drive motor
The GH3 with horizontal drive motor can operate in the rail system.
Be aware that the drive motor takes time to both accelerate and brake
the hoist.
It is possible to position the hoist with horizontal driving motor with a high
degree of accuracy by a brief activation of the hand control.
The GH3 with horizontal drive motor runs on its own power and it should
not be pulled through the rail system.
1.14 GH3 with horizontal drive motor and infrared remote (IR) control
The GH3 has an integrated IR receiver which is controlled by the IR
remote control.
The hand control should be left attached to the hoist.
This means that the hoist can always be operated, in the the event that
the IR remote control is mislaid or the battery is uncharged.
2.00 Description of functions
Information panel on the GH3 bottom surface.
Lamp indicator

RESET
15
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
2.01 Pictograms
Emergency stop
Emergency lowering function
Reset emergency stop
Direction of travel (horizontal drive motor) denoted by grey arrow
2.02 Indicator lamps and audio signals
Status Indicator
lamps
Audio signals Possible GH3
Functions
Up Down Emergency lowering Horizontal drive motor Communication
Off
– stand by
Off
All OK Green x x x x x
No charging Yellow,
after 15 sec
3 x Beep after 60 sec x x x x x
Low battery Yellow x x x x x
Fault on
hoist
Yellow Beeps at button activation x x
Battery
critical low
Yellow Beeps at button activation
that is not permitted
x x x
Over load Yellow Beeps at button activation x x
Service date
exceeded
more than
60 days
Yellow Beeps at button activation x x x x x

16
6
5
1
2
4
3
7
1
3
2
4
1
5
6
2
7
1
2
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
2.03 Operation
Hand control
The GH3 is switched on automatically when
a button on the hand control is pressed.
The GH3 is switched off automatically after
approx. 8 minutes without activation.
GH3
1. Lift
2. Lower
GH3 with horizontal drive motor
1. Lift
2. Lower
3. Movement in the direction of the arrow
on the GH3 information panel (section 2.00).
4. Movement in the direction opposite to
the arrow on the GH3 information panel
(section 2.00).
GH3+
1. Lift
2. Lower
5. Function selection button
(section 2.05, supplementary modules)
6. Function selection button
(section 2.05, supplementary modules)
7. PDA interface (mini USB) x)
GH3+ with horizontal drive motor
1. Lift
2. Lower
3. Movement in the direction of the arrow on
the GH3 information panel (section 2.00).
4. Movement in the direction opposite to
the arrow on the GH3 information panel
(section 2.00).
5. Function selection button
(section 2.05, supplementary modules)
6. Function selection button
(section 2.05, supplementary modules)
7. PDA interface (mini USB) x)
x) Accessories to CLM module
(see Supplementary modules, GH3+
(section 2.04))

17
1
4
32
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
Parking the hand control
When the hand control is not in use it can be placed on the lifting hanger.
Infrared remote control
1. Lift
2. Lower
3. Movement in the direction
of the arrow on the GH3
information panel (section 2.00).
4. Movement in the direction opposite
to the arrow on the GH3 (section 2.00).
Note:
In order for the GH3’s lowering function
to work, the strap must be carrying a
load equal to the minimum capacity for
Guldmann’s lifting hanger.
Transport/running in the rail system
The GH3 is manually pushed forward in the rail system by the helper.
The GH3 with horizontal drive motor will run in the rail system when
activated by the hand control/remote control.

OK Start
Scale
KG
Show
CLM
2008.04.22
Next service
Setup
Setup
ExitZero
Scale KG
248.0
ExitNext
Lifetime
total lifts
987
Exit
Service date
exceeded
call service
OK
Low battery
OK
Critical low
battery
OK
No charging
OK
Fault hoist
ExitZero
Scale KG
0.0
ExitNext
Lifetime
heavy lifts
232
ExitNext
CLM 2-5
CLM 3-5
CLM 1-5
Last week
total lifts
60
ExitNext
CLM 4-5
Lifts per
week avg
72
Exit
Next
Hoist ID
Hoist #1
Change
Language
English
OK
Change
Language 4-8
Italianio
OK
Change
Language 1-8
Dansk
OK
Change
Language 5-8
Espanol
OK
Change
Language 2-8
Deutsch
OK
Change
Language 6-8
Francaise
OK
Change
Language 3-8
Svenska
Change
Language 7-8
Portuguese BR
Change
Units
KG
Change
Units
lbs
Change
Units
KG
OK
OK
Change
Language 8-8
English
Pop-ups
Next
service
2008.04.22
OK
CLM 5-5
2.04 Supplementary modules, GH3+
There are various supplementary modules for the GH3+
• Scale module (GH3+ with integrated scale)
• CLM module (GH3+ with statistical function for management use)
• Service module (GH3+ with Service module)
Menu structure, Supplementary modules GH3+
(Detailed description follows in sections 2.05-2.09)
18
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10

OK Start
Scale
KG
Show
CLM
2008.04.22
Next service
Setup
Setup
ExitZero
Scale KG
248.0
ExitNext
Lifetime
total lifts
987
Exit
Service date
exceeded
call service
OK
Low battery
OK
Critical low
battery
OK
No charging
OK
Fault hoist
ExitZero
Scale KG
0.0
ExitNext
Lifetime
heavy lifts
232
ExitNext
CLM 2-5
CLM 3-5
CLM 1-5
Last week
total lifts
60
ExitNext
CLM 4-5
Lifts per
week avg
72
Exit
Next
Hoist ID
Hoist #1
Change
Language
English
OK
Change
Language 4-8
Italianio
OK
Change
Language 1-8
Dansk
OK
Change
Language 5-8
Espanol
OK
Change
Language 2-8
Deutsch
OK
Change
Language 6-8
Francaise
OK
Change
Language 3-8
Svenska
Change
Language 7-8
Portuguese BR
Change
Units
KG
Change
Units
lbs
Change
Units
KG
OK
OK
Change
Language 8-8
English
Pop-ups
Next
service
2008.04.22
OK
CLM 5-5
19
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10

Menu Start
Scale
KG
Show
Statistics
2008.04.22
Next service
Setup
Setup
Change
Language
English
20
© Guldmann GB/US-12/2016 • # 550216_10
© Guldmann GB/US-12/2016 • # 550216_10
2.05 Conguration of supplementary modules, GH3+
Before the GH3+ is put into use, the hoist must be congured. Conguration
covers language (Scale module/CLM module/Service module) and the unit for
specication of weight (Scale module).
Factory setting: Language: English (UK)
Unit of weight: kg
Conguration of supplementary modules takes place from the GH3+
hand control.
Setting the language
1. Press any key on the GH3 hand control to activate the hoist.
When the hoist is activated, the display on the hand control is switched on
and the Guldmann logo “G” appears.
2. Select “Menu” using the function key located immediately below the display
and then select until the “Setup” menu appears in the display.
3. Select “Setup” and then until the “Language” menu appears in the
display.
4. Select “Change” until the preferred language appears in the display, and
conrm the selection by pressing “OK”.
5. Then return to “Setup”. Select to return to the start menu.
