H-KING Cloud Clipper Instruction Manual

BUILDING INSTRUCTION

Please read this instruction manual fully and become completely familiar with the features of this product
before operating. Failure to operate this product correctly could result in damage to the product, personal
property and cause serious injury. This is a sophisticated hobby product and is NOT a toy. It must always be
operated with caution, common sense and some basic mechanical ability. This manual provides instructions
as to the assembly, safe operation and maintenance of this hobby product. It is highly recommended that you
follow and read fully the instructions and warnings stated in this manual including safety, assembly, set-up and
flying guidelines in order to operate this product correctly and avoid damage or serious injury.
WARNING
As the user of this product you and you alone are responsible for operating it in a manner that does not
endanger yourself and others around you or result in damage to the product or property of others. This
product is operated via a radio controlled system that in some cases can be subject to interference from
sources outside of your control. Interference may result in a momentary loss of control so it is always
recommended that this product be used in a suitably open outdoors space.
• This is a radio controlled flying model and as such must always be flown with caution and care.
This is not a toy.
• The Tiger Moth is designed for intermediate to advanced pilots.
• Alway exercise great caution when using the recommended battery to power this product. For full safety notes
and operating procedures, please see information provided by your battery supplier.
• Take great care when connecting/disconnecting the battery. See battery supplier for full safty procedures.
• Never power up the model in confined spaces and always keep the prop clear of obstructions.
• This product is not a toy. Children must be accompanied by an adult at all times if operating this product.
• Only fly this model in an open area away from crowds, people, buildings, trees, power lines and obstructions.
• Always put safety first when operating this model and consider the warnings stated above.
• The supplier/manufacturer accepts no responsibility for damage or injury caused through the use of the
product. Not suitable for children under the age of 14. THIS IS NOT A TOY.
SAFETY PRECAUTIONS

PRODUCT LIST
KIT FEATURES , SPECIFICATIONS
BUILDING INSTRUCTION
1）FUSELAGE ASSEMBLY
2）WING
3）EMPENNAGE
P.1
P. 2
P.3-P.23
P.24-P.30
P.31-P.35
Contents:

PRODUCT LIST:
• Plywood sheet pack x 1 pc
• 1:1 drawing plan
• A set of pinewood stringer
• An instruction manual
• A PVC windshield x 1 pc
• Metal fitting pack x 1 pc
• A set of landing gear x 1 pc
• A pair of high-quality rubber main wheels
1
1

2
FEATURES:
Building instruction:
SPECIFICATION:
• Wingspan: 1800 mm
• Length: 1320 mm
• Flying weight: 1800 grams (With battery)
Recommend equipment:
• Motor: 2814 KV1000 brushless
• Engine: .25-.30 2T or a .30 4T
• ESC: 40A 3S 3000mAh
• Servo: >17 grams x 2〜3 pcs
• Prop: 11 x 4
• The Cloud Clipper 71" is a "Vintage " model
airplane which has been designed for 3 channel
R/C control. ( Elevator, Rudder and Motor)
• This kit is suitable for beginners to advanced mod-
ellers who want to build and fly a simple R/C plane
for leisurely sport flying.
• All parts are precision laser-cut and therefore they
fit together perfectly. This makes for quick and
accurate building.
• This model can be powered either with a nitro
engine (.25-302T or a .30 4T ) or with an electric
motor on 3S Li-Po battery
This Cloud Clipper kit includes precision pre-cut wing ribs, plywood formers, balsa wood strips/
sheets/blocks for the wing and stabilizers. Hardwoods and dowels for the fuselage, a set of piano
wire landing gear, a set of wheels, a hardware accessories pack, and a complete set of full size
building plans. Almost everything needed to build the basic airframe of this model is included. You
will need to supply your own covering film, power system, radio system, CA and epoxy glues, and
you are then ready to start building this wonderful balsa model kit.

3
BUILDING INSTRUCTIONS
1 FUSELAGE ASSEMBLY:
1) The supplied 6 x 6mm balsa strips for the fuselage require joining and extending. You
need to assemble over the building plan a left and a right hand fuselage side as shown.
We recommend that you cover this part of the plan using clear food wrapping film and scotch
tape. Do this before pinning and gluing the balsa down in the required positions, this will keep
the plan clean and intact.
2) Position the fuselage frame over the plan, cut the supplied strips and cross braces as shown.
Use clamps and pins to hold the parts together as the glue dries.

4

5
3) Glue to the fuselage frame part B15 which reinforces the nose section as shown. Do this to both
the left and right hand fuselage sides. You will need to soak the balsa at the front of the the
bottom longeron to enable it to bend to the underneath shape of B15.

6
4) Glue parts B19 to all the frame joints as shown, ensure you continue to make a left and right
hand fuselage side.. Add 3mm balsa sheet to the tail as shown below to form the push-rod exit,
again, ensure you are making a left and a right hand side.

7

8
5) Add a piece of 8mm balsa sheet to the nose of both the left and right hand fuselage sides.

9
6) Glue former B13 and B14 together with epoxy glue. Use some mini clamps to hold them whilst the
glue sets.

10
7) Laminate together the two B25 parts to form the front former for the motor mount.
8) Glue B25 and B13/B14 to the right hand fuselage side as shown. Note: Ensure both formers
remain perpendicular to the fuselage side as the glue sets.

11
9) Now assemble the left hand fuselage side to the right hand fuselage side. Use some mini
clamps to hold the assembly together. Ensure both formers remain perpendicular and square to
the left and right fuselage frame as the glue sets.

12
10) Place the fuselage over the plan and bring the tail together as shown below, add parts B20 and
B26, clamp these together as the glue sets. Add balsa strips to the top and bottom of the fuselage
frame so that the fuselage sides follow the contour shown on the plan. You will need to cut the
balsa strips to the lengths shown on the plan to ensure the contour is followed precisely.

13
11) Add the balsa longerons to the fuselage sides as shown.

14
12) Add the formers to the top of the fuselage as shown below and on the plan.

13) Add the balsa stringers to the formers to form the turtle deck etc. Ensure all the formers are
positioned correctly according to the plan.
15

16
14) At this point it is best to install the push-rod tubes into the fuselage. Trim the excess push-rod
tubes where they exit the rear of the fuselage.

17
15) Install the B17 servo mounting plate into the fuselage.
