H-KING F-35 User manual

INSTRUCTION MANUAL

1
Packing list:
1: PP F35 fuselage *1
2: Carbon strip for fuselage *3
3: Carbon strip for vertical tail *2
4: Pull rod *2
5: Motor mount *1
6: Quick rod adjuster *2
7: Hinge *2
8: M3 screws *4
9: wood strip *2
10: Hook and loop tape *1
Tools:
1: 1.5mm allen wrench
2: Phillips screwdriver
3: Modelling knife
4: Wire cutters
5: Hot melt glue gun and glue sticks
6: Foam Glue
7: No.502 glue
Electronic equipment:
Motor: 2208-2212-2216
2000KV-2600KV *1
Prop: 5-6 inch *1
ESC: 20-40A *1
Servo: 8/9g *2
Battery: 1300-2200mah 3S *1

2
Glue the 2 pcs horizontal fuselages using
hot glue sticks.
Then put the 3 pcs carbon strips into horizontal
fuselage using No.502 glue.
Stick the 2 pcs carbon strips on vertical tail using
foam glue.
Applying foam glue on 2 pcs nose.

3
Important: Wait 3 mins after applying foam glue,
then assemble the 2 pcs nose. Make sure 2 pcs
nose trim. Especially for step.
Applying glue on 2 pcs vertical fuselages using
hot glue sticks.
Important: just glue top side.
Wait 3 mins. Then take down bottom fuselage with
2 pcs vertical fuselages.
Reinforce bottom fuselage using hot glue sticks inside.
Then assemble bottom fuselage on vertical fuselage.
Reinforce bottom fuselage using hot glue sticks after
assembly.
Press the 2 pcs vertical fuselages into horizontal fuselage
Important: don’t use glue!

4
Then assemble vertical fuselage and bottom fuselage
on horizontal fuselage using hot glue sticks.
Also don’t forget to reinforce vertical fuselage using
hot glue sticks.
Assemble the nose on fuselage using hot glue sticks
or foam glue, make sure the motor mount location
must be flat!
Install vertical tail on fuselage using hot glue sticks.
Must use triangle foam board to make sure vertical
tail’s incline.
Assemble motor on motor mount using motor’s screws.
Reinforce nose using hot glue sticks after assembly.

5
Assemble prop on motor. Notice the prop’s direction.
Install arm on servo and electrify all servos to make
sure the arm perpendicular to servo. Then install arm
screws. Install servo in the hole using hot melt glue.
Install wood strip in the hole using No.502 glue.
Assemble Quick rod adjuster and install it in hinge,
apply a little No.502 to the nuts.
Assemble motor mount on fuselage, then reinforce
motor mount using a little hot glue sticks.

6
Install hinge into the hole on fuselage with foam glue.
Notice must let pull rod through the wood strip’s hole.
Install the 2 pcs wood clips in the bottom cover using
foam glue.
Put on hook and loop tape on fuselage using foam glue.
Then install ESC and receiver.
Use another hook and loop tape through the hole to
fix battery.
Then the wood clip can block bottom fuselage
when close.
Cut bevel in the end of bottom cover using knife.

7
C of G is on the front of the motor mount 11.5cm as
shown in the picture above.
PP F35 just has tail control, so we need set delta
wing mixed control on radio (Elevator and aileron
mixed control). We advise set elevator parameter to
60/70 and set aileron parameter to 90/100 on radio.
