H-KING SU-27 User manual

INSTRUCTION MANUAL

2
Packing list:
1: PP Su27 fuselage *1
2: Carbon tube 5*4*650mm*1
3: Pull rod *2
4: Motor mount *1
5: Quick rod adjuster *4
6: Hinge*4
7: M3 screws*4
8: Hook and loop tape*1
Tools:
1: 1.5mm allen wrench
2: Phillips screwdriver
3: Modelling knife
4: Wire cutters
5: Hot melt glue gun and glue sticks
6: Foam Glue
7: No.502 glue
Electronic equipment:
Motor：2208-2212-2216
1400KV-2600KV*1
Prop：5-8 inch *1
ESC：20-40A*1
Servo：8/9g *2
Battery：1300-2200mah 3S *1
1

2
Applying foam glue on 2 pcs nose.
Important: Wait 3 mins after applying foam glue,
then assemble the 2 pcs nose. Make sure 2 pcs
nose trim. Especially for step.
Glue the 3 pcs horizontal fuselages using hot glue
sticks.

Glue the carbon tube on fuselage using hot glue
sticks.
Put the vertical tail on the fuselage and mark the hole
for carbon tube. Then put on the carbon tube on the
hole’s location.
Cut the horizontal tail using knife.
Assemble all vertical tail on fuselage using hot glue
sticks.
3

4
Make sure the vertical tail is vertical to fuselage.
Assemble the nose on fuselage using hot glue sticks,
make sure the motor mount location must be flat!
Reinforce nose using hot glue sticks after assemble.
Important: Don’t glue too much on motor mount
location to avoid influence the motor mount’s
assemble.
Assemble tail on fuselage using hot glue sticks.

Reinforce all parts from bottom using hot glue sticks
after assemble.
Assemble motor on motor mount using motor’s
screws.
Assemble prop on motor. Notice the prop’s direction. Assemble motor mount on fuselage, then reinforce
motor mount using a little hot glue sticks.
Applying foam glue on nose’s hook and loop tape
location, then cut suitable hook and loop tape and stick
on the location.
5

6
Connect the motor and ESC, then put ESC on hook
and loop tape.
Place the motor wire through the hole behind motor
mount .
Install arm on servo and electrify all servos to make
sure the arm perpendicular to servo. Then install arm
screws. Install servo in the hole using hot melt glue.
Also glue the servo’s wire on fuselage using hot glue
sticks.
Assemble baseboard using hot glue sticks. Applying foam glue on horizontal tail and fuselage,
wait 3 mins, then assemble horizontal tail on fuselage.

Reinforce the horizontal tail using hot glue sticks after
assemble.
Assemble hinge with foam glue.Assemble Quick rod adjuster and install it in hinge,
apply a little No.502 to the nuts.
Put on hook and loop tape on fuselage using foam
glue and then place another hook and loop tape
through the hole.
Assemble the battery and receiver using hook and
loop tape.
7

8
C of G is on the front of the motor mount 4cm as
shown in the picture above.
PP Su27’s elevator and aileron are linkage mode, so
we need set delta wing mixed control on radio. Then it
can super-maneuver flight.
