H-KING Nori User manual

INSTRUCTION MANUAL

Packing list:
1: EPP Nori fuselage *1
2: Carbon tube 4*4*750mm *1
3: Carbon strip 1mm *5
4: Carbon rod 2mm *2
5: Pull rod *4
5: Motor mount *1
6: Quick rod adjuster *4
6: Hinge *4
7: Hook and loop tape *1
8: Wood strips *4
Tools:
1: 1.5mm allen wrench
2: Phillips screwdriver
3: Modelling knife
4: Wire cutters
5: Hot melt glue gun and glue sticks
6: Foam Glue
7: No.502 glue
8: Y cord *1
9: Servo extension cord *1
Electronic equipment:
Motor: 2208-2212-2216 1400KV-2600KV *1
Prop: 5-8 inch *1
ESC: 20-40A *1
Servo: 8/9g *4
Battery: 1300-2200mah 3S *1
Indoor Flying electronic equipment:
Motor: 2205-2206 1400KV-1700KV *1
Prop: 7-8 inch *1
ESC: 10-12A *1
Servo: 4.5/4.7g *4
Battery: 350-500mah 2S/3S *1
1

Install the carbon tube on fuselage using foam glue.
Install the carbon strip on fuselage using foam glue.
Install 2 pcs different length carbon strips on upper
half vertical fuselage using No.502 glue.
Important: don’t install bottom half vertical
fuselage!
Assemble the vertical fuselage on horizontal fuselage
using hot glue sticks or foam glue or No.502 glue (for
indoor flying), make sure the motor mount location
must be flat!
Install carbon strip on horizontal tail using foam glue
or No.502 glue. Then wait glue dried.
Glue the 2 pcs horizontal fuselages using hot glue sticks.
2

Wait glue dried. Then put plane on horizontal desk as
shown picture above.
Install the 2 pcs carbon strips on bottom half vertical
fuselage and assemble bottom half vertical fuselage
on horizontal fuselage using foam glue.
Must check whole fuselage to ensure fuselage
orthogonality before glue dry.
Reinforce all carbon strips using No.502 glue after
check. Especially for cross parts. Then reinforce
cross part of fuselage using hot glue sticks.
Ensure fuselage orthogonality before glue dried.
3

Install the 2 pcs 2mm carbon rod using No.502 glue as
shown picture above. Make sure the carbon rod front end
touch the carbon strip on wing and the carbon rod tail
end touch the location behind carbon strip on fuselage.
Install arm on servo and electrify all servos to make
sure the arm perpendicular to servo. Then assemble
Quick rod adjuster and install it on arm, apply a little
No.502 on the nuts.
Install pull rod on servo and hinge and adjust the rod’s
length. Then tighten the screws.
Install hinge into the hole on aileron with No.502 glue.
Install servo into the hole on wing using hot glue
sticks.
Make sure both side unification.
4

Same way to install fuselage’s servos. Let the 2
servo’s wires in same side.
Install wood strip in the hole using No.502 glue or hot
glue sticks. Notice must let pull rod through the
second hole on wood strip.
Install pull rod on servo and hinge and adjust the
rod’s length. Then tighten the screws.
Same way to the install rudder’s hinge and pull rod. Don’t forgot wood strip.
Same way to install hinge.
5

Assemble motor on the metal cross using screws.
Assemble prop on motor. Notice the prop’s direction.
Then assemble motor mount on fuselage using hot
glue sticks.
Put on hook and loop tape on fuselage using foam glue.
Then install ESC . Reinforce the cord using hot glue sticks. Then
connect ESC with extension cord.
Install motor mount on metal cross with 4 pcs
m3 screws.
4

Same way to install receiver.
Put hook and loop tape on fuselage using foam glue
behind ESC.
Then install battery.
C of G is behind the motor mount 2cm as shown in
the picture bellow.
Tie all wires up with cable ties.
5

EPP Nori looks very Cute and funny when flying, it
will take you a new flying feeling.
