H-KING j-20 User manual

INSTRUCTION MANUAL

1
Packing list:
1: PP J20 fuselage *1
2: Carbon strip 1mm*3
3: Carbon strip 0.5mm * 2
4: Pull rod *2
5: Motor mount *1
6: Quick rod adjuster *2
7: Hinge*2
8: Hook and loop tape*1
Tools:
1: 1.5mm allen wrench
2: Phillips screwdriver
3: Modelling knife
4: Wire cutters
5: Hot melt glue gun and glue sticks
6: Foam Glue
7: No.502 glue
Electronic equipment:
Motor：2208-2212-2216
2000KV-2600KV*1
Prop：5-6 inch *1
ESC：20-40A*1
Servo：8/9g *2
Battery：1300-2200mah 3S *1

2
Glue the 2 pcs horizontal fuselages using hot glue
sticks.
Then put the 3 pcs carbon strips into horizontal
fuselage using No.502 glue.
Stick the 2 pcs carbon strips on vertical tail using foam
glue.
Press the 2 pcs vertical fuselages into horizontal
fuselage. Important: Don’t use glue!

3
Assemble bottom fuselage on vertical fuselage.
Reinforce bottom fuselage using hot glue sticks after
assembly. Then wait glue dried.
Applying glue on 2 pcs vertical fuselages using foam
glue sticks. Important: Just glue top side.
Reinforce bottom fuselage using hot glue sticks inside.Then take down bottom fuselage with 2 pcs vertical
fuselages.
Then assemble vertical fuselage and bottom fuselage
on horizontal fuselage using foam glue or hot glue
stick.
Also don’t forget to reinforce vertical fuselage using hot
glue sticks.

4
Applying foam glue on 2 pcs nose. Important: Wait 3 mins after applying foam glue,
then assemble the 2 pcs nose. Make sure 2 pcs
nose trim. Especially for step.
Assemble the nose on fuselage using hot glue sticks
or foam glue, make sure the motor mount location
must be flat!
Reinforce nose using hot glue sticks after assembly.
Install vertical tail on fuselage using hot glue sticks. Must use triangle foam board to make sure vertical
tail’s incline.

5
Assemble motor on motor mount using motor’s
screws. Then install prop on motor. Notice the prop’s
direction.
Assemble motor mount on fuselage, reinforce motor
mount using a little hot glue sticks.
Put hook and loop tape on fuselage using foam glue.
Then install ESC .
Install hinge into the hole on tail aileron using hot glue
stick.
Install arm on servo and electrify all servos to make
sure the arm perpendicular to servo. Then install arm
screws. Fix servo on fuselage using hot glue sticks.

6
Put hook and loop tape on fuselage using foam glue.
Then install battery. Let battery cable through the hole
to fix battery.
Then install the pull on the quick rod adjuster and
hinge. Adjust pull rod’s length and tighten the screw.
Put hook and loop tape near battery using foam glue.
Connect servo, ESC with receiver. Then put receiver
on tape.
C of G is on the front of the motor 8cm as shown in the
picture above.
Fix battery use battery cable and block the cover. IPP J20 need set delta wing mixed control on radio
(Elevator and aileron mixed control), it’s very stable
when flying. You can also add servo on canard wing
to make flying more agility.
