H-KING FRENZY User manual

H-KING FRENZY
EPO SPORTS AEROBATIC MODEL WITH LED LIGHTS 1400MM

This radio controlled model is not a toy. It requires skill to fly and is not recommended
for use by beginners without assistance from an experienced model pilot. It should
not be operated by children without the supervision of a suitably experienced adult.
HobbyKing reserves the right to modify the specification of this model at any time.
WARNING
1. Do not attempt to repair or modify this aircraft with non-factory parts.
2. Never fly this model over roads, railway lines, near to power lines, airports, and do not
fly this model in excessively strong winds, rain, or thunderstorms.
3. Do not fly or launch the model towards people.
4. Keep hands and face away from the rotating propeller at all times.
5. We strongly recommend that all fixings and fasteners used in the construction of this
model are checked regularly for integrity. Failure to do so could cause a crash, injury to
yourself or others around you.
6. We only recommend the use of 2.4GHz radio equipment with this model.
SAFETY PRECAUTIONS
1. This radio controlled model is not a toy. Used incorrectly it is capable of inflicting
serious injury to persons or damage to property. The owner/pilot assumes all
responsibility for any damage to persons or property resulting from the use of this
product.
2. The manufacturer and distributor decline all responsibility for any liability arising
from use of this product.
3. It is very important that you follow all instructions for assembling and the setting up
of this model. Failure to do so could result In a loss of control and possibly a crash.
DISCLAIMER
EPO foam is a very tough and durable material perfect for the manufacture of model
aircraft. When using screwed fixings with EPO components it is important to tighten the
screws only enough to provide a firm fixing, do not over-tighten. Excess tightening
could result in the foam material becoming compressed, possibly damaging
or distorting the part. Take care to ensure that all screws are tightened sufficiently to
provide a firm fixing, do not over-tighten. We recommend that all fixings are checked
regularly for security and safety purposes..
EPO

INTRODUCTION:
SPECIFICATION:
The Frenzy offers a stunning combination of terrific looks and a sensational flight performance.
Manufactured from tough EPO it is extremely robust, however, in the event of a "less than
perfect" arrival, we supply a range of spares to get you flying again in the shortest time. It is
capable of a wide range of amazing aerobatic manoeuvres to thrill the experienced pilot, but
with reduced control throws it provides a solid and predictable flight performance, this
makes it perfect for the sports and early solo pilots.
We are certain you will enjoy your new model, please take the time to read this manual
thoroughly and understand its contents completely prior to commencing assembly.
• Wingspan:1400mm
• Length: 1130mm
• Weight: 1480g
• Motor: 3720-880KV Out-Runner Brushless
• Battery Required: 2200 - 2400mAh 11.l V LiPo (Not Included)
• Recommended Battery: 2200mAh 11.1 V 40C or greater
• ESC: 40A Brushless
• Servos: 2 x 9g, 2 x 17g
• Wing Loading: 40.3g/dm2
FEATURES:
• Powerful Brushless Motor
• 40A Brushless Electronic Speed Controller
• Efficient 2 Blade 11x7 Propeller
• Chrome Finish Spinner
• Pre-Installed Servos
• Pre-hinged Control Surfaces
• Durable EPO Construction w/Carbon
Reinforcement
• Plastic Cover on Cowl for Protection
• Steerable Tail Wheel
• Superb Flight Performance
• Excellent Power to Weight Ratio on 3S Set-up
• Very Bright LED Lighting System
• High-Viz Color Scheme
1

ASSEMBLY INSTRUCTIONS:
2. HORIZONTAL STABILIZER
Remove the molded tab at the end of the fuselage with a sharp knife (B). Slide the horizontal
stabilizer into the fuselage slot as shown (C). Make certain that the holes in the stabilizer line up
with the corresponding fuselage holes. If desired, a small amount of foam glue can be used for
maximum security.
A
B C
1. UNDERCARRIAGE
Fix the undercarriage halves into position with the
four 2.6 x 12mm self-tapping screws as shown in ( A).
If the screws become excessively tight whilst fixing,
simply back them off a tum or two, and then continue.
Note: The undercarriage legs are angled towards the
front of the fuselage.
3. VERTICAL STABILIZER & RUDDER
Install the vertical stabilizer and rudder
assembly into the slot in the fuselage. Please
make certain that the tail-wheel control wire is
located correctly in the plastic hole in the
rudder slot as shown (D).
If desired, a small amount of foam glue can be
used for maximum security. D
2

E
4. HORIZONTAL AND VERTICAL
STABILIZER FIXING
Fix the horizontal stabilizer and vertical stabilizer in
position with the two 2.6 x 35mm screws provided,
(E). The screws must be tightened sufficiently to
securely fix the parts in position, however be careful
not to over-tighten the screws.
2 x screws 2.6 x 35mm
5. TAIL CONTROL HORNS
Connect the rudder and elevator snap-links to their respective control horns as shown in images
F & G. Minor adjustment to obtain perfect neutral positions of the control surfaces can be
achieved by rotating the plastic link on the threaded portion of the control push-rod.
Make certain the plastic link is securely "snapped" closed when connected to the control horn.
FG
6. WING ASSEMBLY
Locate the 500mm carbon wing joining spar
and slide it into the round aperture of one wing
panel. Locate the small plywood rear wing
joiner and insert it into the rectangular aperture
behind the main wing spar (H). Slide the
remaining wing panel onto the exposed portion
of the carbon spar. The plywood locking plate
will ensure perfect alignment of the two wing
halves. It is highly recommended that the joint
of the wing panels is glued together for
maximum security. Apply glue to the roots of
the wing panels and push them together, be careful that all the wires are routed correctly via the
molded slots, and that they do not foul the joint between the wing roots. Once the joint is together,
temporarily wrap some tape around the joint, then screw the wing to the fuselage to ensure the
perfect fit. Once the glue has dried, remove the wing and then the tape.
H
3

J
K
Note: The plastic connectors are
angled for the wing camber.
The Frenzy is supplied with a unique 4 way lead for
joining the aileron servos and the LED lights.
Connect two of the 4 leads to the aileron servos, and
two of the leads to the LED lights as shown (J). The
other single lead goes to the aileron port in your
chosen receiver.
7. WING FIXING
Insert the front and rear plastic connectors into the wing, (K). They are angled to provide a
perfect fit. Make certain you have them located correctly! The wing can now be fixed in
position onto the fuselage using the three M4 x 50mm screws provided.
3 x Screw M4 x 50mm
1 x
1 x
4

5
8. PROPELLER & SPINNER
L
1. Remove the propeller set out of its packaging.
2. Disassemble the spinner using a screwdriver.
3. Install the propeller assembly onto the motor shaft as shown in illustration (L).
4. Using a wrench on the adapter nut, tighten the assembly onto the motor shaft.
5. Re-assemble the spinner to the propeller assembly using the 2 screws.
6. Assembly of propeller unit is completer.
Securely tightening the nut will clamp the adapter to the motor shaft and fix the propeller
in position. Note: Use of excessive force will cause damage to the aluminum adapter.
Note: It is essential that the propeller is securely fixed. Failure to do
so could result in serious injury.
9. RECEIVER INSTALLATION
Connect the speed controller to the throttle channel of your receiver, (not included). This
wire is easily identified, it is the only one that is routed from the front of the model.
Connect the rudder and elevator servos to the corresponding channel outputs of the
receiver and connect the plug on the 4 way lead to the aileron channel output. There is a
molded recess in this compartment which is sufficient to accommodate most popular
2.4GHz receivers; however there is ample room elsewhere to locate yours if it does not fit
in the recess.
We recommend that it should be securely positioned with self-adhesive hook and loop tape.
You must adhere to the receiver manufacturer recommendations regarding positioning and
aerial routing.

10. BATTERY INSTALLATION
The battery compartment is accessed by gently squeezing the two raised white tags and lifting
the rear of the front hinged cover, (M). Your flight battery, (not-included) can easily be installed
and connected to the factory fitted XT60 connector, (N). Make certain the battery and cover are
both secure before flight, the battery compartment has been made bigger to except larger
batteries if required, if your battery is loose in the compartment please use some foam sponge
packing to keep it in place.
11. CONTROL SURFACES
Check that all control surfaces are centered and responding correctly to transmitter inputs.
Adjustments can be made to control surface centers by carefully rotating the plastic control
links on the threaded portion of the metal control rods. Use the servo reversing function on your
transmitter for any control that is not responding in the correct sense to control inputs. Make
certain that all plastic links are securely "snapped" closed and that all control surface hinges are
secure. Use a small amount of foam glue if any hinges are not firmly attached.
13. CENTRE OF GRAVITY
It is vital that you check that the center of gravity is correct.
Failure to do so could result in a complete loss of control.
We recommend the balance point of the model, complete
with battery, should be 75 -90mm back from the
leading edge of the wing for initial flights, (Q). Very
experienced pilots may wish to move the balance point
further back after initial flight testing.
M N
12. PROPELLER ROTATION
Double-check that the propeller is
securely fixed and it is rotating in the
correct direction, (P).
P
Q
6

7
14. CONTROL SURFACE DEFLECTIONS
We suggest the following recommendations for control surface deflections. Experienced pilots
may wish to increase these movements after initial flight testing.
Ailerons: 10mm each way.
Elevator: 10mm each way.
Rudder: 12mm each way.
We hope you enjoy many happy and safe flights with your new H-King Frenzy model aircraft.
Check-out the other aircraft in the H-King range at www.hobbyking.com.
A FULL RANGE OF SPARE PARTS IS AVAILABLE FOR THE FRENZY..
SPARE PARTS:
Fuselage w/Decals
SKU: 9325000077-0
Wing w/Decals
SKU: 9325000078-0
Horizontal Stabilizer w/Decals
SKU: 9325000079-0
Horizontal Stabilizer w/Decals
SKU: 9325000080-0
Landing Gear Set
SKU: 9325000081-0
Cowling
SKU: 9325000082-0

8
Tailwheel Assembly
SKU: 9325000088-0
Plastic Wing Joiners
SKU: 9325000087-0
Wing Joining Rod
SKU: 9325000083-0
OrangeRx Tx6i Mode 2 6ch
2.4GHz DSM2/DSMX Compatible
Radio System
SKU: 9171001328-0
RADIOMASTER TX12 2.4GHz
Compact 12ch Multi Protocol
RC Transmitter
SKU: 9325000088-0
OrangeRx R620X V3 6Ch
2.4GHz Receiver
SKU: 9171001391-0
Rhino 2200mAh 3S 50C LiPo
Battery Pack w/XT60
SKU: 9952000025-0
Turnigy Graphene 2200mAh 3S
45C LiPo Pack w/ XT60
SKU: 9067000134-0
Turnigy Reaktor T240 AC/DC
10A 2 x 150W Charger
SKU: 995900002-3
Prop Adapter
SKU: 9325000086-0
Accessory Pack
SKU: 9325000084-0
3720-880KV Brushless Motor
SKU: 9325000085-0
RECOMMENDED ACCESSORIES:

UK REP
EC REP
APEX CE SPECIALISTS LIMITED
89 Princess Street, Manchester,
M1 4HT, UK
APEX CE SPECIALISTS LIMITED
Unit 3D North Point House,
North Point Business Park,
New Mallow Road, Cork, T23 AT2P, Ireland
