H3C S9500E LSR1FW2A1 User manual

Manual version: 6PW102-20150210 BOM: 3123A0A5
i
H3C S9500E LSR1FW2A1 Card Manual
1 Card identifier
The card identifier LSR1FW2A1 is at the upper right corner of the front panel.
2 Introduction
The LSR1FW2A1 card provides one console port, one CF card interface, two USB interfaces, two
10/100/1000BASE-T Ethernet copper interfaces, and two Gigabit Combo interfaces.
You can use a GE port or combo interface to provide the following functions:
•In-band management.
•Outgoing interface for log messages.
•Failover interface for stateful failover.
3 Specifications
Figure 1 Front panel
(1) CF card eject button (2) CF card slot (CF CARD) (3) CF LED (CFS)
(4) Console port (CONSOLE) (5) USB interface 1 (reserved) (6) USB interface 2 (reserved)
(7) Management Ethernet interface 1
(10/100/1000BASE-T)
(8) Management Ethernet interface
2 (10/100/1000BASE-T)
(9) Management Ethernet
interface 1 LED (LINK)
(10) Management Ethernet interface 1
LED (ACT)
(11) Management Ethernet interface
2
LED (LINK)
(12) Management Ethernet
interface 2 LED (ACT)
(13) Management interface 3
(Electrical port of combo interface
10/100/1000BASE-T)
(14) Management interface 4
(Electrical port of combo interface
10/100/1000BASE-T)
(15) Management interface 3
(Optical port of combo
interface 1000BASE-X)
(16) Management interface 4 (Optical
port of combo interface 1000BASE-X)
(17) Management interface 3 LED
(LINK)
(18) Management interface 3
LED (ACT)
(19) Management interface 4 LED
(LINK)
(20) Management interface 4 LED
(ACT)
(21) Ejector lever
(22) Captive screw

Manual version: 6PW102-20150210 BOM: 3123A0A5
ii
Table 1 Card specifications
Item S
p
ecification
CF card One CF card slot, 256MB by default for the external CF card
256 MB, 512 MB, or 1 GB for an optional external CF card
Dimensions (H × W × D) 40.1 × 400 × 380 mm (1.58 × 15.74 × 14.96 in)
Power consumption 85 W to 104 W
Weight 3.6 kg (7.94 lb)
Hot swapping Supported
Ports
•1 console port
•2 USB ports (reserved for future use)
•2 pairs of combo ports, each pair containing the following ports:
{1 x 10/100/1000BASE-T copper port
{1 x 1000BASE-X SFP fiber port
You can use the combo enable { copper | fiber } command to activate either of
the ports in a pair. By default, the copper combo port is activated.
Ambient temperature
•Operating: 0°C to 45°C (32°F to 113°F)
•Not operating: –40°C to +70°C (–40°F to +158°F)
Ambient relative humidity
•Operating: 10% to 95%, noncondensing
•Non-operating: 5% to 95%, noncondensing
Compatible device models H3C S9500E series switches
System software version See the release notes that come with the card.
Table 2 Console port specifications
Item S
p
ecification
Connector RJ-45
Interface standard RS-232
Transmission baud rate 9600 bps (default) to 115200 bps
Transmission medium Asynchronous serial cable
Transmission distance ≤15 m (49.21 ft)
Services
•Provides connection to an ASCII terminal.
•Provides connection to the serial port of a local or remote PC (through a
pair of modems) that is running a terminal emulation program.
•Supports command line interface (CLI).
Table 3 10/100/1000BASE-T copper port specifications
Item S
p
ecification
Connector RJ-45
Interface standard 802.3, 802.3u, and 802.3ab
Interface type MDI/MDIX autosensing
Supported cable Category-5 (or above) twisted pair cable

Manual version: 6PW102-20150210 BOM: 3123A0A5
iii
Item S
p
ecification
Transmission distance 100 m (328.08 ft)
Operating mode
•10 Mbps, half/full duplex
•100 Mbps, half/full duplex
•1000 Mbps, full duplex
Table 4 1000BASE-X fiber port specifications
Item S
p
ecification
Transceiver module SFP
Connector LC
Interface standard 802.3, 802.3u, and 802.3ab
Operating mode 1000 Mbps, full duplex
Table 5 1000BASE-X SFP port specifications
Gigabit SFP module Central
wavelength
Connector Cable specifications
Maximum
transmission
distance
SFP-GE-SX-MM850-A 850 nm LC 62.5/125μm
multi-mode optical fiber 0.55 km (0.34 miles)
SFP-GE-LX-SM1310-A 1310 nm LC 9/125 μm single-mode
optical fiber 10 km (6.21 miles)
SFP-GE-LH40-SM1310 1310 nm LC 9/125 μm single-mode
optical fiber 40 km (24.86 miles)
SFP-GE-LH40-SM1550 1550 nm LC 9/125 μm single-mode
optical fiber 40 km (24.86 miles)
SFP-GE-LH70-SM1550 1550 nm LC 9/125 μm single-mode
optical fiber 70 km (43.5 miles)
SFP-GE-LH100-SM1550 1550 nm LC 9/125 μm single-mode
optical fiber 100 km (62.14 miles)
4 LEDs
The card provides LEDs to show the operating status of the card and interfaces.
Table 6 LED description
LED Status Descri
p
tion
CF card(CFS)
Off The CF card is not present or cannot be identified.
Steady green The CF card is present and has passed the power on self test
(POST).
Flashing green The system is reading the CF card data. Do not unplug the CF
card.

Manual version: 6PW102-20150210 BOM: 3123A0A5
iv
LED Status Descri
p
tion
GE/Combo copper
port
(LINK/ACT)
Off No link is present on the port.
Steady green A link is present on the port.
Flashing yellow The port is sending or receiving data.
5 Installing and removing the card
CAUTION:
•Wear a well-grounded ESD wrist strap or ESD gloves before you install or remove the card.
•Do not touch the components on the PCB.
5.1 Installing the card
1. Locate the slot where you will install the LSR1FW2A1, and remove the blank panel from the
position. This manual describes installing the LSR1FW2A1 to slot 2.
2. Push the module with the components facing upward into the slot along the guide rails until the
positioning hole of the module is seated onto the positioning pin on the backplane. Push the ejector
levers inward to lock the module in place.
3. Fasten the captive screws on the module with a Philips screwdriver.

Manual version: 6PW102-20150210 BOM: 3123A0A5
v
Figure 2 Installing the card
5.2 Removing the card
1. Use a Phillips screwdriver to loosen the captive screws at both sides of the card.
2. Pull the ejector levers at both sides of the card outward to separate it from the backplane, and then
pull the card along the guide rails to remove it from the chassis.
3. Place the card on an anti-static workbench with the surface-mounted components up. You can also
put it in an anti-static bag.
4. If you are not going to install a new card, install a filler panel to prevent dust and ensure good
ventilation in the switch.
6 Logging in to the card
The card uses an independent operating system. Before you can configure the card, you must log in to
the card by using one of the following methods:
•Log in from the switch's CLI through the oap connect command.
•Log in through the card's Web interface, console port, Telnet, or SSH.
H3C recommends that you log in to the card from the switch's CLI the first time you access the card. This
section includes a procedure for logging in from the switch's CLI. For more information about other login
methods, see H3C SecBlade II Firewall Cards Configuration Guide.

Manual version: 6PW102-20150210 BOM: 3123A0A5
vi
To log in to the card from the switch's CLI, perform the following task in user view:
Task Command Remarks
Log in to the card through OAP.
•In standalone mode:
oap connect slot slot-number
•In IRF mode:
oap connect chassis
chassis-number slot slot-number
To return to the CLI interface of the
switch, press Ctrl+K.
7 Software upgrade
The card uses independent BootWare and system software images. You must upgrade the card software
separately from the switch software. To ensure a successful card upgrade, H3C recommends that you
upgrade the card through the card's console port or management Ethernet port. For more information
about software upgrade of the card, see the release notes that come with the card.
8 Obtaining documentation
To access the most up-to-date H3C product documentation on the World Wide Web
at http://www.h3c.com:
1. Go to http://www.h3c.com/Technical_Documents, or click Technical Support & Documents >
Technical Documents on the top navigation bar at http://www.h3c.com.
2. Click Security Products > H3C SecBlade Module to choose the desired product category and
model.
