HACH LANGE FP 360 sc User manual

DOC023.52.90161
FP 360 sc
User Manual
01/2010, Edition 1B
© HACH-LANGE GmbH, 2010. All rights reserved. Printed in Germany

3
Table of Contents
Section 1 Specifications ........................................................................................................................ 5
1.1 Dimensions ........................................................................................................................................ 6
Section 2 General information............................................................................................................... 7
2.1 Safety information............................................................................................................................... 7
2.1.1 Use of hazard information.......................................................................................................... 7
2.1.2 Precautionary labels .................................................................................................................. 7
2.2 Product overview ................................................................................................................................ 8
2.3 Measuring principle............................................................................................................................. 8
2.4 Product components........................................................................................................................... 8
2.4.1 FP 360 sc sensor ...................................................................................................................... 9
2.5 Function test ....................................................................................................................................... 9
Section 3 Installation............................................................................................................................ 11
3.1 Connect sensor cable ....................................................................................................................... 11
3.2 Installation options............................................................................................................................ 13
3.2.1 Installation with the chain mount kit ......................................................................................... 13
3.2.2 Installation of chain mount kit for sensors with cleaning unit ................................................... 13
3.2.2.1 Install the cleaning unit hose........................................................................................... 13
3.2.3 Installation with flow cell........................................................................................................... 15
Section 4 Operation.............................................................................................................................. 17
4.1 User interface and navigation ........................................................................................................... 17
4.2 Sensor setup..................................................................................................................................... 17
4.3 Sensor data logger ........................................................................................................................... 17
4.4 Menu structure.................................................................................................................................. 18
4.4.1 SENSOR STATUS................................................................................................................... 18
4.4.2 SENSOR SETUP..................................................................................................................... 18
4.5 Calibration......................................................................................................................................... 20
4.5.1 Factory calibration.................................................................................................................... 20
4.5.2 Process calibration/adjustment................................................................................................ 20
4.5.2.1 Determination of factors and adjustment of slope........................................................... 20
4.5.2.2 Multi-point calibration ...................................................................................................... 21
4.5.3 Check the zero point................................................................................................................ 21
4.5.4 Adjustment of slope and zero point; multi-point calibration...................................................... 21
4.5.4.1 Adjust the slope (FACTOR) ............................................................................................ 21
4.5.4.2 Adjust the zero point (OFFSET)...................................................................................... 22
4.5.4.3 Multi-point calibration (2 to 5-point calibration) ............................................................... 22
Section 5 Maintenance ......................................................................................................................... 23
5.1 Maintenance schedule...................................................................................................................... 23
5.2 Maintenance for the connectors on the sensor................................................................................. 23
5.3 Cleaning the measurement windows................................................................................................ 24

4
Table of Contents
Section 6 Troubleshooting ...................................................................................................................25
6.1 Error messages.................................................................................................................................25
6.2 Warnings ...........................................................................................................................................25
6.3 Replacement parts ............................................................................................................................25
Section 7 Replacement parts and accessories ..............................................................................27
7.1 Sensor options ..................................................................................................................................27
7.2 Replacement parts ............................................................................................................................27
7.3 Accessories.......................................................................................................................................27
Section 8 Contact information ............................................................................................................29
Section 9 Warranty and Liability..........................................................................................................31
Appendix A Modbus register ..............................................................................................................33
Index.......................................................................................................................................................35

5
Section 1 Specifications
Specifications are subject to change without notice.
Measurement
Measurement method
UV fluorescent measurement process for polycyclic aromatic
Hydrocarbons (PAH)
Excitation wavelength: 254 nm
Emission (measurement) wavelength: 360 nm
Measuring range
Low measurement range
0 to 50 ppb and 0 to 500 ppb in relation to PAH calibration standard, 
corresponding to 0.1 to 1.5 ppm and 0.1 to 15 ppm of oil calibration
standard
High measurement range
0 to 500 ppb and 0 to 5000 ppb in relation to PAH calibration standard, 
corresponding to 0.1 to 15 ppm and 0.1 to 150 ppm of oil calibration
standard
Display units ppb, ppm, μg/L, mg/L
Reproducibility 2.5% of measurement value at a constant temperature
Measurement accuracy 5% of measurement value ±2% from measurement range limit
at a constant temperature
Limit of detection 1.2 ppb (PAH)
Response time 10 s (T90)
Calibration Factory calibration with UV fluorescence calibration standard, custom
adaptation possible
Sensor software
Software version From 1.14
Equipment properties
Weight
Measurement sensor Stainless steel version 2.8 kg, titanium version 1.8 kg
Flow cell Approximately 0.6 kg, including installation board approximately 2.0 kg
Pressure range
Sensor Max. 30 bar
Flow cell Max. 1 bar
Dimensions
Measurement sensor 
(Ø × length)
68 mm x 306 mm (2.68 in. x 12.05 in.) 
(without plugs or suspension pin)
68 mm x 399 mm (2.68 in. x 15.71 in.) (including suspension pin)
68 mm x 413 mm (2.68 in. x 16.26 in.) 
(with additional cleaning option)
Flow cell (L × W × D)
98 mm x 98 mm x 150 mm (3.86 in. x 3.86 in. x 5.91 in.) (without
fittings), 
installation board: 600 x 300 x 10 mm (23.62 in. x 11.81 in. x 0.39 in.)
Materials
Measurement sensor
Housing: stainless steel 1.4571 or titanium
Optic bracket: POM
Housing bolts: stainless steel 1.4571
Measurement window: synthetic quartz glass (Suprasil)
Gaskets (housing): Viton
Gaskets (measurement window): NBR (Nitrile Butadiene Rubber)
Flow cell
Housing: POM
Installation board: PVC
Gaskets: NBR (Nitrile Butadiene Rubber)
Fittings: nickel-plated brass
Shackle Stainless steel 1.4301

6
Specifications
1.1 Dimensions
Figure 1 Sensor without and with cleaning unit
1Sensor without cleaning unit 2Sensor with cleaning unit
Environment considerations
Sample temperature 1 to 40 °C (34 to 104 °F)
Ambient temperature
–5 to +45 °C (23 to 113 °F)
Measurement sensor wetted by at least half from the measuring
medium: 
–25 to +55 °C (-13 to 131 °F)
Sensor distance - wall/ground min. 100 mm (3.94 in.) (recommended)
Miscellaneous
Cable length 1.5 or 10 m, extension cable up to total maximum length of 40 m
Connection
information
Sensor side 8-pin, type of protection IP68, PUR
Controller side M12, type of protection IP67
Inspection interval Every 2 years; 1/year service agreement by request, with warranty
extension up to 5 years
Maintenance requirements Clean the measurement window, if necessary. Intervals are dependent
on the measuring medium.
Compliance CE
Warranty 2 years

7
Section 2 General information
2.1 Safety information
Please read this entire manual before unpacking, setting up or operating this equipment.
Pay attention to all danger and caution statements. Failure to do so could result in serious
injury to the operator or damage to the equipment.
Make sure that the protection provided by this equipment is not impaired, do not use or
install this equipment in any manner other than that specified in this manual.
2.1.1 Use of hazard information
Note: Information that supplements points in the main text.
2.1.2 Precautionary labels
Read all labels and tags attached to the instrument. Personal injury or damage to the
instrument could occur if not observed. A symbol on the instrument is referenced in the
manual with a precautionary statement.
DANGER
Indicates a potentially or imminently hazardous situation which, if not avoided, will result in death
or serious injury.
WARNING
Indicates a potentially or imminently hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION
Indicates a potentially hazardous situation that may result in minor or moderate injury.
NOTICE
Indicates a situation which, if not avoided, may cause damage to the instrument. Information that
requires special emphasis.
This is the safety alert symbol. Obey all safety messages that follow this symbol to avoid potential injury. If on the
instrument, refer to the instruction manual for operation or safety information.
This symbol indicates that a risk of electrical shock and/or electrocution exists.
This symbol shows that a UV lamp is used in the equipment.
Electrical equipment marked with this symbol may not be disposed of in European domestic or public disposal
systems after 12 August 2005. In conformity with European local and national regulations (EU Directive
2002/96/EC), European electrical equipment users must now return old or end-of life equipment to the manufacturer
for disposal at no charge to the user.
Note: For return for recycling, please contact the equipment producer or supplier for instructions on how to return
end-oflife equipment, producer-supplied electrical accessories, and all auxiliary items for proper disposal.

8
General information
2.2 Product overview
The FP 360 sc sensor is a UV fluorimeter used to continuously measure the concentration
of PAH (polycyclic aromatic hydrocarbons) in water. The measurement values can be
converted to reflect the total oil content for mineral oils using lab data.
The sensor may need to be installed with additional accessories depending on its area of
application.
Do not apply the sensor to any hard mechanical effects.
2.3 Measuring principle
The measuring principle is based on the fluorescent properties of PAHs. After excitation
caused by UV rays, PAHs emit light with longer wavelengths after a short time delay. The
intensity of this light is measured. This measuring principle is considerably more sensitive
than absorption and scattered light measurement. It is possible to detect even the slightest
trace of PAH contamination in water. PAHs are integral parts of most mineral oil products
and are a very specific indicator of oil contamination in water bodies and process water.
2.4 Product components
Each sensor is supplied with
•a connector cable with safety sleeve,
•a shackle,
•a basic user manual and
•a CD.
The sensor is available in a variety of types (refer to section 7.1 on page 27). Refer to
Figure 2 to make sure that all components have been received. If any of these items are
missing or damaged, contact the manufacturer or a sales representative immediately.
DANGER
This product is not suitable for use in potentially explosive atmospheres.
WARNING
The UV rays from the flash bulb are harmful to eyes and skin. Do not look directly through the
measurement window during operation under any circumstances. Remove the measurement
sensor from operation before carrying out any maintenance or installation work.
Area of application Installation with Sensor variants
Open channels, shafts, tanks (solid
matter max. 200 mg/L) Chain mount kit Sensor with or without cleaning unit
Measurement media without solid
matter with continuous, low sample
throughput
Flow cell Sensor without cleaning unit

9
General information
2.4.1 FP 360 sc sensor
Figure 2 FP 360 sc sensor
1FP 360 sc measurement sensor 56 mm fitting for cleaning unit (depending on model)
2Basic user manual with CD 6Safety sleeve
3Measurement window 7Connector cable
4Sensor with cleaning unit (depending on model) 8Shackle
2.5 Function test
After the components are removed from the package, do a function test.
1. Connect the connector cable to the sensor (8-pin polarized connector) and an
appropriate sc controller (5-pin polarized connector) (refer to section 3.1 on page 11).
2. Apply power to the sc controller. The display is activated and the sensor goes to
measurement mode.
The sensor ticks quietly and regularly.
CAUTION
Before power is applied, refer to the controller operation instructions.

10
General information
3. Cover the sensor measurement window with a sheet of white paper (do not use
recycled paper).
4. Vary the distance between the measurement window and the paper. 
The measurement value on the display will change accordingly.
Note: In air, the measurement value displayed is not exactly zero due to reflections on the window
surface (refer to section 4.5.3 on page 21).

11
Section 3Installation
3.1 Connect sensor cable
1. Connect the polarized socket on the connector cable to the sensor plug (8-pin plug)
(refer to Figure 3 step 1).
2. Push the safety sleeve on the plug (step 2).
3. Hand-tighten the safety sleeve in position (step 3).
Figure 3 Connect the sensor cable to the sensor
4. Remove the protective cap on the controller socket and keep it to seal the connector
opening in case the sensor must be removed.
5. Connect the sensor to the controller using the keyed quick-connect fitting.
Hand-tighten (refer to Figure 4).
Note: Connector cables are available in various lengths (refer to section 7.2 on page 27). Maximum
overall cable length is 40 m (131,23 ft).
DANGER
Personal injury hazard. Only qualified personnel should conduct the tasks described in this section
of the manual.
NOTICE
If the sensor is not fully inserted, sun protection is recommended in high ambient temperatures
and intense solar radiation to protect against thermal and UV effects.
CAUTION
Always put the cables and hoses in a position that does not bend or cause a trip hazard.
CAUTION
Before power is applied, refer to the controller operation instructions.

Figure 4 Connect the sensor to the controller
Figure 5 Pin configuration
1+12 VDC brown
2Ground black
3Data (+) blue
4Data (–) white
5Screen Screen (gray)
6Guide
12
Installation
Number Description Standard cable, cable color
6
1 2
5
3
4

13
Installation
3.2 Installation options
The sensor may need to be installed with additional optional accessories depending on
the area of application (refer to section 7.3 on page 27).
Note: Refer to the documentation supplied with the accessories for detailed installation instructions.
3.2.1 Installation with the chain mount kit
The FP 360 sc sensor is installed with the chain mount kit in open channels, shafts and
tanks.
3.2.2 Installation of chain mount kit for sensors with cleaning unit
3.2.2.1 Install the cleaning unit hose
Note: An air hose is required, to operate the sensor with the optional cleaning unit. An oil-free
compressed air (6 bar) and a solenoid valve or the HOAB compressed air cleaning system is also
required (refer to section 7.3 on page 27).
With the HOAB compressed air cleaning system, replace the end of the hose connection
that is connected to the compressed air on the underside of the instrument with the
straight 6 mm fitting (refer to Figure 2 on page 9, item 5) supplied with the probe.
Figure 6 FP 360 sc measurement sensor with chain mount kit

14
Installation
Figure 7 Install the cleaning unit hose
Figure 8 FP 360 sc measurement sensor with cleaning unit and chain mount kit

15
Installation
3.2.3 Installation with flow cell
The FP 360 sc sensor with flow cell is installed for samples free of solids and particulates
and limited sample flows.
Figure 9 Installation with flow cell

16
Installation

17
Section 4 Operation
4.1 User interface and navigation
The sensor can be used with sc controllers from sc100. Refer to the controller
documentation for keypad description and navigation information.
4.2 Sensor setup
When the sensor is connected for the first time, the sensor serial number is displayed as
the name of the sensor. To change the sensor name:
1. Open the MAIN MENU.
2. Select SENSOR SETUP and confirm.
3. Select the corresponding sensor and confirm.
4. Select CONFIGURE and confirm.
5. Select EDIT NAME and confirm.
6. Edit the name and confirm to return to the SENSOR SETUP menu.
Complete sensor configuration in the same manner, with the following menu options
selected:
• SET PARAMETER
• SELECT UNITS
• AVERAGE
• LOG SETUP
• GAIN VALUE
4.3 Sensor data logger
There is a data log and event log available for each sensor. 
In the data log, the measurement data are stored at preset intervals; the event log stores
events such as configuration changes, alarm messages and warning messages. Both logs
can be exported to CSV format (refer to the controller manual).

18
Operation
4.4 Menu structure
Note: Refer to Section 6 on page 25 for a list of all possible error and warning messages
together with a description of all necessary countermeasures to be taken.
4.4.1 SENSOR STATUS
SELECT SENSOR (if there is more than one sensor)
ERROR LIST Possible error messages: SENSOR ERROR
WARNING LIST Possible warning messages: TEST/MAINT, BULB CHANGE, LAST CONFIGUR, TARGET
VALUE
4.4.2 SENSOR SETUP
SELECT SENSOR (if there is more than one sensor)
CALIBRATE
SET OUTMODE Behavior of the outputs during calibration and zero point adjustment
HOLD
ACTIVE
SET TRANSFER
SENSOR MEASURE Current, uncorrected measurement value
CONFIGURE FACTOR: 0.1 to 100
OFFSET: –1000 to +1000
FACTOR
OFFSET
2 POINT
3 POINT
4 POINT
5 POINT
FACTOR Is shown when FACTOR has been selected under CONFIGURE.
Refer to section 4.5 on page 20 for detailed information.
OFFSET Is shown when OFFSET has been selected under CONFIGURE.
Refer to section 4.5 on page 20 for detailed information.
2 POINT Is shown when 2 POINT has been selected under CONFIGURE.
Refer to section 4.5 on page 20 for detailed information.
3 POINT Is shown when 3 POINT has been selected under CONFIGURE.
Refer to section 4.5 on page 20 for detailed information.
4 POINT Is shown when 4 POINT has been selected under CONFIGURE.
Refer to section 4.5 on page 20 for detailed information.
5 POINT Is shown when 5 POINT has been selected under CONFIGURE.
Refer to section 4.5 on page 20 for detailed information.
SET CAL DEFLT Security query, reset to (FACTOR=1, OFFSET=0)

19
Operation
CONFIGURE
EDIT NAME Name can include up to 16 characters,
DEFAULT CONFIG: sensor serial number
SET PARAMETER
PAH: Measurement value related to PAH calibration standard
OIL: Measurement value related to oil calibration standard
DEFAULT CONFIG: PAH
SELECT UNITS ppb, ppm, μg/L, mg/L,
DEFAULT CONFIG: ppb
AVERAGE 1 to 300 s,
DEFAULT CONFIG: 3 s
LOG SETUP 5 s, 30 s, 1 min, 2 min, 3 min, 4 min, 5 min, 6 min, 10 min, 15 min, 30 min,
DEFAULT CONFIG: 10 min
GAIN VALUE
Range 0 to 500 ppb: AUTO, 0.01 to 50, 0.01 to 500,
Range 0 to 5000 ppb: AUTO, 0.01 to 500, 0.01 to 5000
DEFAULT CONFIG: AUTO
SET DEFAULTS Security query,
reset to preset configuration for all menu options listed above.
DIAG/TEST
PROBE INFO
SENSOR NAME Device name
EDIT NAME
SERIAL NUMBER Device serial number
RANGE 0 to 500 or 0 to 5000
MODEL NUMBER Item no. Sensor
CODE VERSION Sensor software
COUNTER
OPERATING HOURS Operating hours counter
MAINTENANCE Counter counting down days
BULB CHANGE Counter counting down days
TEST/MAINT
SET OUTMODE Equipment output behavior in the SERVICE menu
HOLD
ACTIVE
SET TRANSFER
SIGNALS
LAMP CURR Flash lamp intensity
DIAG/TEST Zero point and slope check with external standards
REDADING OFFSET
CUBE CAL
Password-protected access for the service
4.4.2 SENSOR SETUP (Continued)
SELECT SENSOR (if there is more than one sensor)

20
Operation
4.5 Calibration
4.5.1 Factory calibration
The calibration curve zero point and slope are preset. Retrospective calibration of these
basic settings is generally not required outside of the inspection intervals.
Do regular zero point checks to make sure that impurities or faults are being detected
(refer to section 4.5.3 on page 21).
If the zero signal increases due to the measuring medium components or the installation
conditions, you can compensate for this influence via an offset correction. Carry out a lab
analysis of the sample to do this. If there is no PAH/oil contamination in the measuring
medium, enter the measurement value shown by the device as the offset (refer to section
4.5.4.2 on page 22).
4.5.2 Process calibration/adjustment
The sensor is pre-calibrated with various concentrations of a special calibration standard
in ultra-pure water. These ideal measurement conditions rarely occur in reality. The
measurement values shown are qualitative trend indicators if no adjustment is made to the
on-site measurement conditions.
If you require quantitatively correct measurement values, either a slope adjustment or a
multi-point calibration needs to be carried out. Both of these operations must be carried
out on site using lab analysis data. Basic prerequisites for quantitative measurements are
precise knowledge about the oil type in occurrence and constant measurement conditions,
e.g. in cool water in a heat exchanger. If several oils are present in varying quantities, it is
generally not possible to carry out a quantitative measurement.
If the measurement conditions change, you must check the accuracy of the results again
through lab analyses and make any adjustments where necessary.
The measurement conditions can change in terms of
• Composition of PAH or oil impurities
• Distribution of impurities in water
• Temp
• Measuring medium composition
• Measurement sensor and measurement window
4.5.2.1 Determination of factors and adjustment of slope
To adjust the slope:
1. At the sensor installation site, draw a lab sample of the measuring medium and
promptly analyze the sample for PAH and oil content.
2. Make a note of the measurement value shown on the controller at the time of the
sample being taken. Make sure the correct unit is shown for the measurement value,
e.g. as ppm oil.
3. Repeat steps 1 and 2 several times.
4. Use the sample value and the value shown on the controller at the time of sampling
to calculate a factor.
5. Find an average value from the factors.
