Halma BEA SEAGLE TWO User manual

SEAGLE TWO
1
3
5
4
2
Specifications are subject to changes without prior notice.
Measured in specific conditions
TECHNICAL SPECIFICATIONS
DESCRIPTION
ENGLISH
BIDIRECTIONAL OPENING SENSOR
FOR AUTOMATIC DOORS
1. main connector
2. potentiometer for field size adjustment
3. radar antenna
4. DIP-switch
5. cover
Technology:
Transmitter frequency:
Transmitter radiated power:
Transmitter power density:
Detection mode:
Min. detection speed:
Supply voltage:
Mains frequency:
Max power consumption:
Output:
Max. contact voltage:
Max. contact current:
Max. switching power:
Mounting height:
Degree of protection:
Temperature range:
Dimensions:
Tilt angles:
Material:
Weight:
Cable lenght:
Conformity:
microwave doppler radar
24.150 GHz
< 20 dBm EIRP
< 5 mW/cm²
motion
5 cm/s (measured in sensor axis)
12 V to 24 V AC ±10%; 12 V to 24 V DC +30% / -10%
50 to 60 Hz
< 2 W
relay (free of potential change-over contact)
42 V AC/DC
1 A (resistive)
30 W (DC) / 60 VA (AC)
from 1.8 m to 3 m
IP54
from -20 °C to + 55 °C
120 mm (L) x 80 mm (H) x 50 mm (W)
0° to 90° vertical; -30° to +30° lateral
ABS
120 g
2.5 m
RED 2014/53/EU; 2011/65/EU
Other use of the device is outside the permitted purpose and can not be
guaranteed by the manufacturer. The manufacturer cannot be held responsible
for incorrect installations or inappropriate adjustments of the sensor.
Please keep for further use
Designed for colour printing
For product version 0100 and more
This user’s guide is an informative document and can not be seen as a commitment of result.

Before fixing After fixing
Avoid proximity to neon
lamps or moving objects.
Do not cover the sensor.Avoid vibrations.Do not touch electronical
parts.
Wall mounting above sliding or
revolving doors Ceiling mounting in front of sliding,
revolving or swing doors
(outside of the door motion range)
OPENING THE SENSOR
TIPS
APPLICATIONS

2
23
1
MIN MAX
1
ON
OFF
ADJUSTMENTS
Apply the mounting template.
Drill 1 hole for the cable and
pull it through.
Drill 2 holes for the screws.
Fix the sensor firmly.
ANGLE
2.2 m
2.2 m
Pull the cable through the hole
and connect the wires as follows:
1 - BROWN - POWER SUPPLY
2 - GREEN - POWER SUPPLY
3 - WHITE - COM
4 - YELLOW - NO/NC
FIELD SIZE DIP-SWITCH
DIP 1
NOT USED
DIP 2
OUTPUT CONFIG.
DIP 3
NOT USED
DIP 4
IMMUNITY FILTER
active - NO
passive - NC high
normal
field size: max
vertical angle: 30°
2.2 m 2.2 m
MOUNTING & WIRING

BEA SA | LIEGE Science Park | ALLÉE DES NOISETIERS 5 - 4031 ANGLEUR [BELGIUM] | T [phone] | F [phone] | [email protected] | WWW.BEA-SENSORS.COM
1
1
2
3
4
1
2
1
2
1
3
1
2
©BEA | Original instructions | 42.8149 / V2 - 07.18
BEA hereby declares that the SEAGLE TWO is in conformity with the basic requirements and the
other relevant provisions of the directives 2014/53/EU and 2011/65/EU.
The complete declaration of conformity is available on our website.
TROUBLESHOOTING
The door remains
closed.
The LED is OFF.
The sensor power is off. Check the wiring and the power supply.
The door does not
react as expected.
The door closes and
opens constantly.
Improper output
configuration on the sensor.
The sensor is disturbed by
the closing of the door or
vibrations caused by the
door motion.
The door opens for
no apparent reason.
It rains and the sensor
detects the motion of the
rain drops.
Change the output configuration setting on
each sensor connected to the door operator.
Make sure the sensor is fixed properly.
Increase the antenna angle.
Increase the immunity filter.
Reduce the field size.
Change the antenna angle.
Decrease the field size.
Increase the immunity filter.
Increase the immunity filter.
Install the ORA (rain accessory).
In highly reflective
environments, the sensor
detects objects outside of its
detection field.
In airlock vestibules,
the sensor detects the
movement of
the opposite door.
Change the antenna angle.
Increase the immunity filter.
For EC countries: according to the directive 2012/19/EU for Waste Electrical and Electronic Equipment (WEEE)
