Halma LZR-WIDESCAN User manual

LZR®-WIDESCAN
User’s Guide for software version SW 0400 and higher
(refer to tracking label on product)
* please refer to page 4
OPENING, PRESENCE & SAFETY* SENSOR FOR INDUSTRIAL DOORS
EN
Download the LZR WIDESCAN
installation app!

INSTALLATION & MAINTENANCE
SAFETY
2
INSTALLATION & MAINTENANCE TIPS
SAFETY PRECAUTIONS
Wipe the laser window
with a soft, clean and
damp microfibre cloth. We
recommend using optical lens
cleaner.
Do not use aggressive
products or dry towels to
clean the optical parts.
• The device cannot be used for purposes other than its intended use. All other uses cannot be guaranteed by
the manufacturer of the sensor.
• The manufacturer of the door system is responsible for installing the sensor and the door system in compliance
with applicable national and international regulations.
• The manufacturer of the sensor cannot be held responsible for incorrect installations or inappropriate
adjustments of the sensor.
Only trained and
qualified personnel
may install and setup
the sensor.
The warranty is invalid if
unauthorized repairs are
made or attempted by
unauthorized personnel.
Always test the good
functioning of the
installation before
leaving the premises.
The metal base on
which the sensor is
mounted, must be
correctly earthed.
Avoid extreme
vibrations.
Do not cover
the laser window screens.
Avoid moving objects in
the detection field.
Avoid exposure to
sudden and extreme
temperature changes.
Avoid direct exposure to
high pressure cleaning.
Do not stare directly
into the visible laser
beams.
CAUTION!
Use of controls, adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
The device emits invisible (IR) and visible laser radiations. The visible laser beams can be
activated during the installation process to adjust precisely the position of the detection
field.
The visible laser beams are inactive during normal functioning.
Do not stare directly into the visible laser beams.
Keep the protection film
during the mounting of the
sensor. Remove it before
launching a teach-in.

3
1
11
12
7
13
14
6
9
10
8
2
3
5
4
DESCRIPTION
1. main connector
2. protection film
3. laser window
4. USB cap
5. LED-display
6. cover
7. cover lock
8. cable passage
9. LCD-screen
10. keypad
11. tilt angle adjustment screw (1x)
12. parallel angle adjustment screw (2x)
13. lateral angle lock screw (1x)
14. mounting bracket
The LZR®-Widescan is an industrial door sensor with opening and presence features.

4
H
D
H
L LD
MOTION
BASIC PRINCIPLES: FUNCTIONS & OBJECT
There are 3 main functions that create 3 overlapping detection fields with certain detection characteristics each:
The sensor carries out a 3D-object analysis
and detects depending on the following
characteristics: height, width & depth.
DOOR OPENS IF:
- motion in motion field
- certain object type
- certain direction
DOOR DOES NOT CLOSE IF:
- presence in presence field
- certain object type
DOOR DOES NOT CLOSE IF:
- presence in safety field
* The detection characteristics in this field
increase the comfort of door users and the
protection of equipment. These characteristics
allow for additional safety but the sensor is
not a sensitive protective equipment providing
protection of persons according to safety
standards. For a full featured safety solution,
please look at other option(s) in BEA’s cata-
logue or contact BEA.
PRESENCE
SAFETY *
There are 4 additional functions. All detection functions can be combined to trigger a specific output (see output functions
on page 16).
Motion +: assignation of an other moving object type for the motion field
Virtual pull cord: detection of an object standing still in a learned pull cord zone
Speed: detection of an object moving below a defined speed
Height: presence detection of an object exceeding a defined height

5
12 3
x
x
Motion +: assignation of an other moving object type for the motion field
Virtual pull cord: detection of an object standing still in a learned pull cord zone
Speed: detection of an object moving below a defined speed
Height: presence detection of an object exceeding a defined height
LED flashes LED flashes
slowly
LED is off LED flashes
x times
LED flashes
quickly
LED is on
LED-SIGNAL
Motion detection
Pull cord detection
Presence detection
Safety detection
Before opening the sensor, make
sure the cover is not locked (red
cover lock).
If needed, remove the cover
completely before installing the
sensor.
OPENING THE SENSOR
To open the top cover, pull both
flags while tilting the cover away
from its initial position.
Factory value
Motion
Presence
Safety
Important! Good to know
MAIN FUNCTIONS: ADDITIONAL FUNCTIONS: Motion +
Pullcord
Remote control session
Teach-in status
Troubleshooting
No smartphone connected
Smartphone connected
All fields
Motion field
Pull cord
Presence field
Safety field
Speed
Height
SETTINGS DETECTION GENERAL
SYMBOLS

...
....
..
...
....
..
Password
XX X X
Value Value
More >Diagnostics
Parameter Parameter
2X
.
.
.
x
2x 3x
1x 5x
1x
6
HOW TO ADJUST THE SENSOR BY REMOTE CONTROL
After unlocking, the red
LED flashes and the sensor
can be adjusted by remote
control.
To end an adjustment
session, always lock the
sensor.
If the red LED flashes quickly after unlocking, enter
an access code from 1 to 4 digits. If you do not
know the access code, cut and restore the power
supply. During 1 minute, you can access the
sensor without any code.
If necessary, select first the corresponding detection field before pushing on the parameter and changing the value.
The second LED indicates the detection field.
Activate red spots
Teach-in: install
Teach-in: pull cord
Presettings
Restoring to factory values
MOTION
PRESENCE
SAFETY
Select to return to
previous menu or display.
Select your Language before entering the
first LCD-menu.
During the first 30 seconds after power-on of the
sensor or later in the diagnostics menu.
Enter a Password if necessary.
«Specific» menu password: 1234
Select More to access advanced
adjustments.
Displayed value = saved value
Displayed value = factory value
Scroll up or down the menu
items or values.
Select Diagnostics to go to the
diagnostics menu
Enter the LCD-menu.
Select a folder, parameter or value.
Confirm a value and exit edit mode.
Activate red spots on floor.
Launch CENTRE TOOL for correct
positioning of detection field (see p. 8).
HOW TO ADJUST THE SENSOR BY LCD
PULL CORD
SHORT
LONG
= field width: 2.35 m
x = number of flashes = value of the parameter

7
COM
NO
NC
INSTALL
5
RD
BK
YE
YE
PK
PK
BU
BU
GN-GREY
OK
1
2
GN
WH-GN
TEST
Unscrew the angle lock screw if necessary.
Position the sensor on the mounting bracket
and turn as shown to click into place.
Plug the connector and pass the cable through the
cable passage without making a loop.
Connect the wires.
**The output functions can be configured if necessary, see p. 16.
* Ouput status when in non detection.
Mounting height: as high as possible in acc. to the limitations in the Technical specifications
The size of the detection field depends on the mounting height.
Mounting position:centre of door or upper left corner.
Mounting on the right side of the door should be avoided.
Push OK to return to
detection display.
POWER
OUT 2**
OUT 1**
REL AY**
INSTALLATION STEPS
Teach-in reminder
MOUNTING & WIRING
The UNIVERSAL MOUNTING BRACKET can be used if the environment requires it.
1a
Screw the mounting bracket on the wall. You can
also install the sensor directly without using the
mounting bracket.
*
*
*

PH 2 / PZ 2
1
2
12
L
OK
OK
OK
12
34
56
OK
POSITIONING OF DETECTION FIELD
1b
8
1. Slightly spread the cover and clip it horizontally.
2. Close the cover. Lock the cover by turning the lock screw clockwise.
CLOSING THE SENSOR
1c
Make sure the curtain is parallel to the door by
adjusting one or both screws on the side. Position the curtain closer to or further away
from the door by turning the screw at the top.
Push OK to confirm.
Look at the CENTER-TOOL on the LCD display.
Rotate the sensor until both arrows on the LCD screen are aligned.
The visible spots must now be off-center for the detection
field to cover the whole door symmetrically !
Carefully lock the sensor position by firmly
fastening the angle lock screw. Make sure the
red spots have not moved.
Push OK to exit and deactivate the visible spots.
First of all, remove the blue protection film from the laser window.
Rotate the sensor in order to align the centre of
the red spots with the centre of the door.
Push long on OK to enter the CENTRE-TOOL
and activate the visible spots.
If the sensor is mounted in the center of the door, follow steps and to adjust the field.
If the sensor is mounted on the left (or right side*), follow all steps described on this page.
* Note that right side mounting could alter the performance of the motion detection
PARALLEL ANGLE
TILT ANGLELATERAL ANGLE
AWAYAWAY
CLOSERCLOSER
LONG
31 4 6
LCD DISPLAY
LCD DISPLAY LCD DISPLAY

9
5
H
H
H
5 s 10 s
REL
REL
Masking
REL
OUT1
OUT2
OUT1
OUT2
OUT1
OUT2
CORNER
CORRIDOR
STANDARD
- confined space
- traffic from and to all directions
- no storage
- corner
- no parallel traffic
- storage right and/or left
(Bold = differs from factory settings)
Choose one of the following presettings. They adjust a number of parameters automatically according to your application.
If necessary, you can also adjust a parameter independently via remote control (see p. 10).
PRESETTINGS
- Make sure the blue protection film is removed and the sensor is closed!
- Make sure the laser window is free from dust and/or water drops.
- The teach-in zone (square in front of the 2 visible spots) must be empty and even. If not, see troubleshooting.
- This teach-in must be launched each time a sensor’s position/orientation has been changed.
Wait while position, angle and height
are learned and the background is
analysed.
TEACH-IN: INSTALL
field width: max, field stop: max
object type: vehicle
direction: uni CTR
field width: max, field stop: 2 m
object type: vehicle
max presence time: infinite
field width: max, field stop: max
object type: vehicle
direction: uni
field width: max, field stop: 3 m
object type: vehicle
max presence time: 30 min
motion or pull cord or
safety
presence or safety
speed trigger
motion or pull cord or
presence
presence or safety
presence + height
Launch a teach-in
by remote control.
The teach-in is
finished. If not ok
see troubleshoo-
ting.
The teach-in starts after 5 seconds.
The teach-in zone must be empty
and even!
3
2
field width: max, field stop: 0.4 m
(infinite detection for objects > 25 cm)
field width: max, field stop: 0.4m
(infinite detection for objects > 25 cm)
- open space
- traffic from and to all
directions
- storage right and/or left
field width: max, field stop: max
object type: vehicle
direction: uni CTR +
field width: max, field stop: 3 m
object type: vehicle
max presence time: 30 min
field width: max, field stop: 0.4 m
(infinite detection for objects > 25 cm)
motion or pull cord
presence or safety
presence + height

0 1 2 3 4 5 6 7 8 9
-
123 4
...
000 - 999 cm 999 cm
-000 - 999 cm 999 cm
-000 - 999 cm 000 cm
..
....
123
-000 - 999 cm 999 cm
-000 - 999 cm 040 cm
-000 - 999 cm 999 cm
-000 - 999 cm 300 cm
123 4
-000 - 999 cm 000 cm
30 s 1 min 2 min 5 min 10 min 30 min 60 min 120 min infinite
.
44 5
0 s 1 s 2 s 3 s 4 s 5 s 6 s 7 s 8 s
# 1 # 2 # 3
stop
any uni
away
45
10
OVERVIEW OF REMOTE CONTROL SETTINGS (OPTIONAL)
Teach-in
Presettings
Service Mode
Factory Reset
Red spots
install
full partial
full: complete reset of all values
partial: reset of all values except IN/OUT
The service mode deactivates the presence and safety detection during 15 minutes and can be useful during an installation,
a mechanical teach-in of the door or maintenance work. Exit the service mode by using the same sequence.
STD cornercorridor
MOTION
Field width
Field depth (stop)
Field start
Object type
Direction
Immunity
PULL CORD
Teach-in
Object type
Min. presence time
vehicle any
vehicle XL (WH): detects large vehicles; rejects bicycles & narrow forklifts
vehicle: detects all types of vehicles; rejects pedestrians
any: detects all objects
PRESENCE
Field width
Field depth (stop)
Field start
Object type
Immunity
Max presence time
SAFETY
Field width
Field depth (stop)
Immunity
vehicle
XL (WH)
vehicle any
vehicle
XL (WH)
vehicle
XL (WH) vehicle any
pedes-
trian
pedestrian: detects
pedestrians only
vehicle XL (WH): detects
large vehicles; rejects
bicycles & narrow forklifts
vehicle: detects all
types of vehicles; rejects
pedestrians
any: detects all objects
Activates the red spots on the floor. The spots stay active during 15 minutes or can be switched off the same way.
CTR: cross traffic rejection
INV: inverted
uni
CTR
uni
CTR+
vehicle XL (WH): detects large vehicles; rejects bicycles & narrow forklifts
vehicle: detects all types of vehicles; rejects pedestrians
any: detects all objects
DOOR
DOOR
The max. reachable
dimensions will
automatically adapt acc.
to mounting conditions
000 cm = red spots’
position
DOOR
The max. reachable
dimensions will
automatically adapt acc.
to mounting conditions
000 cm = red spots’
position
The max. reachable
dimensions will
automatically adapt acc.
to mounting conditions
