Hama 00054836 User manual

GB
Operating Instructions
Digital Radio
Digital Radio
00054836
(DIR3600MBT)

Technical Data
Radio Receiver DAB
ü
DAB+
ü
FM
ü
Internet
ü
Spotify
ü
Connectivity LAN (10/100), WiFi (b/g/n), USB (Play & Charge 5V 1A), Bluetooth Standard (4.0)
Display 3.2“ (8.13 cm) Colour TFT
Encryption WEP, WPA, WPA2, WPS
Speaker 3" 40 W RMS (2x 20 W)
Subwoofer 4" 30 W RMS
Impedance 6 Ohm
Speaker
75 Ohm
Antenna
Power input 110-240 V ~ 50-60Hz
Frequency range DAB/DAB+:
174-240 MHz
FM:
87.5-108 MHz
Sensitivity DAB/DAB+:
-97 ~ 99 dBm
FM:
-105 ~ 109 dBm
Power consumption Operation max. 90 W Standby
< 2 W (network standby)
< 1 W (non network mode)
Input & Output Line OUT, AUX IN, 3.5mm Earphone Jack, RJ45, Optical Out, USB
Presets DAB/DAB+:
30
FM:
30
Internet:
30
Spotify Connect:
10
Codec
IR:
MP3, WMA,
ADTS, MPEG-
DASH
UPNP:
MP3, WMA, v9/ASF,
M4A, ADTS, WAV,
LPCM, FLAC, ALAC
DAB:
MP2, AAC
USB Stick:
MMP3, WMA, M4A,
ADTS, FLAC, WAV
UI Languages English, German, Danish, Dutch, Finnish, French, Italian, Norwegian, Polish, Portuguese,
Spanish, Swedish,Turkish, Czech, Slovak
Package Content DIR3600MBT, Power Cord, Remote Control, Batteries, Short Manual, Telescope Antenna
Dimension (WxHxD) 380 x 255 x 155 mm
Weight 5800 g

11
2
20
13 14
15 17 19
16 18
12
4 6 9
357
81 10

25
6
10
16
14
17
20
22
27
3
7
15
11
19
21
25
26
1
2
18
45
23
9
13
24
8
12

1
GOperating Instructions
Controls and Displays
A: Front
1[VOLUME/
POWER]
Rotate: Volume control
Press: On/off switch
2[ ] Direct access to the menu
3[ ] List/save favourites
4[ ] Display additional information
5[ ]
Changing operating mode
(Internet radio, Spotify
Connect, Music player, Aux in)
6[ ] Home
7[ ] Back one menu level
8[ENTER/
NAVIGATE]
Rotate: Select
Press: Conrm
9LED
10 Infrared receiver
11 2.8“ Colour TFT
B: Rear
12 Mains power supply
13 LED-switch (ON/OFF)
14 LAN connection
15 AUX IN socket
16 Headphone socket
17 LINE OUT socket
18 Optical output
19 USB connection
20 Antenna*
Note
* This radio has a changeable antenna. You can use
an active or passive antenna equipped with a coaxial
connetion.

2
C: Remote Control
1[ ] On/off switch
≙Press [volume -/+]/ [ ]
2[ ] Mute
3[IR] Direct access to operating
mode Internet radio ≙[mode]
4[DAB] Direct access to operating
mode DAB≙[mode]
5[FM] Direct access to operating
mode FM ≙[mode]
6[AUX] Direct access to operating
mode Aux in ≙[mode]
7[ ] Backlight settings
8[MEDIA] Direct access to operating
mode Music player ≙[mode]
9[MODE]
Changing operating mode
(Internet radio, Spotify
Connect, Music player, Aux
in) ≙[mode]
10 [ ] Equaliser settings
11 [ALARM] Direct access to alarm clock
settings ≙[alarm]
12 [SLEEP] Snooze settings
13 [SNOOZE] Activating Snooze
14 [MENU] Direct access to the menu
≙[menu]
15 [I◄◄ ]
previous track (operating
mode: Spotify Connect,
Music player)
16 [►►I ]
next track (operating
mode: Spotify Connect,
Music player)
17 Navigation
keys
▲Up /▼Down /
◄Back one menu level
≙[back] /
►Forward/ Confirm
≙Press [enter/navigate]/[OK]
18 [OK] Conrm ≙Press
[enter/navigate]
19 [◄◄]
Rewind (operating
mode: Spotify Connect,
Music player)
20 [►► ]
Fast forward (operating
mode: Spotify Connect,
Music player)
21 Volume keys
[+]/[-]
Volume control ≙Rotate
[volume -/+]/ [ ]
22 Favourite keys
[+]/[-] Selection from favourites list
23 [ ]
Start/ Stop playback
(operating mode:
Spotify Connect,
Music player, Aux in)
24 [ ] Back one menu level ≙[back]
25 Number keys Direct access to favourites/
Save favourites
26 [FAVORITES] List/save favourites
27 [INFO] Display additional
information ≙[info]

3
Contents
1. Explanation of Warning Symbols and Notes ...........8
2. Package Contents ................................8
3. Safety Notes ....................................8
4. Informations and notes before getting started .........9
4.1 LAN connection (wired network) .......................9
4.2 WLAN connection (wireless network) ....................9
5. Getting started ..................................9
5.1 Remote Control ....................................9
5.2 Radio – Connecting and starting up.....................9
5.3. General notes on use ..............................10
5.4 Initial setup ......................................11
6. Main menu / modes..............................12
7. Internet radio ..................................13
7.1 Station search ....................................13
7.1.1 Search by country or region.......................13
7.1.2 Search by Genre ...............................13
7.1.3Searchbyname................................14
7.1.4 Popular stations ...............................14
7.1.5 New stations..................................14
7.1.6 Local stations .................................14
7.2 Podcasts ........................................15
7.2.1 Search by country or region.......................15
7.2.2 Search by format (subjects or categories) .............15
7.2.3Searchbyname................................15
7.3 Last listened .....................................15
7.4 Favourites (local) ..................................15
7.4.1 Save favourites ................................16
7.4.2 Access favourites...............................16
7.4.3 Management of favourites with the remote control .....16
7.5 Favourites (vTuner - http://www.wiradio-frontier.com) .....17
7.5.1 First use – Registering your radio...................17
7.5.2 Managing favourites online
(vTuner - http://www.wiradio-frontier.com) ...............17
7.5.3 Opening the favourites list........................17
7.5.4 My Added Stations .............................18
8. Spotify ........................................18
9. Music player (UPNP, USB) .........................19
9.1 Playback from external storage media (USB)..............19
9.2 Playback from a computer (streaming) ..................20
9.3 Playback from the network –
Accessing les using the radio ...........................20
9.4 Playback of Playlist ................................21
9.5 General playback options............................21
10. DAB .........................................22
10.1 Search/ Automatic search...........................22
10.2 Manual station search .............................22
10.3 Station list .....................................23
10.4 Sort station list ..................................23
10.5 Edit station list...................................23
10.6 Presets ........................................23
10.6.1 Save favourites ...............................23
10.6.2 Access favourites..............................24
10.6.3 Management of favourites with the remote control ....24
10.7 DRC (Dynamic Range Control) .......................24
11. FM ..........................................25
11.1 Scan setting.....................................25
11.2 Automatic station search ...........................25
11.3 Manual station search .............................25
11.4 Presets ........................................25
11.4.1 Save favourites ...............................25
11.4.2 Access favourites..............................26
11.4.3 Management of favourites with the remote control ....26
11.5 Audio setting....................................26
12. Auxiliary Input.................................26
13. Bluetooth.....................................27
13.1 BIuetooth pairing.................................27
13.2 Automatic Bluetooth connection
(after successful pairing) ...............................28
13.3 Terminate Bluetooth connection......................28
14. Sleep ........................................28
15. Alarms .......................................29
15.1 Alarm settings ...................................29
15.2 Activating/ deactivating the alarm ....................29
15.3 Stopping the alarm/ Snooze function ..................30
16. System settings ................................30
16.1 Equaliser .......................................30
16.2 Network .......................................31
16.2.1 Network wizard –
Conguration of internet connection / Automatic search ......31
16.2.2 Wireless network connection (WLAN) ..............31
16.2.3 Wired network connection (LAN) ..................32
16.2.4 Manual conguration of network connection –
wireless (WLAN) and wired (LAN) .......................32
16.2.5Viewsettings.................................33
16.2.6 Network prole ...............................34
16.2.7 Keep network connected ........................34

4
16.3 Time/ Date......................................34
16.4 Language ......................................35
16.5 Factory Reset....................................35
16.6 Software update .................................36
16.7 Setup wizard ....................................36
16.8 Info ...........................................36
16.9 Backlight.......................................37
16.10 AUX: Auto-Standby ..............................37
17. UNDOK – everything in the palm of your hand .......37
17.1 Interface/layout of the UNDOK home screen.............38
17.2 First-time setup of the device with UNDOK..............38
17.2.1 Procedure for iOS users .........................38
17.2.2 Procedure for Android users .....................39
17.3 General control of a device or group ..................39
17.4 Creating/managing multi-room groups.................40
17.5 Multi-room setup on the radio .......................41
17.5.1 General information ...........................41
17.5.2 Creating a group..............................41
17.5.3 View details .................................41
17.5.4 Add clients to a group..........................41
17.5.5 List current clients .............................41
17.5.6 Leave group .................................41
17.5.7 Delete group.................................41
17.6 Settings and standby ..............................42
17.7 Additional functions (music player / Spotify) .............42
18. Care and Maintenance ..........................42
19. Warranty Disclaimer ............................42
20. Service and Support ............................43
21. Recycling Information
Note on environmental protection: ...................43
22. Declaration of Conformity........................43

5
MAIN MENU*
INTERNET RADIO
Last listened
Station list
My favourites
Local stations
Stations
Countries
Genre
Search for
stations
Popular stations
New stations
Podcasts
Countries
Codec
Search podcasts
My Added Stations
Help
Getting the
access code
FAQ
System settings
Main menu
SPOTIFY
System settings
Main menu
MUSIC PLAYER
Shared media
USB playback
Playlist
Repeat
Shue
Clear playlist
Prune servers
System settings
Main menu
DAB
Station list
Full scan
Manual tune
Reset invalid
DRC
DRC high
DRC low
DRC off
Station order
Alphanumeric
Ensemble
Valid
Slide Show
Picture / text
Full screen
System settings
Main menu
Menu structure

6
FM
Search setting
Audio setting
System settings
Main menu
AUXILIARY INPUT
System settings
Main menu
BLUETOOTH
Terminate connection
System settings**
Main menu*
SLEEP
ALARMS
Alarms 1
Alarms 2
SYSTEM SETTINGS**
Equaliser
Normal
Medium
Jazz
Rock
Soundtrack
Klassik
Pop
News
My EQ
My EQ prole setup
Bass
Treble
Network
Network wizard
PBC WLAN setup
View settings
Manual settings
Wired
Wireless
NetRemote PIN Setup
Network prole
Keep network connected
Time/ Date
Set Time/ Date
Auto update
Update from DAB
Update from FM
Update from Network
No update
Set format
Set timezone
summer-/wintertime
Language
Factory Reset
Software update
Auto update
Start a check for updates
