HAMPTON BAY L-DNC1418PST-A User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this Glider. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
FLINTRIDGE METAL GLIDER
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item #1003535 856
Model #L-DNC1418PST-A

2
Table of Contents
Table of Contents ................................... 2
Important Safety Instructions
....................... 2
What is covered ...................................2
What is not covered ................................2
Warranty..........................................2
Pre-Installation
. ....................................3
Planning Installation ...............................3
Installation
.........................................
Care and Cleaning
Important Safety Instructions
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this furnishing is used by or
near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the chaise lounge chair while it is occupied. Failure
to obey this caution could result in injury.
DANGER: Keep children and parts away from the
assembly area.
WARNING: Do not leave the gazebo where there is a
risk of high wind, as possible damage will occur to the
structure.
CAUTION: Do NOT over tighten any of bolts or nuts.
NOTE: For outdoor use only.
WARNING: To avoid destroying the finish ,please handle
the surface by using a soft cloth instead of your bare
hands.Due to the nature of iron,surface oxidation(rusting)
will occur once these protective coatings are scratched.We
recommend immediate touch-up with rust inhibiting
paint(not included).
Warranty
2 YEAR WARRANTY
WHAT IS COVERED
This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your item provided the
item is maintained with care and used only for personal, residential purposes. The item is warranted to be free from defects in material or
workmanship for a period of 2 years.
WHAT IS NOT COVERED
We do not reimburse for transportation of delivery costs, or compensate the individual or any outside party for assembling or
disassembling the product.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit HAMPTONBAY.COM.
5
..................................7

3 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Installation
PLANNING INSTALLATION
Before beginning assembly of this product, make sure all parts are present. Compare parts with the Hardware Included and Package
Contents lists. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
AA BB CC DD
EE FF GG HH II
JJ
Hex wrench
AA
BB
CC
DD
EE
FF
GG
HH
II
JJ
Bolt M6*15
Bolt M6*30
Bolt M6*40

4
Pre-Installation (continued)
PACKAGE CONTENTS
AB1 B2C
D1 D2 EF
（ ）
（ ）
（ ）
（ ）

5
Installation
1Connecting the Back and Handrail
DANGER: To avoid destroying the finish, do not put the
parts on the ground directly.
Attach the Handrail (B1&B2) to the Back (A) using the bolts (CC), spring
washers (DD) and flat washers (EE) with the hex wrench (GG). Do not tighten
the bolts.
2Connecting the Handrail and Seat
DANGER: To avoid destroying the finish, do not put the
parts on the ground directly.
Connect the Handrail (B1&B2) with the Seat Insert a space (C) using the bolts
(BB), spring washers (DD) and flat washers (EE) with the hex wrench (GG). Do
not tighten the bolts.
3Connecting the Handrail and Glide bar
DANGER: To avoid destroying the finish, do not put the
parts on the ground directly.
Connect the Handrail (B1&B2) with the Glider Bar (E) using the bolts (BB),
flat washers (EE) and plastic washer (FF) with the hex wrench (GG). Do not
tighten the bolts.
4Connecting the Leg and Connect bar
DANGER: To avoid destroying the finish, do not put the
parts on the ground directly.
Attach the Legs (D1&D2) to the Connect bar (F) using the bolts (AA), spring
washers (DD) and flat washers (EE) with the hex wrench (GG). Do not tighten
the bolts.

6
Installation (continued)
5Connecting the Leg and Connect bar
DANGER: To avoid destroying the finish, do not put the
parts on the ground directly.
6Connecting the Glide bar and Leg
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.
Attach the Legs (D1&D2) to the Connect bar (F) using the bolts (AA), spring
washers (DD) and flat washers (EE) with the hex wrench (GG). Do not tighten
the bolts.
Connect the Glider bar (E) with the Legs (D1&D2) using the bolts (BB), spring
flat washers (EE) and plastic washer (FF) with the hex wrench (GG). Tighten
all the bolts using wrench (GG).

7
Care and Cleaning
□Before using, clean the glider completely with a soft dry towel.
□Do not put your glider in wet conditions where there is a risk of rust developing.
□When not in use, store in a cool, dry area.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
