Harbor Breeze CEDAR HILL User manual

Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-527-1292, 8:30 a.m.-5 p.m., CST, Monday-Friday.
ITEM #0312114
MODEL #E-PEN44BCW5MC
CEDAR HILL CEILING FAN
español p. 20
Harbor Breeze® is a registered trademark
of LF, LLC.All Rights Reserved.
E206035
Federal regulations require all ceiling fans with light kits manufactured
or imported after January 1, 2009, to limit total wattage consumed by the
light kit to 190W. Therefore, this fan is equipped with a wattage limiting
device.
1

2
TABLE OF CONTENTS
Safety Information ....…………………………………………………………………………...……..….3
Package Contents ........…………………………………………………………………..……..…..…..4
Hardware Contants ........................................................................................................................5
Preparation .........….…………………..……………………….…………….………………....6
Initial Installation ...............……………………...………………………………….............6 - 7
Downrod Style Fan Mounting ...…………………………....……………....……..........................8 - 9
Closemount Style Fan Mounting ……………………...............…....……………………....9 - 10
Wiring ..............................................................................………………………..............10 - 12
Final Installation ………….…………….……………………….………….....…....................12 - 15
Fan Operation ..............................................................………………………………...15 - 16
Care and Maintenance ....……………………………………………………………….......................16
Troubleshooting .....................………...………………………….……………..………...........17 - 18
Warranty ………………………………….…………………………………………..……..............18
Replacement Parts List ...............................................................................................................19

3
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
Please read and understand this entire manual before attempting to assemble, install or operate
the product. If you have any questions regarding the product, please call customer service at
1-800-527-1292, 8:30 a.m.-5:00 p.m., CST, Monday-Friday.
1. Before you begin installing the fan, disconnect the power by removing fuses or turning off
circuit breakers
.
2. CAUTION: Read all instructions and safety information before installing your new fan.
Review the accompanying assembly diagrams.
3.
CAUTION: To avoid personal injury, the use of gloves may be necessary while
handling fan parts with sharp edges.
4. Make sure that all electrical connections comply with local codes, ordinances, the National
Electrical Code and ANSI/NFPA 70-1999. Hire a qualified electrician or consult a
do-it-yourself wiring handbook, available at Lowe's, if you are unfamiliar with installing
electrical wiring.
5. Make sure the installation site you choose allows a minimum clearance of 7 feet from the
blades to the floor and at least 30 in. from the end of the blades to any obstruction.
6. WARNING: To reduce the risk of fire, electrical shock, or personal injury, mount fan to
outlet box marked "ACCEPTABLE FOR FAN SUPPORT" and use mounting screws provided
with the outlet box. Most outlet boxes commonly used for the support of lighting fixtures are
not acceptable for fan support and may need to be replaced. Consult a qualified electrician if
in doubt. Secure the box directly to the building structure. The outlet box and its support must
be able to support the moving weight of the fan (at least 35 lbs.). Do NOT use a plastic outlet
box.
7. After you install the fan, make sure that all connections are secure to prevent the fan from
falling.
8. WARNING: To reduce the risk of fire, electrical shock, or personal injury, wire
connectors provided with this fan are designed to accept only one 12 gauge house wire and
two lead wires from the fan. If your house wire is larger than 12 gauge or there is more than
one house wire to connect to the two fan lead wires, consult an electrician for the proper size
wire connectors to use.
9. WARNING: To reduce the risk of fire or electric shock, do not use the fan with
any solid state speed control device or control fan speed with a full range dimmer
switch.
10. WARNING: To reduce the risk of fire, electric shock, or personal injury, do not bend
the blade arms when installing them, balancing the blades, or cleaning the fan. Do not insert
objects between the rotating fan blades.
11. WARNING: To reduce the risk of personal injury, use only parts provided with this
fan. The use of parts OTHER than those provided with this fan will void the warranty.
12. The net weight of this fan including the light kit is: 16.31 lbs. (7.4 kg).

4
AC
I
H
F
G
D E
B
J
K
L M
N O
PACKAGE CONTENTS
Part Description Quantity
A Downrod 1
B Canopy 1
C Mounting Bracket(pre-attached to canopy) 1
D Yoke Cover 1
E Motor Housing 1
F Switch Housing Cap(pre-attached to motor housing) 1
G Glass Shade 1
H Blade Arm 5
I Blade 5
J Pull Chain Extension (in hardware pack) 2
K Light Kit Fitter 1
L Finial Plate (pre-attached to light kit fitter) 1
M Finial (pre-attached to light kit fitter)
1
N Candelabra Base Bulb 3
O Canopy Cover (pre-attached to canopy) 1
IMPORTANT REMINDER: You must use
the parts provided with this fan for proper
installation and safety.

5
JJ
LL
KK
HARDWARE CONTENTS
Part Description Quantity Part Shown to Size
Motor Screw (10 in motor; 1 in hardware pack) 11
3/16 Blade Screw (in hardware pack) 16
5.4M/M Lock Washer (10 in motor; 11
1 attached to motor screw in hardware pack)
Blade Washer (in hardware pack) 16
E3 Wire Connector (in hardware pack) 4
Canopy Mounting Screw 4
(attached to mounting bracket)
Pin (in downrod) 1
Clip (attached to pin) 1
Hex Nut (pre-attached to light kit fitter) 1
Lock Washer (pre-attached to light kit fitter) 1
3/16 x 11 mm Screw (in hardware pack) 3
5 mm Lock Washer (in hardware pack) 3
AA
GG
II
BB
CC
DD
EE
FF
HH

1. Turn off circuit breakers and wall switch to the fan supply
line leads. (Fig. 1)
DANGER: Failure to disconnect power supply prior
to installation may result in serious injury or death.
6
A
B
Fig. 1
Fig. 2
2. Determine mounting method to use. (Fig. 2)
A. Downrod mount (normal or angled ceiling)
B. Closemount (normal ceiling only)
Important: If using the angle mount, check to make sure
the ceiling angle is not steeper than 19°.
INITIAL INSTALLATION
PREPARATION
1. Before beginning assembly, installation or operation of product, make sure all parts are
present. Compare parts with package contents list and diagram above. If any part is missing or
damaged, do not attempt to assemble, install or operate the product.
Estimated Assembly Time: 120 minutes
Tools Required for Assembly (not included):
electrical Phillips pliers safety stepladder wire
tape screwdriver glasses strippers
Helpful Tools (not included):
A/C tester tape do-it-yourself wiring handbook
light measure (available at Lowe’s) wire cutters
Bulbs Required (included):
3 candelabra base
60 watt max. bulbs
DANGER: When using an existing outlet box, make sure the outlet box is securely
attached to the building structure and can support the full weight of the fan. Failure to do this can
result in serious injury or death. The stability of the outlet box is essential in minimizing wobble
and noise in the fan after installation is complete.
CAUTION: Be sure outlet box is properly grounded and that a ground (green or bare) wire
is present.
2. After opening top of carton, remove mounting hardware package from foam inserts. Remove
motor from packing and place on carpet or on foam to avoid damage to finish.
CAUTION: Carefully check all screws, bolts and nuts on fan motor assembly to ensure that
they are secured.
A-15

Canopy Mounting Screw x 4
INITIAL INSTALLATION
4. Loosen canopy mounting screws (FF) in
slotted holes in canopy (B) and remove the
other two screws (FF)--save screws (FF) for
later use. Remove mounting bracket (C) from
canopy (B). (Fig. 4A) Secure mounting bracket
(C) to outlet box using screws, spring washers,
and flat washers provided with the outlet box.
(Fig. 4B)
*Note: It is very important that you use the
proper hardware when installing the mounting
bracket (C) as this will support the fan.
Important: If using the angle mount, make
sure open end of mounting bracket (C) is
installed facing the higher point of the ceiling.
5. Remove motor screws (AA) and lock washers
(CC) from underside of motor and save for blade
arm (H) attachment later on. [If there are plastic
motor blocks installed with the motor screws (AA)
and lock washers (CC), discard the plastic motor
blocks.] (Fig. 5)
Follow mounting instructions on page 8 and or 9
depending on mounting method (A or B) chosen in
Step 2 on previous page.
Fig. 5
Fig. 4A
C
Fig. 4B
C
C
B
FF FF
AA
CC
E
CC
AA
FF
Hardware Used
Motor Screw x 10
Hardware Used
5.4 M/M Lock Washer x 10
7
3. Check to make sure blades (I) are at least 30 in. from
any obstruction and at least 7 ft. above the floor. (Fig. 3) Fig. 3
7 ft.
min.
30 in.
min.
I

DOWNROD STYLE FAN MOUNTING
3. Slip downrod (A) into motor housing yoke, align holes
and re-install pin (GG) and clip (HH). Re-tighten set
screws in motor housing yoke and then tighten nuts.
Slide yoke cover (D) down until it rests on top of motor
housing (E). (Fig. 3)
2. Insert downrod (A) through canopy (B) and
yoke cover (D). Thread wires from motor
housing (E) through downrod (A). (Fig. 2)
Fig. 2
Fig. 3
Set Screw
A
A
HH
GG
D
B
D
E
GG
HH
Hardware Used
Pin x 1
Clip x 1
1. Remove pin (GG) and clip (HH) from
downrod (A). (Fig. 1A) Partially loosen set
screws in motor housing yoke at top of motor
housing (E). (Fig. 1B)
*Helpful Hint: Downrod style mounting is
best suited for ceilings 8 ft. (2.44 m) high or
higher. For taller ceilings you may want to use
a longer downrod (not included) than the one
provided. Angle style mounting is best suited
for angled or vaulted ceilings. A longer
downrod is sometimes necessary to ensure
proper blade clearance.
Set
Screw
Fig. 1A Fig. 1B
A
E
GG
HH
A
GG
HH
Hardware Used
Pin x 1
Clip x 1
8

4. Depending on the length of downrod (A) you use, you
may need to cut the lead wires back to simplify the wiring.
If you decide to cut back the lead wires, it is suggested
that you do so in the following manner:
Take the lead wires and make sure that you have pulled
them all the way through the top of the downrod (A). Start
at the TOP of the ball on the downrod (A) and measure 8
in. of lead wire, and then cut the excess wire off with wire
cutters. (Fig. 4)
Note: If you did not cut back the lead wires, Steps 4 and
5 are not necessary and you may proceed to Step 6
instead.
6. Install ball end of downrod (A) into mounting
bracket (C) opening. Align slot in ball with tab in
mounting bracket (C). (Fig. 6)
DANGER: Failure to align slot in ball with
tab may result in serious injury or death.
Continue to "Wiring" instructions on page 10.
Fig. 6
Hanging
Ball Slot
1. Remove canopy cover (O) from bottom of canopy (B).
(Fig. 1) [Note: It may be necessary to use the handle end of
a screwdriver to remove the canopy cover (O) by tapping
on the canopy cover (O) from the inside of the canopy (B).]
*Helpful Hint: Close style mounting is more suitable for
ceilings lower than 8 ft. (2.44 m) high. The downrod (A),
hanging ball, yoke cover (D), and canopy cover (O) are not
used in this type of installation.
Fig. 1
CLOSEMOUNT STYLE FAN MOUNTING
A
B
C
B
O
Tab
Ball
DOWNROD STYLE FAN MOUNTING
9
5. If you decided to cut back the lead wires in Step 4, strip
1/2 of an inch of insulation from end of white wire. Twist
stripped ends of each strand of wire within the insulation
with pliers. (Fig. 5) Repeat Step 5 for black, blue (if
applicable) and green wires.
Fig. 5
Fig. 4
Ball
A
E

WIRING
10
WARNING: To reduce the risk of fire, electrical
shock, or personal injury, wire connectors provided
with this fan are designed to accept only one 12 gauge
house wire and two lead wires from the fan. If your
house wire is larger than 12 gauge or there is more
than one house wire to connect to the two fan lead
wires, consult an electrician for the proper size wire
connectors to use.
CAUTION: Be sure outlet box is properly
grounded and that a ground (green or bare) wire is
present.
WARNING: If house wires are different colors
than referred to in the following steps, stop immediately.
A professional electrician is recommended to determine
wiring.
2. Pull wires through hole in the middle of the canopy
(B) and attach canopy (B) to motor housing (E) using
the three screws (KK) and three lock washers (LL)
provided. (Fig. 2)
3. Hang motor housing (E) on the tab on the
mounting bracket (C) using one of the non-slotted
holes in the canopy (B). (Fig. 3)
E
B
Fig. 2
Fig. 3
C
E
Tab
E
Hardware Used
KK
LL
KK
LL
3/16 X 11 mm Screw x 3
5 mm Lock Washer x 3
CLOSEMOUNT STYLE FAN MOUNTING
