Harbor Breeze PLM52CB5D User manual

ITEM #0295011
BAJA CEILING FAN
Questions, problems, missing parts? Before returning to your retailer, call or contact our customer
service department at 1-800-527-1292, 8:30 a.m.- 5:00 p.m., CST, Monday - Friday.
Harbor Breeze® is a registered trademark
of LF, LLC. All Rights Reserved.
Español p. 17
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
1
MODEL #PLM52CB5D
E206035
FOR DAMP LOCATIONS

TABLE OF CONTENTS
Safety Information ………………………………………………………...……..…...............2 - 3
Package Contents ……………………………………………………..……..…..…..................4
Hardware Contents ..................
.... ........................................................................................ ......... 5
Preparation ....….…………………..……………………….…………….……………............5
Initial Installation .........……………………...………………………………………
…. ......6 - 7
Normal or Angle Style Fan Mounting .......……………………………………………………........7 - 8
Wiring ....................…………………….............................................………
….. ............9 - 10
Final Installation …………….……………………….…………….……..............
.….. ..........10 - 12
Operation Instructions ..............................…………………………....................................13
Care and Maintenance ……………………………………………………………..……………........14
Troubleshooting .....………...………………………….……………..……
…. ... …... ...................14
Warranty ……………………………….…………………………………………..…..................15
Replacement Parts List .......................................................................................................
.... 16
2
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
Please read and understand this entire manual before attempting to assemble, install or operate the
product. If you have any questions regarding the product, please call customer service at
1-800-527-1292, 8:30 a.m. - 5:00 p.m., CST, Monday - Friday.
• Do not discard fan carton or foam inserts. Should this fan need to be returned to the factory for
repairs, it must be shipped in its original packaging to ensure proper protection against damage that
might exceed the initial cause for return.
• Make sure that all electrical connections comply with local codes, ordinances, the National Electrical
Code and ANSI/NFPA70-1999. Hire a qualified electrician or consult a do-it-yourself wiring handbook,
available at Lowe's, if you are unfamiliar with installing electrical wiring.
• Make sure the installation site you choose allows a minimum clearance of 7 feet from the blades to
the floor and at least 30 in. from the end of the blades to any obstruction.
• After you install the fan, make sure that all connections are secure to prevent the fan from falling.
• The net weight of this fan is: 22.05 lbs. (10 kg).

3
To reduce the risk of fire, electrical shock, or personal injury, mount fan to an outlet box
marked "ACCEPTABLE FOR FAN SUPPORT" and use mounting screws provided with
the outlet box. Most outlet boxes commonly used for the support of lighting fixtures are
not acceptable for fan support and may need to be replaced. Consult a qualified electrician if in
doubt. Secure the outlet box directly to the building structure. The outlet box and its support must
be able to support the moving weight of the fan (at least 35 lbs.). Do NOT use a plastic outlet box.
To avoid personal injury, the use of gloves may be necessary while handling fan parts with
sharp edges.
To reduce the risk of fire, electrical shock, or personal injury, wire connectors provided with this
fan are designed to accept only one 12 gauge house wire and two lead wires from the fan. If your
house wire is larger than 12 gauge or there is more than one house wire to connect to the two fan
lead wires, consult an electrician for the proper size wire connectors to use.
To reduce the risk of fire or electrical shock, do not use the fan with any solid state speed
control device or control fan speed with a full range dimmer switch.
To reduce the risk of fire, electrical shock, or personal injury, do not bend the blade arms when
installing them, balancing the blades, or cleaning the fan. Do not insert objects between the
rotating fan blades.
To reduce the risk of personal injury, use only parts provided with this fan. The use of parts
OTHER than those provided with this fan will void the warranty.
WARNINGS
CAUTIONS
Before proceeding, be sure to shut off electricity at main switch or circuit breaker in order to avoid
electrical shock.
Read all instructions and safety information before installing your new fan. Review the
accompanying assembly diagrams.
SAFETY INFORMATION
DANGER
If using this fan in a DAMP location, this fan must be connected to a supply circuit that is protected
by a Ground Fault Circuit Interrupter (GFCI) to reduce the risk of personal injury, electrical shock
or death.

4
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
PART DESCRIPTION QUANTITY
J Motor Screw 10
(preassembled)
K Lock Washer 10
(preassembled)
L
Canopy Mounting Screw 2
(preassembled)
M Pin (preassembled) 1
N
Clip (preassembled) 1
O Pull Chain Extension 1
P Blade Arm 5
Q Blade Arm Screw 15
(preassembled)
PART DESCRIPTION QUANTITY
A Downrod 2
B
Canopy 1
C
Mounting Bracket 1
D
Motor Housing 1
E Switch Housing 1
F Yoke Cover
1
G* Plastic Locking Mechanism
5
H Blade 5
I Canopy Cover 1
*US Pat. No. 7351037
PACKAGE CONTENTS
A
E
D
B
F
C
H
G
O
K
M
L
J
I
P
N
Q
*

HARDWARE CONTENTS (shown actual size)
AA
E3 Wire
Connector
Qty. 4
5
Before beginning assembly and installation of product, make sure all parts are present. Compare
parts with package contents list and hardware contents above. If any part is missing or
damaged, do not attempt to assemble, the product. Contact customer service for replacement parts.
Estimated Assembly Time: 120 minutes
Tools Required for Assembly (not included): Electrical Tape, Phillips Screwdriver, Pliers, Safety
Glasses, Stepladder and Wire Strippers
Helpful Tools (not included): AC Tester Light, Tape Measure, Do-It-Yourself Wiring Handbook
(available at Lowe’s) and Wire Cutters
DANGER: When using an existing outlet box, make sure the outlet box is securely attached to
the building structure and can support the full weight of the fan. Failure to do this can result in serious
injury or death. The stability of the outlet box is essential in minimizing wobble and noise in the fan
after installation is complete.
CAUTION: Be sure outlet box is properly grounded and that a ground wire (green or bare) is
present.
After opening top of carton, remove mounting hardware package from foam inserts. Remove motor
from packing and place on carpet or on foam to avoid damage to finish.
CAUTION: Carefully check all screws, bolts and nuts on fan motor assembly to ensure that they
are secured.
PREPARATION

INITIAL INSTALLATION
1
ON
OFF
ON
OFF
Turn off circuit breakers and wall switch to the fan
supply line leads. (Fig. 1)
DANGER: Failure to disconnect power supply
prior to installation may result in serious injury or
death.
1.
Determine mounting method to use. (Fig. 2)
A. Normal mount
B. Angle mount
Important: If using the angle mount, check to
make sure the ceiling angle is not steeper than 19°.
A
B
2. 2
Check to make sure blades (H) are at least 30 in.
from any obstruction. Check downrod (A) length to
ensure blades (H) are at least 7 ft. above the floor.
(Fig. 3)
3H
3.
4
C
Secure mounting bracket (C) to outlet box using
screws, spring washers, and flat washers
provided with the outlet box. (Fig. 4)
*NOTE: It is very important that you use the
proper hardware when installing the mounting
bracket (C) as this will support the fan.
IMPORTANT: If using the angle mount, make
sure open end of mounting bracket (C) is installed
facing the higher point of the ceiling.
4.
7 ft.
min.
30 in.
min.
6

Slip downrod (A) into housing yoke, align holes and
re-install pin (M) and clip (N). Tighten downrod set
screws and then tighten nuts. Slide yoke cover (F)
down until it rests on top of motor housing (D). (Fig. 3)
Choose downrod (A) length you wish to use.* If you
choose to use the 12 in. downrod (A), remove
hanging ball from the 6 in. downrod (A) and attach to
the 12 in. downrod (A). Insert downrod (A) through
canopy (B), canopy cover (I), and yoke cover (F).
(Fig. 2). [Note: Canopy cover (I) must be turned with
the shiny side toward the motor housing (D).] Thread
wires from motor housing (D) through downrod (A).
INITIAL INSTALLATION
5
5.
J
K
D
Remove motor screws (J) and lock washers (K)
from underside of motor and save for bade arm
(P) attachment later on. [If there are plastic motor
blocks installed with the motor screws (J) and
lock washers (K), discard the plastic motor
blocks.] (Fig. 5)
FAN MOUNTING
2
I
B
F
Hanging
Ball
2.
Set
Screw
M
F
3
D
N
A
3.
7
M
N
A
D
Remove pin (M) and clip (N) from downrod (A). (Fig. 1A)
Partially loosen set screws in motor housing yoke at top
of motor housing (D). (Fig. 1B)
*Helpful Hint: Downrod style mounting is best suited for
ceilings 8 ft. (2.44 m) high or higher. For taller ceilings
you may want to use a longer downrod (sold separately)
than the ones provided. Angle style mounting is best
suited for angled or vaulted ceilings. A longer downrod
is sometimes necessary to ensure proper blade
clearance.
Set
Screw
1. 1A 1B

8
Install ball end of downrod (A) into mounting
bracket (C) opening. Align slot in ball with tab in
mounting bracket (C). (Fig. 6)
DANGER: Failure to align slot in ball with tab
may result in serious injury or death.
6.
BBHanging
Ball Slot
A
6
Ball Tab
C
If you decided to cut back the lead wires in Step 3,
strip 1/2 of an inch of insulation from end of white
wire. Twist stripped ends of each strand of wire
within the insulation with pliers. (Fig. 5) Repeat
Step 4 for black, blue (if applicable) and green
wires.
5
5.
Depending on the length of downrod (A) you use,
you may need to cut the lead wires back to
simplify the wiring. If you decide to cut back the
lead wires, it is suggested that you do so in the
following manner:
Take the lead wires and make sure that you have
pulled them all the way through the top of the
downrod (A). Start at the TOP of the ball on the
downrod (A) and measure 8 in. of lead wire, and
then cut the excess wire off with wire cutters.
(Fig. 4)
NOTE: If you do not cut back the lead wires,
Steps 4 and 5 are not necessary and you may
proceed to Step 6 instead.
4.
Ball
A
D
4
FAN MOUNTING

9
WIRING
WARNING: To reduce the risk of fire,
electrical shock, or personal injury, wire connectors
provided with this fan are designed to accept only
one 12 gauge house wire and two lead wires from
the fan. If your house wire is larger than 12 gauge
or there is more than one house wire to connect to
the two fan lead wires, consult an electrician for the
proper size wire connectors to use.
CAUTION: Be sure outlet box is properly
grounded and that a ground (green or bare) wire is
present.
WARNING: If house wires are different colors
than referred to in the following steps, stop
immediately. A professional electrician is
recommended to determine wiring.
For each wire connection below, use one of the wire
connectors (AA) provided, making sure to screw
wire connector (AA) on in a clockwise direction.
Connect BLACK and BLUE wire from fan to
BLACK wire from ceiling. Connect WHITE wire
from fan to WHITE wire from ceiling. Connect all
GROUND (GREEN) wires together from fan (on
downrod and mounting bracket) to BARE/GREEN
wire from ceiling. (Fig. 1)
1.
FAN CONTROLLED BY PULL CHAINS
BLACK
WHITE
GROUND/GREEN (BARE)
WHITE
BLUE
WHITE
FROM FAN
120 V Power
FROM
CEILING
FAN
GREEN
BLACK
GREEN
DANGER: If using this fan in a DAMP location,
this fan must be connected to a supply circuit that is
protected by a Ground Fault Circuit Interrupter
(GFCI) to reduce the risk of personal injury,
electrical shock or death.
1
Note: Black wire is hot power for fan. Blue wire is
hot power for light kit. White wire is common for fan
and light kit. Green or bare wire is ground.

10
WIRING
Wrap electrical tape around each individual wire
connector (AA) down to the wire as shown in Fig. 2.
WARNING: Make sure no bare wire or wire
strands are visible after making connections. Place
green and white connections on opposite side of box
from the black and blue (if applicable) connections.
Turn spliced/taped wires upward and gently push
wires and wire connectors (AA) into outlet box.
IMPORTANT: Using a full range dimmer switch to
control fan speed will cause a loud humming noise
from fan. To reduce the risk of fire or electrical
shock, do NOT use a full range dimmer switch to
control fan speed. (Fig. 3)
AA AA
2AA
AA E3 Wire Connector x4
3
1
2
3
Dimmer
Switch Speed
Switch
For illustrative purposes only--not
intended to cover all types of controls
2.
Hardware Used
3.
FINAL INSTALLATION
B
L
I
A
1. Locate two canopy mounting screws (L) on
underside of mounting bracket (C) and remove
canopy mounting screw (L) closest to the open end
of the mounting bracket (C). Partially loosen the
other canopy mounting screw (L). Lift canopy (B) to
mounting bracket (C). Place rounded part of slotted
hole in canopy (B) over loosened canopy mounting
screw (L) in mounting bracket (C) and push up.
Twist canopy (B) to lock. Re-insert canopy
mounting screw (L) that was removed, and then
tighten both canopy mounting screws (L). Slide
canopy cover (I) up to canopy (B). Press up gently
but firmly on canopy cover (I) until you hear it snap
onto the bottom of the canopy (B). (Fig. 1)
1

Locate motor screws (J) and lock washer (K) that
were removed in Step 5 on page 7.
Insert only one motor screw (J), with lock
washer (K), through blade arm (P) to attach
blade arm (P) to motor and partially tighten
motor screw (J). (Fig. 4) Repeat with remaining
blade arms (P).
FINAL INSTALLATION
Align the three blade arm screws (Q), pre-installed
on the blade arm (P), with the three holes on the
blade (H). Press up on the blade arm (P) firmly so
that the blade arm screws (Q) come through the
holes in the blade (H). Be careful not to use so
much force that the blade arm (P) bends. (Fig. 2)
Repeat for each blade arm (P).
2.
Q
P
H
2G
Place the plastic locking mechanism (G) on the
opposite side of the blade (H) as the blade arm
(P), with the shorter end toward the end of the
blade (H) and against the blade arm screw (Q)
on the end as shown in Fig. 3. Rotate plastic
locking mechanism (G) counterclockwise to lock
plastic locking mechanism (G) into place. Repeat
for each blade (H).
3.
Q
P
H
3
G
4.
J
P
4
K
H
11
Insert remaining motor screws (J) with lock
washers (K). (Fig. 5) Repeat with remaining blade
arms (P). Tighten all motor screws (J) securely.
5.
D
J
K
P
5
H
P

Align holes in switch housing (E) with holes in
fitter plate. Re-insert screws that were removed in
the previous step and tighten all screws securely.
(Fig. 7)
Attach pull chain extension (O) supplied in
one of the hardware packs or custom pull
chain extension (sold separately) to fan pull
chain. (Fig. 8)
NOTE: This fan is remote control adaptable
(remote control sold separately). Any remote
control used with this fan MUST be
UL-approved for DAMP LOCATIONS.
Remove three screws from fitter plate on
underside of motor housing (D). Connect male
plug from motor housing (D) to female plug from
switch housing (E). (Fig. 6) Make sure plugs
connect tightly.
Fitter
Plate
Female
Plug
Male Plug
FINAL INSTALLATION
D
D
E
E
6
D
7
Fitter
Plate
E
8
O
8.
7.
6.
12

13
OPERATION INSTRUCTIONS
The pull chain located on the switch housing has
four positions to control fan speed. One pull is
HIGH, two is MEDIUM, three is LOW and four turns
the fan OFF. (Fig. 1)
1.
2.
2C
2A 2B
Switch
Housing
1
Switch
Housing
2
Use the fan reverse switch, located on the switch
housing (B), to optimize your fan for seasonal
performance. (Fig. 2) A ceiling fan will allow you
to raise your thermostat setting in summer and
lower your thermostat setting in winter without
feeling a difference in your comfort.
Note: Wait for fan to stop before moving the
reverse switch.
2A. In warmer weather, setting the
reverse switch to the LEFT will result in
downward airflow creating a wind chill
effect. (Fig. 2A)
2B. In cooler weather, setting the reverse
switch to the RIGHT will result in upward
airflow that can help move stagnant, hot air
off the ceiling area.(Fig. 2B)
IMPORTANT: Reverse switch must be set either
completely to the RIGHT or completely to the
LEFT for fan to function. If the reverse switch is
set in the middle position (Fig. 2C), fan will not
operate.

Fan does not move. 1. Reverse switch not engaged. 1. Push switch firmly either way.
2. Power is off or fuse is blown. 2. Turn power on or check fuse.
3. Faulty wire connection. 3. Turn power off. Loosen canopy
(B) and check all connections.
4. Plugs not connected properly. 4. Check that male and female
plugs in switch housing (E) are
connected properly according to
instructions on page 12.
Noisy operation. 1. Blades (H) are loose. 1. Check to be sure plastic locking
mechanisms (G) are secure.
2. Cracked blade (H). 2. Replace blade (H).
3. Unapproved speed control. 3. Replace with an approved
speed control device.
Excessive wobbling. 1. Blades (H) are loose. 1. Check to be sure plastic locking
mechanisms (G) are secure.
2. Blade arms (P) incorrectly 2. Re-install blade arms (P).
installed.
3. Unbalanced blades (H). 3. Switch one blade (H) with a
blade (H)from the opposite side.
4. Fan not securely mounted. 4. Turn power off. Carefully loosen
canopy (B) and verify that
mountingbracket (C) is secure.
5. Fan too close to vaulted ceiling. 5. Use a longer downrod (A) or
move fanto another location.
6. Set screw(s) on motor housing 6. Tighten yoke set screw(s)
yoke is (are) not tightened securely.
properly.
7. Set screw on hanging ball is not 7. Carefully loosen and lower
tightened properly. canopy (B) and verify that set
screw on hanging ball is tightened
securely.
14
Note: A small amount of "wobble" is normal and should not be considered a defect.
TROUBLESHOOTING
If you have any questions regarding the product please call customer service at 1-800-527-1292, 8:30
a.m. - 5 p.m., CST, Monday - Friday.
Warning: Before beginning work, shut off the power supply to avoid electrical shock.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
At least twice each year, lower canopy (B) to check downrod (A) assembly, and then tighten all
screws on the fan. Clean motor housing (D) with only a soft brush or lint-free cloth to avoid
scratching the finish. Clean blades (H) with a lint-free cloth. You may occasionally apply a light coat
of furniture polish to wood blades for added protection.
Important: Shut off main power supply before beginning any maintenance. Do not use water or a
damp cloth to clean the ceiling fan.
CARE AND MAINTENANCE

15
WARRANTY
LIMITED LIFETIME WARRANTY: Litex Industries warrants this fan to be free from defects in
workmanship and materials present at time of shipment from the factory for Lifetime limited from
the date of purchase. This warranty applies only to the original purchaser. Litex Industries
agrees to correct any defect at no charge or, at our option, replace the ceiling fan with a
comparable or superior model.
To obtain warranty service, present a copy of your sales receipt as proof of purchase. All cost of
removal and reinstallation are the express responsibility of the purchaser. Any damage to the
ceiling fan by accident, misuse or improper installation, or by using parts not produced by the
manufacturer of this fan or affixing accessories not produced by the manufacturer of this fan, are
the purchaser's own responsibility. Litex Industries assumes no responsibility whatsoever for fan
installation during the limited lifetime warranty. Any service performed by an unauthorized
person will render the warranty invalid.
Due to varying climatic conditions, this warranty does not cover changes in brass finish, rusting,
pitting, tarnishing, corroding or peeling. Brass finish fans maintain their beauty when protected
from varying weather conditions. Any glass provided with this fan is not covered by the
warranty.
Any replacement of defective parts for the ceiling fan must be reported within the first year from
the date of purchase. For the balance of the warranty, call our customer service department (at
1-800-527-1292) for return authorization and shipping instructions so that we may repair or
replace the ceiling fan. Any fan or parts returned improperly packaged is/are the sole
responsibility of the purchaser. There is no further express warranty. Litex Industries disclaims
any and all implied warranties. The duration of any implied warranty which cannot be disclaimed
is limited to the limited lifetime period as specified in our warranty. Litex Industries shall not be
liable for incidental, consequential or special damages arising at or in connection with product
use or performance except as may otherwise be accorded by law. This warranty gives you
specific legal rights and you may also have other rights which vary from state to state. This
warranty supersedes all prior warranties.

A Downrod
B
Canopy
C
Mounting Bracket
E Switch Housing
F Yoke Cover
G Plastic Locking Mechanism
H Blade
I Canopy Cover
J
Motor Screw
K
Lock Washer
L
Canopy Mounting Screw
M
Pin
N
Clip
O Pull Chain Extension
P Blade Arm
Q Blade Arm Screw
AA E3 Wire Connector
A
E
B
F
C
H
G
IJ
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-800-527-1292, 8:30 a.m. - 5:00
p.m., CST, Monday - Friday. When ordering parts, please have the Model # or Item # of the fan
available, which can be found on page 1.
K
AA
N
M
L
Printed in China
16
PQ
O
PART DESCRIPTION

ARTICULO #0295011
MODELO #PLM52CB5D
Harbor Breeze® es marca registrada de LF,
LLC. Reservados todos los derechos.
VENTILADOR DE TECHO BAJA
17
E206035
¿Preguntas, problemas, faltan piezas? Antes de regresar a la tienda, llame o póngase en
contacto con nuestro departamento de servicio al cliente al 1-800-527-1292, de 8:30 a.m. a
5:00 p.m., hora central, de lunes a viernes.
ADJUNTE SU RECIBO AQUI
Número de serie Fecha de compra REGISTRADO PARA
LUGARES HUMEDOS

Información de seguridad .................................................................................................18 - 19
Contenido del paquete ........................................................................................................
..... 20
Contenido de artículos de ferretería ..........................................................................................21
Preparación ..................….…………………..……………………….…………….….........….21
Instalación inicial ........................……………………………………………………………...22 - 23
Montaje del ventilador .............................................……....................................................23 - 24
Conexión de los cables .…………………………………………………...…..........................25 - 26
Instalación final ..………………….……...…….……...............…….....................
.... 27 - 29
Instrucciones de funcionamiento .......................…………………………………........29 - 30
Cuidado y mantenimiento …………………………………………..………….......................30
Localización de fallas ..…………………………………..………....…................................
... 31
Garantía …………………………….………………………………………….………
................ ... 32
Lista de piezas de repustos ......................................................................................................33
18
INDICE DE MATERIAS
POR FAVOR LEA Y GUARDE ESTAS INSTRUCCIONES
Por favor lea el instructivo entero antes de tratar de ensamblar, instalar o hacer funcionar el producto.
Si tiene alguna pregunta acerca del producto, por favor llame al servicio al cliente al 1-800-527-1292,
de 8:30 a.m. a 5:00 p.m., hora central, de lunes a viernes.
• No deseche la caja del ventilador ni la goma espuma incluida. Si hay que mandar el ventilador a la
fábrica por alguna reparación, se debe enviar en su paquete original para asegurar la protección
apropiada contra daños que podrían exceder la causa inicial por la cual se devolvió.
• Asegúrese de que todas las conexiones eléctricas cumplen con los códigos y las ordenanzas
locales, con el Código Nacional Eléctrico (NEC, por sus siglas en inglés), y ANSI/NFPA 70-1999.
Contrate un electricista calificado o consulte una guía de instalación eléctrica de hágalo usted mismo,
disponible en Lowe's, si no está familiarizado con la instalación eléctrica.
• Asegúrese de que el lugar de instalación que usted escogió tiene un mínimo de 2,13 m de desde las
paletas hasta el piso y que la punta de las paletas quede a por lo menos 76,2 cm de cualquier
obstrucción.
• Después de instalar el ventilador, verifique que todas las conexiones estén seguras para que no se
caiga el ventilador.
• El peso neto del ventilador con el juego de luz es de: 10 kg.
INFORMACION DE SEGURIDAD

Antes de proseguir, desconecte la electricidad, quitando los fusibles o cortando el suministro de
energía de los circuitos para evitar un choque eléctrico.
Lea todas las instrucciones y la información de seguridad antes de instalar su ventilador nuevo.
Revise los diagramas de ensamblaje acompañantes.
Para reducir el riesgo de incendio, choque eléctrico o daño corporal, sujete el ventilador
a una caja de salida marcada "Aceptable para sostener ventilador" ("ACCEPTABLE FOR
FAN SUPPORT" en inglés) y use los tornillos de montaje proporcionados con la caja de
salida. La mayoría de las cajas de salida que se usan comúnmente para sostener aparatos de
alumbrado no son aceptables para sostener ventiladores y es posible que sea necesario
reemplazarla. Consulte con un electricista calificado si tiene alguna duda. Asegure la caja de
salida directamente a la estructura del edificio. La caja de salida y el soporte deben ser capaces
de sostener el peso móvil del ventilador (por lo menos 15,88 kg). NO use una caja de salida
plástica.
Para reducir el riesgo de daño corporal, es posible que sea necesario usar guantes al manejar
las piezas del ventilador que tengan bordes afilados.
Para reducir el riesgo de incendio, choque eléctrico o daño corporal, los conectores para cable
provistos con este ventilador son diseñados para aceptar sólo un cable de calibre 12 de la casa y
dos cables principales del ventilador. Si el calibre del cable de la casa es superior al 12 o hay
más de un cable de la casa para conectar a los cables principales del ventilador, consulte con un
electricista para informarse sobre el tamaño correcto de conectores para cable que se debe usar.
Para reducir el riesgo de incendio o un choque eléctrico, no use el ventilador con ningún
control de velocidad de estado sólido ni controle la velocidad del ventilador con un
interruptor con reductor de luz de gama completa.
Para reducir el riesgo de incendio, choque eléctrico o lesión personal, no doble brazos de las
paletas mientras las esté instalando, ni cuando esté balanceando las paletas ni cuando esté
limpiando el ventilador. No inserte objetos entre las paletas giratorias del ventilador.
Para reducir el riesgo de lesión personal, use sólo las piezas provistas con este ventilador. Al
usar piezas DISTINTAS a las provistas con este ventilador se invalidará la garantía.
ADVERTENCIAS
PRECAUCIONES
INFORMACION DE SEGURIDAD
PELIGRO
Si va a utilizar este ventilador en un lugar HUMEDO, hay que conectar el ventilador a uncircuito de
alimentación que esté protegido por un Interruptor de Circuito de Falla de Tierra (GFCI,por sus
siglas en inglés) para reducir el riesgo de daño corporal, descarga eléctrica o la muerte.
19

20
A
E
D
B
F
C
H
G
O
K
M
L
J
I
P
N
Q
CONTENIDO DEL PAQUETE
*Pat. No. 7351037 de EUA
RECORDATORIO IMPORTANTE: Se
tienen que utilizar las piezas provistas con
este ventilador para una instalación
adecuada y su seguridad.
PIEZA DESCRIPCION CANTIDAD
J Tornillo del motor 10
(preensamblado)
K
Arandela del motor 10
(preensamblada)
L
Tornillo para montaje de la 2
cubierta (preensamblado)
M Clavija (preassemblada) 1
N
Sujetador (preensamblado) 1
O Extensión para la cadena 1
de encendido
P Brazo para la paleta 5
Q Tornillo para el brazo de 15
paleta (preensamblado)
PIEZA DESCRIPCION CANTIDAD
A Vástago 2
B
Cubierta 1
C
Soporte de montaje 1
D
Bastidor del motor 1
E Caja del interruptor 1
F Cubierta del yugo 1
G* Mecanismo de seguridad 5
de plástico
H
Paleta 5
I Decoración para la cubierta 1
*
