HBM C2 Series User manual

Force transducer
C2
Mounting Instructions
Electrical
measurement
of mechanical
quantities
HBM Mess- und Systemtechnik GmbH
B 20.C2.10 e
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:[phone] FAX:[phone] E-MAIL:[email protected]
SUNSTAR自动化 http://www.sensor-ic.com/ TEL: [phone] FAX:[phone] E-MAIL:[email protected]

SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:[phone] FAX:[phone] E-MAIL:[email protected]
SUNSTAR自动化 http://www.sensor-ic.com/ TEL: [phone] FAX:[phone] E-MAIL:[email protected]

3
C2
Content Page
Safety instructions 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 Scope of supply 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Applicationnotes 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Structure and mode of operation 8. . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Measuring body 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Disturbance variables and their compensation 8. . . . . . . . . . . . . . . . . .
4 Conditionson site 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 Ambient temperature 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Moisture 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 Air pressure 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.4 Chemical effects 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Mechanicalinstallation 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1 Important measures for installation 10. . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2 General installation guidelines 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3 Mounting accessories 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 Electrical connection 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.1 Instructions for cabling 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.2 Wiring pin assignment 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7 Specifications 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Dimensions 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 Declaration of conformity 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:[phone] FAX:[phone] E-MAIL:[email protected]
SUNSTAR自动化 http://www.sensor-ic.com/ TEL: [phone] FAX:[phone] E-MAIL:[email protected]

4C2
Safety instructions
Use in accordance with the regulations
Force transducers of the C2 type are designed for force measurements in test
rigs/presses/test devices/testing machines. Use for any additional purpose
shall be deemed to be not in accordance with the regulations.
In the interests of safety, the transducer should only be operated as described
in the Mounting Instructions. It is also essential to observe the appropriate
legal and safety regulations for the application concerned during use. The
same applies to the use of accessories.
The transducer is not a safety element within the meaning of its use as
intended. Proper and safe operation of this transducer requires proper
transportation, correct storage, assembly and mounting and careful operation
and maintenance.
General dangers due to non–observance of the safety instructions
The C2 force transducer corresponds to the state of the art and is fail–safe.
The transducers can give rise to residual dangers if they are inappropriately
installed and operated by untrained personnel.
Everyone involved with the installation, commissioning, maintenance or repair
of a force transducer must have read and understood the Mounting
Instructions and in particular the technical safety instructions.
Residual dangers
The scope of supply and performance of the transducer covers only a small
area of force measurement technique. In addition, equipment planners,
installers and operators should plan, implement and respond to the safety
engineering considerations of force measurement technique in such a way as
to minimise residual dangers. Prevailing regulations must be complied with at
all times. There must be reference to the residual dangers connected with
force measurement technique.
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:[phone] FAX:[phone] E-MAIL:[email protected]
SUNSTAR自动化 http://www.sensor-ic.com/ TEL: [phone] FAX:[phone] E-MAIL:[email protected]

5
C2
In these mounting instructions residual dangers are pointed out using the
following symbols:
Symbol: DANGER
Meaning: Highest level of danger
Warns of a directly dangerous situation in which failure to comply with safety
requirements will lead to death or serious physical injury.
Symbol: WARNING
Meaning: Possibly dangerous situation
Warns of a potentially dangerous situation in which failure to comply with
safety requirements can lead to death or serious physical injury.
Symbol: ATTENTION
Meaning: Possibly dangerous situation
Warns of a potentially dangerous situation in which failure to comply with
safety requirements could lead to damage to property, slight or moderate
physical injury.
Symbol: NOTE
Refers to the fact that important information is being given about the product
or its use.
Symbol:
Meaning: CE mark
The CE mark signals a guarantee by the manufacturer that his product meets
the requirements of the relevant EC directives (see Declaration of conformity
at the end of this document).
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:[phone] FAX:[phone] E-MAIL:[email protected]
SUNSTAR自动化 http://www.sensor-ic.com/ TEL: [phone] FAX:[phone] E-MAIL:[email protected]

6C2
Prohibition of own conversions and modifications
The transducer must not be modified from the design or safety engineering
point of view except with our express agreement. Any modification shall
exclude all liability on our part for any damage resulting therefrom.
Qualified personnel
These transducers are only to be installed by qualified personnel strictly in
accordance with the specifications and with the safety rules and regulations
which follow. It is also essential to observe the appropriate legal and safety
regulations for the application concerned. The same applies to the use of
accessories.
Qualified personnel means persons entrusted with the installation, fitting,
commissioning and operation of the product who possess the appropriate
qualifications for their function.
Conditions on site
Protect the transducer from damp and weather influences such as rain, snow,
etc.
Maintenance
The C2 force transducer is maintenance free.
Accident prevention
Although the specified nominal force in the destructive range is several times
the full scale value, the relevant accident prevention regulations from the
trade associations must be taken into consideration.
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:[phone] FAX:[phone] E-MAIL:[email protected]
SUNSTAR自动化 http://www.sensor-ic.com/ TEL: [phone] FAX:[phone] E-MAIL:[email protected]

7
C2
1 Scope of supply
•C2 force transducer
•C2 Operating Manual
Accessories (not included in the scope of supply)
•EPO3/EPO3R thrust piece mounting accessory
for 500N...10kN: Order no. 1–EPO3/200KG
20kN, 50kN: Order no. 1–EPO3R/5t
100kN, 200kN: Order no. 1–EPO3R/20t
500kN: Order no. 1–EPO3/50t
Options
•Operating temperature range extended to 120 oC
•Degree of protection IP68
