HealthyAir Source Capture HA-SSC-G4-AE User manual

Source Capture®
Aerosol Extractor
HA-SSC-G4-AE
Owner's Manual
Table of Contents
HealthyAir® Series 1213 Filters
1
Important Safety Instructions
2
Technical Specifications
3
Packaging Reference
4
Packaging Notice
5
Component Reference
6
Assembly Instructions
7-10
Operation Guidelines
11-12
Filter Replacement
13-15
Maintenance
16
Basic Service and Troubleshooting
17-21
Electrical Wiring Schematic
22
1-Yeart Limited Warranty
23
Product Registration Form
24
Healthy Air Inc.
800-259-2535
www.HealthyAir.com

1
HealthyAir® Model HA-SSC-G4-AE
Source Capture Aerosol Extractor
with
HealthyAir® Series 1213 Filters
HealthyAir®
Pre-Filter
HealthyAir®
eHEPA® Filter
HealthyAir®
Activated Carbon Filter

2
WARNING
Unplug the power cord before servicing or replacing filters. Failure
to do so could result in serious personal injury and death.
I. Important Safety Instructions
Read the Owner's Manual and Important Safety Instructions carefully. Failure to
follow these instructions could cause a malfunction of the filter or unsatisfactory
performance. Follow a regular service and maintenance schedule for efficient
operation.
To reduce the risk of electric shock, fires, and/or injury:
• Do not use the air purifier in wet or damp locations
• Do not use outdoors
• Do not use at ambient temperature of above 95°F/35°C
• Do not use fabrics or other material to cover the inlet and outlet of the unit
• Do not allow children to operate or play with the unit
For safety reasons and to prevent electric shock, unplug the power cord from the
electric outlet socket under the following conditions:
• When not in use for a long period of time
• When cleaning, servicing the machine or during replacement of filters
• When moving the air purifier
To prevent electric shock, do not dismantle, repair or modify this product.
Maintenance and cleaning instructions should be followed exactly as directed in
this manual. In case of malfunction, please contact an authorized distributor or
Healthy Air Inc. for service instructions.
To reduce the risk of electric shock, the equipment has a grounding type plug
that has a third (grounding) pin. This plug will only fit into a grounding type power
outlet. If the plug does not fit into the outlet, contact qualified personnel to install
the proper outlet. Do not alter the plug in any way.
To reduce the risk of electric shock, do not pull the cord to remove the plug from
its outlets. Protect the cord against heat, oil and sharp objects. Do not run any
appliance over the cord. Do not pull or carry by the cord, use cord as a handle,
close a door on the cord, or pull cord around sharp edges or corners.

3
II. Technical Specifications
Model Number
HA-SSC-G4-AE-W/B
Rated Voltage
120V/60HZ
Power Consumption
200W
Weight
48 lbs. (22 kg)
Base Dimensions
16x14x20 in (40×35×51 cm)
Flex Hose Length
5 ft. (1.52 m)
Air Flow Rate
200 cfm (325 m3/h)
Noise Level
56 dB

4
III. Packaging Reference
The Source Capture Air Purification System is shipped in two (2) cartons, as
follows:
Carton 1: (1) Air Purification Unit w/ (3) Filters, (4) Wheel Casters, (1)
Remote Control, (1) Power Cord, (1) Screwdriver, (1) Manual
Carton 2: (1) Flex Hose w/ Hood, (1) Inlet Tube, (1) Hose Clamp

5
IV. Packaging Notice
NOTICE
Before operating the machine, do the following:
1. Open the Access Door
2. Remove the HEPA and Activated Carbon Filter
3. Remove the plastic wrapping from the filter!
4. Re-install the HEPA and Activated Carbon Filter
5. Replace and secure the Access Door
Remove plastics wrapping
from Activated Carbon
Filter prior to use!
Access
Door
Activated
Carbon Filter

6
V. Component Reference
18. Flex Hose
19. Hood
20. Display Panel
21. Main PCB
22. Power Cord
23. Plastic Screw
24. Spring
25. Remote Control
9. eHEPA Filter
10. eGrid
11. Pre-Filter
12. LED Cable Plug
13. HV PCB
14. Capacitor
15. PCB
16. Inlet Tube
17. Hose Clamp
1. Outer Frame
2. Blower/Motor
3. Base Plate
4. Caster Wheels
5. Motor Mounting Plate
6. Baffle Plate
7. Activated carbon
8. Ground Screen

7
VI. Assembly Instructions
6.1 Install Wheel Casters
6.1.1 Place the unit on its side on a flat surface, as shown in Fig. 1.
6.1.2 Locate the four (4) Caster Wheels and the Screwdriver that are
provided in Carton 1.
6.1.3 Unscrew and remove the screws that are pre-mounted onto the
Base Plate on the bottom of the unit. There are four (4) screws
per wheel, for a total of sixteen (16) screws.
6.1.4 Align the holes of the Caster Wheel Mount with the holes on the
Base Plate and use four (4) screws to securely mount each
Caster Wheel to the Base Plate one by one.
6.1.5 After the four wheels are installed, stand the unit up and proceed
to install the hose assembly.
Fig. 1 – Caster Wheel Installation

8
VI. Assembly Instructions
6.2 Install Inlet Tube
6.2.1 Unscrew and remove the six (6) M5x16 screws that are pre-
mounted around the 4” Ø cutout on the top of the unit, as shown
in Fig. 2.
6.2.2 Position the Inlet Tube on top of the unit, such that the tube aligns
with the 4” Ø cutout and the hole pattern at the base of the Inlet
Tube aligns with the hole pattern on the main unit.
6.2.3 Secure the Inlet Tube to the unit, as shown in Fig. 2, by screwing
in the six (6) M5x16 screws.
Fig. 2 – Inlet Tube Installation

9
VI. Assembly Instructions
6.3 Install Flex Hose
The Flex Hose is constructed of interlocking bands that enable its length
and shape to be adjusted. Note that, the Flex Hose will unravel if it is
lengthened or bent past its tolerance point. The diameter of the Flex Hose
can be also slightly adjusted by twisting the hose.
6.3.1 Install the Flex Hose on the unit by sliding the end of the Flex
Hose over the top of the Inlet Port.
If the diameter of the Flex Hose needs to be increased, rotate the
end of the hose counterclockwise.
6.3.2 Hold the end of the Flex Hose and rotate it clockwise, to reduce
its diameter, to fit it to the diameter of the Inlet Port.
6.3.3 Position the Hose Clamp at the base of the Flex Hose and screw
the hex nut to tighten the Hose Clamp and secure the Flex Hose
on the Inlet Port.
Fig. 3 – Flex Hose Installation

10
VI. Assembly Instructions
6.4 Unwrap and Reinstall Filters
6.4.1 Open and remove the Access Door, located on the Back Panel of
the unit, by unscrewing the two (2) Thumb Screws. When opening
the Access Door for the first time, some force may be required to
pry open and break the seal.
6.4.2 Remove the HEPA and Activated Carbon Filter from the unit.
6.4.3 Remove the plastic wrapping from the HEPA and Activated
Carbon Filter.
6.4.4 Place the HEPA and Activated Carbon Filter back into the unit,
making sure that the filters are reinserted with the side with the
white pull tabs facing out.
6.4.5 Replace the Access Door, ensuring that the panel is properly
inserted into its track, and screw in the two (2) Thumb Screws to
secure the panel.
Fig. 4 – Unwrapping HEPA and Activated Carbon Filter
Remove plastics wrapping
from HEPA and Activated
Carbon Filter prior to use!

11
VII. Operation Guidelines
7.1 Source Capture System Positioning
Place the HealthyAir® Source Capture Aerosol Extractor in the desired
location and adjust the Flex Hose to position the Hood approximately 6”
from the source.
7.2 Source Capture System Activation
7.2.1 Plug the Power Cord into the Power Socket, located on the
bottom of the side panel of the unit, and then plug the other end of
the cord into a wall power socket.
Once plugged in, the Power indicator light [ ] will turn on and
display a red light.
7.2.2 Activate the unit by pressing the Power button located on the
Control Panel, shown in Fig. 6, or on the Remote Control.
Once the unit is powered, the motor will start with the Fan Speed
set to the Mid-Speed and the eHEPA® indicator will light up and
display a green light, which indicates that the eHEPA® system is
activate.
7.3 Source Capture System Controls
Each of the respective control elements shown on the Control Panel
Display in Fig. 5 work as follows:
• SPEED button on the Control Panel or Remote Control adjusts the
volume of airflow being taken in through the hood. Airflow speed
can be adjusted to one of three settings: Low – Mid – High Speed.
• eHEPA button turns the eGrid on and off. When the eGrid is
powered the symbol above the eHEPA button, as well as the eGrid
Active light, will turn green. Pressing the eHEPA button once more
will shut off the eGrid and turn off the indicator light.

12
VII. Operation Guidelines
7.3 Source Capture System Controls
• TIMER button is for operation of the timing clock. When this feature is
in use the unit will automatically shut off after the set time expires. The
system's default timing is 4 hours of operation.
To set the timer manually, press the TIMER button once for every hour
you wish to run the machine (i.e. press TIMER once for 1-hour of run
time, press TIMER twice for 2-hours of run time, press TIMER three
times for 3-hours of run time, and press TIMER four times for 4-hours
of run time).
If the TIMER button is pressed five (5) times, such that it passes
through the complete timing schedule, it will run continuously until the
unit is manually turned off.
• LIGHT button turns the Hood LED Light on and off. When the LED
Light is on the symbol above the button turns green. Pressing the
LIGHT button once more will turn off the LED Light as well as the
indicator light.
• eGrid Active indicator light indicates the status of the eHEPA® and
eGrid system. When the eGrid Active indicator light is green, while the
eHEPA button is on, the eGrid is functioning properly. If the eGrid
Active indicator light is off, while the eHEPA button is on, it signals that
the eGrid is malfunctioning and the unit requires service.
Fig. 5 - Control Panel Display

13
VIII. Filter Replacement
8.1 Replacement Filters
The HealthyAir® Source Capture Aerosol Extractor Model HA-SSC-G4-
AE utilizes the HealthyAir® Series 1213 Replacement Filters, as follows:
• HealthyAir® Pre-Filter: Model No. HA-PF-1213
• HealthyAir® eHEPA® Filter: Model No. HA-EH-1213
• HealthyAir® Activated Carbon Filter: Model No. HA-PF-1213
Note that, only manufacturer supplied HealthyAir® Replacement Filters
are compatible with HealthyAir® Source Capture Systems. No other
replacement filters are to be used with this unit. The improper use of non-
manufacturer supplied filters will void any potential warranty claim.
8.2 Filter Replacement
The recommend filter replacement cycle is 9-12 months on
average. However, the need for filter replacement naturally varies
depending on the frequency and nature of use.
When the unit has been in operation for 400-hours, the Filter Change
indicator light, on the Control Panel, will begin to flash. This serves as a
reminder to inspect and/or replace the filter.
8.2.1 Turn the Power Off and unplug the Power Cord from the Power
Socket.
8.2.2 Remove the Access Door by unscrewing the two (2) Thumb
Screws.
8.2.3 Remove the Pre-Filter, eHEPA® Filter, and Activated Carbon
Filter.

14
VIII. Filter Replacement
8.2 Filter Replacement
8.2.4 Install a new set of HealthyAir® Series 1213 Replacement Filters.
8.2.5 Reinstall the Access Door, ensuring that the Access Door is
properly inserted back into its track. Once the Access Door is
properly aligned and set in place, secure it by screwing in the
Thumb Screws.
8.2.6 Plug the Power Cord back into the Power Socket and wall socket.
Fig. 6 - Filter Replacement
eHEPA® Filter
HA-EH-1213
Activated
Carbon Filter
HA-AC-1213
Pre-Filter
HA-PF-1213
eGrid

15
VIII. Filter Replacement
8.3 Filter Change Indicator Light Reset
Once the filters have been replaced and the unit is powered on, the Filter
Change indicator light may continue to flash. To reset the filter change
timer and deactivate the flashing light, go through the following reset
procedure:
8.3.1 Unplug the Power Cord from the Power Socket, wait a couple
seconds and plug the Power Cord back into the Power Socket.
8.3.2 Press and hold down the Power Button [ ] on the Control Panel
(not the Remote Control) for five (5) seconds.
8.3.3 After five (5) seconds has passed, release the Power Button. The
filter change timer will have reset to 400-hours and the Filter
Change indicator light will have stopped flashing now.
Fig. 7 - Filter Change Indicator Light Reset
Filter Change
indicator light
flashing
Press and Hold
Power button for
5 seconds

16
IX. Maintenance
9.1 Cleaning Filter Compartment
Visually inspect the interior of the Filter Compartment when the filters are
removed from the unit during the filter replacement process. If debris has
accumulated in the Filter Compartment, clean the interior of the unit as
follows:
9.1.1 Turn the Power Off, unplug the Power Cord from the Power
Socket, remove the Access Door, and remove the filters from the
unit.
9.1.2 The HV Contact Spring will likely contain a small charge and
should not be directly touched! Using an electrically insulated
instrument, such as the Screwdriver provided, make contact with
the HV Contact Spring and the interior metal wall of the unit. This
will discharge the HV contact spring.
9.1.3 Vacuum and remove any debris that has accumulated in the filter
compartment and adjacent accessible areas of the interior of the
unit.
9.1.4 Properly replace the Access Door, as previously described herein.
Fig. 8 – Cleaning Filter Compartment
HV
Contact
Spring
Access
Door
Filter
Compartment
Power
Socket

17
X. Basic Service and Troubleshooting
The Basic Service Guide should cover most performance issues. If you
continue to experience issues after referring to this list, please contact
Healthy Air Inc.
10.1 Air Purification System Inoperable
If the unit fails to power on, the issue may be the result of one of the
following causes. In some cases, the unit will require service by the
manufacturer or a professionally licensed electrician.
Possible Cause
Solution
Blown Fuse
Replace the Fuse
Safety Switch not engaged
Properly close the Access Door
Safety Switch malfunction
Replace the Safety Switch
HV Board malfunction
Replace the HV Board
PCB Board delay function
Unplug and re-plug Power Cord
10.2 Air Purification System Power On but Inoperable
If the unit powers on but fails to operate properly, the issue may be the
result of a faulty electrical board and will require service by the
manufacturer or a professionally licensed electrician.
Possible Cause
Solution
PCB Board malfunction
Reconnect/Replace PCB Board

18
X. Basic Service and Troubleshooting
10.3 Air Purification System Power On but Fan Inoperable
If the unit powers on but the fan fails to operate, the issue may be the
result of a faulty motor and will require service by the manufacturer or a
professionally licensed electrician.
Possible Cause
Solution
Fan/Motor malfunction
Replace the Fan/Motor
PCB Board malfunction
Replace the PCB Board
10.4 Fan Speed Cycle Error
If the unit does not properly cycle through all three (3) fan speed settings,
or the unit shuts off when cycling through the fan speed settings, the issue
may be the result of one of the following causes.
Contact the manufacturer for the Control Panel reset instructions. If that
does not resolve the issue, the unit will require service by the
manufacturer or a professionally licensed electrician.
Possible Cause
Solution
Control Panel program error
Control Panel reset procedure
Display Board malfunction
Replace Display Board

19
X. Basic Service and Troubleshooting
10.5 eGrid Activity Indicator Light Not Lit
If the eGrid Activity indicator light fails to turn on when the eHEPA®
system is on, the issue may be the result of one of the following causes
and will require service by the manufacturer or a professionally licensed
electrician.
Possible Cause
Solution
eGrid malfunction
Remove and clean the eGrid
Faulty HV contact
Remove and reinstall the eGrid
HV Board malfunction
Replace the HV Board
10.6 Irregular Sound from eGrid
If an irregular crackling sound is detected from the unit, the issue may be
the result of one of the following causes and will require service by the
manufacturer or a professionally licensed electrician. Never tamper with
eGrid while the unit is plugged into an electrical outlet.
Possible Cause
Solution
Accumulation of debris
Remove and clean the eGrid
Accumulation of moisture
Remove and dry the eGrid
Pre-Filter missing
Install Pre-Filter
