Heart of House Wimbourne User manual

Wimbourne - 3 Door Centre Mirror Gents
Dimensions
Width - 132.6cm
Depth - 61cm
Height - 198cm
BK04100 - Issue 1 - 05/12/2014
Important – Please read these instructions fully before starting assembly
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6403030
346/0575
346/5817

1
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• Due to difference in floor
levels, doors may not be
aligned. Adjustment may be
necessary.
• To prevent bowing of shelves
do not over load, and always
distribute weight evenly.
• If a residual aroma is
experienced with your new
furniture after the packaging
is removed simply ensure the
room is well ventilated and this
will assist a speedy removal
• We do not
recommend the
use of power drill/
drivers for inserting
screws, as this
could damage the unit. Only use
hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• It is essential that this unit be
fixed to a wall with the fittings
provided.
• Please retain the product label
on the back of the unit, as this
information will help support any
queries.
• Dust with a clean cloth or, if
required a slightly damp cool
cloth. Do not use household
cleaners, abrasives or polishes
as permanent damage may
occur.
• Your furniture is finished to the
required colour. Avoid exposure
to strong sunlight as this can
change the colour. Change in
appearence may also occur if
items are permanently left on a
surface.
• Do not drag the furniture or lift
it by its top.
• Avoid sharp objects, contact
with water and direct heat on all
surfaces
• From time to time check that
there are no loose screws on
this unit.
• Doors should be secured or
removed before moving.
• You should get assistance
when moving or lifting your
furniture. Furniture consisting of
more than one unit should be
disassembled before attempting
to move it.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance - Non compliance with this information may affect your guarantee

Components - Panels
Please check you have all the panels listed below
2
Double wardrobe (191 x 82.3 x 57.6 cm)
1Single wardrobe (191 x 42.3 x 57.6 cm)
2
Cornice section (132.6 x 11cm)
3
If you have damaged or missing components, call the
Customer Helpline:
Argos = 0345 6403030

3
Please check you have all the fittings listed below
Ruler - Use this ruler to help correctly identify the screws
Tools required
A
Wall strap x 1
E
B
15mm Screw x 1
C
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
15mm Washer x 2
D
Components - Fittings
Phillips screwdriver
(medium)
Step ladder
(or equivalent)
The following components are pre-fitted and are illustrated for reference only.
Cup handle x 6
18mm Conecting bolt x 2 Threaded sleeve x 2
Handle screw x 9
F
20mm Cornice screw x 7
Knob Handle x 3

4
Assembly Instructions
Step 1
Position and connect
the units
a: Before connecting the
units you will first need
to remove all doors and
drawers.
Loosen but do not
remove bolt B in the
centre of the hinge back
plates which are attached
to the wardrobe side
panel.
Slide the door off the
back plates allowing bolt
B to go through the key
hole.
Pull the drawers out to
full extension and tilt
upwards to allow you to
lift it off the runners.
b: Position the double
wardrobe 1in the
required position [please
note it will be hard to
move once connected].
Once in place position
the single wardrobe 2
along side so the the
front edges are aligned.
To fix the two units
together you will need
two 18mm connecting
bolts Dand two
Threaded sleeves E.
Thread 18mm connecting
bolt Dthrough the
top hole inside the
double wardrobe then
screw threaded sleeve
Ethrough from inside
single wadrobe.
Repeat for bottom hole
A
A
B
C
a:
b: WARNING: Help may be
required for this step.
D
E
1 2

5
Step 3
Remove and replace
handles
a: The handles are
fitted to the inside of
the unit, using a Philips
screwdriver unscrew the
handle screws in each
handle and remove both
the handle screw and the
handle.
Handle screw
Assembly Instructions
Step 2
A
A
B
C
Re-fitting the doors
Starting from the top,
slide the keyhole shaped
groove in the hinge over
bolt B on the hinge plate.
Once located tighten bolt
B and move on to the
next hinge.
a:
1
2
Philips screwdriver

Assembly Instructions
Step 4
6
Handle
Handle screw
Step 3 - continued
b: Replace the handle
on the front of the
unit. Fix in position by
screwing the handle
screw into each handle
from inside the unit using
a Philips screwdriver.
b:
1 2
Philips screwdriver
a:
Assemble Cornice
Philips screwdriver
WARNING: Help may be
required for this step.
1
2
F
3
a: Place the cornice on
top of the robe, you may
need to use step ladders
to do this. Position the
cornice being careful
to ensure that the back
edges of the cornice
are flush with the back
of the robe and that
the overhang on each
side is equal. Once the
position is correct, screw
down firmly with a philips
screwdriver and the
20mm cornice screws F.
Note: There are not any
pre drilled in the top of
the robes for this.

Assembly Instructions
A
Using the correct type of screw
screw through the washer and wall
strap into a pre-drilled hole in the
wall
C
B
B
7
Step 5
Fixing to wall
It is recommended that
the wardrobe is fixed to
a wall.
Fix wall strap Cto the
top of wardrobe using
15mm screw Aand
15mm washer B.
Warning: The
15mm screw A
is for fixing the
wall strap Cto furniture
only. In addition to this
you will need to choose
a screw or fitting which is
suitable for securing the
wall strap Cto the type
of walls you have. If you
are unsure about what
type of screw to use seek
professional help.
Adjusting doors
1. To adjust the height /
level of the door loosen
all screw ‘A’s on all hinge
plates, level the door
height and retighten all
screw ‘A’s.
2. To adjust the gap
between the doors
loosen screw ‘B’, then
turn screw ‘C’ clockwise
to close the gap or
anticlockwise to increase
the gap. Re-tighten
screw ‘B’ to lock position.
3. To adjust the distance
away from the unit
loosen screw ‘B’, this
allows the hinge arm
to slide back and forth.
Adjust as required then
re-tighten screw ‘B’.
Assembly is complete.
Step 6
A
A
B
C
3
1
2

If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6403030
