1
C-Bow Taschenhalter / C-Bow holder
KTM 1290 Super Duke R
2020-
Artikel Nr.: / Item-no.:
6307603 00 01 schwarz/black
271120
INHALT
CONTENT
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
2x 700007063 C-Bow schwarz
1x 700011292 Halter links
1x 700011293 Halter rechts
1x 700011294 Verbindungsstrebe
1x 700011295 Schraubensatz:
2x 700007063 C-Bow black
1x 700011292 Holder left
1x 700011293 Holder right
1x 700011294 Connection strut
1x 700011295 Screw kit:
Set Verlängerung/extension Ratsche/Ratchet
2x Zylinderschraube M8x40
2x Zylinderschraube M8x35
4x Sechskantschraube M6x16
4x Sechskantschraube M6x20
8x U-Scheibe Ø6,4
2x Allen screw M8x40
2x Allen screw M8x35
4x Hexagon bolt M6x16
4x Hexagon bolt M6x20
8x Washer Ø6,4
Baubreite 35cm
Width: 35cm
Soziustauglichkeit ist eingeschränkt.
Pillion rider fitness is limited.
2
WICHTIG
IMPORTANT
Beachten Sie die in Ihrem Land geltenden Zulassungsbestimmungen.
Für den Bereich der BRD gilt: Ein Eintrag in die Fahrzeugpapiere ist nicht erforderlich.
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,wie
man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen.
Ziehen sie alle zugänglichen Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf
das entsprechende Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist.
Anzugsmomente beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
VORBEREITUNG
PREPARING
Rechts und links die beiden Originalschrauben im Heck demontieren, diese entfallen!
Remove the two original screws in the rear on the right and left side, these are not necessary!
ACHTUNG
CAUTION
Eine Seite nach der anderen montieren, da sich sonst die originale Verbindungsstrebe im Heck absenkt.
Mount one side after the other, otherwise the original connecting strut in the rear will be lowered.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
1
2x
2x
Montage der Halter rechts/links:
Vorne
mit der Zylinderschraube M8x35
Hinten
mit der Zylinderschraube M8x40
befestigen.
Fastening of the holders right/left:
Front
with allen screw M8x35
Rear
with allen screw M8x40
Fahrtrichtung/driving direction
6307603 00 01
3
6307603 00 01
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: vertrieb@hepco-becker.de
www.hepco-becker.de
Als weiteres Zubehör lieferbar:/ Also available:
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
6707603 00 01 Sportrack
5017603 00 06 Motorschutzbügel orange / Engine guard
5067603 00 09 Tankring
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren! Abgebaute Teile wieder montieren.
Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the dismantled parts.
Please notice our enclosed service information.
2
3
4x
4x
4x
4x
Montage der C-Bows rechts/links vorne:
An den montierten Adaptern.
Dazu die Sechskantschrauben M6x16
und die U-Scheiben Ø6,4 verwenden.
Montage der C-Bows rechts/links hinten:
An den montierten Adaptern zusammen mit
der Verbindungsstrebe. Dazu die Sechskant-
schrauben M6x20 und die U-Scheiben Ø6,4
verwenden.
Fastening of the C-Bows right/left front:
On the mounted adapters.
Use hexagon bolts M6x16 and washers
Ø
6,4.
Fastening of the C-Bows right/left rear:
On the mounted adapters together with the
connection strut. Use hexagon bolts M6x20
and washers
Ø
6,4.
Fahrtrichtung/driving direction
Fahrtrichtung/driving direction
