Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: [email protected]
www.hepco-becker.de
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
1
200617
1x Hitzeschutzblech
1x Halter
1x Schraubensatz
Hitzeschutzblech / Heat protection plate
KTM 790 Duke
ab Baujahr 2018 / from date of manufacture 2018
Artikel Nr.: / Item-no.:
42247569 00 91 schwarz/silber - black / silver
2x Aludistanz Ø15xØ9x13
2x Linsenschraube M8x80
2x Sechskantschraube M6x16
4x U- Scheibe Ø6,4
2x Hutmutter M6
2x U- Scheibe Ø6,4x3mm
HINWEIS
NOTICE
1x Heat protection plate
1x Holder
1x Screw set
2x Alu spacer Ø15xØ9x13
2x filister head screw M8x80
2x Hexagon bolt M6x16
4x Washer Ø6,4
2x cap nut M6
2x Washer Ø6,4x3mm
Zur Montage gemeinsam mit dem Hepco & Becker Easyrack / Alurack / Minirack / Verbreiterung
For mounting together with the Hepco & Becker Easyrack / Alurack / Minirack / Enlargement
Ratsche/Ratchet
Verlängerung/extension
Set
2x 10
INHALT
CONTENTS
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
2
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
WICHTIG
IMPORTANT
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
1
Montage des Halters vorne/hinten:
An den nun freien Gewindebohrungen
mit den Linsenschrauben M8x80 und
U- Scheiben ø8,4. Zwischen Rohradapter
und Halter die Aludistanzen
ø15xøx9x13mm fügen.
Montage des Hitzeschutzblechs:
Die Montage erfolgt am Halter mit den
Sechskantschrauben M6x16 sowie
U- Scheiben ø6,4 von unten. Zwischen
Halter und Hitzeschutzblech die U-
Scheiben ø6,4x3mm fügen. Von oben
mit den Hutmuttern M6 und U-Scheiben
ø6,4 verschrauben.
2x
4x
Sollte bereits ein Rack montiert sein, die beiden Schrauben auf der rechten Seite entfernen, diese entfallen.
U- Scheiben werden wieder verwendet.
If a rear rack is already installed, remove the two screws on the right side. Washers are reused.
2x
2x
2x
2x
2x
Hitzeschutzblech / Heat protection plate
KTM 790 Duke
ab Baujahr 2018 / from date of manufacture 2018
Artikel Nr.: / Item-no.:
42247569 00 91 schwarz/silber - black / silver
Fastening of the holder front/rear:
With filister head screws M8x80 and
washers ø8,4 in the free threads. Add alu
spacer Ø15xØ9x13mm between holder
and frame.
Mounting the heat protection plate:
It is mounted on the holder with M6x16
hexagon screws and washers ø6,4 from
below. Fit the washer ø6.4x3mm between
the holder and the heat protection plate.
Screw from above with cap nuts M6 and
washers ø6.4.
