5067609 00 01 / 5067620 00 01 / 506721 00 01 1
1x Montageset mit Tankring
2x Abdeckung Magnetdome
1x 700011977 Schraubensatz:
1x Mounting set with tank ring
2x Cover magnetic dome
1x 700011977 Screw kit:
1x Senkschraube M5x20
1x Senkschraube M5x25
1x Senkschraube M5x30
1x Senkschraube M5x35
1x Senkschraube M5x40
1x Senkschraube M5x50
1x Linsenschraube M5x16
1x Linsenschraube M5x25
1x Linsenschraube M5x35
1x Linsenschraube M5x40
1x Linsenschraube M5x50
4x Aluhülse Ø8,4xØ5,3x9
4x Aluhülse Ø8,4xØ5,3x16
1x Countersunk screw M5x20
1x Countersunk screw M5x25
1x Countersunk screw M5x30
1x Countersunk screw M5x35
1x Countersunk screw M5x40
1x Countersunk screw M5x50
1x Filister head screw M5x16
1x Filister head screw M5x25
1x Filister head screw M5x35
1x Filister head screw M5x40
1x Filister head screw M5x50
4x Alu spacer Ø8,4xØ5,3x9
4x Alu spacer Ø8,4xØ5,3x16
Inhalt Content
TANKRING
021120/161120/180122
Ratsche/Ratchet
Benötigte Werkzeuge / Required tools
Set Verlängerung/extension
VOGE 500R / 650DS/X
(2020-)
Art.Nr./Item-no.:
5067609 00 01 schwarz/black
VOGE 500 DS/X
(2020-)
Art.Nr./Item-no.:
5067620 00 01 schwarz/black
VOGE 300 AC
(2020-)
Art.Nr./Item-no.:
5067621 00 01 schwarz/black
5067609 00 01 / 5067620 00 01 / 506721 00 01 2
Weiteres Zubehör auf www.hepco-becker.de / More accessories see www.hepco-becker.de
HEPCO&BECKER GmbH | An der Steinmauer 6 | 66955 Pirmasens | Germany | Tel. +49 6331 1453100 | Fax: +49 6331 1453 120 | Mail: vertrieb@hepco-becker.de
Wichtig / Important:
Wenn Sie sich nicht sicher sind,wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen.
Ziehen sie alle zugänglichen Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann
auf das entsprechende Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei
angebaut ist. Anzugsmomente beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
If you are not sure how to execute a determined action, you should ask your local distributor to do it. First, tighten all
screws only loosely. After mounting all parts, the screws should be tightened to the torque specified. This guarantees, that
the product is mounted without tension. Observe the tightening torques of the manufacturer! Control all screw connections
after the assembling for tightness!
1
Montage des Tankrings:
500 R / 650 DS/X:
A
Senkschraube M5x20 (hinten links)
2
Senkschraube M5x40 (hinten rechts)
3
Linsenschraube M5x40 (vorne links)
4
Linsenschraube M5x16 (vorne rechts)
Aluhülsen Ø8,4xØ5,3x9
500 DS/X:
A
Senkschraube M5x30 (hinten links)
2
Senkschraube M5x35 (hinten rechts)
3
Linsenschraube M5x35 (vorne links)
4
Linsenschraube M5x25 (vorne rechts)
Aluhülsen Ø8,4xØ5,3x16
300 AC:
A
Senkschraube M5x25 (hinten links)
2
Senkschraube M5x50 (hinten rechts)
3
Linsenschraube M5x50 (vorne links)
4
Linsenschraube M5x25 (vorne rechts)
Aluhülsen Ø8,4xØ5,3x16
Fastening of the tank ring:
500 R / 650 DS/X:
A
Countersunk screw M5x20 (rear left)
2
Countersunk screw M5x40 (rear right)
3
Filister head screw M5x40 (front left)
4
Filister head screw M5x16 (front right)
Alu spacers Ø8,4xØ5,3x9.
500 DS/X:
A
Countersunk screw M5x30 (rear left)
2
Countersunk screw M5x35 (rear right)
3
Filister head screw M5x35 (front left)
4
Filister head screw M5x25 (front right)
Alu spacers Ø8,4xØ5,3x16
300 AC:
A
Countersunk screw M5x25 (rear left)
2
Countersunk screw M5x50 (rear right)
3
Filister head screw M5x50 (front left)
4
Filister head screw M5x25 (front right)
Alu spacers Ø8,4xØ5,3x16
Montageanleitung / Installation Instruction
Die 4 vorderen Originalschrauben der Tankringbefestigung entfernen, diese entfallen.
Remove the 4 original front screws of the tank ring bolting, these are omitted.
Vorbereitende Maßnahmen / Preparatory actions
