HEROSE 7111 User manual

HEROSE GMBH ARMATUREN UND METALLE
Operating instructions
Diverter plug valve
Type 7111

Operating instructions
herose.com
I
IMPORTANT
Read carefully before use.
Keep for future reference.
© 2020 HEROSE GMBH
ARMATUREN UND METALLE
Elly-Heuss-Knapp-Straße 12
23843 Bad Oldesloe
Germany
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
Web: www.herose.com
2nd issue 03/2020
The transmission or duplication of this document and the use or communication of its
content are forbidden unless expresslypermitted. Any violations shall result in liabilityfor
damages. All rights in the event of patent, utility model or registered desi gn are
reserved.

Operating instructions
II
Phone [phone]
Table of contents
1About these instructions.....................................................................................................1
2Safety .................................................................................................................................1
3Transport and storage........................................................................................................4
4Description of the valve......................................................................................................4
5Assembly ............................................................................................................................7
6Operation............................................................................................................................8
7Maintenance and service...................................................................................................8
8Disassembly and disposal ...............................................................................................10

Operating instructions
herose.com
1
1 About these instructions
1.1 Principles
The operating instructions are part of the valve named on the front page.
1.2 Applicable documents
Document
Contents
Catalogue page
Description of the valve
For accessories, refer to the respective manufacturer's documentation.
1.3 Hazard levels
The warning notes are marked and classif ied according to the following hazard lev els:
Symbol
Explanation
DANGER
Identif ies a hazard with a high risk lev el that will result in death
or serious injury .
WARNING
Identif ies a hazard with a moderate risk lev el that will result in
death or serious injury .
CAUTION
Identif ies a hazard with a low risk lev el that will result in a minor
or moderate injury .
NOTICE
Identif ies a risk to property. Damage to property may occur if
this notice is ignored.
2 Safety
2.1 Intended use
The v alv e is intended for installation in a pipeline or pressure tank sy stem in order to block media or allow
them to pass through within the permissible operating conditions. The permissible operating conditions
are specif ied in these operating instructions.
The v alv e is suitable for the media listed in these operating instructions; see section 4.5 “Media”.
Operating conditions and applications dev iating from these require the approval of the manufacturer.
Only media may be employed to which the materials used for the valve body and seals are resistant.
Contaminated media or usage outside of the pressure and temperature specifications can lead to damage
to the v alv e body and seals.
Avoidance of foreseeable incorrect use
Nev er exceed the permissible usage limits specified in the data sheet or in the documentation
with regard to pressure, temperature, etc.
Follow all saf ety instructions and operating procedures in these operating instructions.
2.2 Meaning of the operating instructions
The operating instructions are to be read and f ollowed by the responsible technical personnel before
mounting and start-up. As part of the valve the operating instructions must always be available close to it.
People could be seriously injured or killed if the operating instructions are not followed.
Read and observ e the operating instructions before using the valve.
Retain the operating instructions and make sure they are available.
Pass on the operating instructions to subsequent users.

Operating instructions
2
Phone [phone]
2.3 Instructions for people who work with the valve
People could be seriously injured or killed if the v alve is used improperly. In order to av oid accidents, all
persons who work on the v alv e must meet the following minimum requirements:
They are phy sically capable of controlling the valve.
They can saf ely carry out the work with the v alve within the scope of these operating instructions.
They understand the operating principles of the valve within the scope of their work and are able to
recognise and av oid the hazards of the work.
They hav e understood the operating instructions and are able to implement the information of the
operating instructions accordingly.
2.4 Personal protective equipment
Missing or unsuitable personal protective equipment increases the risk of damage to health and injuries to
people.
The f ollowing protectiv e equipment is to be prov ided and worn during work:
Protectiv e clothing
Saf ety shoes
Def ine and use additional protective equipment depending on the application and the media:
Saf ety gloves
Ey e protection
Ear protection
Wear the specif ied personal protective equipment for all work on the v alve.
2.5 Additional equipment and spare parts
Additional equipment and spare parts not conf orming to the manufacturer's requirements can negatively
af f ect the operational safety of the valve and cause accidents.
In order to ensure operational saf ety, use original parts or parts that conform to the
manuf acturer's requirements. If in doubt, have these confirmed by the dealer or manufacturer.
2.6 Adhere to the technical thresholds
If the technical thresholds for the valve are not adhered to, the valve may sustain damage, accidents may
be caused and people may be seriously injured or killed.
Adhere to the thresholds. See section “4 Description of the valve”.
2.7 Safety instructions
DANGER
Hazardous medium.
Escaping operating medium can lead to poisoning, burns and caustic burns!
Wear the prescribed protectiv e equipment.
Prov ide suitable collecting containers.
WARNING
Harmful and/or hot/cold conveyed media, lubricants and fuels
Hazardous f or persons and the env ironment!
Collect and dispose of rinsing medium and any residual media.
Wear protectiv e clothing and a protective mask.
Observ e legal regulations regarding the disposal of harmful media.

Operating instructions
herose.com
3
WARNING
Risk of injury if maintenance work is done incorrectly!
Incorrect maintenance can lead to serious injury and considerable material damage.
Bef ore the start of work, ensure there is sufficient room for doing the work.
Ensure the space around the work is tidy and clean! Parts and tools in loose piles or ly ing around
are hazard sources.
If parts hav e been removed, take care to assemble correctly and re-install all attachment items.
Bef ore putting back into service, ensure:
All maintenance work has been carried out and completed.
There are no persons in the hazard area.
All cov ers and safety devices are installed and operating correctly.
CAUTION
Cold/hot pipelines and/or valves.
Risk of injury due to thermal influences!
Insulate v alves.
Attach warning signs.
Medium escaping at high speed and high/low temperature.
Risk of injury !
Wear the prescribed protectiv e equipment
NOTICE
Impermissible stresses arising from operating conditions and extensions / added structures.
Leakage or rupture of the v alve body!
Prov ide suitable support.
Additional loads, such as traf fic, wind or earthquakes, are not explicitly taken into account by
def ault and require separate sizing.
Condensation in air conditioning, cooling and refrigeration plants.
Icing!
Blocking of the actuation mechanism!
Damage due to corrosion!
Insulate v alves with diffusion-tight material
Improper mounting.
Damage to the v alv e!
Remov e cover caps before mounting.
Clean the sealing surf aces.
Protect the body against hammering.
Painting of valves and pipelines.
Functional impairment of the valve / loss of information!
Protect stem, plastic parts and type plate against the application of paint.
Impermissible load.
Damage to the control mechanism!
Do not use the v alv e as a f oothold.
Tools f or increasing the torque of the lever are not permitted.
Exceeding the maximum permissible operating conditions.
Damage to the v alv e!
The maximum permissible operating pressure must not be exceeded, and the minimum and
maximum allowable operating temperatures must be observed.

Operating instructions
4
Phone [phone]
3 Transport and storage
3.1 Inspection of condition on delivery
Inspect the v alve for damage upon receipt.
In case of transport damage, determine and document the precise extent of the damage, and
report it immediately to the supplying dealer/carrier and the insurer.
3.2 Transportation
Transport the v alv e in the packaging supplied.
The v alv e is delivered ready to operate with lateral connections protected by cover caps.
Protect the v alve against shocks, impacts, vibrations and dirt.
Adhere to a transport temperature range of -20 °C to +65 °C.
3.3 Storage
Store the v alv e in a clean and dry place.
Make use of a desiccant or heating in damp storerooms to prevent the formation of
condensation.
Adhere to a storage temperature range of -20 °C to +65 °C.
4 Description of the valve
Ref er to the respective catalogue page f or further detailed information.
4.1 Structure
Design
Non-automatically opening and closing, straight-type globe v alve.
Component
Design
Body
Multi-way design, one-piece body
Bonnet
Flanged, without stem thread
Operating mechanism
Non-rising stem
Obturator
Plug with seal made of non-metallic materials
Stem bushing
Non self -sealing, packing gland
Body end
Thread end
4.2 Marking
The v alv es are provided with an indiv idual marking for identification.
Symbol
Explanation
DN
Nominal size
PN
Rated working pressure (max. permissible operating
pressure)
-…..°C+…..°C
Temperature, min. / max.
Manuf acturer’s mark “HEROSE”
01/16
Date of manuf acture, MM/Y Y
12345
Ty pe
01234567
Serial no.
e.g. EN1626
Standard
0045
CE-mark, ID of notified body
e.g. CC491K
Material

Operating instructions
herose.com
5
4.3 Intended use
Div erter plug v alve for the installation of two safety valves in combination with bursting discs for protecting
gas storage tanks. The requirements of the pressure equipment directive for redundant or different types
of saf ety devices are f ulfilled with this valve and in combination with safety valves with the same setting
pressure. Additional connections for suitable bursting discs are av ailable on each side.
In the case of serv icing the safety valves or replacement of the bursting discs, the side to be serviced is
isolated f rom the tank.
In the end position one outlet is open and the other is closed. It is not possible to shut off both outlets at
the same time.
4.4 Operational data
Valv e
Nominal
pressure
Temperature
Max. operating pressure
7111
PN50
-196 °C to +120 °C
50 bar
-196 °C to +60 °C
40 bar with O2 application
-196 °C to +120 °C
25 bar with O2 application
4.5 Media
Gases, cry ogenic liquefied gases and their gas mixtures, such as:
Name
Argon
Chlorotrif luoromethane
Nitrous oxide
Ethane
Ethy lene
Carbon dioxide
Carbon monoxide
Kry pton
LPG
LNG
Methane
Oxy gen
Nitrogen oxide
Nitrogen
Trif luoromethane
Hy drogen

Operating instructions
6
Phone [phone]
4.6 Materials
Part
no.
Name
Material
1
Body
CC491K
2
Bolt
1.4301
3
Lev er
CC491K/1.4308
4
Stem
1.4301
5
Top work
CC491K
6
Obturator
CW614N/PTFE
4.7 Scope of delivery
Valv e
Operating instructions
4.8 Dimensions and weights
See catalogue page.
4.9 Lifetime
The user is obligated to use Herose products only for their intended purpose.
In this case, a technical service life may be assumed in accordance with the underly ing product standards
(e.g. EN1626 f or shut-off valves and EN ISO 4126-1 f or safety valves).
The technical serv ice life can be restarted several times through the exchange of wearing parts within the
context of the maintenance intervals, and lifetimes of more than 10 years can be achieved.
If products are stored for a period exceeding 3 y ears, then the plastic components and elastomer sealing
elements f itted to the product should be replaced as a precautionary measure before mounting and use.
1
2
3
4
5
6

Operating instructions
herose.com
7
5 Assembly
5.1 Installation position
Attention must be paid to the direction of flow.
The installation position is arbitrary .
The pref erred installation position should be with the stem horizontal.
5.2 Notices regarding the mounting
Use suitable tools.
Clean tools bef ore the installation
Open the packaging only directly before the mounting. Freedom from oil and grease f or oxygen
(O2)
Valv es f or oxygen are permanently marked with “O2”.
Only install the v alve if the maximum operating pressure and operating conditions correspond to
the marking on the v alv e.
Remov e protective caps or covers before mounting.
Inspect the v alve for dirt and damage. DO NOT install a damaged or dirty valve.
Remov e any dirt and residues from the pipeline and v alve in order to prev ent leaks.
Av oid damaging the connections.
The sealing surf aces must remain clean and intact.
Seal the v alv e with suitable seals.
No sealant (sealing tape, liquid sealing tape) may enter the v alve.
Respect the suitability for use with O2.
Connect pipelines in a f orce-f ree and torque-free manner.
Stress-f ree mounting.
In order to ensure trouble-f ree operation, no impermissible static, thermal or dynamic stresses
may be transmitted to the valve. Observe reaction forces.
Temperature-dependent changes in length in the pipework sy stem must be compensated with
expansion joints.
Fasten the v alve in the body with the existing threads.
The v alv e must be protected against dirt and damage during construction work.
Check the leak-tightness.

Operating instructions
8
Phone [phone]
Tightening torques
Diverter plug valve
Nominal size [G; Rc; NPT]
Tightening torque (Nm)
Number of
layers of PTFE
tape
Tightening torque G [Nm]
Tightening torque NPT [Nm]
Tightening torque SV with double nipple and clamping sleeve in diverter valve [Nm]
Tightening torque SV with copper washer in diverter valve [Nm]
Tightening torque Rc [Nm]
G thread
NPT thread
Rc thread
Length [cm]
min.
max.
min.
max.
min.
max.
7111
1/2
50
30
50
40
60
40
60
3
20-
25
3/4
50
40
60
40
70
40
70
5
40-
45
1
50
50
80
50
80
50
80
6
55-
60
1.1/4
55
50
100
50
100
50
100
6
80-
85
1.1/2
60
70
100
60
100
60
100
6
90-
95
Screw plug
test thread
1/4
20
20
20
20
20
20
20
20
2
2
10-
15
6 Operation
6.1 Prior to start-up
Check the f ollowing points prior to start -up:
All mounting and installation work are completed.
The saf ety guards are in place.
Compare the material, pressure, temperature and installation position with the lay out plan for
the pipework sy stem.
Remov e dirt and residues f rom the pipeline and v alve in order to prev ent leaks.
7 Maintenance and service
7.1 Safety during cleaning
Take note of the specifications in the safety data sheet and the general occupational health and
saf ety rules if degreasers are used for process-related reasons for the cleaning of bearing parts,
unions and other precision parts.
7.2 Maintenance
The maintenance interv als must be defined by the user according to the operating conditions.
The recommendations f or the functional checking of the valves are to be taken from section 7.2.1
“Inspection and maintenance intervals” in these operating instructions.

Operating instructions
herose.com
9
7.2.1 Inspection and maintenance intervals
Recommended interv als
Description
Interval
Scope
Inspection
During start-up
Visual inspection
of the div erter plug v alve for damage:
of the v alving marking for legibility;
Leak-tightness
at the gland packing;
of the v alve seat;
at the connections;
at the plug screw;
Test of the opening and closing f unctions of the
div erter plug v alve.
Functional testing
Annually
Test the opening and closing f unctions of the
div erter plug v alve including a v isual inspection.
External inspection
Ev ery 2 y ears
Check of f unction and leak-tightness including visual
check.
Internal inspection
Ev ery 5 y ears
Replacement of all sealing elements, including a
f unction and leak test as well as a v isual inspection.
Hy draulic testing
Ev ery 10 y ears
Replacement of all sealing elements, including a
f unction and leak test as well as an inspection.
7.3 Fault table
Fault
Cause
Remedial action
Leak at the stem
Gland nut loose
Retighten the gland nut
Gland packing def ective
Replace the div erter plug v alve
Fit on the stem damaged
Replace the div erter plug v alve
Leaking lateral
connections
Inadequate seals
Seal with suitable sealants
Blind plug / bolted-on saf ety
v alv es loose
Tighten to the specif ied torques
Lateral connections cracked
Replace the div erter plug v alve
Body leaking
Discontinuity/gas cavity open
Replace the div erter plug v alve
Div erter plug v alve
cannot be switched
ov er
Gland nut ov ertightened
Loosen the gland nut
Tightness must still be ensured
Thread seized
Replace the div erter plug v alve
Lev er lock not remov ed
Remov e lev er lock
7.4 Spare parts
We require the f ollowing details f or your spare part orders:
Article no. of the spare part package,
desired deliv ery quantity,
dispatch and deliv ery address,
desired method of dispatch.

Operating instructions
10
Phone [phone]
7.5 Returns / complaints
Use the Serv ice f orm in case of returns/complaints.
Contact in case of service:
Herose.com › Serv ice › Product service › Complaints
E-mail: serv [e-mail]
Fax: [phone]
8 Disassembly and disposal
8.1 Notices regarding the disassembly
Take note of all national and local saf ety requirements.
The pipework sy stem must be depressurised.
The medium and v alv e must be at ambient temperature.
Aerate / f lush the pipework sy stem in the case of corrosive and aggressive media.
8.2 Disposal
1. Dismount the v alves.
Collect greases and lubricating f luids during dismantling.
2. Separate the materials:
Metal
Sy nthetic material
Electronic scrap
Greases and lubricating f luids
3. Carry out a sorted disposal of the materials.
