HIKOKI C 10RJ Troubleshooting guide

SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL
WARNING
IMPROPER OR UNSAFE use of this power tool can result in death or serious bodily injury!
This manual contains important information about product safety. Please read and understand this manual
BEFORE operating the power tool. Please keep this manual available for other users and owners before
they use the power tool. This manual should be stored in safe place.
Model Table SawC 10RJ (X)

CONTENTS
SECTION
SYMBOLS ...........................................................................................................................................................3
SAFETY INSTRUCTIONS ...................................................................................................................................4
OVERVIEW .........................................................................................................................................................8
SPECIFICATIONS..............................................................................................................................................10
LOOSE PARTS ..................................................................................................................................................11
ASSEMBLY .......................................................................................................................................................12
OPERATION .....................................................................................................................................................22
ADJUSTMENTS ................................................................................................................................................29
MAINTENANCE ................................................................................................................................................31
TROUBLESHOOING ........................................................................................................................................32
SELECTING ACCESSORIES ...........................................................................................................................32
GUARANTEE ....................................................................................................................................................32
PAGE

3
English
The following show symbols used for the machine. Be sure that you understand their meaning before use.
MeaningSymbol
C 10RJ (X): Table saw
To reduce the risk of injury, user must read instruction manual.
Always wear eye protection.
Always wear hearing protection.
Danger keep hands away from blade.
Never operate the tool in a damp or wet environment.
Lock / to tighten or secure.
Unlock / to loosen.
Volts
Hertz
Amperes
No load speed
Revolutions per minute
Input power
Kilogram
Decibel (A-rated)
Alternating current
V
Hz
A
no
---/min
W
kg
dB(A)
~
Caution, Warning or Danger.
Class II Construction
SYMBOLS

WARNING: Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to
follow all instructions listed below may result in electric shock, fire and/or serious injury.
4
English
SAFETY INSTRUCTIONS
The term “power tool” in the warnings refers to your mainsoperated (corded) power tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust.
Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an
increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from
heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk or electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor
use reduce the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a RESIDUAL CURRENT DEVICE (RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool
while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety
shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery
pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have
the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected
situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts.
Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and
properly used. Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles.
A careless action can cause severe injury within a fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better
and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch
is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are
easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working
conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a
hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do
not allow for safe handling and control of the tool in unexpected situations.
5) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that
the safety of the power tool is maintained.
General power tool safety warnings
Save all warnings and instructions for future reference.

5
English
1) Guarding related warnings
a) Keep guards in place. Guards must be in working order and be properly mounted. A guard that is loose, damaged, or is
not functioning correctly must be repaired or replaced.
b) Always use saw blade guard, riving knife and anti-kickback pawls for every through–cutting operation. For through-cutting
operations where the saw blade cuts completely through the thickness of the workpiece, the guard and other safety devices help
reduce the risk of injury.
c) Immediately reattach the guarding system after completing an operation (such as rabbeting) which requires removal
of the guard, riving knife and/or anti-kickback pawls. The guard, riving knife, and anti-kickback pawls help to reduce the risk
of injury.
d) Make sure the saw blade is not contacting the guard, riving knife or the workpiece before the switch is turned
on. Inadvertent contact of these items with the saw blade could cause a hazardous condition.
e) Adjust the riving knife as described in this instruction manual. Incorrect spacing, positioning and alignment can make the
riving knife ineffective in reducing the likelihood of kickback.
f) For the riving knife and anti-kickback pawls to work, they must be engaged in the workpiece. The riving knife and anti-
kickback pawls are ineffective when cutting workpieces that are too short to be engaged with the riving knife and anti-kickback
pawls. Under these conditions a kickback cannot be prevented by the riving knife and anti-kickback pawls.
g) Use the appropriate saw blade for the riving knife. For the riving knife to function properly, the saw blade diameter must match
the appropriate riving knife and the body of the saw blade must be thinner than the thickness of the riving knife and the cutting
width of the saw blade must be wider than the thickness of the riving knife.
2. Safety instructions for sawing procedures
a) DANGER: Never place your fingers or hands in the vicinity or in line with the saw blade. A moment of inattention or a
slip could direct your hand towards the saw blade and result in serious personal injury.
b) Feed the workpiece into the saw blade only against the direction of rotation. Feeding the workpiece in the same direction
that the saw blade is rotating above the table may result in the workpiece, and your hand, being pulled into the saw blade.
c) Never use the mitre gauge to feed the workpiece when ripping and do not use the rip fence as a length stop when cross
cutting with the mitre gauge. Guiding the workpiece with the rip fence and the mitre gauge at the same time increases
the likelihood of saw blade binding and kickback.
d) When ripping, always apply the workpiece feeding force between the fence and the saw blade. Use a push stick when
the distance between the fence and the saw blade is less than 150 mm, and use a push block when this distance is less
than 50 mm. Work helping” devices will keep your hand at a safe distance from the saw blade.
e) Use only the push stick provided by the manufacturer or constructed in accordance with the instructions. The push stick
provides sufficient distance of the hand from the saw blade.
f) Never use a damaged or cut push stick. A damaged push stick may break causing your hand to slip into the saw blade.
g) Do not perform any operation"freehand". Always use either the rip fence or the mitre gauge to position and guide the
workpiece. "Freehand" means using your hands to support or guide the workpiece, in lieu of a rip fence or mitre gauge. Freehand
sawing leads to misalignment, binding and kickback.
h) Never reach around or over a rotating saw blade. Reaching for a workpiece may lead to accidental contact with the moving
saw blade.
i) Provide auxiliary workpiece support to the rear and/or sides of the saw table for long and/or wide workpieces to keep
them level. A long and/or wide workpiece has a tendency to pivot on the table’s edge, causing loss of control, saw blade binding
and kickback.
j) Feed workpiece at an even pace. Do not bend or twist the workpiece. If jamming occurs, turn the tool off immediately,
unplug the tool then clear the jam. Jamming the saw blade by the workpiece can cause kickback or stall the motor.
k) Do not remove piece of cut-off material while the saw is running. The material may become trapped between the fence or
inside the saw blade guard and the saw blade pulling your fingers into the saw blade. Turn the saw off and wait until the saw blade
stops before removing material.
I) Use an auxiliary fence in contact with the table top when ripping workpieces less than 2 mm thick. A thin workpiece may
wedge under the rip fence and create a kickback.
3. Kickback causes and related warnings
Kickback is a sudden reaction of the workpiece due to a pinched, jammed saw blade or misaligned line of cut in the workpiece with
respect to the saw blade or when a part of the workpiece binds between the saw blade and the rip fence or other fixed object.
Most frequently during kickback, the workpiece is lifted from the table by the rear portion of the saw blade and is propelled towards the
operator.
Kickback is the result of saw misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions
as given below.
a) Never stand directly in line with the saw blade. Always position your body on the same side of the saw blade as the
fence rail. Kickback may propel the workpiece at high velocity towards anyone standing in front and in line with the saw blade.
b) Never reach over or in back of the saw blade to pull or to support the workpiece. Accidental contact with the saw blade
may occur or kickback may drag your fingers into the saw blade.
c) Never hold and press the workpiece that is being cut off against the rotating saw blade. Pressing the workpiece being cut
off against the saw blade will create a binding condition and kickback.
d) Align the fence to be parallel with the saw blade. A misaligned fence will pinch the workpiece against the saw blade and create
kickback.
e) Use a featherboard to guide the workpiece against the table and fence when making non-through cuts such as rabbeting.
A featherboard helps to control the workpiece in the event of a kickback.
f) Use extra caution when making a cut into blind areas of assembled workpieces. The protruding saw blade may cut objects
that can cause kickback.
g) Support large panels to minimise the risk of blade pinching and kickback. Large panels tend to sag under their own weight.
Support(s) must be placed under all portions of the panel overhanging the table top.
h) Use extra caution when cutting a workpiece that is twisted, knotted, warped or does not have a straight edge to guide
it with a mitre gauge or along the fence. A warped, knotted, or twisted workpiece is unstable and causes misalignment of the
Safety instructions for table saw

6
English
kerf with the saw blade, binding and kickback.
i) Never cut more than one workpiece, stacked vertically or horizontally. The saw blade could pick up one or more pieces and
cause kickback.
j) When restarting the saw with the saw blade in the workpiece, centre the saw blade in the kerf so that the saw teeth are
not engaged in the material. If the saw blade binds, it may lift up the workpiece and cause kickback when the saw is restarted.
k) Keep saw blades clean, sharp, and with sufficient set. Never use warped saw blades or saw blades with cracked or
broken teeth. Sharp and properly set saw blades minimise binding, stalling and kickback.
4. Table saw operating procedure warnings
a) Turn off the table saw and disconnect the power cord when removing the table insert, changing the saw blade or making
adjustments to the riving knife, anti-kickback pawls or saw blade guard, and when the machine is left unattended.
Precautionary measures will avoid accidents.
b) Never leave the table saw running unattended. Turn it off and don’t leave the tool until it comes to a complete stop.
An unattended running saw is an uncontrolled hazard.
c) Locate the table saw in a well lit and level area where you can maintain good footing and balance. It should be installed
in an area that provides enough room to easily handle the size of the workpieces. Cramped, dark areas, and uneven
slippery floors invite accidents.
d) Frequently clean and remove sawdust from under the saw table and/or the dust collection device. Accumulated saw dust
is combustible and may self ignite.
e) The table saw must be secured. A table saw that is not properly secured may move or tip over.
f) Remove tools, wood scraps, etc. from the table before the table saw is turned on. Distraction or a potential jam can be
dangerous.
g) Always use saw blades with correct size and shape (diamond versus round) of arbour holes. Saw blades that do not
match the mounting hardware of the saw will run off-centre, causing loss of control.
h) Never use damaged or incorrect saw blade mounting means such as flanges, saw blade washers, bolts or nuts. These
mounting means were specially designed for your saw, for safe operation and optimum performance.
i) Never stand on the table saw, do not use it as a stepping stool. Serious injury could occur if the tool is tipped or if the cutting
tool is accidentally contacted.
j) Make sure that the saw blade is installed to rotate in the proper direction. Do not use grinding wheels, wire brushes, or
abrasive wheels on a table saw. Improper saw blade installation or use of accessories not recommended may cause serious
injury.
k) Only use 10" saw blade with kerf width of 2.8mm and blade body thickness is 1.8 mm match the riving knife with thickness
of 2.3 mm.
l) Always use only a saw blade diameter in accordance with the markings on the saw; Use only saw blades for which the
maximum possible speed is not less than the maximum spindle speed of the product.
m)Do not use any blunt, cracked, deformed or damaged saw blades.
5. Additional safety instructions
• Please also observe the special safety instructions in the respective chapters.
• Where applicable, follow the legal directives or regulations for the prevention of accidents pertaining to the use of table saws.
• Avoid overheating of the saw teeth.
• Do not attempt to stop the saw blade by pushing the workpiece against its side.
• Store saw blade in such manner that nobody will get hurt.
• Before making a cut, be sure all adjustments are secure.
• Be sure blade path is free of nails. Inspect for and remove all nails from lumber before cutting.
• Never touch blade or other moving parts during use.
• Make sure the work area has ample lighting to see the work and that no obstructions will interfere with safe operation before performing
any work using the table saw.
• If this saw makes an unfamiliar noise or if it vibrates excessively, cease operating immediately, turn unit off and unplug the tool until
the problem has been located and corrected. Contact a HiKOKI Authorized Service Center if the problem can not be found.
SAVE THESE INSTRUCTIONS
AND
MAKE THEM AVAILABLE TO
OTHER USERS
AND
OWNERS OF THIS TOOL!

7
English
GLOSSARY OF TERMS
The safe use of this product requires an understanding of the information on the tool and in this operator’s manual as well as a knowledge
of the project you are attempting. Before use of this product, familiarize yourself with all operating features and safety rules.
• Anti-kickback Pawls: Kickback is a hazard in which the workpiece is thrown back toward the operator. The teeth on the anti- kickback
pawls point away from the workpiece. If the workpiece should be pulled back toward the operator, the teeth dig into the wood to help
prevent or reduce the possibility of kickback.
• Bevel Scale: The easy-to-read scale on the front of the cabinet shows the exact blade angle.
• Blade: For maximum performance, it is recommended that you use the 40-tooth, 254 mm carbide tipped combination blade. provided
with your saw. The blade is raised and lowered with the height/bevel adjusting handwheel. Bevel angles are locked with the bevel lock
lever.
• Blade Guard: Always keep the guard down over the blade for through sawing cuts.
• Bevel Lock Lever: This lever under the working table surface on the front of the cabinet, locks the angle setting of the blade.
• Height/Bevel Adjusting Handwheel: Located on the front of the cabinet, this handwheel is used to lower and raise the blade for
adjustments or blade replacement. The handwheel also makes the adjustment for bevel angles easy.
• Fence Rails Lock Lever: The lever under working table surface on the right of the saw releases the fence rails or locks it in place.
• Adjusting Knob: This knob is under the working table surface on the front of the saw. Turn it clockwise will slide the fence rails to right.
Turn it counter-clockwise will slide fence rails to left.
• Outfeed Support: The outfeed support at the back of the tool gives the operator additional support when cutting long workpieces.
• Mitre Gauge: The mitre gauge aligns the wood for a cross cut. The easy-to-read indicator shows the exact angle for a mitre cut, with
positive stops at 0°, 22.5° and 45°.
• Mitre Gauge Grooves: The mitre gauge rides in these grooves on either side of the blade.
• Front Rail: Front rail provides support for the front fence rail and rip fence.
• Rip Fence with a Narrow Fence: A sturdy metal fence guides the workpiece and It can be fixed on three positions of the fence rails
with rip fence lock levers secure in place, the narrow fence can supports workpiece that extends beyond the working table.
• Scale: Located on the front rail, the easy-to-read scale provides precise measurements for rip cuts.
• Riving Knife: A metal piece, slightly thinner than the saw blade, which helps keep the kerf open and prevent kickback.
• Arbor: The shaft on which a blade or cutting tool is mounted.
• Overload Reset Switch: The saw is equipped with the overload reset switch to prevent the saw from overload damage. The saw will
automatically shut off if the machine was with overloaded cutting or low voltage. Wait for the motor to cool down for at least five minutes.
And press the overload reset switch button to resume the overload switch. After the motor has cooled down, press the green “I”-button
on the ON/OFF switch to restart saw.
• Working table: Surface where the workpiece rests while performing a cutting operation.
• Kerf: The material removed by the blade in a through-cut, or the slot produced by the blade in a nonthrough or partial cut.
• Push Stick: A push stick should be used for narrow ripping operations when the fence is 150 mm or less from the blade. These aids
help to keep the operator’s hands well away from the blade.
• Kickback: A hazard that can occur when the blade binds or stalls, throwing the workpiece back toward the operator.
• Ripping or Rip Cut: A cutting operation along the length of the workpiece.
• Bevel Cut: A cutting operation made with the blade at any angle other than 90° to the table surface.
• Compound Cut: A crosscut made with both a mitre angle and a bevel angle.
• Crosscut: A cutting or shaping operation made across the grain or width of the workpiece.
• Mitre Cut: A cutting operation made with the workpiece at any angle other than 90° to the blade.
• Non-Through Cut: Any cutting operation where the blade does not extend completely through the thickness of the workpiece.
• Through-sawing: Any cutting operation where the blade extends completely through the thickness of the workpiece.
• Freehand: Performing a cut without the workpiece being guided by a fence, mitre gauge, or other aid Never perform any cut freehand
with this saw.
WARNING: Do not use blades rated less than the speed of this tool. Failure to heed this warning could result in personal injury.
WARNING: Be careful of your hand. Blade are sharp. Wear work gloves when removing or installing blades.

1 2
17
28
3
4
7
8
9
20
21
24
25
11
12
13
26
14
15
5
6
18
10
22
23
16
27
19
8
English
OVERVIEW

29
40
39
38
37
35
3
30
41
42
44
43
45
46
31
32
33
34
47
48
49
36
9
English
Blade guard
1Blade wrench 14 Stand support assembly 26 Push stick 38
Narrow fence
2Outfeed support 15 Scale 27 Handle II 39
Rip fence lock lever
3Riving knife 16 Mitre gauge 28 Lock knob 40
Adjusting knob
4Rear rail 17 Table insert 29 Working table 41
Handle I
5Rip fence 18 Saw blade 30 Front fence rail 42
Adjustable foot
6Blade guard storage 19 Mitre gauge groove 31 Rip fence scale indicator 43
Bevel scale
7Foot mat 20 Lock pin 32 Mitre gauge lock knob 44
Bevel indicator
8Height/bevel adjusting handwheel 21 Dust extraction port 33 Blade wrench storage 45
Overload reset switch
9Height adjusting knob 22 Small baffle 34 Power cord storage 46
Foot
10 Bevel lock lever 23 Anti-kickback pawls storage 35 Mitre gauge storage 47
Stand leg
11 Switch assembly 24 Push stick storage 36 Anti-kickback pawls 48
Wheel
12 Front rail 25 Fence rails lock lever 37 Rear fence rail 49
Power cord
13

10
English
230-240V~, 50HzInput Voltage
Power Input
No Load Speed no
Blade Size
Bevel Range
Working Table Size
Outfeed Support Size
Max. cutting depth at 0°
Max. cutting depth at 45°
Max. rip to left to blade
1500W
4500/min
ø254mm × ø30mm × 2.8mm, 40T
0°~45°
730mm x 559mm
730mm x 50mm
79mm
57mm
440mm
Max. rip to right to blade 880mm
Protection class II/
Weight 44kg
SPECIFICATIONS

A
C
E
D
F
G
T
V
U
M
H
O
J
QK
I
L
O
P
N
R
N
BS
11
English
DESCRIPTIONPART
A
B
C
D
E
F
G
H
I
QUANTITY
1
1
1
1
1
1
1
Table saw assembly
Mitre gauge (in stored position)
Blade guard assembly (in stored position)
Anti-kickback pawls assembly (in stored position)
1Outfeed support assembly
Rip fence assembly (in stored position)
Push stick (in stored position)
Stand support assembly
Wheel shaft 1
JWheels 2
KStand assembly 1
LHandle I assembly 1
MFlat round head screws M8 x 45 4
NLock nuts M8 6
OFlat round head screws M8 x 10 4
PFlat round head screws M8 x 100 2
QBig flat washers 10 2
RLock nuts M10 2
SBlade wrenches 2
T5mm Hex key 1
U4mm Hex key 1
V2.5mm Hex key 1
The following items are included with your table saw:
LOOSE PARTS

51
54
26
51
45
52
53
50
12
English
This product requires assembly.
◌ Carefully lift saw from the carton and place it on a level work surface.
◌ Inspect the tool carefully to make sure that no breakage or damage occurred during shipping.
◌ Do not discard the packing material until you have carefully inspected and satisfactorily operated the tool.
◌ The saw is factory set for accurate cutting. After assembling it, check for accuracy. If shipping has influenced the settings, refer to
specific procedures explained in this Operator’s Manual.
◌ If any part is missing or damaged, do not attempt to assemble the table saw, plug in the power cord, or turn the switch ON until the
missing or damaged part is obtained and is installed correctly.
Items not supplied
◌Flat head screwdriver
◌Screwdriver
◌13mm wrench / Adjustment wrench
◌Framing square
◌Triangle square
Fig. 1a Fig. 1b
Items supplied
◌Blade wrench (2 pc)
◌2.5mm Hex key (1 pc)
◌4mm Hex key (1 pc)
◌5mm Hex key (1 pc)
UNPACKING YOUR TABLE SAW
YOU WILL NEED
◌Place cardboard or an old blanket on floor in order to protect the surface of the working table.
◌Place the table saw assembly (50) upside down on the protective material.
◌Attach the stand assembly (51) to the table saw assembly (50) with four flat round head screws M8 x 45 (52) and four lock nut M8 (53)
(two holes on the side board of the stand assembly located on the blade wrench storage). (Fig. 1a)
◌Attach the tubes of the stand support assembly (26) with the corresponding tubes (located on side of blade wrench storage (45)) on
the stand assembly (51) and align the holes. Insert the flat round head screws M8 x 10 (54) into the hole and tighten with 5mm hex key.
(Fig. 1b)
ASSEMBLE THE STAND (Fig. 1a-1e)
CAUTION: This tool is heavy. To avoid back injury, lift with your legs, not your back, and get help when needed.
WARINING: Remove the protective polyfoam from between the saw’s housing and the motor.
WARINING: The use of attachments or accessories not listed in this manual might be hazardous and could cause serious personal
injury.
WARINING: Do not attempt to modify this tool or create accessories not recommended for use with this tool. Any such alteration or
modification is misuse, and could result in a hazardous condition leading to possible serious personal injury.
WARINING: Do not connect to the power supply until assembly is complete. Failure to comply could result in accidental starting and
possible serious personal injury.
WARINING: Always make sure the table saw is securely mounted to the stand. Failure to heed this warning can result in serious
personal injury.
WARINING: To avoid injury, do not connect this table saw to a power source until it is completely assembled and adjusted and you
have read and understood the operator’s manual.
CAUTION: Many of the illustrations in this manual show only portions of the table saw. This is intentional so that we can clearly show
points being made in the illustrations. Never operate the saw without all guards securely in place and in good operating
condition.
ASSEMBLY

55
57
56
12
58
53
51
59
5
54
51
5
12
32
11
37
26
13
English
Fig. 1c
Fig. 1e
Fig. 2a
Fig. 1d
◌Slide one wheel (12), one big flat washer 10 (55) and one lock nut M10 (56) onto the wheel shaft (57), secure wheel in place by tightening
the lock nut M10. Repeat with the second wheel. (Fig. 1c)
◌Attach the wheel assembly (58) to the stand assembly (51) with two flat round head screws M8 x 100 (59) and two lock nut M8 (53).
(Fig. 1d)
◌Attach the tubes of the handle I assembly (5) with the corresponding tubes (located on side of blade guard storage) on the stand
assembly (51) and align the holes. Insert the flat round head screws M8 x 10 (54) into the hole and tighten with 5 mm hex key. (Fig. 1e)
◌Push the fence rails lock lever (37) toward the front of the saw to lock it. (Fig. 2a)
◌Grasp the handle I (5) and tilt saw back onto wheels until the stand is balanced on the wheels (12) and stand support assembly (26).
(Fig. 2a)
◌Fold out two upper stand legs (11) (located on side of the handle I). To do this, push the lock pins (32) until they unlock the stand legs
(11) from the holes, then swing the stand legs (11) upward until the stand legs (11) are locked with the lock pins (32) engage the holes.
(Fig. 2a)
OPEN THE STAND (Fig. 2a-2d)

5
32
11
26
6
14
English
Fig. 2b
Fig. 2d
Fig. 3
Fig. 2c
◌ Grasp the handle I (5) firmly and slowly tilt saw downward until the saw is balanced on the ground. (Fig. 2b-2c)
◌ Grasp the stand support assembly (26) and lift it up until two other stand legs (11) leaving off the ground, then fold out two stand legs
(11). To do this, push the lock pins (32) until they unlock the stand legs (11) from the holes, then swing the stand legs (11) downward
until the stand legs are locked with the lock pins (32) engage the holes. (Fig. 2c) Make sure the table saw is balanced with four leg
stands stand on the floor.
◌ Fig. 2d is the leg stand assembly in an open position.
With the stand open, resting on a level surface, the stand should not move or rock from side to side. If the stand rocks from side to side,
the adjustable foot (6) need adjusting until the stand is balanced.
◌ Lift the stand slightly so that you may turn the adjustable foot (6) until the stand no longer rocks.
◌ Turning clockwise will lower the foot.
◌ Turning counter-clockwise will raise the foot.
TO SECURE/LEVEL THE STAND (Fig. 3)
WARINING: Keep your fingers clear of the hinge points while opening the stand. Danger of fingers being crushed or contused.
WARINING: The table saw must be secured. A table saw that is not properly secured may move or tip over.

22
23
21
60
29
61
23
22
16
16
16 16
61
61
40
40
15
English
Fig. 4a Fig. 4b
Fig. 5a Fig. 5b
◌Lower the blade all the way to down position by turning the height adjusting knob (22) counter-clockwise.
◌Lock the blade by turning bevel lock lever (23) clockwise.
◌To remove the table insert: Turn the lock knob (40) counter-clockwise to unlock the table insert (29). Place your index finger in the
hole, pulling the table insert (29) out toward the front of the saw.
◌To reinstall the table insert: Push the table insert (29) down, turn the lock knob (40) clockwise to lock the table insert in place. When
the table insert is not level with the saw table, using a 2.5 mm hex key (supplied), adjust the four set screws (60) pre-assembled to the
table located on the four holes of the table insert until the table insert is level with the working table.
TO REMOVE/REPLACE/ALIGN THE TABLE INSERT (Fig. 4a-4b)
WARINING: The table insert must be level with the saw table. If the table insert is too high or too low, the workpiece can catch on the
uneven edges, resulting in binding or kickback, which could result in serious personal injury.
WARINING: Be care of your hands avoided to be striked with the saw blade which could result in serious personal injury when removing
or reinstalling the table insert.
Through cutting riving knife installation
◌Unplug the saw.
◌Remove the table insert.
◌Set the saw blade angle to 0°.
◌Raise the saw blade to the uppermost position by turning the height adjusting knob (22) clockwise.
◌Lock the blade by turning bevel lock lever (23) clockwise.
◌Unlock riving knife lock knob (61) by turning it clockwise.
◌Grasp the riving knife (16) and pull toward right side of saw to release it from spring-loaded lock pin.
◌Position the riving knife in the uppermost position with springloaded lock pin is re-engaged.
◌Lock the riving knife lock knob (61) by turning it counter-clockwise.
◌Reinstall the table insert.
To place riving knife in middle position, refer to the above procedure.
TO INSTALL THE RIVING KNIFE (Fig. 5a-5b)
CAUTION: This saw is shipped with riving knife in “MIDDLE” position. Riving knife must be placed in uppermost position to attach
anti-kickback pawls and blade guard for all through cut operations. The “MIDDLE” position is for non-through cuts (with
blade guard and anti-kickback pawls removed).
WARINING: Be extremely careful when adjust the riving knife position. Do not allow hands to contact blade.

14
63
64
16
65
66
14
30
30
30
62
65
64
63
3-8mm
1
2
48
35
67
16
English
Fig. 6a
Fig. 6b
Fig. 7a
◌Unplug the saw.
◌Turn height adjustment knob clockwise to raise blade to maximum height.
◌Remove the table insert.
◌Set the saw blade angle to 0° and raise the saw blade to the uppermost position.
◌Remove the blade wrenches from storage area.
Remove the blade:
◌Using one opened-ended blade wrench (14), place the flat open end on the flats
on the inner blade flange (62).
◌Using the other opened-ended blade wrench (14), place the flat open end on
the flats on the arbor nut (64). Holding both wrenches firmly, pull the opened-
ended blade wrench on the arbor nut (64) forward to the front of the machine.
◌Remove arbor nut (64), outer blade flange (65), saw blade (30) and ring (66).
◌Lower the saw blade to lowest position and replace table insert.
◌Unplug the saw.
◌Set the blade angle to 0°.
◌Raise the saw blade to maximum height by turning height adjusting knob
clockwise.
◌Lock the blade by turning bevel lock lever clockwise.
◌Place the riving knife in the highest position.
◌Pull out and hold knob (67) and push anti-kickback pawls up, remove it from
the anti-kickback pawls storage (35) located on inside of the left side of saw.
(Fig. 7a)
REMOVING AND INSTALLING THE BLADE (Fig. 6a-6b)
CAUTION: Check the arbor hole diameter of the blade before installing the blade. Always use the correct ring for the arbor hole of the
blade you intend to use.
CAUTION: To work properly, the saw blade teeth must point down toward the front of the saw. Failure to heed this instruction could
cause damage to the saw blade, the saw or the workpiece.
WARNING: Make sure that the saw blade is installed to rotate in the proper direction. Do not use grinding wheels, wire brushes, or
abrasive wheels on a table saw. Improper saw blade installation or use of accessories not recommended may cause
serious injury.
CAUTION: The ring 30 mm in outer diameter is factory-installed onto the arbor.
WARNING: The large, flat surface of the outer blade flange faces the saw
blade and the saw blade (30) is firmly seated against the inner
blade flange (62).
WARNING: The saw blade (30) should be aligned with the riving knife (16)
and ensuring there is a gap of 3 to 8 mm between the blade teeth
and the riving knife (16).
WARNING: If the inner blade flange has been removed, reinstall it before
placing the saw blade on arbor. Failure to do so could cause an
accident.
WARNING: Be extremely careful when loosening arbor nut. Keep firm grasp
on both wrenches. Do not allow hands to slip and contact blade.
WARNING: Make sure the anti-kickback pawls are reinstalled immediately
after finishing any non-through cut operations which require their
removal.
WARNING: Replace dull or damaged anti-kickback pawls. Dull or damaged
anti-kickback pawls may not stop a kickback, increasing the risk
of serious personal injury.
WARNING: Only use a 254 mm diameter blade. To avoid injury from an accidental start, make sure the switch is in the OFF position
and the plug is not connected to the power source outlet.
WARNING: Be extremely careful when loosening arbor nut. Keep firm grasp on both wrenches. Do not allow hands to slip and contact
blade.
ANTI-KICKBACK PAWLS INSTALLATION (Fig. 7a-7b)
Anti-kickback pawls should only be installed for through cuts.
Install the blade:
◌Place the ring (66) and one new blade on arbor (63). Make sure saw blade teeth
point down at the front side of saw table. Place outer blade flange (65) and arbor
nut (64) on arbor and use blade wrenches to tighten nut securely. DO NOT over
tighten.

16
71
48
67
70
68
6967
2
1
19
72
1
19
74
72 73
16
75
76
1
72 72
1
77
17
English
Fig. 7b
Fig. 8a
Fig. 8b
Fig. 8c
WARNING: KEEP GUARDS IN PLACE and in good working order for all through
cut operations. Reinstall the blade guard immediatelyafter finishing
any non-through cut operations which require removal of the blade
guard. Failure to heed this instruction could result in serious
personal injury.
WARNING: After the installation, check the blade guard to ensure that it is
properly placed and workable before operation the saw.
WARNING: When using the blade guard, lift the left and right blade guard and
make sure that they move independently and contact the table
surface. The blade guard can be raised to adjust the cut line, but
must be lowered to contact the table surface before starting the
saw.
WARNING: Make sure blade guard and anti-kickback pawls move freely before
starting the saw. Ensure the direction of rotation by checking blade
teeth point down at the front side of saw table.
◌Pull out and hold knob (67). Align slot in anti-kickback pawls (48) over the slot
A (68) indicated of riving knife (16). Place the spring pin (69) on the anti-kickback
pawls (48) into the slot (A) (68) indicated on the riving knife (16).
◌Press anti-kickback pawls (48) down until it snaps into place and release knob
(67) to insert the pin (70) into hole (71) indicated on the riving knife (16).
◌Unplug the saw.
◌Hold the knobs (72) (one on either side of the blade guard) and push the knobs
forward to the front of the blade guard and up until the pin comes out from the
slot in the mounting bracket (blade guard storage) (19) at bottom front right side
of the saw, then remove the blade guard from the U-bracket (blade guard storage)
(19) at bottom middle right side of the saw (Fig. 8a).
◌Hold and push knobs (72) forward to the front of the blade guard. Place the pins
(73, 74) on the blade guard (1) into the slot B (75) and slot C (76) indicated on
the riving knife (16). (Fig. 8b)
◌Pull blade guard fully back onto riving knife. Push pin and release it to lock guard
into position.
◌If blade guard is not parallel to table when riving knife is in uppermost position
(through cuts), adjust the set screw (77) as necessary. (Fig. 8c)
CAUTION: Pull up on anti-kickback pawl assembly to make sure it is secured
to riving knife.
WARNING: Gently pull up the anti-kickback pawls to ensure it is locked into
place. Make sure that the anti-kickback pawls move freely and
are not stuck in the table insert slot.
WARNING: Use extra caution when cutting wood products having slippery
surface as the anti-kickback pawls may not always be effective.
BLADE GUARD INSTALLATION (Fig. 8a-8c)

79
15
78
78
79
80
15
18
3
37 A
B
B
A
C
C42
49
81
81
81
81
81
81
A
B
B
A
C
C
18
English
Fig. 9a Fig. 9b
Fig. 10a Fig. 10b
◌Loosen and remove two stop screws (78) on the extension poles (79) of the outfeed support (15).
◌Loosen the locking knobs (80) under the working table counterclockwise.
◌Insert the rear extension poles (79) into the two holes in the rear of the working table and into the extension tube brackets that are
located under the working table.
Position the outfeed support (15).
◌Thread the locking knobs (80) into the holes under the working table and tighten them.
◌Thread the two stop screws (78) into the holes located on ends of the extension poles (79) and tighten them.
CAUTION: There are three position screws (81) (position A, B, C) on the each front and rear fence rails (42, 49) to attach rip fence.
Position screws (81) (position A and B) use for rip fence on the right of saw blade. Position screws (81) (position C) use
for rip fence on the left of saw blade. (Fig. 10b)
CAUTION: The rip fence should be parallel to the saw blade. If not, refer to the section “Aligning rip fence to blade” (Page 29).
CAUTION: Three position screws (81) (position A, B, C) apply to three different scales:
Position screw (Position A): Begin with 0 to 680 mm end. (Rip fence located on the right of the blade)
Position screw (Position B): Begin with 200 mm to 880 mm end. (Rip fence located on the right of the blade)
Position screw (Position C): Begin with 0 to 440 mm end. (Rip fence located on the left of the blade)
OUTFEED SUPPORT ASSEMBLY INSTALLATION (Fig. 9a-9b)
◌Push down the fence rails lock lever (37) toward the rear of the saw to unlock it.
◌Open the rip fence lock levers (3) located on two ends of the rip fence (18), then remove the rip fence (18) from the front and rear fence
rails (42, 49).
◌Align the fence slots (82) with the position screws (front and back) on the fence rails.
◌Push the slots (82) down onto the position screws and secure the rip fence in place by pushing the rip fence lock levers (3) down.
◌Lock the fence rails lock lever (37).
RIP FENCE INSTALLATION (Fig. 10a-10c)

1
2
28
28
31
47
83
19
English
Fig. 10c
Fig. 11a Fig. 11b
Fig. 12a Fig. 12b Fig. 12c
The mitre gauge (28) can be installed on each mitre gauge groove (31) on either side of blade.
◌Remove the mitre gauge (28) from mitre gauge storage (47) located on inside of the right side of saw.
◌Slide the guide rail (83) of the mitre gauge (28) into one of the guide grooves (31) of the saw table intended for this purpose.
MITRE GAUGE INSTALLATION (Fig. 11a-11b)
◌The table saw has two convenient storage areas (one on either side and back of the saw) specifically designed for the saw’s accessories:
rip fence (18), blade guard (1), push stick (38), blade wrenches (14), power cord (13), anti-kickback pawls (48) and mitre gauge (28).
◌When not in use, store accessories securely.
TO STORE THE TABLE SAW ACCESSORIES (Fig. 12a-12c)
82
3
18
37
CA
B
48
18
14
13
28 1
1
18
38

26
32
11
32
32
12
26
11
26
12
5
12
5
5
5
12
20
English
Fig. 13a
Fig. 13b Fig. 13c
Fig. 13d Fig. 13fFig. 13e
WARNING: Keep your fingers clear of the hinge points while folding the stand. Danger of fingers being crushed or contused.
◌To fold the stand for moving, return fence rails and lock the fence rails lock lever and return outfeed support to inner position. Store the
accessories securely.
◌Grasp the stand support assembly (26) and lift it up until two stand legs (11) (located on side of the wheel) leaving off the ground, then
fold in two stand legs (11). To do this, push the lock pins (32) until they unlock the stand legs (11) from the holes, then swing the stand
legs (11) upward until the stand legs are locked with the lock pins (32) engage the holes.
◌Grasp the handle I (5) and tilt saw back onto wheels until the stand is balanced on the wheels (12) and stand support assembly (26).
(Fig. 13b-13c)
◌Fold in other two stand legs (11). To do this, push the lock pins (32) until they unlock the stand legs (11) from holes, then swing the
stand legs downward until the stand legs are locked with the lock pins (32) engage the holes.
◌Grasp the handle I (5) firmly and tilt saw to you, push the saw to the desired location (Fig. 13e) then either open the stand or store the
saw (Fig. 13d & 13f) in a dry environment.
FOLDING THE STAND (Fig. 13a-13f)
