Hilti TE 30-A36 User manual

TE 30A36
English 1
Français 15
Español 30
Português 45
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

1
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

2
3
4
5
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

6
7
8
9
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

TE 30A36
en Original operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 1
fr Moded'emploioriginal ............................... 15
es Manual de instrucciones original . . . . . . . . . . . . . . . . . . . . . . . 30
pt Manual de instruções original . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

*2173713* 2173713 English 1
1 Information about the documentation
1.1 About this documentation
• Read this documentation before initial operation or use. This is a
prerequisite for safe, trouble-free handling and use of the product.
• Observe the safety instructions and warnings in this documentation and
on the product.
• Always keep the operating instructions with the product and make sure
that the operating instructions are with the product when it is given to
other persons.
1.2 Explanation of symbols used
1.2.1 Warnings
Warnings alert persons to hazards that occur when handling or using the
product. The following signal words are used:
DANGER
DANGER !
▶Draws attention to imminent danger that will lead to serious personal
injury or fatality.
WARNING
WARNING !
▶Draws attention to a potential threat of danger that can lead to serious
injury or fatality.
CAUTION
CAUTION !
▶Draws attention to a potentially dangerous situation that could lead to
slight personal injury or damage to the equipment or other property.
1.2.2 Symbols in the documentation
The following symbols are used in this document:
Read the operating instructions before use.
Instructions for use and other useful information
Dealing with recyclable materials
Do not dispose of electric equipment and batteries as household
waste
1.2.3 Symbols in the illustrations
The following symbols are used in illustrations:
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

2 English 2173713 *2173713*
These numbers refer to the corresponding illustrations found at the
beginning of these operating instructions
The numbering reflects the sequence of operations shown in the
illustrations and may deviate from the steps described in the text
Item reference numbers are used in the overview illustrations and
refer to the numbers used in the product overview section
This symbol is intended to draw special attention to certain points
when handling the product.
1.3 Product-dependent symbols
1.3.1 Symbols on the product
The following symbols are used on the product:
Drilling without hammering action
Drilling with hammering action (hammer drilling)
Chiseling
Chisel positioning
Forward / reverse
Diameter
Rated speed under no load
Revolutions per minute
1.4 Product information
products are designed for professional users and only trained,
authorized personnel are permitted to operate, service and maintain the
products. This personnel must be specifically informed about the possible
hazards. The product and its ancillary equipment can present hazards if
used incorrectly by untrained personnel or if used not in accordance with
the intended use.
The type designation and serial number are printed on the rating plate.
▶Write down the serial number in the table below. You will be required to
state the product details when contacting Hilti Service or your local Hilti
organization to inquire about the product.
Product information
Combihammer TE 30A36
Generation 03
Serial no.
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

*2173713* 2173713 English 3
1.5 Declaration of conformity
We declare, on our sole responsibility, that the product described here
complies with the applicable directives and standards. A copy of the
declaration issued by the certification department can be found at the end
of this documentation.
The technical documentation is filed here:
Hilti Entwicklungsgesellschaft mbH | Tool Certification | Hiltistrasse 6 | 86916
Kaufering, Germany
2 Safety
2.1 General power tool safety warnings
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
Work area safety
▶Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
▶Do not operate power tools in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
▶Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
▶Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
▶Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
Personal safety
▶Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in serious personal
injury.
▶Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
▶Prevent unintentional starting. Ensure the switch is in the off‐position
before connecting to battery pack, picking up or carrying the tool.
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

4 English 2173713 *2173713*
Carrying power tools with your finger on the switch or energising power
tools that have the switch on invites accidents.
▶Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
▶Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
▶Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
▶If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
Power tool use and care
▶Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
▶Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
▶Disconnect the battery pack from the power tool before making any
adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool
accidentally.
▶Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these instructions
to operate the power tool. Power tools are dangerous in the hands of
untrained users.
▶Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power
tools.
▶Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
▶Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and
the work to be performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
Battery tool use and care
▶Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of
fire when used with another battery pack.
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

*2173713* 2173713 English 5
▶Use power tools only with specifically designated battery packs. Use
of any other battery packs may create a risk of injury and fire.
▶When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a
fire.
▶Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
Service
▶Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
2.2 Hammer safety warnings
▶Wear ear protectors. Exposure to noise can cause hearing loss.
▶Use auxiliary handles, if supplied with the tool. Loss of control can
cause personal injury.
▶Hold power tool by insulated gripping surfaces, when performing an
operation where the cutting accessory may contact hidden wiring..
Cutting accessory contacting a "live" wire may make exposed metal parts
of the power tool "live" and could give the operator an electric shock.
2.3 Additional safety instructions for breakers
Personal safety
▶Use the product only when it is in technically faultless condition.
▶Never tamper with or modify the tool in any way.
▶When chiseling into ceilings, walls and floors, always make sure that you
have a safe and firm stance. A sudden break-through can affect your
balance!
▶Apply appropriate safety measures at the opposite side of the workpiece
in work that involves breaking through. Parts breaking away could fall out
and / or fall down causing injury to other persons.
▶You and any other persons in the vicinity must wear suitable eye pro-
tection, a hard hat, ear protection, protective gloves and respiratory
protection while the tool is in use.
▶Wear protective gloves also when changing the accessory tool. Touching
the accessory tool can result in cuts and burns.
▶Wear eye protection. Flying fragments can injure the body and eyes.
▶Before starting work, check the hazard class of the dust that will be pro-
duced when working. Use an industrial vacuum cleaner with an officially
approved protection class in compliance with the locally applicable dust
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

6 English 2173713 *2173713*
protection regulations. Dust from materials such as lead-based paint,
certain types of wood and concrete/masonry/stone containing quartz,
minerals or metal can be harmful to health.
▶Make sure that the workplace is well ventilated and, where necessary,
wear a respirator appropriate for the type of dust generated. Contact with
or inhalation of the dust may cause allergic reactions and/or respiratory
or other diseases among operators or bystanders. Certain kinds of dust
are classified as carcinogenic such as oak and beech dust, especially
in conjunction with additives for wood conditioning (chromate, wood
preservative). Material containing asbestos may be handled only by
specialists.
▶Take breaks and do physical exercises to improve the blood circulation
in your fingers. Exposure to vibration during long periods of work can
lead to disorders of the blood vessels and nervous system in the fingers,
hands and wrists.
Electrical safety
▶Before beginning work, check the working area for concealed electric
cables or gas and water pipes. External metal parts of the power tool
can become live, presenting a risk of electric shock, if you accidentally
damage an electric cable.
Careful handling and use of electric tools
▶Wait until the power tool stops completely before you lay it down.
3 Description
3.1 Product overview 1
@Chuck
;Depth gauge release button
=Depth gauge
%Function selector switch
&Forward / reverse switch
(Control switch
)Battery state of charge / fault
display
+Release buttons / battery state
of charge display
§Battery
/Side handle
3.2 Intended use
The product described is a cordless (battery-powered) combihammer with
pneumatic hammering mechanism. It is designed for drilling in concrete,
masonry, wood and metal. The product can also be used for light to medium-
duty chiseling on masonry and surface finishing work on concrete.
▶Use only Hilti Li-ion batteries from the B 36 series with this product.
▶Use only the Hilti battery chargers from the C4/36 series for these
batteries.
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

*2173713* 2173713 English 7
3.3 Possible misuse
• This product is not suitable for working on hazardous materials.
• This product is not suitable for working in a damp environment.
3.4 ATC
The power tool is equipped with the ATC (Active Torque Control) quick-
acting electronic cut-out.
If the accessory tool sticks or stalls, the power tool will suddenly pivot about
its own axis in the opposite direction. ATC detects this sudden pivoting
movement of the power tool and switches the tool off immediately.
For ATC to function correctly, the power tool must be free to pivot.
After the power tool has cut out due to ATC, switch it back on again by
releasing the control switch for a moment and then pressing the switch
again.
3.5 Motor protection system
The tool is equipped with a motor protection system. The system monitors
current input and motor temperature and thus prevents the tool from
overheating.
If the motor is overloaded through application of excessive working pressure,
the power tool’s performance drops noticeably or it may stall completely.
If the power tool stalls or slows significantly due to overloading, release the
pressure applied to the tool and then allow it to run under no load for approx.
30 seconds.
3.6 Lithiumion battery status display
The Li-ion battery state of charge and malfunctions of the power tool are
indicated by the display on the Liion battery. The Liion battery state of
charge is displayed after pressing one of the two battery release buttons.
Status Meaning
4 LEDs light. State of charge: 75 % to 100 %
3 LEDs light. State of charge: 50 % to 75 %
2 LEDs light. State of charge: 25 % to 50 %
1 LED lights. State of charge: 10 % to 25 %
1 LED blinks. State of charge: < 10 %
1 LED blinks, the power tool is not
ready for use.
The battery has overheated or is
completely discharged.
4 LEDs blink, the power tool is not
ready for use.
The power tool is overloaded or has
overheated.
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

8 English 2173713 *2173713*
Battery state of charge cannot be displayed while the control switch is
pressed and for up to 5 seconds after releasing the control switch.
If the battery display LEDs blink, please observe the instructions given
in the Troubleshooting section.
3.7 Items supplied
Combihammer, side handle with depth gauge, operating instructions.
To help ensure safe and reliable operation, use only genuine Hilti spare
parts and consumables. Spare parts, consumables and accessories
approved by Hilti for use with the product can be found at your local
Hilti Center or online at: www.hilti.com
4 Technical data
TE 30A36
Rated voltage 36 V
Weight 11.2 lb
(5.1 kg)
5 Operation
5.1 Preparations at the workplace
CAUTION
Risk of injury by inadvertent starting!
▶Before inserting the battery, make sure that the product is switched off.
▶Remove the battery before making any adjustments to the power tool or
before changing accessories.
Observe the safety instructions and warnings in this documentation and on
the product.
5.1.1 Inserting the battery 2
1. Push the battery into the battery holder until it engages with an audible
click.
2. Check that the battery is seated securely.
5.1.2 Removing the battery 3
1. Press the release buttons on the battery.
2. Pull the battery out toward the rear.
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

*2173713* 2173713 English 9
5.1.3 Charging the battery
Make sure that the outer surfaces of the battery are clean and dry before
inserting the battery in the approved battery charger.
Read the operating instructions for the charger for further information
about the charging process.
▶Use an approved charger to charge the battery.
5.1.4 Fitting the side handle 4
CAUTION
Risk of injury! Loss of control over the rotary hammer drill.
▶Check that the side handle is fitted correctly and tightened securely.
Check that the clamping band is engaged in the groove in the tool.
1. Release the side handle clamping band by turning the handle grip.
2. Slide the side handle clamping band over the chuck from the front and
into the recess provided.
3. Set the side handle to the desired position.
4. Tighten the side handle clamping band by turning the handle grip.
5.1.5 Adjusting the depth gauge (optional) 5
1. Press the release button on the side handle.
2. Adjust the depth gauge to the desired drilling depth.
3. Release the release button.
4. Check that the side handle is securely attached.
5.1.6 Removing the chuck 6
CAUTION
Risk of injury. The depth gauge, if fitted but not used, might hinder the
operator.
▶Remove the depth gauge from the product.
Set the function selector switch to the “Chiseling” position for
changing the chuck.
1. Remove the battery from the tool.
2. Grip the chuck as shown in the illustration and pull the three chuck release
rings upwards.
3. Lift the chuck upwards away from the tool.
5.1.7 Fitting the chuck 6
CAUTION
Risk of injury. The depth gauge, if fitted but not used, might hinder the
operator.
▶Remove the depth gauge from the product.
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

10 English 2173713 *2173713*
When changing the chuck, set the function selector switch to this
position: .
1. Remove the battery from the tool.
2. Grip the chuck as shown in the illustration and pull the three chuck release
rings upwards.
3. Fit the chuck onto the chuck mount.
4. Rotate the chuck until it engages in position.
5.1.8 Inserting the tool 7
1. Lightly grease the connection end of the accessory tool.
➥ Use only genuine Hilti grease. Using the wrong grease can result in
damage to the tool.
2. Push the accessory tool into the chuck as far as it will go (until it engages).
3. After fitting the accessory tool, grip it and pull it in order to check that it is
securely engaged.
➥ The product is ready for use.
5.1.9 Removing the accessory tool 7
CAUTION
Risk of injury! The accessory tool gets hot during use.
▶Wear protective gloves when changing the accessory tool.
▶Do not place the hot accessory tool on readily flammable materials.
▶Pull the chuck back as far as it will go and remove the accessory tool.
5.2 Types of work
ATTENTION
Risk of damage by incorrect handling!
▶Do not operate the switches for direction of rotation and/or function
selection during operation.
Observe the safety instructions and warnings in this documentation and on
the product.
5.2.1 Function selector switch 8
▶Set the function selector switch to the desired working position.
➥ Do not operate the function selector switch while the motor is running.
Risk of damage!
5.2.2 Drilling without hammering
▶Set the function selector switch to this symbol: .
5.2.3 Drilling with hammering action (hammer drilling)
▶Set the function selector switch to this symbol: .
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

*2173713* 2173713 English 11
5.2.4 Chisel positioning
▶Set the function selector switch to this symbol: .
➥ The chisel can be adjusted to 12 different positions (in 30° increments).
This ensures that flat chisels and shaped chisels can always be set to
the optimum working position.
5.2.5 Chiseling
▶Set the function selector switch to this symbol: .
5.2.6 Forward / reverse 9
▶Set the forward / reverse switch to the desired direction of rotation.
6 Care and maintenance
WARNING
Risk of injury with battery inserted !
▶Always remove the battery before carrying out care and maintenance
tasks!
Care and maintenance of the tool
• Carefully remove stubborn dirt.
• Clean the air vents carefully with a dry brush.
• Use only a slightly damp cloth to clean the casing. Do not use cleaning
agents containing silicone as these can attack the plastic parts.
Care of the Liion batteries
• Keep the battery free from oil and grease.
• Use only a slightly damp cloth to clean the casing. Do not use cleaning
agents containing silicone as these may attack the plastic parts.
• Avoid ingress of moisture.
Maintenance
• Check all visible parts and controls for signs of damage at regular intervals
and make sure that they all function correctly.
• Do not operate the product if signs of damage are found or if parts
malfunction. Have it repaired immediately by Hilti Service.
• After cleaning and maintenance, fit all guards or protective devices and
check that they function correctly.
To help ensure safe and reliable operation, use only genuine Hilti spare
parts and consumables. Spare parts, consumables and accessories
approved by Hilti for use with the product can be found at your local
Hilti Store or online at: www.hilti.group.
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

12 English 2173713 *2173713*
7 Transport and storage of cordless tools
Transport
CAUTION
Accidental starting during transport !
▶Always transport your products with the batteries removed!
▶Remove the battery.
▶Never transport batteries in bulk form (loose, unprotected).
▶Check the tool and batteries for damage before use after long periods of
transport.
Storage
CAUTION
Accidental damage caused by defective or leaking batteries !
▶Always store your products with the batteries removed!
▶Store the tool and batteries in a place that is as cool and dry as possible.
▶Never store batteries in direct sunlight, on heating units or behind a
window pane.
▶Store the tool and batteries in a place where they cannot be accessed by
children or unauthorized persons.
▶Check the tool and batteries for damage before use after long periods of
storage.
8 Troubleshooting
If the trouble you are experiencing is not listed in this table or you are unable
to remedy the problem by yourself, please contact Hilti Service.
8.1 The combihammer is in working order.
Trouble or fault Possible cause Action to be taken
The battery runs
down more quickly
than usual.
Battery condition is not
optimal.
▶Replace the battery.
The battery doesn’t
engage with an audi-
ble click.
The retaining lugs on the
battery are dirty.
▶Clean the retaining
lugs and refit the
battery.
The control switch
can’t be pressed, i.e.
the switch is locked.
The forward / reverse
switch is in the middle
position.
▶Push the forward /
reverse switch to the
right or left.
The drive spindle
doesn’t rotate.
The permissible operat-
ing temperature of the
combihammer’s elec-
tronics has been ex-
ceeded.
▶Allow the combiham-
mer to cool down.
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

*2173713* 2173713 English 13
Trouble or fault Possible cause Action to be taken
The drive spindle
doesn’t rotate.
The battery is
discharged.
▶Change the battery
and charge the empty
battery.
The combihammer
switches itself off
automatically.
The overload cut-out
has been activated.
▶Release the control
switch. Allow the
combihammer to cool
down. Press the
control switch again.
Reduce the load on
the tool.
The combihammer
or the battery gets
very hot.
Electrical fault. ▶Switch the combiham-
mer off immediately.
Remove the battery
and keep it under
observation. Allow it
to cool down. Contact
Hilti service.
The combihammer has
been overloaded (appli-
cation limits exceeded).
▶Select a tool that
is suitable for the
intended purpose.
The insert tool can’t
be released.
Chuck not pulled back
fully.
▶Pull the chuck back
as far as it will go and
remove the accessory
tool.
The drill bit makes
no progress.
The combihammer is
set to run in reverse
rotation.
▶Move the forward / re-
verse selector switch
to the “Forward” posi-
tion.
8.2 The combihammer is not in working order.
Malfunction Possible cause Action to be taken
No LEDs light. The battery is not fully
inserted.
▶Push the battery in
until it engages with a
click.
The battery is
discharged.
▶Change the battery
and charge the empty
battery.
The battery is too hot or
too cold.
▶Bring the battery to
the recommended
working temperature.
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03

14 English 2173713 *2173713*
Malfunction Possible cause Action to be taken
1 LED blinks. The battery is
discharged.
▶Change the battery
and charge the empty
battery.
The battery is too hot or
too cold.
▶Bring the battery to
the recommended
working temperature.
4 LEDs blink. The combihammer has
been overloaded briefly.
▶Release the control
switch and then press
it again.
The overheating preven-
tion cut-out has been
activated.
▶Allow the combiham-
mer to cool down and
clean the air vents.
9 Disposal
Most of the materials from which Hilti tools and appliances are manu-
factured can be recycled. The materials must be correctly separated before
they can be recycled. In many countries, your old tools, machines or appli-
ances can be returned to Hilti for recycling. Ask Hilti Service or your Hilti
representative for further information.
▶Do not dispose of power tools, electronic equipment or batteries as
household waste!
10 Manufacturer’s warranty
▶Please contact your local Hilti representative if you have questions about
the warranty conditions.
Printed: 30.04.2019 | Doc-Nr: PUB / 5351688 / 000 / 03
