Hirschmann MSP30 User manual

Installation MSP30/32
Release 04 07/2014
Technical support
https://hirschmann-support.belden.eu.com
User Manual
Installation
MICE Switch Power
MSP30/32
MSP30/MSP32-0804... MSP30/MSP32-1604...
MSP30/MSP32-2404...

The naming of copyrighted trademarks in this manual, even when not specially indicated, should
not be taken to mean that these names may be considered as free in the sense of the trademark
and tradename protection law and hence that they may be freely used by anyone.
© 2014 Hirschmann Automation and Control GmbH
Manuals and software are protected by copyright. All rights reserved. The copying, reproduction,
translation, conversion into any electronic medium or machine scannable form is not permitted,
either in whole or in part. An exception is the preparation of a backup copy of the software for
your own use. For devices with embedded software, the end-user license agreement on the
enclosed CD/DVD applies.
The performance features described here are binding only if they have been expressly agreed
when the contract was made. This document was produced by Hirschmann Automation and
Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right
to change the contents of this document without prior notice. Hirschmann can give no guarantee
in respect of the correctness or accuracy of the information in this document.
Hirschmann can accept no responsibility for damages, resulting from the use of the network
components or the associated operating software. In addition, we refer to the conditions of use
specified in the license contract.
You can get the latest version of this manual on the Internet at the Hirschmann product site
(www.hirschmann.com).
Printed in Germany
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
Tel.: [phone]
MSP30/32 040 014-001-04-0714 - 27.8.14

Installation MSP30/32
Release 04 07/2014 3
Contents
Safety instructions 5
About this manual 15
Key 15
1 Description 16
1.1 General device description 16
1.2 Device name and product code 17
1.3 Combination options 21
1.4 Device views 22
1.4.1 Front view 22
1.4.2 View from below 23
1.4.3 View from above 24
1.5 Number of ports and connections 25
1.6 Power supply 27
1.6.1 Working voltage with the characteristic value C 27
1.6.2 Working voltage with the characteristic value P 27
1.7 Display elements 27
1.7.1 Device state 27
1.7.2 Digital input 28
1.8 Management interfaces 29
1.8.1 V.24 interface (external management) 29
1.8.2 SD card interface 30
1.8.3 USB interface 30
1.9 Input/output interfaces 31
1.9.1 Signal contact 31
1.9.2 Digital input 31
2 Installation 32
2.1 Checking the package contents 32
2.2 Installing the SD card (optional) 32
2.3 Installing and grounding the device 33
2.3.1 Installing the device onto the DIN rail 33
2.3.2 Grounding the device 34
2.4 Connecting the terminal blocks 35
2.4.1 Working voltage with the characteristic value C 35
2.4.2 Working voltage with the characteristic value P 36

4Installation MSP30/32
Release 04 07/2014
2.4.3 Signal contact 37
2.5 Connecting the ferrite 37
2.6 Installing terminal blocks, switching on the working voltage 38
2.7 Installing media modules 39
3 Basic Settings 40
4 Upgrading Software 41
5 Maintenance and service 42
6Disassembly 43
6.1 Removing a media module 43
6.2 Removing the device 44
7 Technical data 45
A Further Support 57

Installation MSP30/32
Release 04 07/2014 5
Safety instructions
General safety instructions
You operate this device with electricity. The proper and safe operation of
this device depends on proper handling during transportation, proper
storage and assembly, and conscientious operation and maintenance
procedures. Improper use of this device is associated with the risk of
personal injury or property damage.
Read this documentation as well as the safety instructions and warn-
ings before connecting any cables.
Never start operation with damaged components.
The device does not contain any service components. If the device is
not functioning correctly, or if it is damaged, turn off the power supply
and return the device to Hirschmann for inspection.
Qualification requirements for personnel
Only allow qualified personnel to work on the device.
Qualified personnel have the following characteristics:
Qualified personnel are properly trained. Training as well as practical
knowledge and experience make up their qualifications. This is the
prerequisite for grounding and labeling circuits, devices, and systems
in accordance with current standards in safety technology.
Qualified personnel are aware of the dangers that exist in their work.
Qualified personnel are familiar with appropriate measures against
these hazards in order to reduce the risk for themselves and others.
Qualified personnel receive training on a regular basis.
WARNING
UNCONTROLLED MACHINE ACTIONS
To avoid uncontrolled machine actions caused by data loss, configure all
the data transmission devices individually.
Before you start any machine which is controlled via data transmission, be
sure to complete the configuration of all data transmission devices.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.

6Installation MSP30/32
Release 04 07/2014
Intended usage
Use the product only for the application cases described in the
Hirschmann product information, including this manual.
Operate the product only according to the technical specifications.
See “Technical data” on page 45.
Connect to the product only components suitable for the requirements
of the specific application case.
National and international safety regulations
Verify that the electrical installation meets local or nationally applicable
safety regulations.
Grounding the device
Grounding the device is by means of a separate ground connection on the
device.
Ground the device before connecting any other cables.
Disconnect the grounding only after disconnecting all other cables.
The overall shield of a connected shielded twisted pair cable is connected
to the ground connector on the front panel as a conductor.
Working voltage
Connect only a working voltage that corresponds to the type plate of
your device.
Every time you connect the electrical conductors, make sure that the
following requirements are met:
The power supply conforms to overvoltage category I or II.
The power supply has an easily accessible disconnecting device
(e.g., a switch or a plug). This disconnecting device is clearly iden-
tified. So in the case of an emergency, it is clear which discon-
necting device belongs to which power supply cable.
The disconnecting device is clearly identified so that in the case of
an emergency, it is clear which disconnecting device belongs to
which line.
The electrical wires are voltage-free.
A fuse suitable for DC voltage is located in the plus conductor of the
power supply.
Regarding the properties of this fuse: See “General technical data”
on page 45.
A fuse suitable for DC voltage is located in the minus conductor of
the supply voltage, if this is not grounded.
Regarding the properties of this fuse: See “General technical data”
on page 45.
The wire diameter of the supply voltage at the input is at least 1
mm² (North America AWG16).

Installation MSP30/32
Release 04 07/2014 7
The power supply cables used are permitted for the temperature
range required by the application case.
Relevant for North America:
The power cords are suitable for ambient air temperatures of at
least 167 °F (75 °C). The power cord wires are made of copper.
Start connecting the electrical wires only if all the above safety require-
ments are fulfilled.
Use undamaged parts.
Internal fuses are triggered solely in the case of a detected error in the
device. In case of damage or malfunction of the device, turn off the
working voltage and return the device to the plant for inspection.
Only switch on the operating voltage for the device when the following
requirements are fulfilled:
The housing is closed
The terminal blocks are wired correctly
The terminal blocks for the operating supply are connected
Note: The working voltage is connected to the chassis through protective
elements exclusively.
Installation site requirements
Verify that there is at least 4 in (10 cm) of space above and below the
device.
Verify that there is at least 0.8 in (2 cm) of space on the right and left
sides of the device.
Install the device at ambient temperatures greater than 113 °F (45 °C)
in “restricted access locations” based on EN 60950-1 exclusively.
Housing
Only technicians authorized by the manufacturer are permitted to open
the housing.
The switch basic module is an inseparable unit. The switch basic
module may be damaged by detachment of the display and connec-
tion part.
Keep the ventilation slits free to ensure good air circulation.
Make sure there is at least 3.94 inches (10 cm) of space in front of the
ventilation slits of the housing.
Never insert sharp objects (small screwdrivers, wires, etc.) into the
inside of the device.
Never insert sharp objects (small screwdrivers, wires, etc.) into the
connection terminals for the supply voltage or the signal contact, and
do not touch the terminals!
If you are operating the device in a living area or office environment,
only operate it in switch cabinets with fire protection characteristics in
accordance with EN 60950-1.

8Installation MSP30/32
Release 04 07/2014
The surfaces of the device housing may become hot. Avoid touching
the device while it is operating.
LED or laser components
LED or LASER components according to IEC 60825-1 (2007):
CLASS 1 LASER PRODUCT
CLASS 1 LED PRODUCT
CE marking
The labeled devices comply with the regulations contained in the following
European directive(s):
2011/65/EU (RoHS)
Directive of the European Parliament and of the Council on the restriction
of the use of certain hazardous substances in electrical and electronic
equipment.
2004/108/EC (EMC)
Directive of the European Parliament and the council for standardizing the
regulations of member states with regard to electromagnetic compati-
bility.
In accordance with the above-named EU directive(s), the EU conformity
declaration will be at the disposal of the relevant authorities at the
following address:
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
Tel.: [phone]
The device can be used in the industrial sector.
Interference immunity: EN 61000-6-2
Emitted interference: EN 55022
Reliability: EN 60950-1
You find more information on technical and industry standards here:
“Technical data” on page 45.
Warning! This is a class A device. This device can cause interference in
living areas, and in this case the operator may be required to take appro-
priate measures.
Note: The assembly guidelines provided in these instructions must be
strictly adhered to in order to observe the EMC threshold values.

Installation MSP30/32
Release 04 07/2014 9
Relevant for Use as Industrial Control Equipment
(according to the Standards UL508 / CSA C22.2 No. 142-
1987)
When using the MSP30/32 devices as industrial control equipment the
following restrictions apply:
Max. surrounding air temperature: +60 °C
(... to apply for operating temperature characteristic values S, T or E)
Use Copper Conductors only.
Temperature rating of field installed conductors:
Use 75 °C conductors only.
For use in Polution Degree 2 Environment only.
Digital Output - Relay (Fault): max. 30 V DC, 1 A, resistive load.

10 Installation MSP30/32
Release 04 07/2014
Relevant for Use in Hazardous Locations Class I Div. 2
Groups A, B ,C and D (according to the Standards
ANSI/ISA12.12.01-2013 / CSA C22.2 No.213-M1987)
This equipment is suitable for use in Class I, Division 2, Groups A, B ,C,
D– OR non-hazardous locations, if labeled "FOR USE IN HAZARDOUS
LOCATIONS".
Additional to the restrictions refering UL508 the following restriction-
sapply:
Ta: -40°F ... +140°F (-40°C ... +60°C), Temperature Code: T4
for temperature range characteristic value T and E
Ta: +32°F ... +140°F (0°C ... +60°C), Temperature Code: T4
for temperature range characteristic value S.
WARNING - EXPLOSION HAZARD - Do not disconnect equipment
unless power has been removed or the area is known to be non-
hazardous.
WARNING - EXPLOSION HAZARD - Substitution of any compo-
nentsmay impair suitability for Class I, Division 2.
- For installation and use of the MSP- modules the Control Drawing
No.000172843DNR is to apply - see the next two pages.
- The SD card has to be secured with the knurled thump-screw. Do
not connect or disconnect the SD card unless area is known to be
non-hazardous. Connection or disconnection in an explosive atmo-
sphere could result in an explosion.
Note: For information about the position on the device see “View from
above” on page 24.
- For installation and use of the MSM20/24/40/42 Media Modules-
refer to the document "USER MANUAL Installation" document to the
Media Modules MSM20/24/40/42.

Installation MSP30/32
Release 04 07/2014 11
CONTROL DRAWING for MSP30 and MSP32 devices for Use in Hazardous Locations Class I Division 2 , Groups A, B, C, D Rev. 1 Document No.:000172843DNR Page 1/2
MSP30 / MSP32
Class I Division 2
Groups A, B, C, D Hazardous Location
Ordinary Location, Non-Hazardous Area,
Nonexplosive Atmosphere
1 2 3 4 4 3 2 1
The earth conductor must be at least
of the same wire size (mm² or AWG) as the supply conductors.
Nonincendive field wiring parameters:
THE RELAY TERMINALS ARE DEPENDENT UPON THE FOLLOWING ENTITY PARAMETERS: *)
U
i
I
i
C
i
L
i
30 V 90 mA 3 nF 1 µH
The USB connector and the V.24 connector
(RJ45) are for temporary connection only. Do not use, connect, or disconnect unless area is known to be non-hazardous. Connection or disconnection in an explosive atmosphere could result in an explosion.

12 Installation MSP30/32
Release 04 07/2014
For Use in Hazardous Locations Class I Division 2 Groups A, B ,C ,D: Only allowed for MSP30 or MS32 model No´s. which are individually labelled ´FOR USE IN HARDOUS LOCATIONSµ
Nonincendive field wiring circuits must be wired in accordance with the National Electrical Code (NEC), NFPA 70 , article 501.
WARNING - EXPLOSION HAZARD – SUBSTITUTION OF ANY COMPONENTS MAY IMPAIR SUITABILITY FOR HAZARDOUS LOCATIONS OR EXPLOSIVE ATMOSPHERES. WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE NON-HAZARDOUS. *) Notes: The nonincendive field wiring circuit concept allows interconnection of nonincendive field wiring apparatus and associated
nonincendive field wiring apparatus using any of the wiring methods permitted for unclassified locations when certain parametric conditions are met. Capacity: C
a
C
i
+ C
Cable
; Inductivity: L
a
L
i
+ L
Cable
The maximum cable length has to be determined as follows: (a) max. Cable Length < (L
a
-L
i
) / Cable
L
(”Cable
L
“ denotes the inductance per unit length of used cable) and
(b) max. Cable Length < (C
a
-C
i
) / Cable
C
(“Cable
C
“ denotes the capacitance per unit length of used cable).
The lower value of (a) and (b) is to apply. Manufactured in 72654 Neckartenzlingen / Germany by Hirschmann Automation and Control GmbH. DOM: ww/yyyy (Date of manufactur w - week, Y - year. Refer to the device label).
CONTROL DRAWING for MSP30 and MSP32 devices for Use in Hazardous Locations Class I Division 2 , Groups A, B, C, D Rev. 1 Document No.: 000172843DNR Page 2/2

Installation MSP30/32
Release 04 07/2014 13
Relevant for use in Ex Zone 2 according to ATEX 95
(European directive 94/9/EC)
In Ex zone 2, only devices with a corresponding label may be operated.
When operating the MSP30/32 devices in Ex zone 2, the following
applies:
II 3G
Ex nA IIC T4 Gc
Ta: –40 °C ... +70 °C for characteristic values T and E for
temperature range
Ta: 0 °C ... +60 °C for characteristic value S for temperature
range
DEKRA 13ATEX0090 X
DO NOT OPEN THE DEVICE WHEN IT IS CONNECTED TO ELEC-
TRICITY.
THE USB CONNECTOR MUST NOT BE USED WHEN THE DEVICE IS
OPERATED IN EXPLOSIVE HAZARDOUS LOCATIONS.
Special conditions for safe use
The modules shall be installed in a suitable housing providing a
degree of protection of at least IP54 according to EN 60529, taking into
account the environmental conditions under which the equipment will
be used.
When the temperature under rated conditions exceeds 158 °F (70 °C)
on the cable or at conduit entry point, or 176 °F (80 °C) at the
branching point of the conductors, take measures so that the tempera-
ture specification of the selected cable is in compliance with the actual
measured temperature values.
Make provisions to prevent the voltage of the rated voltage connec-
tions from exceeding the 119 V threshold due to transient distur-
bances.
If an SD card is used, it has to be secured with a knurled screw. For
information about the position on the device see “View from above” on
page 24.
Temperature code T4
List of stan-
dards:
EN 60079-0: 2012
EN 60079-15: 2010

14 Installation MSP30/32
Release 04 07/2014
FCC note:
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference; (2) this device must accept any interference received,
including interference that may cause undesired operation.
Appropriate testing has established that this device fulfills the require-
ments of a class A digital device in line with part 15 of the FCC regula-
tions.
These requirements are designed to provide sufficient protection against
interference when the device is being used in a business environment.
The device creates and uses high frequencies and can also radiate these
frequencies. If it is not installed and used in accordance with this oper-
ating manual, it can cause radio transmission interference. The use of this
device in a residential area can also cause interference, and in this case
the user is obliged to cover the costs of removing the interference.
Recycling note
After usage, this device must be disposed of properly as electronic waste,
in accordance with the current disposal regulations of your county, state,
and country.

Installation MSP30/32
Release 04 07/2014 15
About this manual
The “Installation” user manual contains a device description, safety instruc-
tions, a description of the display, and the other information that you need to
install the device.
The following manuals are available as PDF files on the CD/DVD supplied:
Basic Configuration user manual
User Manual Installation MSM20/24/40/42
User Manual Installation MSP30/32
Redundancy Configuration user manual
Command Line Interface user manual
Reference manual for the graphical user interface
The Industrial HiVision network management software provides you with
additional options for smooth configuration and monitoring:
ActiveX control for SCADA integration
Auto-topology discovery
Browser interface
Client/server structure
Event handling
Event log
Simultaneous configuration of multiple devices
Graphical user interface with network layout
SNMP/OPC gateway
Key
The symbols used in this manual have the following meanings:
Listing
Work step
Subheading

16 Installation MSP30/32
Release 04 07/2014
1 Description
1.1 General device description
You can choose from between a wide range of variants. You have the option
to set up your device individually based on different criteria:
Number of ports
Types of connectors
Working voltage range
Temperature range
Transmission speed
Certifications
The MSP30/32 devices are designed for the special requirements of indus-
trial automation. They meet the relevant industry standards, provide very
high operational reliability, even under extreme conditions, and also long-
term reliability and flexibility.
The devices allow you to set up switched industrial Ethernet networks that
conform to the IEEE 802.3 standard.
The devices work without a fan.
The device is mounted by latching in place on a hat rail.
You have the option of choosing various media to connect to the terminal
devices and other network components:
multimode F/O
singlemode F/O
twisted pair cable
There are convenient options for managing the device. Administer your
devices via:
Network management software (e.g. Industrial HiVision)
a Web browser
a V.24 interface (locally on the device)
HiDiscovery (Software for putting the device into operation)
SSH
Telnet
The devices provide you with a large range of functions, which the manuals
for the operating software inform you about. You will find these manuals as
PDF files on the enclosed CD/DVD, or you can download them from the
Internet on the Hirschmann product pages (www.hirschmann.com).
The Hirschmann network components help you ensure continuous commu-
nication across all levels of the company.

Installation MSP30/32
Release 04 07/2014 17
1.2 Device name and product code
The device name corresponds to the product code. The product code is
made up of characteristics with defined positions. The characteristic values
stand for specific product properties.
Item Characteristic Character-
istic value
Description
1 ... 3 Product MSP MICE Switch Power
4 Data rate 3 10 a/100 Mbit/s ports
10 a/100/1000 Mbit/s ports
5 Hardware type 0 Standard
2 Suitable for PoE or PoE+
6 (hyphen) -
7 ... 8 Number:
10 a/100 Mbit/s ports
08 8 ×
16 16 ×
24 24 ×
9 ... 10 Number:
10 a/100/1000 Mbit/s
ports
04 4 ×
11 Number:
10 a/100/1000/10000
Mbit/s ports
00×
12 Temperature range S Standard 0 °C ... +60 °C (+32 °F
... +140 °F)
T Extended −40 °F ... +158 °F
(−40 °C ... +70 °C)
under UL conditions:
max. +140 °F (+60 °C)
E Extended with
conformal coating
−40 °F ... +158 °F
(−40 °C ... +70 °C)
under UL conditions:
max. +140 °F (+60 °C)
13 Working voltage C 2 voltage inputs for redundant power
supply
Rated voltage range DC
24 ... 48 V
P PoE 2 voltage inputs for redundant power
supply
Rated voltage range DC
47 V... 57 V
PoE+ 2 voltage inputs for redundant power
supply
Rated voltage range DC
53 V... 57 V
14 ... 15 Certificates and
declarations bNote: You will find detailed information on the certificates and
declarations applying to your device in a separate overview.
See table 2 on page 19.
Table 1: Device name and product code
P+
+

18 Installation MSP30/32
Release 04 07/2014
16 ... 17 Software packages 99 Reserved
UR Unicast Routing
MR Unicast + Multicast Routing
18 ... 19 Customer-specific
version
HH Hirschmann standard
20 Software configuration E Entry (Hirschmann standard configuration)
21 ... 22 Software level 2A HiOS Layer 2 Advanced
23 ... 27 Software version 02.0 Software version 02.0
XX.X Current software version
a. Only for twisted pair connections
b. Certificates and declarations in brackets are being prepared.
Item Characteristic Character-
istic value
Description
Table 1: Device name and product code

Installation MSP30/32 Release
04
07/2014 19
Application case Certificates and
declarations
Characteristic value
T9 TY U9 UW UX UY V9 VT VU VY W9 WY X9 Y9 Z9
Standard applications ATEX Zone 2 X X X
CE XXXXXXXXXXX X XXX
EN 60950-1 X X X XXXXXXXX X XXX
EN 61131-2 X X X XXXXXXXX X XXX
FCC XXXXXXXXXXX X XXX
ISA 12.12.01 –
Class I, Div. 2
XX
UL508 X XXX XXX X XX
Substation applications IEC 61850-3 X X X X
IEEE 1613 X X X X
Navy applications GL X X X X X
Railway applications EN 50121-4 X X X
Table 2: Assignment: application cases, certificates and declarations, characteristic values

20 Installation MSP30/32
Release
04
07/2014
Figure 1: Example of a device name:MSP32-24040SPZ999HHE2A02.0
,WHP
063




3
(
=
$ 











3URGXFWQDPH
0,&(6ZLWFK3RZHU
&KDUDFWHULVWLFDQGGHVFULSWLRQ
'DWDUDWHRIWKH(WKHUQHWSRUW
0ELWVDQG0ELWV

1XPEHURI0ELWVSRUWV

1XPEHURI0ELWVSRUWV

1XPEHURI0ELWVSRUWV
²
7HPSHUDWXUHUDQJH
6WDQGDUG&&
2SHUDWLQJYROWDJH
3R(9'&RU3R(9'&
&HUWLILFDWHVDQGGHFODUDWLRQV
&()&&(1
6RIWZDUHSDFNDJHV
UHVHUYHG
&XVWRPL]DWLRQ
+LUVFKPDQQVWDQGDUG
6RIWZDUHFRQILJXUDWLRQ
(QWU\+LUVFKPDQQVWDQGDUGFRQILJXUDWLRQ
6

++


6RIWZDUHOHYHO
+L26/D\HU$GYDQFHG
6RIWZDUHYHUVLRQ



 
+DUGZDUHW\SH
VXLWDEOHIRU3R(RU3R(
