Hisense AP0819CR1W Technical manual

IDENTIFICATION OF PARTS
Front
Back
The figures in this manual are based on the external view of a standard model.
They may differ from that of the air conditioner you have selected.
2
10
TEST
RESET
(May differ from the one shown)

3
AIR CONDITIONER SAFETY
All safety messages will tell you what the potential hazard is and tell you how to reduce the chance of injury.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING ."
These words mean:
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electrical shock or injury when using your air conditioner, follow these basic precautions:
SAVE THESE INSTRUCTIONS
Unplug air conditioner before servicing.
Use two or more people to move and install air conditioner.
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an electrical adapter.
Do not use an extension cord.
Your safety and the safety of others is very important.
STORAGE AND DISPOSING OF THE UNIT
Please recycle or dispose of the packaging material for product in an environmentally responsible manner.
Never store or ship the air conditioner upside down or sideways to avoid damage to the compressor .
The appliance is not intended for use by young children or impaired persons without supervision. Young children should be
supervised to ensure that they do not play with the appliance.
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here.
Tools needed
Parts supplied
Check that all parts are included in parts package.
■Phillips screwdriver ■Pencil ■Scissors ■Cordless drill and ¹⁄₈" bit
A hazard that if not avoided will result in death or
serious injury.
A hazard that if not avoided could result in death or
serious injury.
Dispose of this appliance in accordance with Federal and Local regulations. Refrigerants must be evacuated before
disposal.
Quantity
1 pc
1 pc
1 pc
1 pc
4 pc
4 pc
2 pc
1 pc
1 pc
1 pc
1 pc
2 pc
2 pc
Description
A. Foam seal
B. Coupling
C. Flexible exhaust hose
D. Window exhaust adapter
E. Rivets
F. Screws
G. Window-lock bracket
H. Outer slider section with vent
I. Inner slider section-short
J. inner slider section
K. Outer slider section
L. Foam seal-long
M. Foam seal-short
Part

10
PORTABLE AIR CONDITIONER USE
Operating your portable air conditioner properly helps you to
obtain the best possible results.
This section explains proper air conditioner operation.
NOTE: In the event of a power failure, your air conditioner will
operate at the previous settings when the power is restored.
IMPORTANT:
■Do not stay in direct airflow from the air conditioner
for extended periods of time.
Never use in tightly enclosed spaces. Always ensure
there is sufficient airflow of outside air entering the
household especially when used in conjunction with
combustible devices such as gas stoves, fireplaces,
furnaces, hot water heaters etc. Do not place the
power cord or air conditioner near a heater, radiator,
stoves or other apparatus(including amplifiers) that
produce heat.
This air conditioner is intended for household use as
a residential appliance. Do not use it as a precision
climate control for commercial use, or for precision
equipment, food, pets, plants, artwork, etc.
■
■
Do not block or obstruct the exhaust vent hose as it
may severely affect performance, or cause failure of
the air conditioner.
■
The air conditioner display shows the current room
temperature.
■
■When changing modes while the air conditioner is in
operation, the compressor will stop for 3 to 5 minutes
before restarting. If a button is pressed during this time,
the compressor will not restart for another 3 to 5 minutes.
In Cooling or Dry mode, the compressor and condenser
fan will stop when the room temperature reaches the
set temperature.
■
On Dry mode, the humidity level is automatically set,
but is not able to be displayed.
■
Slot
Insert
Screw
5
Insert the window exhaust adapter into the opening
in the vent panel.
Insert the screw in the hole in
the window exhaust adapter to
prevent the window exhaust adapter
from sliding out of the vent opening.
Note: To ensure proper function, DO NOT overextend
or bend the hose. Make sure that there is no obstacle
around the air outlet of the exhaust hose (in the range
of 500mm ) in order to the exhaust system works
properly. All the illustrations in this manual are for
explanation purpose only. Your air conditioner may
be slightly different. The actual shape shall prevail.
Align the tabs on the
adapter with the slots in the vent panel.
Insert the window exhaust adapter into the
opening in the vent panel.
window exhaust
