INS TA L L AT ION MA NUA L
Outdoor Unit:
AMW3-24U4SAD1
AMW4-28U4SAD1
AMW4-36U4SAD1 Refrigerant flow diagram........................................................12
..............01The following should always be observed for safety
Installation diagram&accessories...........................................03
Selecting the installation location............................................04
Outdoor unit installation.........................................................04
Indoor/outdoor units connection finishing and test run...........09
GMZ3-24H-S
GMZ4-28H-S
GMZ4-36H-S

1.THE FOLLOWING SHOULD ALWAYS BE OBSERVED FOR SAFETY
·Please provide an exclusive circuit for the air conditioner and make sure that no other electrical appliances are connected to it.
·Be sure to read <THE FOLLOWING SHOULD ALWAYS BE OBSERVED FOR SAFETY> before installing the air conditioner.
·Be sure to observe the caution specified here as they include important items related with safety.
·The indications and meanings are as follows.
WARNING: Could lead to death, serious injury, etc.
CAUTION: Could lead to serious injury in particular environments when operated incorrectly.
·After reading this manual, be sure to keep it together with the INSTRUCTION MANUAL in a handy place on the customer's site.
01
WARNING
·Dot not install the unit by yourself(customer).
Incomplete installation could cause injury due to fire, electric shock, the unit falling or leakage of water. Consult the dealer from
whom you purchased the unit or special installer.
·Install the unit securely in a place which can bear the weight of the unit.
When installed in an insufficient strong place, the unit could fall and cause injury.
·Use the specified wires to connect the indoor and outdoor units securely and attach the wires firmly to the terminal
block connecting sections so that the stress of the wires is not applied to the sections.
Incomplete connecting and fixing could cause fire.
·Do not use intermediate connection of the power cord or the extension cord and do not connect many devices to
one AC outlet.
It could cause a fire or an electric shock due to defective contact, defective insulation ,exceeding the permissible current, etc.
·Check that the refrigerant gas does not leak after installation has completed.
If refrigerant gas leaks indoors, and comes into contact with the fire of a fan heater, space heater, stove, etc., harmful substances
will be generated.
·Perform the installation securely referring to the installation manual.
Incomplete installation could cause a personal injury due to fire, electric shock, the unit falling or leakage of water.
·Perform electrical work according to the installation manual and be sure to use an exclusive circuit.
If the capacity of the power circuit is insufficient or there is insufficient electrical work ,it could result in a fire or an electric shock
·Attach the electrical cover to the indoor unit and the service panel to the outdoor unit securely.
If the electrical cover in the indoor unit and/or the service panel in the outdoor unit are not attached securely, it could result in
INSTALLATION MANUAL

a fire or an electric shock due to dust water, etc.
·
It could cause an electric shock.
·The appliance shall be installed in accordance with national wiring regulations.
·When installing or relocating the unit, make sure that no substance other than the specified refrigerant(R410A) enters
the refrigerant circuit.
Any presence of foreign substance such as air can cause abnormal pressure rise or an explosion.
Be sure to cut off the main power in case of setting up the indoor electronic control P. C. Board or wiring works.
CAUTION
·Perform earthing.
Do not connect the earth wire to a gas pipe, water pipe, lightning rod or telephone earth wire. Defective earthing could cause an
electric shock.
·Do not install the unit in a place where an inflammable gas leaks.
If gas leaks and accumulates in the area surrounding the unit, it could cause an explosion.
·Fasten a flare nut with torque wrench as specified in this manual.
When fastened too tight, a flare nut may break after a long period and cause a leakage of refrigerant.
·Install an earth leakage breaker depending on the installation place(where it is humid).
If a earth leakage breaker is not installed, it could cause an electric shock.
·Check that the refrigerant gas does not leak after installation has completed.
If refrigerant gas leaks indoors, and comes into contact with the fire of a fan heater, space heater, stove, etc., harmful substances
will be generated.
·Perform the drainage/piping work securely according to the installation manual.
If there is a defect in the drainage/piping work, water could drop from the unit and household goods could be wet and damaged..
02
INSTALLATION MANUAL

More than 100mm
More than 200mm if
there are obstacles to
both sides.
More than 100mm
More as a rule
More than 500mm if
the back ,both sides
and top are open
More than 350mm
Drain hose
A:Installation plate
B:Indoor unit
C:Wall hole cover
Putty
Piping tape
Pipe
Pipe fixing band
Fixing screw
Drain hose
Drainage elbow
DRAIN PIPING FOR OUTDOOR UNIT
·Provide drain piping before indoor and outdoor connection.
(It will be hard to install drain socket ,if indoor unit becomes
immovable.)
·Connect the drain hose(
) as shown in the figure for drainage.
obtainable at a store ,inside diame-
ter:15mm
03
INSTALLATION MANUAL
2.INSTALLATION DIAGRAM&ACCESSORIES
A
B
C
D
Note:
Do not use the drain elbow
in the cold region. Drain
may freeze and it makes
the fan stop.

04
3.SELECTING THE INSTALLATION LOCATION
OUTDOOR UNIT
·Where it is not exposed to strong wind.
·Where airflow is good and dustless.
·Where it is not exposed to rain and direct sunshine.
·Where neighbours are not annoyed by operation sound or hot air.
·Where rigid wall or support is available to prevent the increase of operation sound or vibration.
·Where there is no risk of combustible gas leakage.
·Where it is at least 3m away from the antenna of TV set or radio. An amplifier may be required for the affected device.
·Install the unit horizontally.
·Please install it in an area not affected by snowfall or blowing snow. In areas with heavy snow, please install a canopy, a pedestal
and/or some baffle boards.
INSTALLATION MANUAL
CAUTION
Avoid the following places for installation where air conditioner trouble is liable to occur.
·Where there is much machine oil.
·Salty places such as seaside.
·Where sulfide gas is generated such as a hot spring.
·Where there is high-frequency or wireless equipment.
Note:
When operating the air conditioner in low outside temperature, be sure to follow the instruction describe below.
·Never install the outdoor unit in a place where its air inlet/outlet side may be exposed directly to wind.
·To prevent exposure to wind, install the outdoor unit with its air inlet side facing the wall.
·To prevent exposure to wind, it is recommended to install a baffle board on the air outlet side of the outdoor unit.
4.OUTDOOR UNIT INSTALLATION

4-1 FREE SPACE REQUIRED AROUND OUTDOOR UNIT(Unit:mm)
Obstacles
When there is an obstacle around the outdoor unit, it does not matter if the position of the obstacle as shown in the figures below.
100 or more
500 or more
100 or more 350 or more
200 or more
500 or more
100 or more
500 or more
Blowing guide(MAC-888SG)
(1).Obstacle over the top side. (2).Obstacle in three direction(bu top
side is open) .
(3).Obstacle on front(blowing)
side only. In this case, the
rear, both side and top sh-
ould be open.
(4).Obstacle on front and rear side
only. The unit can be used by
attaching an optional outdoor
blowing guide(but both sides and
top are open).
05
INSTALLATION MANUAL
(5).Service space
Keep the service space as shown
in the figure below for maintenance
100 or more
500 or more
100 or more
500 or more 350 or more
Service space

Window
More than 100mm
More than
350mm
More than 100mm
More than
200mm
Less than 1,200 mm of the
front surface side
More than
100mm
·When installing the unit in an area that is enclosed on four sides
such as a verandah, be sure to leave move than 200mm behind
the unit as shown.
·When there is a lack of airflow or there is a possibility of becom-
ing short cycle, install an outlet guide and make sure there is en-
ough space behind the rear side of the air inlet.
NOTE:
Make sure not to install several outdoor units sideways next
to each other.
4-2 INSTALLING THE UNIT
·Be sure to fix the unit`s legs with bolts when installing it.
·Be sure to install the unit firmly to ensure that it does not fall
by earthquake or gust.
4-3 MOUNTING ARRANGEMENT OF DRAIN SOCKET
Please perform the drain piping work only when draining from
one place.
CAUTION
Do not use drain socket and drain cap in the cold region.
Drain may freeze and it makes the fan stop.
4-4 OUTDOOR WIRE CONNECTION AND OUTDOOR
POWER SUPPLY CORD CONNECTION
·Be sure to lead in the power supply cord to the air conditioner
in accordance with the specification tables below(minimum size)
and ``Technical Standards for Electrical Installation``.
· Be sure to use special circuits for room air conditioner.
·Connect to the power switch which has a gap of 3mm or more
then open to interrupt the source power phase.
·When the power switch is shut off, it must interrupt all phases.
Input capacity Main switch/Fuse:30A
CAUTION
Attach an earth leakage breaker according to your installation
location. If any breaker is not attached, it may cause a risk of
electric shock.
06
INSTALLATION MANUAL
Power supply cord
specification
Indoor and outdoor
connecting wire specification
2
Cable 3-core m , in conformity with
Design 245 IEC 57.(Cable 5-core 2.5 mm²
for 3 phase model)
4.0 m
2
Cable 4-core 1.5mm , in conformity with
Design 245 IEC 57.

INSTALLATION MANUAL
07
4-5 ELECTRICAL WIRING DIAGRAM
INDOOR UNIT B INDOOR UNIT C INDOOR UNIT D
OUTDOOR UNIT
To Power
1
(L)
2
(N)
2
(N)
INDOOR UNIT A
D
NOTE: For model
For model, there is no INDOOR UNIT D.
single phase
24K
NOTE: For multi split and one
for one common indoor unit the
wiring diagram.
3
( )
1
(L)
3
( )
INDOOR UNIT
0
0
M UL T I S P LI T O UT D O O R UN I T

INSTALLATION MANUAL
4-5 ELECTRICAL WIRING DIAGRAM
INDOOR UNIT B INDOOR UNIT C INDOOR UNIT D
OUTDOOR UNIT
To Power
(U) (V) (W)
(W)
(V)
(N)
(N)
INDOOR UNIT A
D
NOTE: For model.3 phase
NOTE: For multi split and one
for one common indoor unit the
wiring diagram.
( )
(U)
( )
INDOOR UNIT
0
0
M UL T I S P LI T O UT D O O R UN I T
07-1

Be sure to comply with ``Technical Standards for Electrical Installation``, follow this manual and use special circuits for elec-
trical work. If there is a lack of circuit capacity or some deficiency in installation, it may cause a risk of electric shock.
. Be careful to choose the correct type of overcurrent protect-ion switch.
WARNING
WARNING
-Be sure to attach the valve cover of the outdoor unit securely, otherwise it may result in a fire or an electric shock from dust
or water.
-Use the indoor/outdoor unit connecting wire that meets the Standards to connect the indoor and outdoor units and fix the
wire to the terminal block securely so that no external force is conveyed to the connecting section of the terminal block.
Incomplete connections or fixing of the wire could result in a fire.
-Be sure to attach the terminal block cover on both indoor and outdoor units. If the terminal block cover is incorrectly attached,
it may cause a risk of fire or electric shock due to dust or water penetration.
-Be sure to use the power cord which type is more than 30A, otherwise it may result in a fire.
08
INSTALLATION MANUAL
1.Remove the screw of terminal cover.
2.Connect the wire and power supply cable to the terminal block.
3.Replace the terminal cover securely.
4.For 24K model, there is no connection terminal panel D.
Cable clamp
To indoor unit A To indoor unit B To indoor unit C
Valve cover
To Power source
3
( )
BRN BLU
1
(L)
2
(N)
1
(L)
2
(N)
3
( )
BRN BLU BLK
1
(L)
2
(N)
4
(SI)
1
(L)
2
(N)
4
(SI)
BRN BLU BLK
1
(L)
2
(N)
4
(SI)
1
(L)
2
(N)
4
(SI)
BRN BLU BLK
1
(L)
2
(N)
4
(SI)
1
(L)
2
(N)
4
(SI)
BRN BLU BLK
1
(L)
2
(N)
4
(SI)
1
(L)
2
(N)
4
(SI)
To indoor unit D
D
A
B
C
D

Be sure to comply with ``Technical Standards for Electrical Installation``, follow this manual and use special circuits for elec-
trical work. If there is a lack of circuit capacity or some deficiency in installation, it may cause a risk of electric shock.
Overcurrent might be produced may include DC substances. Be careful to choose the correct type of overcurrent protect-
ion switch.
WARNING
WARNING
-Be sure to attach the valve cover of the outdoor unit securely, otherwise it may result in a fire or an electric shock from dust
or water.
-Use the indoor/outdoor unit connecting wire that meets the Standards to connect the indoor and outdoor units and fix the
wire to the terminal block securely so that no external force is conveyed to the connecting section of the terminal block.
Incomplete connections or fixing of the wire could result in a fire.
-Be sure to attach the terminal block cover on both indoor and outdoor units. If the terminal block cover is incorrectly attached,
it may cause a risk of fire or electric shock due to dust or water penetration.
-Be sure to use the power cord which type is more than 30A, otherwise it may result in a fire.
08-01
INSTALLATION MANUAL
1.Remove the screw of terminal cover.
2.Connect the wire and power supply cable to the terminal block.
3.Replace the terminal cover securely.
4.For 3 phase model .
Cable clamp
To indoor unit A To indoor unit B To indoor unit C
Valve cover
To Power source
( )
( )
(N) (U)
(U)
(V)
(V)
(W)
(W)
(N)
BRN BLU BLK
1
(L)
2
(N)
4
(SI)
1
(L)
2
(N)
4
(SI)
BRN BLU BLK
1
(L)
2
(N)
4
(SI)
1
(L)
2
(N)
4
(SI)
BRN BLU BLK
1
(L)
2
(N)
4
(SI)
1
(L)
2
(N)
4
(SI)
BRN BLU BLK
1
(L)
2
(N)
4
(SI)
1
(L)
2
(N)
4
(SI)
To indoor unit D
D
A
B
C
D

5. INDOOR/OUTDOOR UNITS CONNECTION
FINISHING AND TEST RUN
5-1 FLARED CONNECTION
PIPE LENGTH AND HEIGHT DIFFERENCE
LIMITS TYPE
Pipe length per indoor unit
Total pipe length for multi-system
25m*
60m
Height difference(I.D ~ O.D) 15m
Height difference(I.D ~ I.D) 7.5m
Refrigerant adjustment: If exceeds 20m,
additional refrigerant (R410A) change is required.(The outdoor
unit is charged with refrigerant for total pipe length up to 20m. )
PIPE LENGTH AND HEIGHT DIFFERENCE
total pipe length
Pipe length
Refrigerant
to be added
PIPE SIZE
If you use commercially available copper, use the following table for
specifications.
Up to 20m
Exceeding 20m
No additional charge is required
Additional charge is required.
15g/m (refrigerant piping length(m)-20)×
*If gas pipe include 12.7,
length 20g/m
refrigerant piping
CAUTION
Be sure to use the insulation of specified thickness. Excessi-
ve thickness may cause incorrect installation of indoor unit
and lack of thickness may cause dew drippage.
5-2 FLARING WORK
Main cause of gas leakage is defect in flaring work. Perform flaring
work correctly in the following procedure.
1.Pipe cutting
Cut the cooper pipe correctly with pipe cutter.
2.Burrs removal
Completely remove all burrs from the cut cross section of the pipe.
Put the end of the copper pipe downward to prevent burrs from dropp-
ing in the pipe.
3.Putting nut on
Remove flare nuts attached to indoor and outdoor units, then put them
on pipe having completed burr removal.
(Not possible to put them on after flaring work).
Flare nut for R410A pipe may differ from R22 pipe depending on the di-
ameter of pipe.
4.Flaring work
Perform flaring work using flaring tool as shown below.
·
·
·
·
·
·
A(mm)
Flare tool for
R410A clutch type
Conventional flare tool
Outsdie
diameter
φ6.35mm 0 to 0.5
Clutch type Wing nut type
φ9.52mm 0 to 0.5
0 to 0.5
0 to 0.5
φ12.7mm
φ15.88mm
1.0 to 1.5
1.0 to 1.5
1.0 to 1.5
1.0 to 1.5
1.5 to 2.0
1.5 to 2.0
2.0 to 2.5
--
09
INSTALLATION MANUAL
Valve size for outdoor unit Wall thickness Insulation thickness
Liquid pipe φ6.35mm 0.8mm
Gas pipe 9.52 mm 0.8mmφ /12.7
UNIT A
Liquid pipe φ6.35mm 0.8mm
Gas pipe φ9.52/12.7mm 0.8mm
Liquid pipe φ6.35mm 0.8mm
Gas pipe φ9.52/12.7mm 0.8mm
UNIT B
UNIT C
Liquid pipe φ6.35mm 0.8mm
Gas pipe φ9.52/12.7mm 0.8mm
UNIT D
8mm
8mm
8mm
8mm
8mm
8mm
8mm
8mm
*Do your best to
reduce the pipe
length. Long pipe
may cause capacity
of the indoor unit
incline.

Tightening torque
N·m
Pipe diameter
φ6.35mm 13.7 to 17.7
φ9.52mm 34.3 to 41.2
49.0 to 56.4
73.5 to 78.4
φ12.7mm
φ15.88mm
140 to 180
350 to 420
500 to 575
750 to 800
Kgf·cm
Firmly hold copper pipe in a die in the dimension shown in the table
above.
5.Check
Compare the flared work with the figure below.
If flare is noted to be defective, cut off the flared section and per-
form flaring work again.
·
·
Tilted Uneven Burred
No good
Good
o
90
Burr Copper pipe
Spare
reamer
Pipe cutter
Flare nut
Copper pipe
Flaring tool
Clutch type Wing nut type
Die
Copper pipe Flare nut Copper pipe
Die
York
Smooth all around
Inside is shining without any scratches
5-3. PIPE CONNECTION
Note:
Fasten a flare nut with a torque wrench as specified in the
table below. When fastened too tight, a flare nut may be
broken after a long period and cause a leakage of refrigerant.
1.Indoor unit connection
Connect both liquid pipe and gas pipe to indoor unit.
-Apply a thin coat of refrigeration oil to the seat surface of pipe.
-For connection, align the center of both pipe and union, then tighten
the first 3 to 4 turns in flare nut by hand.
-For tightening the union part of the indoor unit side, use the table below
as a standard and tighten the flare nut with two wrenched. Excessive
tightening damages the flared section.
2.Outdoor unit connection
Connect pipe to the pipe joint part of the stop valve in the same method
as the indoor unit.
-For tightening, use the same tightening torque applied for indoor unit
and tighten the flare nut with torque wrench or spanner.
INSULATION AND TAPING
Cover piping joints with pipe cover.
For outdoor unit side, surely insulate every piping including valves.
·
·
·
·
10
INSTALLATION MANUAL

5-4. PURGING PROCEDURES·LEAK TEST
1.PURGING PROCEDURES
（1）Connect the refrigerant pipes(both liquid pipe and gas pipe) bet-
ween the indoor unit and the outdoor unit.
（2）Remove the service port cap of the stop valve on the gas pipe
side of the outdoor unit. (The stop valve will not work in it initial
state fresh out of the factory [totally closed with cap on].)
（3）Connect the gauge manifold valve and vacuum pump to the ser-
vice port of the stop valve on the gas pipe side of the outdoor unit.
（4）Run the vacuum pump.（Vacuumize for more than 15 minutes.）
（5）Check the vacuum with the gauge manifold valve, then close the
gauge manifold valve and stop the vacuum cap.
（6）Leave it as is for one or two minutes. Make sure the pointer of the
gauge manifold valve remains in the same position. Confirm that
the pressure gauge shows -0.101MPa（or -760mHg）.
（7）Remove the gauge manifold valve quickly from the service port
of the stop valve.
-0.101MPa
(-760 mmHg)
Compound pressure
gauge(for R410A)
Pressure gauge
(for R410A)
Gauge manifould
Valve(for R410A)
Handle High
Charge hose
(for R410A)
(Or the vacuum
pump with the
function to prevent
the back flow)
Handle
Low
Window
Adapter for
preventing
the back flow
NOTE:
Each set of pipes must be purged individually.
11
Using piping tape, apply taping starting from the entry of outdoor unit.
-Fix the end of piping tape with adhesive tape.
-When piping has to be arranged through above ceiling, closet or area
where temperature and humidity are high, wind addtional commercially
sold insulation for prevention of condensation.
·
*NOTE: If the 18k indoor unit include the switch
tie-in accessory only for 18K indoor, It may switch
9.52 gas connection tube into 12.7 connection
tube,it is installed outdoor unit for above Picture.
Gas valve
Outdoor unit
Switch tie Connection tube
INSTALLATION MANUAL
（8）After refrigerant pipes are connected and evacuated, fully open
all stop valves on both sides of gas pipe and liquid pipe.
（9）Pipe length up to 20m, no gas charge is needed.
Pipe length exceeding 20m,charge the prescribed amount of gas.
（10）Tighten the cap to the service port to obtain the initial status.
（11）Retigten the cap.
（12）Leak test.

INSTALLATION MANUAL
12
UNIT A
UNIT B
UNIT C
UNIT A
UNIT B
UNIT C
UNIT D
UNIT D
INDOOR HEAT EXCHANGER- A INDOOR HEAT EXCHANGER- B INDOOR HEAT EXCHANGER- C INDOOR HEAT EXCHANGER- D
FILTER
COMPRESSOR
OUTDOOR HEAT EXCHANGER
4-WAY VALVE
INDOOR UNIT OUTDOOR UNIT
6. REFRIGERANT FLOW DIAGRAM
The part is only for 28/ .36k model Cooling cycle Heating cycle

This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device, please
use the return and collection systems or contact the retailer where
the product was purchased. They can take this product for
environmental safe recycling.
Correct Disposal of this product
Version NO. 1356188,K
