Hisense AW-12DR3RYFU20 Technical manual

Modelo:
AW-12DR3RYFU20
AW-18CW3RXFUE20
AW-18DR3RXFU20
AW-24CW3RDFUE20
AW-24DR3RDFU20
INSTRUCCIONES DE INSTALACIÓN Y USO
Model/
Para consultas sobre las características, funcionamiento/ rendimiento,
piezas o servicio, llame al: 1-877-465-3566

TABLE OF CONTENTS
4
3
5
6
4
7
6
10
10
14
Annual Maintenance
AIR CONDITIONER SAFETY 2
INSTALLATION REQUIREMENTS 3
Tools and Parts
Electrical Requirements
Location Requirements
INSTALLATION INSTRUCTIONS
Unpack the Air Conditioner
Prepare Air Conditioner for Installation
Window Air Conditioner Installation
Complete Installation
Starting Your Air Conditioner
AIR CONDITIONER USE
Using the Remote Control
Changing Air Direction
Exhaust Air Vent
Normal Sounds
AIR CONDITIONER CARE 14
14
Cleaning the Front Panel 14
Repairing Paint Damage 14
TROUBLESHOOTING 15
11
Cleaning the Air Filter 14
REMOVING AC FROM WINDOW
14
12
13
13

2
AIR CONDITIONER SAFETY
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol .
This symbol alerts you to potential hazards that can kill or hurt you and others .
All safety messages will follow the safety alert symbol and either the word DANGER or WARNING " " " ."
These words mean :
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire electrical shock or injury when using your air conditioner follow these basic precautions , , :
SAVE THESE INSTRUCTIONS
Unplug air conditioner before servicing .
Use two or more people to move and install air conditioner.
Plug into a grounded prong outlet 3 .
Do not remove ground prong .
Do not use an adapter.
Do not use an extension cord .
You safety and the safety of others are very important.
Before throwing the device, it is necessary to pull back the battery cells and get rid of them safety for recycling reasons.
When you need to disposal of the unit consult our dealer. If pipes are removed incorrectly, refrigerant may blow out and
please recycle or dispose of the packaging material for product in an environmentally responsible manner.
Never store or ship the air conditioner upside down or sideways to avoid damage to the compressor .
The wiring diagram is shown at nameplate on the air conditioner.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
DISPOSING OF THE UNIT
come into contact with your skin, causing injury. Releasing refrigerant into the atmosphere also damages the environments.
Do not use means to accelerate the defrosting process
or to clean, other than those recommended by the
manufacturer.
The appliance shall be stored in a room without
continuously operating ignition sources(for example:
open flames, an operating gas appliance or an
operating electric heater.
Do not pierce or bum refrigerant tubing. Be aware that
refrigerants may not contain an odor.
Keep ventilation openings clear of obstruction.
The maximum refrigerant charge amount is shown at
nameplate on the air conditioner.
Do not drill holes in the unit.
When handling, installing, and operating the appliance,
care should be taken to avoid damage to the
refrigerant tubing.
Maintenance, cleaning, and service should only be
performed by technicians properly trained and qualified
in the use of flammable refrigerants.
Dispose of air conditioner in accordance with Federal
and Local Regulations. Flammable refrigerants require
special disposal procedures. Contact your local authorities
for the environmentally safe disposal of your air conditioner.
The appliance shall be stored so as to prevent mechanical
damage from occurring.
DANGER
WARNING
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.

Wiring requirement
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
WARNING
fire, or electrical shock.
Recommended Grounding Method
To contact a qualified .electrical installer
It is the customer’s responsibility:
To assure that the electrical installation is
adequate and conforms to the Nation Electrical
Code,ANSI/NFPA 70-last edition,and all local
codes and ordinances.
Copies of the standards listed may be obtained from:
Nation Fire Protection Association
1 Batterymarch Park
Quincy,Ma 02169-7471
www.nfpa.org
This
conditioner is equipped with a power supply cord with a
three-prong grounding plug. The cord must be plugged
into a mating, grounded three-prong outlet, grounded in
accordance with all local codes and ordinances. If a
mating outlet is not available, it is the customer's
responsibility to have a properly grounded three-prong
outlet installed by a qualified electrical installer.
air conditioner must be grounded. This air
NOTE:
Your air conditioner’s device may differ from the one shown.
To test your power supply cord:
1. Plug power supply cord into a grounded 3 prong outlet.
2. Press RESET (on some devices, a green light will turn on).
3. Press TEST (listen for click; Reset button will trip, and on
some devices, a green light will turn off).
4. Press and release RESET (listen for click; Reset button will
latch, and on some devices, a green light will turn on). The
power supply cord is ready for operation.
NOTE:
■The Reset button must be pushed in for proper operation.
■The power supply cord must be replaced if it fails to trip when
the test button is pressed or fails to reset.
■Do not use the power supply cord as an off/on switch. The
power supply cord is designed as a protective device.
■A damaged power supply cord must be replaced with a new
power supply cord obtained from the product manufacturer
and must not be repaired.
■The power supply cord contains no user serviceable parts.
Opening the tamper-resistant case voids all warranty and
performance claims.
A.Test button
B.Reset button
TEST
RESET
A
B
This room air conditioner is equipped with a power supply cord
required by UL. This power supply cord contains state-of-the-art
electronics that sense leakage current. If the cord is crushed, the
electronics detect leakage current and power will be
disconnected in a fraction of a second.
Power Supply Cord
Electrical Requirements
INSTALLATION REQUIREMENTS
3
Power supply
Model
Time-delay fuse
(or circuit breaker)
208/230V
187.2V min.
253V max.
12K BTU cooling&heating 18A
18K BTU cooling only 15A
20A
18K BTU cooling&heating
24K BTU cooling only
24K BTU cooling&heating

4
Tools and Parts
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Tools needed
■Phillips screwdriver
■Scissors
■Level
■Tape measure
■Cordless drill and bit
■Pencil
1 /8"
Parts supplied
Check that all parts are included in parts package.
A Adhesive seal .
B Foam seal.
H. Angle Brackets (2)
B
C
D
H
G
IJ
Q
F
PR
Remove packaging materials
■ Remove and dispose of/recycle packaging materials.
Remove tape and glue residue from surfaces before turning
on the air conditioner. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
Unpack the Air Conditioner
■Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your air conditioner.
■
■
Handle the air conditioner gently.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
air conditioner .
Failure to do so can result in back or other injury .
Remove top rail from the packaging material.
ST
NOTE:
The
F. Baffle (2)
is not provided for
12K BTU cooling and heating model.
The
R.Lock frame
is only provided for 12K BTU cooling and heating model.
The G.EVA Foam(2) is only provided for E-star models,with
E-star LOGO on the control panel.
PE foam seal
E.Adhesive seal
F. Baffle (2)
G. EVA Foam(2)
I. Lock frame(2)
(for Vinyl-Clad windows)
J. Sash lock
K. EPDM foam sesl(2)
L.
3/4" screws (8)
M. 1/4"
screws (10)
N. 3/4" Long Flat Head
Bolt and Locknut (2)
C . Side curtains (2)
D.Top rail and
O. 1/2" Long Bolt and
Locknut (4)
P. Washer(2)
Q. Left and Right Support
Brackets (2)
R. Lock frame
S. Air conditioner
T. Remote control
A
E

5
Location Requirements
■
■
■
■
■
■
■
■
■
■
Window Installation
If AC is Blocked by Storm Window
Before You Begin
Window opening measurements:
Add wood as shown, or remove storm window before air .
conditioner is installed.
If storm window frame must remain, be sure the drain holes
or slots are not caulked or painted shut. Accumulated rain
water or condensation must be allowed to drain out.
IMPORTANT:
IMPORTANT:
A
(With side curtain panels)
B
Models A B
12K BTU
24K BTU
17(432mm) min "
19 1 min /10" (485mm)
18 1 (470mm) min /2"
27 - 41 " " (686mm) (1041mm)
32 2 5 - 4 / " " (823mm) 4 (1118mm)
29 3/5 - 42 1 " /10" (752mm) (1069mm)
Read these instructions completely and carefully.
Save these instructions for local inspector’s use.
Observe all governing codes and ordinances.
18K BTU
A Cabinet louvers.
A
Board
thickness
as required,
for proper
pitch to rear,
along entire
sill. Fasten
with nails or
screws.
Storm window
frame or other
obstruction.
sash
1-1/2"min
(38 mm)
Cooling and Heating models
without Cabinet louvers on top
IMPORTANT: Observe all governing codes and ordinances.
Check the location where air conditioner will be installed. Proper
installation is your responsibility. Make sure you have everything
necessary for correct installation.
The location should provide:
■
Do not use an extension cord.
The appliance shall be installed in accordance with
national wiring regulations.
■ Free movement of air in room to be cooled.
■ A large enough opening for the air conditioner.
NOTE: Cabinet louvers must not be obstructed. Air must be able
to pass through the cabinet louvers freely.
Note to Installer:
Be sure to leave these
instructions with the
consumer.
Note to Consumer: Keep these instructions for future
reference.
Skill level: Installation of this appliance requires basic
mechanical skills.
Completion time:
Approximately 1 hour.
We recommend that two people install this product.
Proper installation is the responsibility of the installer.
Product failure due to improper installation is not
covered under the Warranty.
You MUST use all supplied parts and use proper
installation procedures as described in these
instructions when installing this air conditioner.
These instructions are for a standard double-hung
window. You will need to modify them for other
types of windows.
The air conditioner can be installed without the
side curtain panels if needed to fit in a narrow
window. See the window opening dimensions.
All supporting parts must be secured to firm
wood, masonry or metal.
The electrical outlet must be within reach of the
power cord.
Follow the dimensions in the table and
illustration for your model
.

Install Top Angle Rail and Side Retainers
Remove Air Conditioner from Cabinet
NOTE: Remove any packaging material from cabinet exterior.
6
INSTALLATION INSTRUCTIONS
Prepare Air Conditioner for Installation
12K model do not need
to attach the two screws
1/4" screws
12K model do not need
to attach two baffles
1. Locate the two Front Panel screws and remove.
These screws will be needed to re-install the
Front Panel later.
2. Push metal cabinet side inward to release plastic tabs
on each side of Front Panel.
4. Remove shipping screws from top of unit and also on
both sides by the base if installed.
6. Add two foam inserts to holes in top of cabinet where
shipping screws were removed from.
1. Remove adhesive strip coating from foam gasket.Attach adhesive side of gasket to bottom of top angle rail.
Insert 4 screws from inside of cabinet and secure to top angle rail.
2. From inside of cabinet insert 3 screws to attach each side baffle as shown. Attach side baffles with flat side
against cabinet and angled edge toward rear of cabinet.
3. Remove Front Panel from the unit.
5. Remove the air conditioner from cabinet carefully.

7
C
B
A
3/4″ long
HEX-HEAD
SCREW
Place Cabinet in Window
A. 3/4" screws
B. Safety Lock (Only for Vinly-Clad Window)
C. Bottom Rail Foam Seal
Side retainer
window
inner sill
cabinet
Angle of cabinet
bracket securely seated
on edge of inner sill.
Bracket
Window Air Conditioner Installation
5. Remove protective strip from adhesive side of
Bottom Rail Foam Seal Apply Seal over screws
fastening bottom rail to window inner sill.
2. Place cabinet in window with cabinet bracket
securely seated over the edge of inner sill as
shown in . Bring window down temporarily
behind top angle rail to hold cabinet in place.
window outer sill
4. For Vinyl-Clad window: Place two safety locks
into the holes located in the bottom of the cabinet
and drive two 3/4" pan-head Phillips locking
screws through the safety locks into the cabinet
as shown.
Install Side Curtains
Side curtain
Curtain housing
A
B
A . Lower window sash
B. Adhesive seal
1. Open the window and mark the center of window inner
sill as shown .
Cut the adhesive seal to the width of the lower window sash.
Remove the backing from the seal and attach the seal
to the bottom of the lower window sash.
3. Shift cabinet left or right as needed to line up center
of cabinet on center line marked on inner sill.
For wooden window: Fasten cabinet to window inner
sill with two 3/4" long hex head screws into holes
(You may wish to pre-drill pilot holes).
1. Place cabinet on the floor, a bench, or a table.
2. Slide "Ⅰ" section at the end of side curtain into side retainer on each side of the cabinet.
3. On each side of cabinet, insert the curtain housing into channel in the top and bottom angle rails.

Install Support Bracket
MARK
MARK
" Long Bolt
and Locknut (4)
1⁄2
2. Attach sill angle brackets to support brackets at
marked positions with flat head bolts and nuts.
Hand tighten only at this point.
RIGHT
LEFT
Angle Brackets
" Long Flat Head
Bolt and Locknut
3⁄4
" Long Bolt
and Locknut
1⁄2
4.
Adjust height of sill angle bracket so that bracket
rests securely on edge of sill, and so that cabinet
has the correct downward tilt for proper water
drainage. Tighten nuts securely.
3°
Side Louvers
Window Sash
Sill Angle Bracket
Window Sill
tabou 3°
8
1/4"screws
1. Hold each support bracket flush against outside
of sill and tight to bottom of cabinet. Mark
brackets at top level of sill. Mark cabinet bottom
at distance of sill width. Remove support brackets.
3. Insert 1/2" long bolts through appropriate holes in
cabinet bottom given the sill width distance. Thread
the bolts into the slots of the support brackets. Tighten
lock washer nuts onto bolts.
5. Place the frame lock between the base and the cabinet
sill with 1/4" (6,5mm) screw as shown.
NOTE:This lock frame is only provided for 12K BTU model.
Attach The Top Rail To Window
1. Close window behind top angle rail.
2. Attach the top angle rail to window frame: Use a drill bit to drill one hole through the hole in the middle of top
angle rail into the window frame,and drive one 3/4" locking screw through the hole in the middle of top angle
rail into the window frame as shown.
