UC 14SD • UC 18SD
INSTRUCTIONS DE SECURITE ET MODE D’EMPLOI
AVERTISSEMENT
Une utilisation INCORRECTE OU DANGEREUSE de ce chargeur de batterie peut entraîner
la mort ou de sérieuses blessures corporelles!
Ce mode d’emploi contient d’importantes informations à propos de la sécurité de ce
produit. Prière de lire et de comprendre ce mode d’emploi AVANT d’utiliser l’outil
motorisé.Gardercemoded’emploiàladisponibilitédesautresutilisateursetpropriétaires
avant qu’ils utilisent le chargeur de batterie. Ce mode d’emploi doit être conservé dans
un endroit sûr.
SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL
WARNING
IMPROPER OR UNSAFE use of this battery charger can result in death or serious bodily
injury!
This manual contains important information about product safety. Please read and
understand this manual BEFORE operating the power tool. Please keep this manual
available for other users and owners before they use the battery charger. This manual
should be stored in safe place.
INSTRUCCIONES DE SEGURIDAD Y MANUAL DE INSTRUCCIONES
ADVERTENCIA
¡La utilización INAPROPIADA O PELIGROSA de este cargador de baterías puede resultar
en lesiones de gravedad o la muerte!
Este manual contiene información importante sobre la seguridad del producto. Lea y
comprenda este manual ANTES de utilizar la herramienta eléctrica. Guarde este manual
para que puedan leerlo otras personas antes de utilizar el cargador de baterías. Este
manual debe ser guardado en un lugar seguro.
Model Battery Charger
Modèle Chargeur de batterie
Modelo Cargador de batterías
UC14SD

2
TABLE DES MATIERES
Français
Page
INFORMATIONS IMPORTANTES
DE SÉCURITÉ............................................... 11
SIGNIFICATION DES MOTS
D’AVERTISSEMENT .................................... 11
SECURITE
CONSIGNES DE SÉCURITÉIMPORTANTES
POUR L’UTILISATION DU CHARGEUR
DE BATTERIE ............................................... 12
CONSIGNES DE SÉCURITÉIMPORTANTES
POUR L’UTILISATION DE LA BATTERIE
ET DU CHARGEUR DE BATTERIE .............. 13
MISE AU REBUT D’UNE BATTERIE USÉE ........ 14
English
Page
IMPORTANT SAFETY INFORMATION ................ 3
MEANINGS OF SIGNAL WORDS ........................ 3
SAFETY
IMPORTANT SAFETY INSTRUCTIONS
FOR BATTERY CHARGER ............................. 4
IMPORTANT SAFETY INSTRUCTIONS
FOR USE OF THE BATTERY AND
BATTERY CHARGER ...................................... 5
DISPOSAL OF THE EXHAUSTED BATTERY ....... 6
Page
OPERATION AND MAINTENANCE
MODEL ................................................................... 7
NAME OF PARTS .................................................. 7
SPECIFICATIONS .................................................. 7
APPLICATIONS ..................................................... 8
CHARGING METHOD ........................................... 8
BEFORE USE ....................................................... 10
MAINTENANCE AND INSPECTION ................... 10
STORAGE ............................................................ 10
SERVICE AND REPAIRS...................................... 10
PARTS LIST ......................................................... 29
Español
Página
INFORMACIÓN IMPORTANTE SOBRE
SEGURIDAD ................................................. 20
SIGNIFICADO DE LAS PALABRAS
DE SEÑALIZACIÓN ..................................... 20
SEGURIDAD
INSTRUCCIONES IMPORTANTES
DE SEGURIDAD PARA EL CARGADOR
DE BATERÍAS ............................................... 21
INSTRUCCIONES IMPORTANTES
DE SEGURIDAD PARA LA BATERÍA
Y EL CARGADOR DE BATERÍAS ................. 22
ELIMINACIÓN LAS BATERÍAS AGOTADAS ..... 23
Página
OPERACIÓN Y MANTENIMIENTO
MODELO .............................................................. 24
NOMENCLATURA ............................................... 24
ESPECIFICACIONES ............................................ 25
APLICACIONES ................................................... 25
MÉTODO DE CARGA .......................................... 25
ANTES DE LA UTILIZACIÓN .............................. 27
MANTENIMIENTO E INSPECCIÓN .................... 27
ALMACENAMIENTO ........................................... 28
SERVICIO Y REPARACIONES ............................. 28
LISTA DE PIEZAS ................................................ 29
CONTENTS
Page
UTILISATION ET ENTRETIEN
MODÈLE .............................................................. 15
NOM DES PARTIES ............................................ 15
SPECIFICATIONS ................................................ 16
UTILISATIONS .................................................... 16
MÉTHODE DE RECHARGE ................................. 16
AVANT L’UTILISATION ...................................... 18
ENTRETIEN ET INSPECTION.............................. 18
RANGEMENT ...................................................... 19
SERVICE APRES-VENTE ET REPARATIONS ..... 19
LISTE DES PIÈCES .............................................. 29
ÍNDICE

English
3
IMPORTANT SAFETY INFORMATION
Read and understand all of the safety precautions, warnings and operating instructions in
the Instruction Manual before operating or maintaining this battery charger.
Most accidents that result from battery charger operation and maintenance are caused by
the failure to observe basic safety rules or precautions. An accident can often be avoided
by recognizing a potentially hazardous situation before it occurs, and by observing
appropriate safety procedures.
Basic safety precautions are outlined in the “SAFETY”section of this Instruction Manual
and in the sections which contain the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by
WARNINGS on the battery charger and in this Instruction Manual.
NEVER use this battery charger in a manner that has not been specifically recommended
by HITACHI.
MEANINGS OF SIGNAL WORDS
WARNING indicates a potentially hazardou situation which, if ignored, could result in death
or serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury, or may cause machine damage.
NOTE emphasizes essential information.

English
4
SAFETY
IMPORTANT SAFETY INSTRUCTIONS
FOR BATTERY CHARGER
WARNING: Death or serious bodily injury could result from improper or unsafe use
of battery chargers. To avoid these risks, follow these basic safety
instructions:
READ ALL INSTRUCTIONS
1. This manual contains important safety and operating instructions for battery
charger Model UC14SD and UC18SD.
2. Before using battery charger, read all instructions and cautionary markings on
(1) battery charger, (2) battery, and (3) product using battery.
3. To reduce risk of injury, charge HITACHI rechargeable battery types EB1414
(For UC14SD) and EB1812S (For UC18SD). Other type of batteries may burst
causing personal injury and damage.
4. Do not expose battery charger to rain or snow.
5. Use of an attachment not recommended or sold by the battery charger
manufacturer may result in a risk of fire, electric shock, or injury to persons.
6. To reduce risk of damage to electric plug and cord, pull by plug when
disconnecting battery charger.
7. Make sure cord is located so that it will not be stepped on, tripped over, or
otherwise subjected to damage or stress.
8. An extension cord should not be used unless absolutely necessary. Use of
improper extension cord could result in a risk of fire and electric shock.
If extension cord must be used make sure:
a. That blades of extension cord are the same number, size, and shape as those of
plug on battery charger;
b. That extension cord is properly wired and in good electrical condition; and
c. That wire size is large enough for AC ampere rating of battery charger as specified
in Table 1.
Table 1
RECOMMENDED MINIMUM AWG SIZE FOR
EXTENSION CORDS FOR BATTERY CHARGERS
AC Input Rating Amperes* AWG Size of Cord
Equal to or but less Length of Cord, Feet (Meter)
greater than than 25 (7.5) 50 (15) 100 (30) 150 (45)
0 2 18 18 18 16
2 3 18 18 16 14
3 4 18 18 16 14

English
5
* If the input rating of a battery charger is given in watts rather than in amperes,
the corresponding ampere rating is to be determined by dividing the wattage
rating by the voltage rating–for example:
9. Do not operate battery charger with damaged cord or plug-replace them
immediately.
10. Do not operate battery charger if it has received a sharp blow, been dropped,
or otherwise damaged in any way; take it to a qualified serviceman.
11. Do not disassemble battery charger; take it to a qualified serviceman when
service or repair is required. Incorrect reassembly may result in a risk of electric
shock or fire.
12. To reduce risk of electric shock, unplug charger from receptacle before
attempting any maintenance or cleaning. Removing the battery will not reduce
this risk.
13. This battery charger might be attached to HITACHI battery operated tools as a
standard accessory. In this case, please confirm Instruction Manual of the
HITACHI battery operated tools before using the battery charger.
IMPORTANT SAFETY INSTRUCTIONS FOR USE OF THE
BATTERY AND BATTERY CHARGER
You must charge the battery before you can use the power tool. Before using the model
UC14SD and UC18SD battery charger, be sure to read all instructions and cautionary
statements on it, the battery and in this manual.
REMEMBER: USE ONLY HITACHI BATTERY TYPES EB1414 (FOR UC14SD) AND EB1812S
(FOR UC18SD). OTHER TYPES OF BATTERIES MAY BURST AND CAUSE INJURY!
Follow these instructions to avoid the risk of injury:
WARNING: Improper use of the battery or battery charger can lead to serious injury.
To avoid these injuries:
1. NEVER disassemble the battery.
2. NEVER incinerate the battery, even if it is damaged or is completely worn
out. The battery can explode in a fire.
3. NEVER short-circuit the battery.
4. NEVER insert any objects into the battery charger’s air vents. Electric shock
or damage to the battery charger may result.
5. NEVER charge outdoors. Keep the battery away from direct sunlight and
use only where there is low humidity and good ventilation.
6. NEVER charge when the temperature is below 50°F (10°C) or above 104°F
(40°C).
7. NEVER connect two battery chargers together.
8. NEVER insert foreign objects into the hole for the battery or the battery
charger.
1250watts
125 volts = 10 amperes
