Ohlins POF6H00 User manual

Öhlins Racing AB
Box 722
S-194 27 Upplands Väsby, Sweden
Phone [phone]
fax [phone]
© Öhlins Racing AB. All rights
reserved. Any reprinting or
unauthorized use without the written
permission of Öhlins Racing AB
is prohibited.
www.ohlins.com
Öhlins products are subject to
continuous improvement and
development, therefore, although
these instructions include the most
up-to-date information available at
the time of printing, minor updates
may occur.
To find the latest information contact
your Öhlins distributor. Please
consult your Öhlins dealer if you
have any questions regarding the
contents in this document.
Shock Absorber for Porsche 997 - rear
POF6H00
Mounting Instructions
Part No. Pcs.
Shock abs. left/right front POF 6H00 1
Sticker 00192-01 1
Sticker 00197-02 1
Screw 00439-01 1
Spring support 05281-01 1
Spring retainer 05411-01 1
Top mount 05722-03 1
Rubber cap 05925-01 2
Ball joint spacer 06119-21 1
Ball joint spacer 06119-22 1
Owners manual TTX, CD 07435-02 1
Note!
No spring included in this kit. Contact an Öhlins
dealer for advice.
Before installing this product, check the
contents of the kit. If anything is missing, please
contact an Öhlins dealer.
Kit Contents
Please note that during storage and
transportation, especially at high ambient
temperature, some of the oil and grease used for
assembling may leak and stain the packaging.
This is in no way detrimental to the product,
wipe off the excess oil/grease with a cloth.
Part no. POF6H00_1
Issued 2010-04-09
Warning!
Before installing this product, read the Öhlins
Owner’s Manual. The shock absorber is an
important part of your vehicle and will affect the
stability.
Compression damping
High speed 15 clicks
Low speed 30 clicks
Rebound damping
High speed 23 clicks
Low speed 28 clicks
Set-up Data
Recommended Springs (Eibach)
Main Spring
Spring Rate 220 N/mm
Length 130 mm (5’’)
ID 57 mm (2.25’’)
Helper Spring
ID 57 mm (2.25’’)
(05173-07)

1 2
How to Install Adjustments
Warning!
It is advisable to have an Öhlins dealer install the
shock absorber.
When installing, read the Vehicle Service
Manual.
When working on a raised vehicle, ensure the
vehicle is securely supported so that it will not
tip.
1
Install the dampers with spacer 06119-22
pointing towards the drive shaft.
2
Read more about the Öhlins shock absorber
and settings in your Öhlins Owner’s Manual.
Warning!
Before driving the vehicle, read and make sure
you understand how the product works. Read
more about adjustments and setting up in the
Öhlins Owner’s Manual before you make any
adjustments. Contact an Öhlins dealer if you
have any questions about setting up the shock
absorber.
Compression Damping
Note!
Install 06119-21 and
06119-22 last.
Rebound Damping
Compression damping adjuster
Adjustments are made with the golden
(left) knob on the valve housing. The
black, 3 mm, allen key in the middle is
the low speed adjuster and the golden
12mm hex is the high speed adjuster.
Note!
Do not turn the golden 19 mm hex.
Rebound damping adjuster
Adjustments are made with the silver
(right) knob on the valve housing. The
black, 3 mm, allen key in the middle is
the low speed adjuster and the silver
12mm hex is the high speed adjuster.
Note!
Do not turn the golden 19 mm hex.
Spring preload adjuster
Adjustments are made with the
adjustment rings on the outer tube of
the damper. Use ÖR tool 03199-01 (not
included). Since no springs are included
in the kit you need to set the ride height
once the dampers are mounted on
thecar.
The adjusters have a normal right hand
thread. Turn clockwise to fully closed. Turn
counter clockwise to open and count the
clicks until you reach the recommended
number.
1
2
3Note!
When delivered the Öhlins strut is not dialed to
recommended settings for the specific brand
and make of the vehicle. You need to reset it
according to the Set-up Data.
Note!
If you have turned the adjuster without counting
the number of clicks you must go back to the
recommended settings. Close the adjuster
and count the clicks when turning it counter-
clockwise.
Caution!
Do not use force, delicate sealing surfaces can
be damaged. Handtighten only.
