Ohlins YA919 User manual

Mounting instructions
YA919
Kit contents
Shock absorber Type 46DR YA919 1
Owners manual 1
Sticker 0192-01 2
Hook spanner 0710-02 1
Set-up data
Total length 457,5 mm
Stroke 79 mm
Preload spring 16 mm
Rebound adjustment 8
Compression adjustment ---
Notes
YA919 Issued 990630
Öhlins Racing AB, Box 722, S-194 27 Upplands Väsby, Sweden.
Phone [phone], fax [phone].
E-mail: [email protected]
Traction, handling,
comfort and safety
WARNING!
If the shock absorber has
an adjustable end eye/
bracket, this must not be
treaded out more than
that one groove is fully
visible beneath the lock
nut. Make sure that the
lock nut is tightened after
adjustment. Groove
WARNING!
The shock absorber is provided with a
separate type reservoir filled with high-
pressure nitrogen gas. To prevent dan-
ger of explosion, study and make cer-
tainthatyoufullyunderstandthefollow-
ing information before handling the
shockabsorber.Themanufacturercan-
not be held responsible for damage to
property or personal injury that may re-
sult from improper handling.
1. Never tamper with or attempt to dis-
assemble the cylinder or the reservoir.
2. Never expose the shock absorber to
an open flame or other excessive heat.
The shock absorber may othervise
explode due to too high pressure.
3. Be careful not to damage any part of
the gas reservoir. A damaged gas res-
ervoir will impair the damping perform-
ance or cause malfunction.
4. Take care not to scratch the contact
surface of the piston rod of the cylinder;
oil could othervise leak out.
5. Never attempt to remove the plug at
thebottomofthenitrogengasreservoir.
Any attempt to remove the plug implies
serious danger.
6.When scrappingthe shockabsorber,
follow the instructions for disposal.

Before you start
WARNING!
Installing a shock absorber, that is not
approved by the vehicle manufacturer,
may affect the stability of your vehicle.
Öhlins Racing AB cannot be held
responsible for any personal injury or
damage whatsoever that may occur
afterfitting the shockabsorber. Contact
an Öhlins dealer or other qualified
person for advice.
Öhlins Racing AB can not be held responsi-
ble for any damage whatsoever to shock
absorber or vehicle, or injury to persons, if
the instructions for fitting and maintenance
are not followed exactly. Similarly, the
warranty will become null and void if the
instructions are not adhered to.
WARNING!
Pleasestudyandmakecertainthatyou
fullyunderstandallthemountinginstruc-
tions and the owner´s manuals before
handling this shock absorber kit. If you
have any questions regarding proper
installation procedures, contact an
Öhlins dealer or other qualified person.
WARNING!
The vehicle service manual must be
referred to when installing the Öhlins
shock absorber.
NOTE!
Öhlinsproductsaresubject to continual
improvement and development. Con-
sequently, although these instructions
includethe mostup-to-date information
available at the time of printing, there
maybeminordifferencesbetweenyour
suspension and this manual. Please
consult your Öhlins dealer if you have
any questions with regard to the con-
tents of the manual.
Safety signals
Important information concerning safety is
distinguished in this manual by the
following notations
The Safety alert symbol means:
Caution! Your safety is involved.
WARNING!
Failure to follow warning instructions
could result insevereor fatal injuryto
anyoneworking with,inspecting orusing
the suspension, or to bystanders.
CAUTION!
Cautionindicatesthatspecialprecautions
must be taken to avoid damage to the
suspension.
NOTE!
This indicates information that is of
importance with regard to procedures
Kit contents
Before installing the shock absorber,
please check the contents of the kit, listed
on the front page of this instruction. If any-
thing is missing, contact your Öhlins
dealer.
NOTE!
During storage and transportation, es-
peciallyathighambienttemperature,the
oilandgreaseusedfor assembling may
run out inside the packing and damage
the expanded polystyrene packing ma-
terial. This is not unusual and is in no
way detrimental to the shock absorber.
© Öhlins Racing AB.
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Öhlins Racing AB is prohibited.
Printed in Sweden.
WARNING!
1. It´s advisable to have an Öhlins
dealer or other qualified person to fit
your shock absorber.
2. Instructions in the vehicle service
manual are to be followed when
changing the shock absorber.
3. When working on a lifted vehicle it
must be securely supported to prevent
it from falling.
NOTE!
Make sure that all bolts are tightened
to the correct torque and that nothing
foulsorrestrictsmovementof the shock
absorber when the suspension isbeing
fully compressed or extended.
WARNING!
Certain modifications may be neces-
sary when installing the Öhlins shock
absorber/suspension. It is essentialthat
the mounting instructions are carefully
followed.
Mounting Instructions
1
Put the motorcycle on a stand so the rear
wheel is clear of the ground. Make sure
it´s steadily fixed so it will not fall over.
2
Loosen and remove the standard shock
absorber(s). See the motorcycles Work-
shop manual.
3
Fitthe Öhlins shock absorber(s) inthe same
position as the standard shock absorber.
4
Continue your work according to the
Owners Manual, section Adjustments.
