Hodedah HITC84-Z User manual

ITEM#HITC84-Z
Dining set
2 person
30 mins
1 Box
1 YR LTD
TABLE: H29.5"W47.2"D31.5"
CHAIR: H38.9"W19.7"D16.5"

A Bolt
16 un.
Wrench bar
1 un.
Ø4*15mm
C
Screw
8 un.
Ø4*12mm
B
D Bolt
24 un.
Wrench bar
1 un.
Ø4*40mm
F
Screw
16 un.
Ø4*16mm
E
2345
Table top
1 un.
Table fence
2 un.
Plastic footing
4 un.
Table fence
2 un.
Table leg
4 un.
Ø50*743mm
940*130mm
1200*800mm 570*130mm
1
Ø50mm
789
10
Chair back frame
4 un.
Seat cushion
4 un.
Plastic footing
16 un.
Chair leg
8 un.
Steel rod
4 un.
Ø16*330mm
377*398mm
412*98.5mm 415*415mm
6
Ø28mm
Table
Chairs

1
B
A
2
4
3
5
10
7
8
9
6
E
D
D

Step 2
●
Attach 1piece table fence(2) and 1 piece table fence(3) on one table leg(4), screw bolt (A)
into the hole after aligned ,make them a combination.(see photos for example)
A
4
3
2
HARDWARE REQUIRED
4*
A
Step 1
Do the same on the other leg following step 1.
Join two combination and other two legs(4) together with bolt (A). tighten with wrench bar (C)
after all aligned. (see photos for example)
●
A
4
3
2
HARDWARE REQUIRED
12*
A
●
C
C

Step 3
●
Cover plastic footing (5)at bottom of table leg (4).
Attach table top(1) on table leg(4), insert screw (B) through the hole on small piece of metal
welded at top of table leg, tighten screw after all fixed.
(See photos for example)
●
Step 4
HARDWARE REQUIRED
8*
B
1
1
B
B
4
4
5
4

Step 5
●
Attach chair back frame(6) on chair leg (8),Screw bolt (D) into the hole after aligned, tighten
with wrench bar (F).
Attach steel rod (9) on chair leg (8),tighten with wrench bar (F).(see photos for example)
●
Step 6
HARDWARE REQUIRED
2*
D
9
D
6
D
8
8
HARDWARE REQUIRED
4*
DF
F
F
F

9
Step 7
●
Cover plastic footing(10) at bottom of chair leg(8).
Assemble all other chairs with same steps.
Attach seat cushion(7)on chair legs, insert screw(B) through holes on small metal welded at
side of chair legs.(see photos for example)
●
Step 8
E
HARDWARE REQUIRED
4*
E
8
10
7
E
●

10
