Hodedah HI71DR-G User manual

Assembly Instructions
This instruction booklet contains important safety information, please read and keep for future reference.
HODEDAH ®
ITEM # HI71DR-G (MOP-SP)
7 DRAWER CHEST
2 people
90 mins
1 YR LTD
2 Box
FRONT VIEW BACK VIEW
www.Hodedah.com 1| Page
Weight Capacity Per Drawer 25Ibs.
Product Dimensions: Height 48.39" x Width 47.24" x Depth 17.76"
Weight Capacity Per Shelf 25Ibs.

HODEDAH ®
www.Hodedah.com 2| Page
DO NOT RETURN PRODUCT TO THE STORE
Phone WebsiteEmail
Questions, need parts, we are here to help!
WARRANTY
WARNING
If parts are missing or damaged please contact our customer service team and we will
gladly ship your replacement parts FREE of charge within ONE YEAR of purchase!
Hodedah warrants this product to be free from defects in materials and workmanship and agrees to
remedy any such defect. This warranty covers one year from the date of original purchase. This is solely
limited to replacement of defective parts and no assembly for labor is included. This warranty does not
apply to any product that has been improperly assembled, subjected to misuse, abuse or which has been
altered or repaired in any way. To obtain warranty service, original purchaser must present the following;
original bill of sale, date of purchase, where the product was purchased and images if applicable.
Components replaced warranted through the remainder of the original warranty only. The defective part
will be replaced without charge, subject to the terms and conditions described above.
Mon - Fri | 9:30 am to 5pm EST Send us an email
FOR PROMPT, RELIABLE SERVICE PLEASE HAVE YOUR INSTRUCTION MANUAL READY
Visit our website to open a case
1 - 855 - HODEDAH
1 - 855 - 463 -3324
[email protected] www.Hodedah.com
·This product contains small parts, keep away from children.
·This product contains plastic bags, keep away from children.
·Serious or fatal crushing injuries can occur from furniture tip-over. To help
prevent this, place heaviest items on the lower shelves and drawers. Do not set
heavy objects on top shelves and drawers.
·Never allow children to climb or hang on drawers, shelves and doors.
·Never open more than one drawer at a time.
·The use of tip-over restraints may reduce but not eliminate the risk of tip-over.

HODEDAH ®
www.Hodedah.com 3| Page
Product Care and Maintenance
Let's get started…
·Never open more than one drawer at a time.
·The use of tip-over restranits may reduce but not eliminate the risk of tip-over.
·Make sure you receive all boxes. If your item is packed in one box, box count will read 1
of 1, likewise if your item is packed in two boxes, box count will read 1 of 2 and second
box will read 2 of 2.
·Read each step carefully. It is very important that each step is performed in the correct
order. If these steps are not followed in sequence, assembly difficulties will occur.
·Work in a spacious level area, preferably carpet, near the place the unit will be used.
·DO NO USE power tools to assemble your furniture, it will strip and damage parts.
·Your package should include the following hardware and parts. Parts are labeled or
stamped on the raw edge. Please inspect contents to ensure you have received all
components. If you are missing any hardware or parts please contact customer
service right away before assembly.
Helpful hints, read before beginning assembly
Assembly Tools Required (not supplied)
·Wipe clean with dry soft cloth, never use chemicals or cleaning products they will
damage the finish.
·Avoid placing your furniture in direct sunlight, as sunlight causes fading.
·Never push, drag or pull your furniture, to move to a new location carefully with
two or more people carry the unit to its new location.
·Avoid extreme changes in temperature by arranging furniture away from radiators,
heat and air vents and air conditioning units.
Hammer Phillips Screwdriver No Power Tools NeededTape Measure

HODEDAH ®
www.Hodedah.com 4| Page
Hardware List
1QTY
Screw M6 x 40mm 20 Pcs
Pvc Cap
2QTY
Screw M4 x 32mm
66 Pcs
3QTY
Screw M3.5 x 14mm
72 Pcs
QTY
8 Sets
6QTY
Pvc Dowel
33 Pcs
7QTY
8QTY
Nail
170 Pcs
9QTY
Allen Key
1 Pc
10 QTY
11 QTY
Hinges
12 QTY
Lock
Pvc Cap
Mini Fix
20 Pcs
8 Pcs
5
*For # 15 Drawer Slides
8 Pcs
Shelf Support
13 QTY
16 QTY
H-Profile
17 QTY
V-Bracket
28 Pcs
Screw M6.2 x 10mm
1 Pc
*For # 14 Drawer Slides
6 Pcs
Screw M 10 X 1/2 MM
3 Pcs
AIM
3 Pcs
18 QTY
2 Pcs
Hanging Rod
1 Pc
19
(separate from
hardware pack)
Anti-Tip Kit
QTY
1 PK

HODEDAH ®
www.Hodedah.com 5| Page
Accessories
4QTY
Handle 8 Pcs
Screw M4 X 20mm 16 Pcs
14
15
Drawer Slide - A
*Fix On Side Panels
QTY
7 Sets
QTY
7 Sets
*Fix On Side Panels Q & R
Drawer Slide - B
Important
1. Before you throw the package, please use the Check Box to identify the parts
and hardware to ensure that you have everything you need.
2. Check and measure the bolts before applying them to parts.
3. Do not completely tighten all hardware until the entire assembly is complete,
unless indicated otherwise.
* Fix On Drawer Side Panels Ⓠ
* Fix On Drawer Side Panels Ⓡ
* Fix On Side & Stand Panels Ⓐ, Ⓗ
* Fix On Stand Panels Ⓗ, ⒾA , H & I

HODEDAH ®
www.Hodedah.com 6| Page
AQTY
1 Pc
BQTY CQTY
1 Pc
DQTY
1 Pc
EQTY FQTY
1 Pc 1 Pc
GQTY HQTY IQTY
Parts List
JQTY KQTY QTY
MQTY
3 Pcs
L
Divider Panel
181x 413 x 15mm
Back Strengthening Panel
773 x 76 x 15mm
Kick Panel
1165 x 89 x 15mm
Right Side Panel
1200x 413 x 15mm
Strengthening Panel -Front
773 x 76 x 15mm
Front Strengthening Panel
773 x 76 x 15mm
Left Side Panel
1200x 413 x 15mm
Partition Panel
376x 340 x 15mm
Stand Panel
1095.5x 412 x 15mm
Strengthening Panel -Back
773 x 76 x 15mm
Bottom Panel
1165 x 412 x 15mm
Top Panel
1200 x 445 x 30mm
Back Panels
1140 x 397 x 3mm
1 Pc
1 Pc 1 Pc 1 Pc
NQTY
Left Drawer Front Panel
-Small Drawer
394 x 180 x 15mm OQTY
Right Drawer Front Panel
-Small Drawer
394 x 180 x 15mm
1 Pcs1 Pc
1 Pc 1 Pc
1 Pc

HODEDAH ®
www.Hodedah.com 7| Page
PQTY QQTY RQTY
SQTY TQTY UQTY
VQTY WQTY XQTY
Parts List
YQTY
Drawer Base
Supporting Panels
394 x 51 x 15 mm
Drawer Base Panels-Small
Drawers
353x 394 x 3mm
Drawer - Left Side Panels
394 x 116 x 15mm
Drawer Base Panels -Big
Drawers
746 x 394 x 3mm
Drawer End Panels -Small
Drawers
324 x 111 x 15mm
D rawer Front Panels -Big
Drawers
793 x 180 x 15mm
Adjust Panel
376x 340 x 15mm
Door Panels
1106 x 394 x 15 mm
Drawer End Panels -Big
Drawers
714 x 111 x 15mm
Drawer - Right Side
Panels
394 x 116 x 15mm
2 Pcs
5 Pcs
2 Pcs
5 Pcs 7 Pcs
2 Pcs
5 Pcs
7 Pcs
5 Pcs
1 Pc

HODEDAH ®
www.Hodedah.com 8| Page

13
13
13
6
6
6
6
6
6
5
5
5
5
5
5
310
11
310
11
310
11
10
11
3
PANEL A
PANEL K
17
3
5
5
5
5
17
3
HODEDAH ®
www.Hodedah.com 9| Page
Pre - Assembly
5
5
Screw M6.2 x 10mm
24 Pcs.
13
3
5Pvc Dowel
8 Pcs.
Screw M3.5 x 14mm
22 Pcs.
17 V-BRACKET
2 Pcs.
11 HINGES
3 Pcs.
10
SCREW M 10 X 1/2 MM
6 Pcs.
Mini Fix
6 Pcs.
6
SHELF SUPPORT
8 Pcs.
9
9
PANEL I
9
9
9
9
9
9
9
Insert the mini fix ⑥ (nuts) with the
cross arrow mark facing upward and
aim to panel A, I& K's top thru
holes. (As shown)
Place the drawer slide A ⑭ onto the 2 holes area
shown at left side panel A and I. Then tighten it
with 2 screws ⑬ and 1 screw ③. Do the same for
the 5 other slide A ⑭.
Insert pvc dowels ⑤,
into 8 non thru holes
as shown using
hammer to gently tap
them in.
Tighten
V-brackets ⑰on
panels Iand Kas
shown by using 2
screws ③.
Place Hinges ⑪ at the
panel Kas shown.
Then tighten the hinges ⑪
with 2 screws ⑩ and 2
screws ③.
1
2
3
4
5
6
13
314
14
3

RIGHT VIEW
5
5
5
5
14
14
13
13
13
PANEL H
PANEL D
PANEL E
PANEL F
PANEL G
5
5
5
5
5
5
5
5
5
5
5
5
PANEL J
5
5
5
PANEL C
5
HODEDAH ®
www.Hodedah.com 10| Page
Pre - Assembly
Screw M6.2 x 10mm
4 Pcs.
13
5
5
5
PANEL B
5
5
PANEL L
6
6
6
6
6
6
6
6
LEFT VIEW
13
13
14
13
5
14 5
6
6
5
5
Mini Fix
2 Pcs.
6
6Mini Fix
8 Pcs.
Pvc Dowel
25 Pcs.
5
Insert pvc dowels ⑤ to
both end of the panels
B, C, D, E, F, G&
Jas shown.
Using hammer to gently
tap them in.
Insert mini fix ⑥ (nuts) with the cross arrow
mark facing upward and aim to the panel H's top
thru holes. (As shown)
Place a drawer slide A ⑭onto the 2
holes area shown at left side of panel H.
Then tighten the drawer slide A ⑭
with 2 screws ⑬ and 1 screw ③ .
Insert, push down and tighten mini fix
screw ⑥, to the hole as shown, 8pcs.
Insert pvc dowels ⑤ to edge of the
panel H's non-thru hole as shown.
Using hammer to gently tap them in.
3
3
3
Screw M3.5 x 14mm
2 Pcs.
3
3

HODEDAH ®
www.Hodedah.com 11| Page
Assembly Of Small Drawers : 2 DRAWERS
Nail
20 Pcs.
7
3
Screw M3.5 x 14mm
12 Pcs.
Lock
2 Sets.
12
R
22
22
22
2
2
Q
S
N & O
Q
RS
T
N & O
3
3
3
3
3
15
15
3
7
(2)
COMPLETED
(4)
Q
R
S
Q
N & O
(3)
QS
12
Q
R
S
N & O
T
12
4
4
Screw M4 x 32mm
16 Pcs.
2
x2 x2
x2
x2
AIM
-Place panel Qand panel R on each side of panel N& Oas shown.
-Then, tighten screw ②to panel Qand panel R's lower thru holes
to fix them onto panel N& O.
-Next tighten screw ②to panel Qand panel R 's upper thru holes
to fix up to the panel S.
-Flip drawer over with bottom side down, disassemble the lock ⑫into 5 parts as shown,then install the lock ⑫
by inserting the lock ⑫'s cylinder into middle thru hole of panel N& O, then fix the lock up.
-Tighten 2 screw ④from inner side of panel N& Ointo the handle ④holes.
Handle Screw
M4 x 20mm
4 Pcs.
4
Handle
2 Pcs.
4
-Flip drawer with bottom side up, place panel Tonto the
drawer and align properly. Then nail the nails provided
with hammer on the border of panel Tas shown.The gap
between 2 nails should be about 100mm.
-After that, place drawer slide B ⑮with the small white
roller facing outward and with other end tip touching
panel N& Oonto each bottom side (angle) edge of
panel R and panel Q. Then tighten 3 screws ③on each
drawer slide B ⑮(as shown).
(1)

HODEDAH ®
www.Hodedah.com 12| Page
Assembly Of Big Drawers : 5 DRAWERS
Nail
80 Pcs.
7
3
Screw M3.5 x 14mm
30 Pcs.
Handle Screw
M4 x 20mm
10 Pcs.
4
Screw M4 x 32mm
50 Pcs.
2
Handle
5 Pcs.
4
(3)
Q
R
U
P
V
4
4
(4)
Q
R
U
P
V
COMPLETED
x5
x5
x5
x5
Q
R
U
P
V
W
3
3
3
3
3
3
15
15
7
2
2
(2)
22
2
2
22
22
(1)
Q
R
U
P
-Place panel Qand
panel Ron each side of
panel Pas shown.
-Then, tighten screw ②
to panel Qand panel R
's lower thru
holes to fix them onto
panel P.
-Next tighten screw ②
to panel Qand panel R
's upper thru
holes to fix up to the
panel U.
-Flip drawer with bottom
side up, place panel V
onto the drawer
and align properly. Then
nail the nails provided
with hammer on the
border of panel Vas
shown.The gap between
2 nails should be about
100mm.
-After that, place a
drawer slide B ⑮with
the small white roller
facing outward and with
other end tip touching
panel Ponto
each bottom side
(angle) edge of panel R
and panel Q. Then
tighten 3 screws ③on
each drawer slide B ⑮
(as shown).
-Put drawer supporting
W onto middle of panel
V, then tighten
screw ②to drawer
supporting W 's thru
hole to fix it onto
panel V/ panel P
(inner panel) / panel U.
-Flip the drawer over.
-Tighten 2 screw ④
from inner side of
panel Pinto the
handle ④holes.

HODEDAH ®
www.Hodedah.com 13| Page
Step 1
Screw
M 6 x 40mm
6 Pcs.
1Allen Key
1 Pc.
8
1
81
1
1
1
1
A
F
G
E
D
B
C
8
8
8
8
8
CAUTIONS : When inserting the PVC Dowels to non-thru holes, don't push to hard. Otherwise, the side
panels ( A, I & K ) may be damaged.
* Fix Panel Bonto Panel Cby inserting the dowel onto the non-thru
holes at Panel Cas shown.
* Fix Panel B,C,D,E,F,Gonto Panel A by inserting the (Left)
dowels onto the non-thru holes at Panel A.
* Using allen key ⑧to tighten screw ① from the 6thru holes
of panel A.

HODEDAH ®
www.Hodedah.com 14| Page
Step 2
Screw
M 6 x 40mm
8 Pcs.
1Allen Key
1 Pc.
8
A
B
C
D
G
F
E
H
I
1
1
1
1
8
1
1
1
1
8
8
8
8
8
8
8
CAUTIONS : When inserting the PVC Dowels to non-thru holes, don't push to hard. Otherwise, the side
panels ( A, I & K ) may be damaged.
* Fix Panel B,C,D,E,F,Gonto Panel Iby inserting the (Right) dowels onto the non-thru holes at Panel I.
*Place Panel H(with drawer slide A ⑭ downward and the small white roller facing frontward) onto panel
Gand panel Fby inserting the (down) dowels onto non-thru holes at bottom area of panel H. Using allen
key ⑧ to tighten the 2 screw ① from the middle thru hole of panel Gand Panel F.
* Using allen key ⑧ to tighten screw ① from the 4thru holes of panel H.

HODEDAH ®
www.Hodedah.com 15| Page
Step 3
Screw
M 6 x 40mm
6 Pcs.
Allen Key
1 Pc.
8
A
K
I
H
F
G
D
E
B
C
J
1
1
1
8
8
8
8
8
8
1
1
1
CAUTIONS : When inserting the PVC Dowels to non-thru holes, don't push to hard. Otherwise, the side
panels ( A, I & K ) may be damaged.
* Fix Panel Jonto Panel Iby inserting the (Left) dowels onto the non-thru holes at
Panel I.
* Using allen key ⑧ to tighten screw ① from the 2 thru holes of panel I.
* Fix panel Konto panel J, Band Cby inserting the (right) dowel onto the non-thru
hole at panel K.
* Using allen key ⑧ to tighten screw ② from 4 thru holes of panel K.
8

HODEDAH ®
www.Hodedah.com 16| Page
Step 4
A
H
6
6F
G
6
6
6
6
6
6
A
K
I
HF
G
E
D
C
B
J
L
Dowel / Mini Fix Installation
Place and fix panel
Lonto panel A,
panel H, panel I
and panel K, and
align properly by
inserting
the 8 (down) mini
fix screws ⑥ onto
the L-thru holes at
top edge of panel
A, H, Iand K. At
the same time,
pushing and light
tapping of panel L
downward to have
panel A, panel H,
panel Iand panel K
's upside dowel
going onto panel L
's non-thru holes.
Mini Fix Cap
8 Pcs.
6
*Then, tighten mini
fix ⑥clockwise
to lock the mini fix
up, for
tightening panel L
up. Cover 8 mini
fix caps provided
by pushing the
cover 's stem onto
the hole of mini
fix nut on upper
side of panel A, H,
Iand K.

HODEDAH ®
www.Hodedah.com 17| Page
Step 5
8Nail
44 Pcs.
A
I
K
M
M
M
F
H
L
GE
C
B
Back View
8
16 H-PROFILE
1 Pc.
16
* Lay the chest at face down position, Place the 3 back Panels Monto
the back of the main unit, and join the 2 panel Mtogather with H-profile
by slotting one side each of panel M into the track of H-profile. Then align
them properly for nailing.
* Then use hammer to nail the nails one by one and at center of
4 side edges. Gap between 2 nails should be about 100mm for all.

HODEDAH ®
www.Hodedah.com 18| Page
Step 6
1
L
HY
10
A
I
G
E
D
C
B
J
Y
K
1
1
1
1
1
1
1
1
Screw Cap
1
* Then take the adjusting panel Y
and place it inside the right
compartment by putting it on top
the 4 shelf support as shown.
* Lift up the main unit carefully and let it stand up properly.
* Cover all the screw ① 's head with the pvc cap provided by
pushing the cover's stem onto the hole of screw head one by
one for all screws.

HODEDAH ®
www.Hodedah.com 19| Page
Step 7
12 Lock
1 Set.
AIM
11 HINGERS
3 Pcs.
Handle Screw
M4 x 20mm
2 Pcs.
4
12
3
11
X
4
4
Handle
1 Pc.
4
Screw M3.5 x 14mm
6 Pcs.
3
* Insert Hinges ⑪into door panel X's non-thru hole as shown, then tighten screw ③
through hinges ⑪ 's thru hole.
-Disassemble the lock ⑫into 5 parts as shown,then install the lock
⑫by insert the lock ⑫'s cylinder into middle thru hole of panel X,
then fix the lock up.
-Tighten 2 screw ④from inner side of panel Xinto the handle
④holes.

HODEDAH ®
www.Hodedah.com 20| Page
Step 8
A
B
J
L
Y
K
Y
C
Adjust
X
NO
P
P
P
P
P
18
18 HANGING ROD
1 Pc.
* You can align the door panel Xby tightening and losening the
screw as shown.
* Place hanging rod onto both panels Iand K's
V-bracket.
