Honeywell Home 5800PIR-RES Assembly instructions

5800PIR-RES
Wireless Motion Sensor
Installation and Setup Guide
SMB-10 1
(P/N 0-000-110-01)
Swivel Mount Bracket
SMB-10C
(P/N 0-000-111-01)
Swivel Mount Ceiling Bracket
SMB-10T 1
(P/N 0-000-155-01)
Swivel Mount Bracket w/Tamper
IS2500-HSLK 1
35’ x 40’ (11 m x 12 m)
High Security Lens Kit
IS2500-PALK 2
35’ x 40’ (11 m x 12 m)
Pet Alley Lens Kit
1Not verified by ETL.
Mounting Height:
1 7 – 9 ft (2.1 m – 2.7 m).
2 4 ft (1.2 m).

ENROLL THE SENSOR
Enroll the sensor in the control panel prior to its usage in the
system. Refer to the control panel instructions for programming
details. Program the sensor as an “RF” type (supervised
RF) device.
To enroll: connect the battery and wait for power up to end
(see LED Indications table). When prompted for the serial
number, activate the sensor (wave a hand in front of the lens)
to enroll the sensor.
Loop 1 Pulse count 2; Up to 80 lbs. Animal Immunity
LED INDICATIONS
Condition
LED Indications
Power Up
Blinks once per second (for < 45 seconds)
Walk Test
ON for 3 seconds = Loop 1 / Low Sensitivity Alarm
Flickers rapidly for 3 seconds = walk test period
ended
Normal
The LED is disabled to conserve battery
MOUNT THE SENSOR (See page 1)
Before mounting the transmitter permanently, conduct Go/No
Go tests (see control panel manual) to verify adequate signal
strength and reorient or relocate the sensor if necessary.
For Animal (Pet) Immunity:
•Install the sensor where animals cannot come within 6 ft
(1.8 m) of the sensor by climbing on furniture or other
objects.
•Aim the sensor away from stairways, furniture or other
objects that can be climbed on by animals.
•Do not use optional swivel mount brackets.
WALK TESTING
The 10 minute walk test mode begins after power up, and can
be restarted by removing and replacing the battery.
As you walk through the detection pattern, the sensor LED will
light for 3 seconds to indicate each alarm detection.
NOTE: In walk test mode all transmissions will be sent as they
occur. During normal operation, only one transmission
sequence will occur within a 3-minute period to conserve
battery life.
TROUBLESHOOTING
Problem: The system displays a “low battery” message.
Solution: Replace the battery within 7 days.
SPECIFICATIONS
Power: Battery* (included).
1 x 3 V, Lithium;
Panasonic CR123A / Duracell
DL123A / Huiderui CR123A /
Resideo 466
Battery Life, years (typical):
5
RF Frequency:
345 MHz
Operating Temperature:
(for indoor use
environment)
14° to 131° F (-10° to 55° C)
Relative Humidity, no
condensation:
95% max.
Detectable Walk Rate:
0.7 – 7ft/Sec.
(0.2 – 2.0m/Sec.)
Temperature
Compensation:
Advanced Dual Slope
APPROVALS / LISTINGS
•FCC part 15, Class B verified
•IC, ICES-003, Class B verified
•C-Tick
•CE
•SIA-PIR-01 Passive Infrared detector standard features for
false alarm immunity.
•cETLus Listed
COMPLIANCE NOTES
•Product must be tested at least once each year.
•Product must be installed within the protected area only.
FEDERAL COMMUNICATIONS COMMISSION (FCC) & INDUSTRY CANADA (IC) STATEMENTS
The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or User's Manual. Unauthorized changes or
modifications could void the user's authority to operate the equipment.
CLASS B DIGITAL DEVICE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, as defined by FCC Rules Part 15.105. The Class B Digital Device statement
can be viewed at:
https://customer.resideo.com/en-US/support/residential/codes-and-standards/FCC15105/Pages/default.aspx
FCC / IC STATEMENT
This device complies with Part 15 of the FCC Rules, and Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Cet appareil est conforme à la partie 15 des règles de la FCC et exempt de licence RSS d’Industrie Canada. Son fonctionnement est soumis aux conditions suivantes: (1) Cet
appareil ne doit pas causer d’interférences nuisibles. (2) Cet appareil doit accepter toute interférence reçue y compris les interférences causant une réception indésirable.
Responsible Party / Issuer of Supplier’s Declaration of Conformity: Ademco Inc., a subsidiary of Resideo Technologies, Inc., 2 Corporate Center Drive., Melville, NY 11747,
Ph: 516-577-2000
The product should not be disposed of with other household waste. Check for the nearest authorized collection centers or authorized recyclers. The correct disposal of end-of-
life equipment will help prevent potential negative consequences for the environment and human health.
SUPPORT, WARRANTY, & PATENT INFORMATION
For the latest documentation and online support information, please go to: www.resideo.com
For the latest warranty information, please go to: www.security.honeywellhome.com/warranty
For patent information, see www.resideo.com
This product manufactured by Resideo and its affiliates.
The Honeywell Home Trademark is used under license from Honeywell International Inc.
Ê800-04182V1C4Š
800-04182V1CRev C3/12
*Battery Caution: Risk of fire, explosion and burns. Do not
recharge, disassemble, heat above 212° F (100° C), or
incinerate. Dispose of used batteries properly. Keep away from
children.
NOTE: Constant exposure to high or low temperature or high
humidity may reduce battery life.
