CIPer EXPIO Modules
PRODUCT DATA
APPLICATION
The WEB-O3022H and WEB-O9056H are Expansion
I/O modules that are exclusively utilized with the CIPer
Model 30 Controller (either WEB-C3036EPVBNH or
WEB-C3036EPUBNH).
They can be directly connected to the CIPer Model 30
Controller or remotely mounted up to 100’ away.
Multiple Expansion I/O Modules can be connected to a
single CIPer Model 30 Controller. You can mix the small
WEB-O3022H and the large WEB-CO9056H in any
combination to meet specific project I/O requirements.
The CIPer Model 30 Expansion I/O modules feature
removable terminal blocks, Hand-Off-Auto switches and
indicator LEDs and can be powered by the CIPer Model
30 Controller.
Features
• Plug-and-play functionality for each installation and
maintenance.
• All wiring connections are made to removable terminal
blocks to simplify device installation and replacement.
• Wide range of sensors supported sensors like 20KNTC,
PT1000 and other resistive sensors.
• Multiple Expansion I/O capability support and 300
additional points. Refer to CIPer Model 30 technical
documentation and SRB for more details.
• 16-bit A/D conversion resolution for accurate
measurement.
• Indication LEDs for all Digital and Analog Outputs (DO
& AO).
• HOA (Hand-Off-Auto) switches on DOs and AOs. HOA
are configurable and can be monitored.
• Compact size for small installation housings.
• Field configurable and programmable for control, input,
and output functions using the Niagara Framework®
based CIPer Model 30 programming tool.

CIPer MODEL 30 EXP I/O MODULES - PRODUCT DATA
31-00239EFS-01 2
Description
The WEB-O9056H module is a large expansion module which adds 20 additional I/O points, and the
WEB-O3022H module is a small expansion module which adds 7 additional I/O points. Multiple
expansion I/O modules can be added to a controller. Both I/O modules use the side-mounted terminal
port to connect with the CIPer Model 30 Controller and additional I/O modules.
Ordering part numbers
Table 1. Ordering part numbers
OS Number
(SKU)
Description
UI
(Universal
Input)
UI/AO
(Universal
Input/Analog
Output)
DO
(Digital
Output)
WEB-O9056H
Large Expansion Module, 20 Mixed I/O
9
5
6
WEB-O3022H
Small Expansion Module, 7 Mixed I/O
3
2
2
WEB-O3022H Dimensions
WEB-O9056H Dimensions
Figure 2. WEB-O9056H
Figure 1. WEB-O3022H

CIPer MODEL 30 EXP I/O MODULES - PRODUCT DATA
3 31-00239EFS-01
Specifications
Electrical
Rated input voltage: 20-30 VAC; 50/60Hz Power
consumption:
WEB-O9056H:
o207VA maximum for I/O module with all
connected loads.
o35 VA maximum for I/O module without any
load.
WEB-O3022H:
o87VA maximum for I/O module with all
connected loads.
o15 VA maximum for I/O module without any
load.
Operating Environment
Ambient temperature: -4 to 131°F (-20 to 55°C)
Storage temperature: -4 to 150°F (-20 to 65°C)
Humidity: 5% to 95% non-condensing
Inputs and Outputs
Analog Outputs (AO)
AOs are individually configurable for current or
voltage. Universal Inputs marked as UI-x/AO-x are
configurable as AOs.
Analog Current Outputs
Current Output Range: 4.0 to 20.0 mA
Output Load Resistance: 550 Ohms maximum
Analog Voltage Outputs
Voltage Output Range: 0.0 to 10.0 VDC Maximum
Output Current: 10.0 mA
Digital Outputs (DO)
Voltage rating: 20 to 30 VAC @ 50/60Hz
Digital Outputs type: Solid-State Relay
Current rating: 1.5A Continuous, 3.5A in-rush for
100 milliseconds
Universal Inputs (UI)
Flexible UI’s to connect external sensors like 20KNTC,
PT1000 and other resistive sensors.
Pulse Inputs:
Type: Dry contact
Frequency: 100Hz max,
Duty cycle: minimum 5 ms ON / 5 ms OFF
Table 2. Universal Inputs specifications
Input Type
Sensor Type
Operating Range
Room/Zone
Discharge Air
Outdoor Air
Temperature
20K Ohm NTC
-40° F to 199° F
(-40° C to 93° C)
Outdoor Air
Temperature
C7031G
-40° F to 120° F
(-40° C to 49° C)
C7041F
-40° F to 250° F
(-40° C to 121° C)
PT1000
(IEC751
3850)
-40° F to 199° F
(-40° C to 93° C)
TR23
Setpoint
Potentiometer
500 Ohm to
10,500 Ohm
50° F to 90° F
(10° C to 32° C)
Resistive Input
Generic
100 Ohms to 100K
Ohms
Voltage Input
Transducer,
Controller
0 - 10 VDC
Discrete Input
Dry Contact
closure
OpenCircuit ≥ 3000
Ohms
ClosedCircuit < 3000
Ohms
Status Indication LEDs
The expansion I/O modules indicate the device Power
and Fault status using the LEDs on top.
Standards and Approvals
•UL/CUL (E87741) listed under UL 60730-1 and CSA
E60730-1, UL 60730-2-9:2010.
•Meets FCC Part 15, Subpart B:2017, Class B (radiated
emissions) requirements.
•Meets Canada ICES-003:2016.
•EMC Directive: 2014/30/EU. Standards Applied:
oEN 61000-6:2005
oEN 61000-6-3:2007 + A1
oEN 60730-1: 2011, EN 60730-2-9: 2010
•RoHS Directive: 2011/65/EU.
oStandard EN 50581: 2012
Conformance Statement
This digital apparatus complies with CAN ICES-3 (B)/
NMB-3 (B).
FCC Notice
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
(2) this device must accept any interference received,
including interference that may cause undesired
operation.

CIPer MODEL 30 EXP I/O MODULES - PRODUCT DATA
Honeywell Building Technologies
Honeywell International Inc.
1985 Douglas Drive North
Golden Valley, MN 55422
customer.honeywell.com
© 2019 Honeywell International Inc.
31-00239EFS|Rev. 01 10-19
Safety Information as per EN60730-1
The Open System is intended for residential, commercial,
and light-industrial environments. The Open System is an
independently mounted electronic control system with
fixed wiring.
The WEB-O9056H and WEB-O3022H are suitable for
mounting in fuse boxes conforming with standard
DIN43880 and having a slot height of max. 1.77 inches
(45 mm).
It is suitable for panel rail mounting on 1.38 inches (35
mm) standard panel rail (both horizontal and vertical rail
mounting possible).
Table 3. Safety information as per EN-60730-1
Electric Shock
Protection
PELV
Pollution Degree
Pollution Degree 2, suitable for use in
industrial environments.
Installation
Class 3
Overvoltage
Category
24 V-powered controls: Category I
Rated Impulse
Voltage
330 VAC for Category I (SELV)
Automatic
Action
Type 1
Software Class
Class A
Purpose of control
Operating Control, Open Energy
Management Equipment.
Enclosure degree
of protection
IP20 (NEMA 1)
Ball-pressure
Test
Temperature
>75 °C for all housing and plastic
parts.
>125 °C in the case of devices
applied with voltage-carrying
parts, connectors, and terminals.
Electromagnetic
Interference
Tested at 230 VAC with the
modules in normal condition.
System
Transformer
Europe: safety isolating
transformers according to
IEC61558-2-6.
U.S.A. and Canada: NEC Class-2
transformers.
Mounting
The CIPer Model30 expansion I/O modules can be
mounted in any orientation on a DIN rail. Ventilation
openings are designed into the cover to allow proper
heat dissipation, regardless of mounting orientation.
When mounting on DIN rail, the locking clip present
on both I/O modules ensures accurate alignment of
connectors between all modules.
The controller can also be screw-mounted on a panel
using the four mounting tabs, accessible under the
covers. These mounting tabs may be broken off if
needed to save space when DIN rail mounting.
Note:
oAvoid mounting in areas where acid fumes or
other deteriorating vapors can attack the metal
parts of the controller, or in areas where
escaping gas or other explosive vapors are
present.
oMount in a position that allows clearance for
wiring, servicing and removal.
oFor complete mounting and wiring information,
refer to the CIPer Model 30 expansion I/O
Installation Instructions.
