Honeywell NOTIFIER ID2000 Series Guide

ID2000 installation &
commissioning
manual
997-433-000-5, Issue 5 May 2010

ID2000 Series Installation & Commissioning Manual
Contents
i 997-433-000-5, Issue 5
May 2010
The ID2000 Series Range of Fire Control Panels

ID2000 Series Installation & Commissioning Manual
Contents
ii997-433-000-5, Issue 5
May 2010
Contents
1 Introduction 1
1.1 CE Marking 1
1.2 System Design and Planning 1
1.3 Personnel 1
1.4 General 1
1.4 Date-dependent Functions 2
Installation: Sections 2-7
2 Installation Guide 3
2.1 How to Use this Guide 3
2.1.1 Related Documents 3
2.1.2 Warnings and Cautions 3
2.1.3 Tips 3
2.1.4 Glossary of Icons 4
2.2 Pre-Installation Check List 5
2.2.1 Some DO’s and DONT’s 5
2.3 Transient Protection 6
2.4 Installation 7
2.4.1 Checking Your Panel for Damage 7
2.4.2 What to do if Your Module is Damaged 8
2.4.3 Back Box Fixing 9
2.4.4 Electronics Modules 10
2.5 Replacing the Electronics Modules 11
2.6 Flush Mounting Bezel (Optional) 11
2.7 Mounded Front Covers 13
3 Cabling 14
3.1 Cabling Instructions 14
3.1.1 Cable Terminations 15
3.2 Cable Installation Notes 16
3.2.1 Introduction 16
3.2.2 Quality of Cable and of Cable Installation 16
3.3 EMC Considerations 17
3.3.1 Screen Termination 17
3.3.2 Ferrite Sleeves (Optional) 17
3.4 MICC Cables 17
4 Sensors and Modules 18
The following markings are used either
on the panel hardware or in the
documentation. They have the following
meaning:
WARNING: Risk of electric
shock. Before working on
mains connections, ensure
mains power supply to the
panel is disconnected.
CAUTION: Refer to the
accompanying documentation.
(When used in the
documentation, this marking is
normally associated with
additional instructions).

ID2000 Series Installation & Commissioning Manual
Contents
iii 997-433-000-5, Issue 5
May 2010
4.1 EN54 Requirements 18
4.1.1 Loop Devices - Sensors and MCPs 18
4.1.2 Loop Devices - Isolators 18
4.2 Loop Wiring Testing 18
5 Panel Electronics Modules 19
5.1 Introduction 19
5.2 Kit PSU3A 20
5.2.1 Procedure 20
5.3 Dual Transmission Path/Booster Module 23
5.4 Main Chassis 25
5.4.1 main Chassis Configurations 25
5.4.1 Procedure 25
5.5 Extension Chassis 26
5.5.1 Zones 17-80 LED Extension Chassis 26
5.5.2 Extension Chassis (With Printer) 26
5.6 PRN-ID Printer 27
5.6.1 Fitting the Paper Roll 27
5.6.2 Printer Used with Stainless Steel Cover 28
5.7 Display PCB 29
5.8 Base PCB 30
5.8.1 Fitting the Replacement Base PCB 31
5.8.2 Cables and Wiring 31
5.9 Processor PCB 32
5.10 Loop Interface PCB 33
5.10.1Cables and Wiring 33
5.11 Isolated RS232 Interface PCB 34
5.11.1Cables and Wiring 35
5.12 Isolated RS485 Interface PCB 36
5.12.1Cables and Wiring 37
5.13 Label Inserts 37
6 Repeaters and Network 38
6.1 Connecting Repeaters 38
6.2 Network Connections 39
7 VDU 40
8 Commissioning 41
8.1 Introduction 41
8.2 Preliminary Checks 41

ID2000 Series Installation & Commissioning Manual
Contents
iv997-433-000-5, Issue 5
May 2010
8.3 Powering the Panel 42
8.4 External Wiring 42
8.4.1 Introduction 42
8.4.2 Loop Checks Before Connecting Wiring 43
8.4.3 Connecting the Loop Wiring to the Panel 44
8.4.4 Loop Checks After Connecting Wiring 44
8.4.5 24V Auxiliary Outputs Check 45
8.4.6 Sounder Circuits Check 45
8.4.7 Fault Relay Wiring 45
8.5 Batteries 46
8.5.1 Connecting the Batteries 46
8.5.2 Battery Disposal 47
8.6 Earth Fault Monitoring 47
8.7 Volt-free Contact Output Option 48
8.8 Repeaters 48
8.9 Configuration and Handover 48
8.10 System Test 48
8.10.1 Zone Walk Test 48
8.10.2 Control Output Test 48
9 Maintenance 47
9.1 Routine Testing 47
9.2 Batteries 47
9.3 Cleaning 47
Appendices:
Appendix 1 Fault Messages and
Possible Meanings A1-1 to A1-5
Appendix 2 Specifications A2-1 to A2-5
Appendix 3 ID2000 System
Design Guide A3-1 to A3-3

1
ID2000 Series Installation & Commissioning Manual
997-433-000-5, Issue 5
May 2010
Introduction
1 Introduction
The purpose of this manual is to provide the user with all
recommended procedure descriptions and full technical
details for the successful installation and commissioning
of NOTIFIER’s ID2000 Series stand-alone fire alarm
controllers and repeaters or for a complete ID2000 Series
integrated Fire Control System.
Procedures described in this manual include appropriate
warnings and cautions to guide the user towards adopting
safe and methodical work practices during the installation
and commissioning phases.
1.1 CE Marking
CE
This panel is CE Marked to show that it conforms to the
requirements of the following European Community
Directives:
The EMC Directive 2004/108/EEC, by the application of
the following EMC Standards:
!EN 61000-6-3: Electromagnetic Compatibility (EMC)
Generic emission standard for Residential,
Commercial and Light industrial environments
!EN 50130-4: EMC Product family standard: Immunity
requirements for components of fire, intruder and
social alarm systems.
Low Voltage Directive 2006/95/EC, by the application of
the safety standard:.
!EN 60950-1: Safety of information technology
equipment.
The Constructive Products Directive 89/1-6/EC, by the
application of the following standards:
!EN 54-2: Fire detection and fire alarm systems -
Control and indicating equipment.
!EN 54-4: Fire detection and fire alarm systems - Power
supply equipment.
1.2 System Design and Planning
It is assumed that the system, of which the ID2000 Series
fire control equipment is a part, has been designed by a
competent fire alarm system designer in accordance with
the requirements of EN54 Part 14 and any other local
codes of practice that are applicable.
The design drawings should clearly show the positions of
all the ID2000 Series control equipment and field devices.
1.3 Personnel
Installation of this product must be carried out only by
suitably-qualified electrical engineers.

2
ID2000 Series Installation & Commissioning Manual
997-433-000-5, Issue 5
May 2010
Introduction
1.4 General
The ID2000 Series of intelligent fire alarm controllers are
designed for use with NOTIFIER’s range of addressable
analogue sensors, control and monitoring modules and
addressable call points.A unique signalling protocol is used,
having digital address and control signals, and analogue
pulse width monitoring for the reply data from devices. The
ID2000 Series supports the use of OPAL protocol devices,
but can only poll these devices in CLIP protocol mode.
The ID2000 Series control panel design complies with the
requirements of EN54 Part 2 and Part 4.
The design of the ID2000 Series of fire control panels is
based on a modular build concept which offers the user
completely flexible system solutions. Each control panel
comprises a number of separate build modules to simplify
the installation process. The electronic components are
contained in an easy-to-fit module called the main chassis.
The control panel can be used with either an internal or
external Power Supply Unit (PSU).
The ID2000 Series fire control panels are available either as:
a. Multi-loop, user-configurable Basic Equipment Kits
which are configurable with up to 8 loops, or as
b. Factory-configured, ID2002 2-loop control panels.
Any references in these manuals to configurations with
more than two loops are not applicable to the ID2002
control panel.
Each control panel has space provision for two sealed, lead-
acid batteries.
The serial communications interface operates under
RS485 protocol and enables networking of control panels
and the connection between control panels and repeaters.
While every effort is made to ensure the accuracy of the
content of this manual, the manufacturer reserves the
right to change the information without notice.
Installation
The ID2000 Series modules are easy to install providing
the recommended procedures described in this manual
are followed. To avoid inadvertant contamination of the
main chassis, comprising the PCBs and PSU, if mounted
internally, the manufacturer recommends that these items
are installed in the back box only after all other trades have
completed their tasks.
1.5 Date-dependent Functions
It should be noted that the calendar end date for this
product is 31/12/2099 (two thousand and ninety nine) and
it will perform correctly up to this date.
The calendar function has not been tested beyond this
date.
Only fit the electronics
module after all the other
trades have completed
their tasks!

ID2000 Series Installation & Commissioning Manual
Installation Guide
3 997-433-000-5, Issue 5
May 2010
2 Installation Guide
2.1 How to Use this Guide
This Installation Guide is intended to provide you with
simple guidelines on how to install an ID2000 Series fire
control panel or system, quickly and safely.
For each stage in the ID2000 Series panel installation
and commissioning procedures a brief description is given
of its purpose, complete with detail drawings, flow
diagrams and/or other graphics to make the instructions
easy to follow. Where required, procedures may be broken
down into one or more related flow diagrams, the number
being dependent upon the complexity of the defined task.
2.1.1 Related Documents
The guide does not describe any of the panel
programming or operating stages, as these are covered
by other related manuals. For more information refer to:
!ID2000 Series Operating Manual (ref. 997-434-XXX)
!ID2000 Series Panel Configuration Manual
(ref. 997-435-XXX)
!ID2000 Series Off-line Configuration Manual
(ref. 997-436-XXX)
2.1.2 Warnings and Cautions
Where appropriate, this guide and the remainder of the
manual include advisory warnings and cautions to remind
you to consider safety at all times, especially when
following the procedures described in this manual.
You are alerted to any areas where high voltage [i.e.
non-Safety Extra-low Voltage (SELV)] is present, or
where there may be a risk of damage to static-sensitive
devices if the recommended procedures described in
this manual are not followed. An example of a high
voltage warning and anti-static caution is provided to the
left of this paragraph.
The ID2000 Series control panel has many powerful built-
in features which, if used inappropriately, may contravene
the requirements of EN54. Where there is a possibility
of such an occurence, a suitable warning is given with
brief details of the EN54 requirement. A typical EN54
non-compliance warning is illustrated at left.
2.1.3 Tips
‘Handy tips’ are included, where appropriate, to assist
you in following quick and safe procedures for fire
detection system installation and integration.
Look for the ‘TIP!’ icon and supporting text, typically
illustrated at left.
WARNING High Voltage!
Take suitable precautions
to avoid electric shock.
EN54-2: 13.7
Maximum of 512
Sensors and/or
MCPs per system.
Magnetise the tip of your
screwdriver to help when
offering small screws to
holes in confined spaces.

ID2000 Series Installation & Commissioning Manual
Installation Guide
4997-433-000-5, Issue 5
May 2010
2.1.4 Glossary of Icons
Throughout this Installation and Commissioning Manual
and other supplied user documentation a number of
simple icons are used, either on their own or together
with larger illustrations, to simplify a particular task or
process.
The following icons are used to advise or indicate:
a) DO follow the recommended procedure or method
b) DO NOT use this procedure or method
c) Inspection of an item or sub-assembly is required at
this point
d) Following a defined process meets the required
approval/inspection criteria or standards
e) Following a defined process does not meet the
required approval/inspection criteria or standards
f) Additional items to be considered
g) This icon placed next to a pushbutton requires you to
press it as part of a described process, such as isolate
or test, or while programming the panel. Where two or
more icons are used, a number may be placed on or
near each hand to indicate the order of selection: 1
coming before 2, etc.
h) Activity process step - flow arrow for single action or
iterative actions
i) Leader arrow - used with activity processes
j) Sounder operating
k) Sounder not-operating or silenced
l) Digital clock timer - press and hold the applicable
pushbutton for the time indicated

ID2000 Series Installation & Commissioning Manual
Installation Guide
5 997-433-000-5, Issue 5
May 2010
2.2 Pre-installation Check List
Before installing the ID2000 equipment or fitting sensors,
you must first ensure that the following criteria have been
met. Failure to do this may not only result in damage to
the equipment, but may also cause problems when
commissioning the equipment or adversely affect its
performance.
2.2.1 Some DO’s and DON’T’s
Before selecting a location for the control panel and
devices, DO make sure that:
a) The operating ambient temperature is in the
recommended range:
5°C to 35°Cand
b) The relative humidity is between:
5% and 95%
c) The panel is wall mounted in a position which allows
clear visibility of displays and easy access to operating
controls. The height above floor level should be chosen
such that the LCD is just above normal eye level
(approximately 1.5 metres)
d) DO NOT locate the panel where it is exposed to high
levels of moisture
e) DO NOT locate the panel where there are high levels
of vibration or shock
1.5m

ID2000 Series Installation & Commissioning Manual
Installation Guide
6997-433-000-5, Issue 5
May 2010
f) DO NOT site the panel where there would be
restricted access to the internal equipment and
cabling/wiring connections.
2.3 Transient Protection
This equipment contains transient-protection devices.
Although no system is completely immune from lightning
transients and interference, for these devices to function
correctly, and to reduce susceptibility, this equipment
must be earthed correctly.
As with all solid state devices, this system may operate
erratically or can be damaged if subjected to lightning-
induced transients.
The use of overhead or outside aerial wiring is not
recommended due to the increased susceptibility to
nearby lightning strikes.

ID2000 Series Installation & Commissioning Manual
Installation Guide
7 997-433-000-5, Issue 5
May 2010
2.4 Installation
The ID2000 Series of modular fire control panels are
relatively simple to install providing the recommended
procedures described in this Installation Guide are
followed.
Follow all installation instructions described in this
manual. These instructions must be understood and
the manufacturer’s recommendations followed to
avoid damage to the control panel and associated
equipment.
2.4.1 Checking Your Panel for Damage
It is important to check all supplied equipment for
damage before proceeding with the installation!
Before attempting to install the modular components of
your ID2000 Series control panel, or other equipment,
you should do the following:
1After removing the various control panel modules or
other related equipment from its packaging, and
before you proceed with installing it in its chosen
location, check for any damage that may have
occurred while in transit.
Note: In the unlikely event that any of the supplied ID2000
Series items has been damaged, you MUST NOT
fit it but return it to your supplier. The procedure
for returning faulty items is described in Section
2.4.2, What to do if Your Module is Damaged or
Suspect.
2If you are satisfied that none of the supplied items
has been damaged you can now proceed with the
installation procedure. This manual addresses the
recommended installation methods of the various
ID2000 Series equipment components which are
supplied as separate build modules. Refer to the
relevant sections that apply to your configuration
requirements.
To prevent unnecessary damage to the electronic
components, the panel back box(es) should be installed
first, i.e. without fitting the main chassis at this stage.
Refer to Section 2.4.3, Back Box Fixing for details.
To avoid damage to the
control panel ensure that
you follow these
instructions
1
2
Do a quality check
before proceeding with
the installation!

ID2000 Series Installation & Commissioning Manual
Installation Guide
8997-433-000-5, Issue 5
May 2010
2.4.2 What to do if Your Module is Damaged or
Suspect
If you have problems regarding the quality of any supplied
order items including the control panel, its ancillaries or
this manual or items are missing, follow the procedure
below.
1DO NOT continue with the installation but contact your
supplier for advice on what to do next.
Similarly, if the product is found to be faulty during
installation contact your supplier immediately.
2To aid your supplier and the manufacturer, you are
requested to:
a. Quote the manufacturer’s unique batch reference
number which can be found on the packaging, main
chassis or inside the back box
b. With reference to PCBs, quote the part number and
revision level which can be found along one edge of
the PCB - refer to the applicable section of this manual
for specific details.
c. Note all the details relevant to your complaint, date of
receipt, packaging condition, etc. and forward this to
your supplier.
3Where the product needs to be returned to your
supplier, you are requested to use the original
packaging, or suitable anti-static equivalent, wherever
possible.
1
2
3
Thhshj iidjdhhh
Thhshj iidjdhhh
Adfddd jhjhgdjsfff iiiiojh
yudjdfh jfklrlkr uuu uui
hjfjufhf jjjk k,kljk uu ulg
efjkfjkjk
Adfddd jhjhgdjsfff iiiiojh
yudjdfh jfklrlkr uuu uui
hjfjufhf jjjk k,kljk uu ulg
efjkfjkjk

ID2000 Series Installation & Commissioning Manual
Installation Guide
9 997-433-000-5, Issue 5
May 2010
2.4.3 Back Box Fixing
The ID2000 Series control panel back boxes are available
122mm deep and 220mm (external dimensions including
fixing dimples). Where required, the deeper back boxes
allow the fitting of high-capacity-rated batteries as defined
in Section 7.5 Batteries and internally-mounted PSUs other
than the 3A-rated version. Where two part numbers are
quoted in the drawing at left, the first number refers to the
shallower back box and the second number refers to the
deeper back box.
The standard back box (PN: 020-472-XXX) is available
only in the 122 mm depth.
The fixing dimensions given below are applicable
irrespective of the back box depth.
Back Box Extension
In addition to the main back boxes, a smaller version, known
as a back box extension, is available. The back box
extension is also available in two depths: standard and deep.
The back box extension is designed to be wall mounted
immediately below any of the range of similar depth main
back boxes and is provided with corresponding 20mm
knockouts on the top and bottom faces. 20mm knockouts
are also provided on the top, bottom and rear faces of the
back box extension.
Wall Flatness
To prevent distortion, the ID2000 Series back box MUST
be installed on the wall as flat as possible, i.e. with a
maximum flatness deviation between any two points of
3mm. Where the wall is out of tolerance, use appropriate
packing pieces when installing the back box to meet the
above requirements.
Failure to comply with this requirement will result in
the misalignment of the internal and external screw
fixings.
Procedure
When a suitable location has been found for installing the
ID2000 Series control panel, proceed as follows:
1Using the centrally-positioned keyhole to temporarily
hold the back box in the required position on the wall,
mark the position of the fixing holes while ensuring
the panel is level.
Drawing showing
large ID2000 back
box fixing details
Notes:
All dimensions are in millimetres.
Fixing hole diameters are 6mm.
Continued overleaf.....
Continued overleaf.....

ID2000 Series Installation & Commissioning Manual
Installation Guide
10997-433-000-5, Issue 5
May 2010
2Using a suitable-sized drilling bit - for holes to take up
to 6mm (No.12-sized) wood screws - drill the required
number of holes.
3Prepare apertures (20mm knockouts) required for
cable access.
4Screw the panel back box to the wall using all fixing
holes and appropriate-sized screws. The back box
fixing holes can take up to 6mm (size No.12) round-
or pan-headed screws (DO NOT use countersunk
screws).
Note: Make sure the screw in the keyhole is driven fully
into the recess to avoid impacting the main chassis
when this is being fitted.
The number of screws required depends on the size
of the back box. The recommended screw quantities
are as follows:
Back Box Part Number Screw Quantity
020-472-XXX 4
020-473-XXX 6
020-474-XXX 6
020-475-XXX 8
020-476-XXX 8
020-508-XXX 4
020-509-XXX 4
DO NOT use the back
box as a guide when
drilling.
2.4.4 Electronics Modules
The ID2000 Series panel electronics modules, i.e. the
main chassis, which contains all processing, user-
interface and input/output processing PCBs, and either
the Power Supply Unit (PSU) or Dual Transmission Path
(DTP) unit, are supplied as separate, self-contained
assemblies. These modules are fitted in the panel back
box once all site power distribution and fire detection loop
cabling has been provided, in accordance with the system
design requirements and applicable local standards.

ID2000 Series Installation & Commissioning Manual
Installation Guide
11 997-433-000-5, Issue 5
May 2010
To avoid damage to the
electronics, remove trades’
operation debris before
fitting module.
This procedure MUST be followed:
1Fit the PSU to the main chassis - refer to Section 5.2
for details.
2Fit the main chassis to the back box - refer to Section
5.3 for details.
3Make all wiring, cabling and battery connections to the
main chassis - refer to Section 8, Commissioning for
details.
2.5 Replacing the Electronics Modules
In the unlikely event that an electronics module becomes
faulty, all necessary instructions are provided with the
replacement item and in this manual under Section 5,
Panel Electronics Modules.
2.6 Flush Mounting Bezel (Optional)
If semi-flush mounting of the ID2000 Series control panel is
required, a recess 110mm deep, for the standard depth
versions, or 208mm, for the deep versions, and large enough
to accommodate the back box must be cut in the wall (refer
to Section 2.4.3 Back Box Fixing for dimensions).
To fit the bezel:
1Offer the bezel (A), flat side towards you, to the front
of the back box (B) and position it so the bezel front
face (C) is lined up with the front face of the back box
shoulder (D).
2With the bezel held in position, use the slotted holes
(E) on the bezel side plates as guides to drill eight
3mm holes. Remove any swarf created.
3Use M3 self-tapping screws for fixing.
Note: The ID2000 Series back box must be fixed using
the rear fixing holes and reliance must not be
placed on the bezel as a means of fixing. The back
box must be fixed to a solid vertical surface, or
sub-frame inside the recess using the normal rear-
mounting holes.
All dimensions in millimetres
Before drilling the back
box, make sure that no
equipment is fitted.

ID2000 Series Installation & Commissioning Manual
Installation Guide
12997-433-000-5, Issue 5
May 2010
2.7 Moulded Front Covers
The ID2000 Series control panel is supplied with one, two
or three moulded front covers, depending upon your panel
configuration. Two moulded cover types are available; the
main and extension. All panel sizes require a main cover
kit (PN: 020-480). The larger panel sizes also require one
or two extension cover kits (PN: 020-481); the extended
versions use one extension cover and the double-extended
versions require two. The moulded front covers are also
available with high-security fasteners: main cover
(PN: 020-513); extension cover (PN: 020-514).
Observe ALL safety and anti-static precautions when
fitting the covers.
User Interface Doors (Optional)
If required, any cover can be fitted with a lockable,
transparent User Interface Door. This must be done
BEFORE the moulded cover is fitted to the back box
(refer to the instructions supplied with the User Interface
Door).
Taking suitable precautions, remove all packaging and
inspect for any damage that may have occurred during
transit. If damage has occurred, DO NOT PROCEED,
contact your supplier and refer to Section 2.4.2. If no
damage is evident, fit the main cover as follows:
1Offer the moulded front cover (C) symmetically to the
front of the back box in the correct orientation. The inner
top edge of the moulded front cover rests on the top flange
of the back box.
2Two types of hexagonal socket-headed M6 screw (D)
are used to fasten the cover to the back box: a. the
standard version, or b. the high-security version. The
standard version is tightened by means of a 4mm
hexagonal socket key, while the high-security version
requires a special 4mm security tool (PN: 334-068).
The tool is supplied with the cover.
To remove the cover, use the appropriate tool to unscrew
the fasteners.
Note: Ensure the cover is supported when releasing the
last fastener!
To fit the upper extension cover (F), follow the same
procedure as described for the main cover but with the
following differences:
1There are only two M6 screws (E), which must be
inserted into their respective fixing locations (G). If a
PRN-ID printer is fitted, refer to step 2 below.
i
ii
C
D (x4)
D (x4)
View
aorb
View
aor b
View
aorb
View
aor b
View
aorb
View
aor b
E (x2)
E (x2)
F
H (x2)
H (x2)
G (x2)
G (x2)
I (x2)
I (x2)
B (x4)
B (x4)
iii
View b
View b
D (x4)
E (x2)
H (x2)
D (x4)
E(x2)
H(x2)
View a
View a
D (x4)
E (x2)
H (x2)
D (x4)
E(x2)
H(x2)

ID2000 Series Installation & Commissioning Manual
Installation Guide
13 997-433-000-5, Issue 5
May 2010
2Prior to fitting the cover, if a printer is installed ensure
that you have allowed a sufficient length of printer
paper to be pulled through the cover aperture.
3Fit the appropriate plate over the printer paper exit
aperture.
The removal procedure for each extension cover is the
same as for the main cover.
The procedure for fitting the lower extension cover is the
same as that for the upper extension cover, using two M6
screws (H) and the lowest set of fixing locations (I). The
removal procedure is the same as for above.
If a printer is fitted ....
Use the metal serrated plate with the aperture (J),
provided, and fix over the extension cover recess (K).
Fit the serrated plate to the extension cover as follows:
1Remove the protective paper strips (L) from the back
face of the plate to reveal the adhesive areas.
2Offer the serrated plate horizontally to the extension
cover and, using sufficient pressure only, fix in the
recess (K).
3Using scissors, cut the end of the printer paper to
produce a straight edge and insert it through the
serrated plate aperture BEFORE fitting the extension
cover.
If a printer is not fitted ....
When fitting any extension cover without a printer use
the blanking label, i.e. with no aperture, (M) provided.
Follow the procedure given above to fix it over the
extension cover printer paper exit aperture (K).
eziSlenaP
)mm(
ylbmessAxoBkcaB
rebmuN
forebmuNlatoT
srenetsaF
)i(004
)ii(026
)ii(026
)iii(048
)iii(048
XXX-274-020
XXX-374-020
XXX-474-020
XXX-574-020
XXX-674-020
4
6
6
8
8
xoBkcaB
:snoisnetxE
XXX-805-020
XXX-905-020
2
2
PN: 236-624
PN: 236-624
PN: 345-338
PN: 345-338
a
b
c
J
K
M
L

ID2000 Series Installation & Commissioning Manual
Installation - Cabling
14997-433-000-5, Issue 5
May 2010
3 Cabling
3.1 Cabling Instructions
All wiring should comply with current IEE wiring
regulations, (BS7671), or the applicable local wiring
regulations. Note also the requirements of EN 54-14 for
cabling and interconnection of a fire detection and alarm
system.
For information on wiring inputs and outputs refer to the
appropriate module cable and wiring instructions to
identify the terminals. Refer also to Section 8.4
Commissioning, External Wiring for detailed
instructions.
Use the following rules when installing cables:
1Cables should be brought into the cabinet through
the 20mm knockouts provided on the top or top-back
face of the back box. Ensure that all openings in the
back box are closed before connecting power to the
panel. For example if more knockouts than required
have been removed, then block the holes with
blanking glands. This is to prevent access to
hazardous voltages.
2Tails should be of sufficient length to connect to the
appropriate termination points at the commissioning
stage.
3Cables should be screened and should be terminated
in appropriate glands to meet local wiring codes and
to preserve the integrity of the screen connection.
The cable screen is to be clamped inside the cable
gland, which must be fitted to ensure a 360obond is
formed with the metal of the back box.
4The supply to the panel must be provided with a
suitable and readily accessible double-pole mains
disconnect device. The mains supply must be suitably
fused and rated according to the specifications (see
Appendix 2, Specifications).
5The knockouts on the extreme right-hand side and
those provided on the bottom of the back box should
be used for mains cable entry. DO NOT bring mains
cables through any other knockouts and ensure that
the mains wiring is always separated from the low
voltage wiring. Tails of mains cables should be
provided with suitable additional sleeving before
connecting to the mains terminal block. All low voltage
cables should have a minimum 300Vac rating.
General cable installation notes are given in Section 3.2,
Cable Installation Notes.
Earth Blade Connections
Note: All blade connections to earth incorporate a locking
barb. To make a connection, push the shrouded
receptacle on to the earth blade (1). To remove
this connection, pull the shroud (2), NOT the earth
wire.
WARNING Risk of electric
shock. Before working on
mains connections, ensure
mains power supply to the
panel is disconnected.

ID2000 Series Installation & Commissioning Manual
Installation - Cabling
15 997-433-000-5, Issue 5
May 2010
3.1.1 Cable Terminations
This section provides some guidance on where to bring
cables into the back box for ease of termination.
a. The mains supply should be brought into the control
panel where the cable path to the mains termination
block is kept as short as possible.
b. All loop and ancillary cable terminations should be
brought into the panel at suitable positions to ensure
tails are kept as short as possible.
c. All loop and ancillary cable terminations should be
brought into the panel at suitable positions to ensure
tails are kept as short as possible.
d. A row of knockouts, ‘u’, should be left to provide
adequate mains supply input/signal cable
segregation.
The drawing below shows recommended points of entry
so that cabling can meet these requirements:
s
u
bmo
npfq
gr
a
e
i
h
g
f
a
e
d
b
l
k
c
n
mpr
oq
t
s
t
kldehi
Name Function Cable Knockouts
a. OUT 1 Sounder 2-core a
OUT 2 Sounder 2-core a
b. OUT 3 Sounder/Volt-free Contact 2-core b
OUT 4 Sounder/Volt-free Contact 2-core b
c. INPUT 1 Control Matrix 2-core Any Spare
INPUT 2 Control Matrix, Day/Night
Mode Remote 2-core Any Spare
d. AUX 1 Auxiliary output 2-core d
e. AUX 2 Auxiliary output 2-core e
f. LOOP 1 Loop circuit 1 OUT 2-core f
LOOP 1 Loop circuit 1 IN 2-core f
g. LOOP 2 Loop circuit 2 OUT 2-core g
LOOP 2 Loop circuit 2 IN 2-core g
Name Function Cable Knockouts
a. OUT 1 Sounder 2-core a
OUT 2 Sounder 2-core a
b. OUT 3 Sounder/Volt-free Contact 2-core b
OUT 4 Sounder/Volt-free Contact 2-core b
c. INPUT 1 Control Matrix 2-core Any Spare
INPUT 2 Control Matrix, Day/Night
Mode Remote 2-core Any Spare
d. AUX 1 Auxiliary output 2-core d
e. AUX 2 Auxiliary output 2-core e
f. LOOP 1 Loop circuit 1 OUT 2-core f
LOOP 1 Loop circuit 1 IN 2-core f
g. LOOP 2 Loop circuit 2 OUT 2-core g
LOOP 2 Loop circuit 2 IN 2-core g
1-
2
3
NOT for the ID2002 Series Panels.
- Power supply cables (x2) and fault indication wiring.
- Recommended with internal PSU option.
1 -
2
3
NOT for the ID2002 Series Panels.
-Power supply cables (x2) and fault indication wiring.
-Recommended with internal PSU option.
Name Function Cable Knockouts
h. FAULT RELAY Fault relay outputs 2-core h
i. FIRE RELAY Fire relay outputs 2-core i
j. COVER OFF Not supported - -
k/l. RS232/RS485 Comms circuits 2-core k/l
m-r LOOPs 3/4,5/6,7/8 As item f. as item f. m-r
s. Fused Mains Block Termination of mains input 3-core s
t. External PSU DTP/Booster termination 3 x 2 cores t
u. Leave Spare Mains/signal wiring segregation - u
1
2
Name Function Cable Knockouts
h. FAULT RELAY Fault relay outputs 2-core h
i. FIRE RELAY Fire relay outputs 2-core i
j. COVER OFF Not supported - -
k/l. RS232/RS485 Comms circuits 2-core k/l
m-r LOOPs 3/4,5/6,7/8 As item f. as item f. m-r
s. Fused Mains Block Termination of mains input 3-core s
t. External PSU DTP/Booster termination 3 x 2 cores t
u. Leave Spare Mains/signal wiring segregation - u
1
2
The drawing shows the recommended points
of entry so that cabling can meet these
requirements.
Panel with internal PSU
i. Base PCB cabling/wiring terminations
using top-face knockouts ‘a, b, f and g’.
ii. Base PCB cabling/wiring terminations
using rear knockouts ‘d, e, h and i’.
iii. RS232 or RS485 cabling terminations using
rear knockouts ‘k and l’.
iv. Loops 3/4, 5/6, 7/8 cabling using top face
knockouts ‘m/n, o/p and q/r’ respectively.
v. Power supply cable entry using knockouts
‘s’.
Panel with external PSU
As above except for item v above, which is
replaced with:
vi. DTP/Booster Module cabling using
knockouts ‘t’. See external PSU and DTP/
Booster Module instructions for details.
