Honeywell Galaxy 16 User manual

16 and 16 plus
Users Guide
123
456
789
0
ent
esc
*#
A
u
B
u
GALAXY 16+ V2.XX
06.22 TUE 30 JUN

iii
Contents
INTRODUCTION ......................................................................... v
QUICK OPERATION GUIDE .....................................................vii
GLOSSARY OF TERMS ............................................................ ix
KEYPAD INFORMATION ........................................................... 1
Star (Ö) Key Features ............................................................................. 2
SETTING AND UNSETTING THE SYSTEM ............................... 3
Setting the System ................................................................................... 3
Unsetting the System ............................................................................... 4
Cancelling Alarms .................................................................................... 5
USER MENU ............................................................................... 7
Option 1  Omit ........................................................................................ 7
Option 2  Chime ..................................................................................... 8
Option 3  Walk ....................................................................................... 8
Option 4  Codes ..................................................................................... 9
Option 5  Test ...................................................................................... 10
Option 9  Log ....................................................................................... 11
Option 10  Time ................................................................................... 12
APPENDIX A  ALARM AND HELP MESSAGES ...................13
APPENDIX B  AVOIDING FALSE ALARMS..........................15
ZONE REFERENCE TABLE ......................................................17

INTRODUCTION
The Galaxy 16 and 16 plus control panels are designed to the highest speci-
fications and requirements using the most advanced software and hardware
technology.
The Galaxy 16 and 16 plus are designed to satisfy the requirements of do-
mestic and smaller commercial installations, yet are flexible enough to pro-
vide ease of use and operational versatility.
This Users Guide contains the information required to operate the system.
The installation engineer will program and commission the system to meet
your requirements. The system is simple to operate but users are advised to
read this guide carefully before using the system and retain it in a safe place
for future reference.
v

vii
ENTER YOUR USER
CODE THEN SELECT
QUICK OPERATION
GUIDE
A SET (an Unset system)
B PART SET (Defaults to Parts 1 and 2)
1key  toggles the Set (ON)/Unset (OFF) status of Part 1
2key  toggles the Set (ON)/Unset (OFF) status of Part 2
3key  toggles the Set (ON)/Unset (OFF) status of Part 3
ent UNSET (a Set system)
1 OMIT ZONES
Aor Bkey to view zones
#to change omit status of zone (must be an omittable zone)
ent key to accept programming and start setting
esc key to accept programming without setting
2 CHIME ZONES
Aor Bkey to view zones
#key to enable/disable chime function on zone
ent key to accept
esc key to cancel
3 WALK TEST
A or Bkey to view zones
#key to enable/disable Walk Test function on zone
ent key to start Walk Test
#key to toggle display between open and tested zones
esc key to end Walk Test
Note: Zones number 10 to 16 will be displayed as A to G
4 (ASSIGNING) USER CODES
Aor Bkey to select user (1  14)
ent key to program code
number keys to enter digits, Ökey to delete digits
ent key to accept programming, esc to cancel
5 TEST OUTPUTS
Aor Bkey to select output for test
#key to enable/disable test function on zone
esc key to end test
9LOG
Akey to step forwards through events
Bkey to step backwards through events
#key to display event date
esc key to exit Log
ent+BTIME
To access the Time option, enter your user code, press the
ent key, the Bkey and then the ent key.
Then press the:
1key to select Time (hh/mm)
2key to select Date (dd/mm/yy)
3key to select Start Summer (dd/mm)
4key to select End Summer (dd/mm).
Press the ent key to accept the programming for each option,
or the esc key to cancel.

GLOSSARY OF TERMS
Chime: Zone attribute which gives an audible indication of the
activation of a detector or contact.
Duress: Applicable when a remote signalling device is fitted.
A Duress code entered at the keypad will unset the
system but transmit a Duress code to the Alarm Re-
ceiving Centre.
Entry Time: The preset time allowed for users to reach the keypad
and unset the system.
Exit Time: The preset time allowed for users to leave the building
after the setting routine has been initiated.
Exit Terminator: A switch or push-button located outside the protected
area and used to set the system.
Event Log: The control panel memory which stores, in sequence,
a record of the system events.
Final Exit: The last door closed or detector operated by the user
on exit.
LCD Liquid Crystal Display.
Nonomit: An alarm circuit which cannot be omitted (bypassed)
by the user.
Numeric Keypad: The unit comprising the LCD display and buttons that
is the interface between users and the system.
Omit: Setting the system with alarm zones excluded from the
system. Only zones programmed as omittable by the
engineer can be omitted.
PA Panic Alarm: an emergency button or switch used to
set off the alarm; results in instantaneous transmission
of a silent alarm signal using the remote signalling de-
vice.
Part Set: To set only a section of the full system.
Programme: To alter the system functions or parameters.
Set: To arm the system.
Unset: To disarm the system.
User Code: A four digit code that identifies users to the system.
Walk Test: A routine test of the alarm detectors.
Security Circuit: An alarm circuit which has been programmed to be
armed continuously whether the system is set or
not.
ix

x

KEYPAD INFORMATION
The Galaxy system is programmed and operated from the LCD keypads.
Figure 1 Galaxy Mk III LCD Keypad.
Number Keys (09): are used to enter your User Code and to select and
modify options.
View (Aand B) Keys: are used to set the system and to step through the
menu options during programming.
Enter (ent) Key: The ent key allows you to unset the system, to access the
menu options and to accept programming selections.
Escape (esc) Key: The esc key permits you to cancel any modifications
made to a menu option and allows you to return to the previous menu option
level. The esc key also aborts the setting routine if pressed during the Exit-
time from the same keypad used to initiate the setting.
Hash (#) Key: The #key is used as a toggle key, which enables or disables
the programming features of certain menu options. It is also used to select the
user attributes feature in menu option 4  Codes.
Star (Ö) Key: The Ökey, when combined with other keys, provides special
functions. The engineer will advise of these where applicable, see also: Star
(Ö) Key Features.
1
2 × 16 CHARACTER
LCD DISPLAY
123
456
789
0
ent
esc
*#
A
u
B
u
GAL AXY 16 + V2.XX
06.22 TUE 30 JUN
POWER LED

Power LED: The green power LED remains lit whenever the system is con-
nected to the a.c. mains power supply and a charged stand-by battery. A
mains power failure is indicated by the LED flashing slowly. A fuse or bat-
tery failure is indicated by the LED flashing quickly.
Your User Code: is a four digit personal identification number which iden-
tifies you to, and allows you to operate, the system.
Note: Entry of an invalid code will cause the keypad to display the message
INVALID CODE. Entry of six consecutive invalid codes will cause a
ten minute keypad lockout during which the keypad horns activate
and the keypad displays the message ALARM IS ACTIVE. No further
code entries will be recognised during the lockout period.
Star (Ö) Key Features
The star key is used as a shift key, when combined with other keys it provides
additional system features. To toggle the enable status of the Star key features
enter either the manager code (User 14) at the keypad and then hold down the
Star (Ö) key and press the esc key; after a second the keypad displays Ú
ENABLE ON, or, ÚENABLE OFF; release both keys.
2
noitanibmoCyeKerutaeFratS
Ö1.emulovrezzubdapyeksegnahC
Ö2.mralaAPsetavitcA
+edoC.rgM Ö3

yxalaGesirohtuaotffO/nOselggoT
.noitcennocdloG
Ö4.ffO/nOgnithgilkcabdapyekselggoT
Ö5.mralalacideMsetavitcA
+edoC Ö6.sliatedmetsyseritneehtstnirP
+edoC Ö7.goltneveeritneehtstnirP
Ö8.mralaeriFehtsetavitcA
Ö9

.tseTs'reenignEehtsetaitinI
Ö#.sesutatsenozsetacidnI
+edoC.rgM Ötne

.kcaBllaCdloGyxalaGehtsetavitcA
+edoC.rgM Öcse selggoT Ö.ffO/nOseutaefyek

61yxalaG sulp .ylno
Table 1: Star Key Features.
Note: The Star mode must be enabled for the Star features to operate.

SETTING AND UNSETTING THE SYSTEM
Setting the System
Before Setting the System
Before the system is Set ensure that:
 All doors and windows are secured.
 All areas protected by movement detectors are free from obstructions
and any animals are excluded from the areas to be protected.
Full Setting the System
Enter your User Code and press the Akey:
 If all the system zones are closed when the setting routine is initiated
the keypad sounders will emit a continuous tone and the keypad
displays the Exit Time countdown blocks.
 If any zones are open (for example: protected doors or windows; or if
someone activates a movement detector when the setting process is
started) then the keypad sounders pulse rapidly and the keypad displays
which zones are open. Closing the open zones allows the setting routine
to restart.
Leave the building using the agreed Exit Route. Close and lock the Final Exit
Door and then, if fitted, operate the Exit Terminator; the horn outputs and the
keypad buzzers become silent for four seconds, the countdown blocks all
clear and the keypad buzzers emit two long tones to confirm that the system
is Set. On the keypad the message SYSTEM IS SET appears before the dis-
play goes blank.
The setting routine can be aborted, before the system sets, by pressing the
esc key on the keypad used to initiate the setting routine.
Part Setting the System
Your alarm system can be Part Set using the B key. To Part Set the system
enter your User Code then press the Bkey. The keypad then displays the Set/
Unset status of those parts assigned to your code, see Figure 2 Part Setting
Options.
3
SELECT P1=OFF
P3TON
Part Set options for user code
with Parts 1 and 3 assigned.
Part 1 is unset, Part 3 set.
Figure 2: Part Setting Options.

4
The Parts marked ON are Set, those marked OFF are Unset. To alter the
set/unset status of a Part press the number corresponding to that part, that is,
pressing the 1 key toggles the set status of Part 1 between set/unset.
The equals sign denotes that what is displayed beside the Part number is the
current status of the Part, that is, P1=ON denotes that Part 1 is currently set.
Pressing the 1key will cause the display to read P1TOFF, this means that
Part 1 is now provisionally programmed as Unset.
The actual set status of the part will not be altered until the ent key is pressed
to accept the programming.
Once the ent key has been pressed leave the building using the agreed exit
route. Close and lock the final exit door and then operate the exit terminator;
the horn outputs and the keypad buzzers become silent for four seconds, the
countdown blocks on the keypad display all clear and the keypad buzzers
emit two long tones to confirm that the system is set. On the keypad the
message SYSTEM IS SET appears before the display goes blank.
The setting routine can be aborted, before the system sets, by pressing the
esc key on the keypad used to initiate the setting routine.
Note: If the Silent Part Set facility has been enabled only the keypad display
indicates the setting status, that is, no audible tones are emitted.
Unsetting the System
Normal Entry
The system begins the unsetting routine whenever a Final door opens or an
Exit/Entry zone is activated. The keypad buzzers pulse slowly indicating that
the Entry Time countdown has started.
To unset the system, go directly to the keypad using the agreed entry route,
enter your code and press the ent key.
Slow Entry
The keypad sounder begins to pulse rapidly after 75% of the entry time has
expired to indicate that time is running short. If the entry time expires before
a valid user code is entered, a full alarm occurs.
Straying From The Entry Route
If, during the entry routine, you stray from the agreed entry route and activate
a zone in a protected area an audible alarm occurs.

5
Alarm Abort
Note: If the system is programmed for Alarm Abort a period of 90 seconds
after expiry of the Entry Time is provided to enable the user to cancel
an alarm caused by exceeding the Entry Time or deviating from the
entry route.
If the 90 second Alarm Abort time is exceeded then a full alarm may
result in the Police being called to the premises and the system requiring
an Engineer Reset.
The installation engineer will explain the operation of the Alarm Abort func-
tion where necessary.
Cancelling Alarms
To cancel an alarm enter your user code. The keypad displays the zones that
have been activated during the alarm. Press the esc key to return to the nor-
mal display.
Certain types of alarms, once cancelled, require a code authorised with the
appropriate reset authorisation to be entered. The system prompts for a valid
reset code by displaying INTRUDER RESET REQUIRED, PA RESET RE-
QUIRED or ENGINEER RESET REQUIRED on the keypad.
Engineer Reset
Certain types of alarm require an engineer to visit the site and, after investi-
gation, reset the system.

7
USER MENU
For access to the menu options enter your user code then press the ent key.
The keypad then displays the menu options available to the user.
