Honeywell GALAXY 16103 User manual

User Guide
Galaxy 2-44
Honeywell Security

iii
Table of Contents
Table of Contents .............................................................. iii
Introduction .........................................................................................1
Controlling Your Alarm System ..........................................................2
Users .................................................................................................................................... 2
Groups .................................................................................................................................. 2
Keypads ................................................................................................................................3
Prox Tags/Cards .................................................................................................................. 3
Wireless Keyfobs ................................................................................................................4
Setting the System — Full Set ............................................................4
Setting the System — Part or Night Set .............................................5
Setting with Faults...............................................................................5
Cancelling System Setting .................................................................6
Unsetting..............................................................................................6
Cancelling an Alarm ............................................................................6
Alert Conditions...................................................................................6
Setting and Unsetting Groups............................................................6
Setting and Unsetting Without Group Choice .................................................................... 6
Menu Access........................................................................................7
Setting and Unsetting With Group Choice .......................................................................... 7
Menu 11 - Omit Zones .......................................................................................................... 8
Menu 12 - Timed Set ............................................................................................................ 8
Menu 13 - Part Set ............................................................................................................... 8
Menu 14 - Night Set .............................................................................................................. 8
Menu 15 - Chime .................................................................................................................. 8
Menu 21 - Zone Status ......................................................................................................... 8
Menu 22 - View Log ............................................................................................................. 9
Menu 23 - Display Version ................................................................................................... 9
Menu 24 - Print ..................................................................................................................... 9
Menu 31 - Walk Test .......................................................................................................... 10
Menu 32 - Output Test........................................................................................................ 10
Menu 41 - Time/Date .......................................................................................................... 10
Menu 42 - Editing Users..................................................................................................... 10
Menu 44 - Mobile Numbers ............................................................................................... 12
Menu 47 - Remote Access ................................................................................................ 12
Menu 48 - Level 3 Access ................................................................................................. 12
Zone Reference Table .......................................................................13
Installer Details ..................................................................................13

iv

1
Introduction
The Galaxy 2-44 is a programmable alarm control panel that will allow you to protect your
home or business by providing secure and reliable intruder detection.
The system can be fully tailored by your installer to operate in the most convenient way for
your lifestyle or working practice. If there are any changes in your requirements, your installer
will be able to make any necessary changes to the system configuration in order to continue to
provide the best protection whilst maintaining ease of use.
An alarm system will protect you best only when used correctly. Please take the time to read
through these instructions carefully in order to get the best from your alarm system, and avoid
false alarms.
Remember: An alarm system will only protect against intruders if it is Set appropriately.
Always remember to Full Set, Part Set or Night Set the system when applicable.
WARNING: There are no user serviceable parts inside the alarm system component housings.
Refer all servicing to qualified alarm service engineers.

2
Controlling Your Alarm System
Users
Each person who uses the system is described as a ‘User’ and can have their own unique
identity, in the form of a PIN code, prox tag or wireless keyfob, or a combination of all 3.
Different users can have a different level of access to the alarm system functions. All this can
be set up in the user programming section described later.
The control panel can be controlled in one of 3 ways:
1. By entering a PIN code at a keypad and pressing function buttons.
2. By presenting a Proximity (prox) tag to a prox reader.
3. By pressing a button on a special encrypted wireless keyfob.
Although all of the above methods of control will allow the user to set and unset the system
for day to day operation, the keypad is required to reset the system after an alarm or fault
condition. The keypad is also used to access the menu structure where additional functions
can be accessed such as:
Viewing the event log
Programming user codes
Temporarily omitting zones from the system
Groups
On larger systems, it is often necessary to split the system into separate areas or ‘Groups’ that
can be set and unset independently by different users. Group operation can only be set up by
an installer. The Galaxy 2-44 can be split into 3 separately controllable groups. If your system
has been set up with Group operation, look for the notes on Groups throughout this manual.

3
Keypads
There are two types of keypad available as shown below but both work in a similar manner.
The number buttons are for entering PIN codes and for changes options. The function keys
down the side have the following use:
A>: This scrolls forward in a list or menu and activates a FULL set.
B<: This scrolls backwards in a list or menu and activates a PART or NIGHT set.
ent: This saves a current setting or activates the currently displayed command.
esc: This aborts an operation or escapes back out of a menu option.
The default user PIN code is 1234. It is strongly recommended that this code be changed to
something else as soon as possible. Choose a PIN code that you can remember easily but
would be difficult for an intruder to guess.
Mk7 LCD Keypad 6160 Keypad
Prox tags/cards are devices that contain a mi-
crochip that has a unique serial number. This
number can be read by holding the tag/card in
front of a prox reader. Prox tags/cards will allow
you to set and unset the system only. The prox
readers are usually built in to the case of a
keypad and are identified by the prox symbol
as shown:
Prox Tags/Cards
Setting/Unsetting Mk7 keyprox with a prox card
123
456
789
0
*
#
FULL PA R T NIGHT
TEST OMIT
CODE CHIME
LOG EASY SET
ESCAPE
A
B
ent
esc
GALAXY 44 V1.0
08:58 TUE 22 NOV
123A
456B
789ent
*
0#esc
GALAXY 44 V1.0
08:58 TUE 22 NOV
123
A
456
B
789
ent
*
0
#esc

4
Wireless Keyfobs
Keyfobs are portable controllers that can
be attached to a key ring. They will allow
you to Set and Unset the system by a
single press of a button and can some-
times be programmed with additional
functions. Because they operate by radio,
they can be used anywhere around the
premises provided that they are within
range of the installed radio receiver.
NOTE: Labels are provided to place over
the buttons to indicate the function.
Setting the System — Full Set
To set the system, make sure all doors are closed and windows are secure. The system cannot
be set if there has previously been an alarm which has not been reset.
To set the entire system:
Keypad:
Type your PIN code
then press [A]
Wireless Keyfob:
Press [ON] button
Prox Tag:
Hold the tag in front
of the prox symbol for 3
seconds
The exit timer will begin and there will be a constant tone. Leave by the agreed exit route and
close the door. When the exit timer expires, there will be a 5 second settle period and then two
beeps will confirm the completion of setting.
If you hear a rapid beeping sound, the system cannot set as there are open zones. The keypad
will show which zones are open.
Open ZoneOpen Zone
Open ZoneOpen Zone
Open Zone 10441044
10441044
1044
The setting procedure can be cancelled at any time during the exit time by pressing the esc key
on the keypad, the [OFF] button on the keyfob or placing the tag back in front of the prox
symbol.
NOTE: Display not shown when
using wireless keyfobs to set
the system.
FULL SET 060FULL SET 060
FULL SET 060FULL SET 060
FULL SET 060
        

5
Setting the System — Part or Night Set
Part and Night setting are similar to Full setting but leave off certain detectors as agreed with
your installer. Additionally, the system can be programmed by the installer not to give any exit
timer tones during the setting period (silent set).
To Part or Night set:
Keypad:
Type your PIN code
then press [B].
Press [1] Part Set or
Press [2] Night Set.
Wireless Keyfob:
Press the [Lower Left]
button (Part) or
Press the [Lower Right]
button (Night).
Prox Tag:
Use the keypad for Part
or Night setting.
The tag will only Full
Set.
A 30 second exit timer will begin. Leave the protected area by the agreed route. A double
beep at the end of the exit time will confirm setting.
Setting with Faults
Normally, if there is a fault of any kind on the system, setting will not be permitted until the
fault is rectified. However, depending on the set-up of your system and the level of your user
access, it may be possible override a fault and proceed with the setting procedure.
If there are faults present when you try to set via the keypad, the following typical display will
be shown:
Fault OverrideFault Override
Fault OverrideFault Override
Fault Override
03 Event(s)>03 Event(s)>
03 Event(s)>03 Event(s)>
03 Event(s)>
Use the cursor keys to scroll through the faults. If you are able to override them, the bottom
row will show the message ENT to continue>.
AC FailAC Fail
AC FailAC Fail
AC Fail
ENT to ContinueENT to Continue
ENT to ContinueENT to Continue
ENT to Continue
Pressing the ent key at this point will override the fault for one set period only and allow the
system to set. If there is more than one fault, this process is repeated for each fault.
NOTE: Display not shown when
using wireless fobs to set
the system.
PART SET 030PART SET 030
PART SET 030PART SET 030
PART SET 030
        

6
Cancelling System Setting
The Full, Part and Night setting routines can be cancelled, before the system sets, by pressing
the esc key on the keypad used to begin the setting routine. To cancel the setting routine on
another keypad, type in your user PIN code and press A> or ent.
Unsetting
To unset the system, enter the protected area by the agreed route. A timed entry period will
begin and a pulsed tone will sound.
Cancelling an Alarm
The process for cancelling an alarm is similar to unsetting the system. However, if a wireless
keyfob or prox tag has been used, the alarms must be viewed on a keypad by typing in a user
code and following the on-screen instructions. Only certain users are able to reset the system
following an alarm condition. You installer will inform you which users have this ability.
Alert Conditions
If a fault condition occurs when the system is unset, an ‘Alert!’ message will be shown on the
keypad accompanied by an intermittent beep. If this occurs, you should go to the nearest
keypad and type in your PIN code and press ent. The keypad display will show what has
happened. The scroll keys A> and B< should be used to scroll through the message screens. If
the condition has cleared, pressing ent or esc will reset the fault condition. A fault condition
cannot be reset if it has not cleared or if it has not been viewed by a user.
If you cannot clear the fault condition yourself, always call the installer for advice.
Setting and Unsetting Groups
It is possible to split the alarm system into separate areas or ‘Groups’ that can be set and unset
independently. Different users can be given access to only certain groups, or to all groups.
Also, individual users can be given the option of simply setting and unsetting all groups
assigned to their code or choosing which groups to set or unset each time.
Setting and Unsetting Without Group Choice
When a user with access to multiple Groups, but no group choice, wants to set or unset, they
should follow the standard procedures on the previous pages.
Keypad:
Type your user code
then press [ent]*.
Wireless Keyfob:
Press the [OFF] button.
Prox Tag:
Hold the tag in front
of the prox symbol.
* NOTE: Unsetting using a keypad may not be possible on DD243 compliant systems.

7
SETSET
SETSET
SET 123123
123123
123
GROUPSGROUPS
GROUPSGROUPS
GROUPS SUUSUU
SUUSUU
SUU
Pressing the ent key will implement the status shown.
If a code, keyfob or tag is used while an entry timer is running or an alarm is in progress, the
group that is active will be unset immediately, without any status needing to be changed on the
keypad.
Menu Access
To access the other functions of the system, users can enter the menu mode by typing their
PIN code and pressing the ent button. This will display the first menu item after showing
system status for 5 seconds.
10 = Setting10 = Setting
10 = Setting10 = Setting
10 = Setting
[ent] to Select[ent] to Select
[ent] to Select[ent] to Select
[ent] to Select
Users can then navigate around the menu using the scroll keys, ent key and esc key, or they
can jump to any specific menu item directly by typing the number of the item. An overview of
all the accessible functions is shown below. Not all users will be able to access all of the
functions. This will depend on their ‘user type’ that is set up in menu 42.
Table 1. Menu Access
The function of each menu item is described in the following pages.
S = SET
U = UNSET
Setting and Unsetting With Group Choice
With group choice, setting is initiated as normal, using a code, tag or fob. However, a choice of
groups will then be displayed along with the current status of each group.
The status can be changed for each group by pressing the appropriate number button and the
display will cycle through the possible options.
10 = Setting 20 = Display 30 = Test 40 = Modify
11 = Omi t Zones 21 = Zone Status 31 = Walk Test 41 = Time/Date
12 = Timed Set 22 = View Log 32 = Output Test 42 = Users
13 = Part Set 23 = System Version 44 = Mobile Nos
14 = Night Set 24 = Print 47 = Remote Access
15 = Chime 48 = Level 3 Access

8
Menu 11 - Omit Zones
This function allows a user to temporarily disable a detection zone from the system (for
example, to disable a movement detector when a dog is left in the house). Zone omits last for
one set period only and automatically switch off when the system is unset. On entering the
menu option, the first omittable zone is displayed. The A> and B< scroll keys can be used to
select the different zones in turn. To omit a particular zone, scroll to the zone so that it is
displayed on screen. Press the #key and the message in the bottom left corner will change to
‘Omitted’. Select other zones as required in a similar way. When all zones have been selected as
required, press ent to begin setting with the omitted zones, or esc to escape back out and save
the omitted zones for setting later.
Menu 12 - Timed Set
This option initiates the timed full setting routine, identical to typing a PIN code and pressing
the A> key.
Menu 13 - Part Set
This menu option initiates the timed Part Set routine as described earlier.
Menu 14 - Night Set
This menu option initiates the timed Night Set routine as described earlier.
Menu 15 - Chime
This menu option allows one or more zones to be put into Chime mode. When chime mode is
enabled for a zone, the internal sounders will beep twice each time the detector on that zone is
activated. This function can be useful, for example, in a shop to indicate when a customer has
come through the front door.
Menu 21 - Zone Status
This menu option is used to show the status of each individual detection zone on the system.
On entering the option, the first system zone will be displayed as shown:
On the top row, the zone address is shown along with the zone function which toggles with
the current status (open, closed, etc).
NOTE: If groups are enabled, the group will be shown.
10011001
10011001
1001 CLOSEDCLOSED
CLOSEDCLOSED
CLOSED
ZONE1ZONE1
ZONE1ZONE1
ZONE1
status
10011001
10011001
1001 FINALFINAL
FINALFINAL
FINAL
ZONE1ZONE1
ZONE1ZONE1
ZONE1
function
1001G11001G1
1001G11001G1
1001G1 CLOSEDCLOSED
CLOSEDCLOSED
CLOSED
ZONE1ZONE1
ZONE1ZONE1
ZONE1
group
On the bottom row, the description of the zone is shown to aid identification.
Using the A> and B< scroll keys, any of the zones on the system can be displayed.
Additionally, pressing the #key will show additional diagnostic information for that zone. This
may be required for fault finding when talking to the alarm installation company by phone.

9
Menu 22 - View Log
This option displays the system event log. The log records all events that occur in the system
and is vital for tracing the chain of events during a break-in or when trying to trace a fault. On
entering the option, the most recent event is displayed on screen in the following format:
Pressing the B< key will jump backwards in time by one event. Pressing the A> key will jump
forwards by one event. Holding the scroll keys down will jump by one day at a time (Mk7
keypad only) with the date only displayed whilst scrolling.
Additional information about each event can be shown, where available, by pressing the # key.
NOTE: If groups are enabled, you can select which groups to view before entering the log.
Menu 23 - Display Version
This menu option simply displays the software version number of the system.
Menu 24 - Print
This option allows system settings to be printed if a printer is connected to the system. If no
printer is connected, it has no effect. On selecting the option, there is a sub-menu of 4 options,
which chose what is to be printed. The options are as follows:
1 = Codes
Prints a list of all users on the system.
2 = Zones
Prints a list of all zones on the system.
3 = Log
Prints the event log.
4 = All
Prints options 1, 2 and 3.
On selecting an option by pressing the appropriate key, a message will display that printing is
in progress.
Date
09:5109:51
09:5109:51
09:51 01/08/0401/08/04
01/08/0401/08/04
01/08/04
1021+1021+
1021+1021+
1021+ IntruderIntruder
IntruderIntruder
Intruder
Event Time
Event Source Event Type

10
Menu 31 - Walk Test
This menu allows the zones to be manually tested. There are two sub-options to this function
as follows:
1 = Test all Zones
This puts all omittable zones into walk test immediately.
2 = Test Selected Zones
This allows the user to select specific zones to be put into test. On selecting the option, the
first zone is displayed with the zone number and description on the top row. On the bottom
row, the test status is displayed. If the # key is pressed that zone is selected for test and the
message in the lower corner displays as appropriate. Each zone can be toggled on or off by
pressing the # key. When all zones have been selected for test as required, press the ent key to
start the test, or the esc key to abort.
Once the test has been started, any activation of a detector on test will cause the internal
sounders to beep twice. The zone number and description will also display on the keypad.
When more than one zone is activated at the same time, the scroll keys can be used to view all
the active zones.
NOTE: For wireless movement detectors, always ensure that the detectors on test are left
undisturbed for 3 minutes before activating the walk test. This is because the
wireless movement detectors will enter a sleep mode after being activated in order
to save battery life during repeated activations.
Press the esc key to end the walk test. All walk-tested zones will be recorded in the event log.
Menu 32 - Output Test
This menu option allows the external bell and strobe to be tested. There are two sub-options
that select between the bell and strobe. Select the appropriate device and press ent. This will
take the user to the status display to show the current condition of the device (on or off).
Pressing the ent key will toggle the status on or off to test the device. Press esc to end the test.
Menu 41 - Time/Date
This option allows the system time and date to be set. On entering this menu, there are two
sub options, A=Time and B=date. Pressing the Aor Bkeys allows the time or date as appro-
priate to be set by directly entering the new value. Time is entered in 24 hour notation and the
date is entered in 6-digit notation, with two digits each for the day of the month, month and the
year.
Menu 42 - Editing Users
The system can have up to 24 users (user 24 is the default master user). Each user can be
assigned a PIN code, a Wireless keyfob and/or a prox tag. They are also assigned an access
type, which dictates what the user can and can’t do. Menu 42 allows users to alter their own
PIN code and allows Master users to add and remove users from the system, as well as manage
users access rights.
On entering menu 42, there is a sub-menu, 1=Users. On entering the sub-menu, the first user is
displayed on the screen (normal users can only see their own user programming).

11
0101
0101
01 User 1User 1
User 1User 1
User 1 *1234*1234
*1234*1234
*1234
User(L2)User(L2)
User(L2)User(L2)
User(L2)
The A> and B< keys are used to select the user to be edited. Pressing ent will show the options
for that user, starting with the PIN option. Again, the A> and B< keys can be used to move
between the options. Pressing the ent key allows the displayed option to be modified. Most
users can only access the PIN option. Only Master users can access the other functions. The
programmable options for each user are listed below:
1 = PIN
This allows a new 4, 5, or 6 digit PIN code to be entered.
2 = Type
This allows the user type to be selected. There are 4 types available to choose from:
0 = Cleaner Can only set and unset the system
1 = User Can do all day-to-day operation but cannot override fault conditions
2 = Manager As per User but can override faults and reset alarms and tampers
3 = Master As per Manager but can add, remove and alter user codes.
3 = Group(s)
If group choice is enabled, this will allow the groups that the user has access to to be altered.
The numbers shown on the display indicate the groups that the user has access to. Pressing
the appropriate number key toggles the group on or off.
4 = Name
This allows a 6-character label to be assigned to the user, to aid identification when viewing
the event log.
5 = RF Fob
This allows a wireless keyfob to be assigned to the user. The fob serial number is shown in the
bottom row. If a new fob is to be assigned it should be ‘learned’ in as follows:
1. Press the star (*) key to start the learn process.
2. Press any button on the keyfob. The display will indicate success.
If a keyfob needs to be deleted, while the serial number is displayed, press the B< key to
delete the serial number then press ent.
6 = Prox Tag (Mk7 Keyprox Units Only)
NOTE: For programming prox tags onto a 6160 keyprox, use menu 5 = RF Fob, but hold
the tag up in place of steps 1 and 2.
This option allows a prox tag to be entered or deleted. On entering the option, the serial
number of the current tag that is programmed will be displayed. To delete the current tag, press
the B< key until the serial number is cleared then press ent. To program a new tag, clear any
current serial number then press the 1and A> keys simultaneously then present the new tag in
front of the prox symbol. The new serial number should appear on the screen. Press the ent key
to save the new number.

12
7 = Duress
The duress function, when enabled, forces a panic signal to be sent to the monitoring station
each time the user PIN, fob or tag is used. Duress codes should only be used in emergency
situations when there is a threat to life.
Menu 44 - Mobile Numbers
This option allows the SMS text messaging feature to be altered. The system can send event
messages to up to 3 mobile phones by text messaging. The type of events that are sent can be
individually selected for each of the three mobile phone numbers. In this menu option, there are
3 sub-menus, one for each of the mobile phones. On selecting a particular mobile (1 to 3) and
pressing ent, there are a further two sub-options as follows:
1 = Mobile numbers
This allows the actual mobile number to be entered. The number is entered directly by typing
the number in directly at the keypad. A number can be deleted or corrected by repeatedly
pressing the B< key. The number is saved by pressing ent.
2 = Message type
This allows the kind of events that are sent to this mobile number. There are 4 options:
1 = Alarm events
Just sends alarm activations.
2 = Alarm & set events
Sends alarms and all set & unset events.
3 = Alarm & fault
Sends all alarm events and fault conditions but not set & unset events.
4 = All events
Sends all of the above events as and when they occur.
Menu 47 - Remote Access
This menu option allows the user to initiate a remote service call when required by the installa-
tion company. The remote servicing function allows the Galaxy alarm system to be remotely
monitored and reprogrammed over the phone line, by way of a modem connection or GSM to a
computer at the alarm installer’s premises at a predetermined phone number. This option should
only be used when required by your installation company.
Menu 48 - Level 3 Access
This option is used to authorise access by an installation or service engineer. An engineer has
a special access code that is only enabled when an appropriate user accesses this menu option
and enables level 3 (installer) access by pressing the 1 key followed by ent. The engineer then
has 5 minutes to enter his own code.

13
Zone Reference Table
Installer Details
EMAN
SSERDDA
ENOHPELET
SRUOHECIFFO
SEMITREHTO
.ONTNUOCCA
00OIRENOZNOITCNUFNOITPIRCSEDEMIHCTIMOTRAP
1001
2001
3001
4001
10OIR 1101
2101
3101
4101
5101
6101
7101
8101

14
IU1-0032 Rev 1 © Copyright Honeywell Security
