Honeywell H.264 HRDP User manual

______________________________________________________________________________________________
Document 800-06801 Rev F 02/13
Xt
HRDP H.264 Rev B
DVR
Digital Recording and Transmission System
User Guide

______________________________________________________________________________________________
2

HRDP H.264 Rev B DVR User Guide
______________________________________________________________________________________________
Document 800-06801 Rev F 3
02/13
Revisions
Issue Date Revisions
A 05/10 Initial Release
B 06/10 Updated Content
C 09/10 Updated Content
D 02/11 Added HRDPX H.264
E 11/11 Dual Login & 1-Day Delete
F 02/13 Updated Content

______________________________________________________________________________________________
Document 800-06801 Rev F 02/13

HRDP H.264 Rev B DVR User Guide
______________________________________________________________________________________________
Document 800-06801 Rev F 5
02/13
Warnings and Safeguards
FCC STATEMENT
INFORMATION TO THE USER: This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Compliance Warning
Users of the product are responsible for checking and complying with all federal, state, and local laws
and statutes concerning the monitoring and recording of video and audio signals. Honeywell video
systems shall not be held responsible for the use of this product in violation of current laws and statutes.
CE Compliance Statement
The manufacturer declares that the equipment supplied with this guide is compliant with the essential
protection requirements of the EMC directive 2004/108/EC and the Low Voltage Directive (LVD)
2006/95/EC, conforming to the requirements of standards EN 55022 for emissions, EN 50130-4 for
immunity, and EN 60950 for Electrical Equipment safety.

Warnings and Safeguards
______________________________________________________________________________________________
6
Important Safeguards
1.
Read Owner’s Manual – After unpacking this product, read the owner’s manual carefully, and
follow all the operating and other instructions.
2.
Power Sources –
This product should be operated only from the type of power source indicated on
the label. If not sure of the type of power supply to your home or business, consult product dealer
or local power company
3.
Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure reliable
operation of the product and to protect it from overheating, and these openings must not be
blocked or covered. The product should not be placed in a built-in installation such as a bookcase
or rack unless proper ventilation is provided or Honeywell’s instructions have been adhered to.
4.
Heat – The product should be situated away from heat sources such as radiators, heat registers,
stoves, or other products that produce heat.
5.
Water and Moisture – Do not use this product near water. Do not exceed the humidity
specifications for the product as detailed in this manual
6.
Cleaning – Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
7.
Power Cord Protection – Power-supply cords should not be routed so that they are likely to be
walked on or pinched by items placed against them, paying particular attention to cords at plugs,
receptacles, and the point where they exit the product.
8.
Overloading – Do not overload wall outlets; extension cords, or integral convenience receptacles
as this can result in a risk of fire or electrical shock.
9.
Lightning – For added protection for this product during storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the
product due to lightning and power line surges.
10.
Object and Liquid Entry Points – Never insert foreign objects into the DVR, other than the media
types approved by Honeywell, as they may touch dangerous voltage points or short-out parts that
could result in a fire or electrical shock. Never spill liquid of any kind on the product.
11.
Accessories – Do not place this product on an unstable cart, stand, tripod, bracket, or table. The
product may fall, causing serious personal injury and serious damage to the product.
12.
Disc Tray – Keep fingers well clear of the disc tray as it is closing. Neglecting to do so may cause
serious personal injury.
13.
Burden –Do not place a heavy object on or step on the product. The object may fall, causing
serious personal injury and serious damage to the product.
14.
Disc – Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may
cause serious personal injury and product malfunction.

HRDP H.264 Rev B DVR User Guide
______________________________________________________________________________________________
Document 800-06801 Rev F 7
02/13
15.
Fuses – CAUTION: For continued protection against risk of fire, replace only with same type and
rating of fuse.
16.
Replaceable Batteries – CAUTION: Risk of Risk of Explosion if Battery is replaced by an Incorrect
Type. Dispose of Used Batteries According to the Instructions
17.
Grounded Outlet – This equipment shall be connected to a properly grounded outlet."
18.
Outlet Location – This equipment must be installed within six feet of an easily accessible outlet.
19.
Damage Requiring Service – Unplug the unit from the outlet and refer servicing to qualified service
personnel under the following conditions:
When the power-supply cord or plug is damaged.
If liquid has been spilled, or objects have fallen into the unit.
If the unit has been exposed to rain or water.
If the unit does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions as an improper adjustment of other controls
may result in damage and will often require extensive work by a qualified technician to restore the
unit to its normal operation.
If the unit has been dropped or the enclosure has been damaged.
When the unit exhibits a distinct change in performance - this indicates a need for service.
20.
Servicing – Do not attempt to service this product. Opening or removing covers may expose the
user to dangerous voltage or other hazards. Refer all servicing to qualified personnel.
21.
Replacement Parts – When replacement parts are required, be sure the service technician has
used replacement parts specified by Honeywell. Unauthorized substitutions may result in fire,
electric shock or other hazards.
22.
Safety Check – Upon completion of any service or repairs to this unit, ask the service technician to
perform safety checks to determine that the unit is in proper operating condition.

Warnings and Safeguards
______________________________________________________________________________________________
8
Notes on Handling
Please retain the original shipping carton and/or packing materials supplied
with this product. To ensure the integrity of this product when shipping or
moving, repackage the unit as it was originally received from Honeywell.
Do not use volatile liquids, such as aerosol spray, near this product. Do not
leave rubber or plastic objects in contact with this product for long periods
of time. They will leave marks on the finish.
The top and rear panels of the unit may become warm after long periods of
use. This is not a malfunction.
Notes on Locating
Place the unit on a level surface. Do not use it on a shaky or unstable
surface such as a wobbling table or inclined stand.
If this unit is placed next to a TV, radio, or VCR, the playback picture may
become poor and the sound may be distorted. If this happens, place the
DVR away from the TV, radio, or VCR.
Notes on Cleaning
Use a soft dry cloth for cleaning.
For stubborn dirt, soak the cloth in a weak detergent solution, wring well and
wipe. Use a dry cloth to wipe it dry. Do not use any type of solvent, such as
thinner and benzene, as they may damage the surface of the DVR.
If using a chemical saturated cloth to clean the unit, follow that product’s
instructions.
Notes on Maintenance
This DVR is designed to last for long periods of time. To keep the DVR
always operational we recommend regular inspection maintenance
(cleaning parts or replacement). For details contact the nearest dealer.

HRDP H.264 Rev B DVR User Guide
______________________________________________________________________________________________
Document 800-06801 Rev F 9
02/13
Notes on Moisture Condensation
Moisture condensation could damage the DVR. Read the following
information carefully.
Moisture condensation might occur under the following circumstances:
•When this product is brought directly from a cool location to a
warm location.
•When this product is moved to a hot and humid location from a
cool location.
•When this product is moved to a cool and humid location from a
warm location.
•When this product is used in a room where the temperature
fluctuates.
•When this product is used near an air-conditioning unit vent.
•When this product is used in a humid place.
Do not use the DVR when moisture condensation may occur.
If the DVR is used in such a situation, it may damage discs and internal
parts. Remove any CD discs, connect the power cord of the DVR to the wall
outlet, turn on the DVR, and leave it for two to three hours. After two to three
hours, the DVR will warm up and evaporate any moisture. Keep the DVR
connected to the wall outlet and moisture will seldom occur.

Warnings and Safeguards
______________________________________________________________________________________________
10
Safety Instructions – Rack Mount
A) Elevated Operating Ambient – If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may
be greater than room ambient. Therefore, consideration should be given to
installing the equipment in an environment compatible with the maximum
ambient temperature (Tma) specified by the manufacturer.
B) Reduced Air Flow – Installation of the equipment in a rack should be such
that the amount of air flow required for safe operation of the equipment is
not compromised.
C) Mechanical Loading – Mounting of the equipment in the rack should be
such that a hazardous condition is not achieved due to uneven mechanical
loading.
D) Circuit Overloading - Consideration should be given to the connection of
the equipment to the supply circuit and the effect that overloading of the
circuits might have on overcurrent protection and supply wiring. Appropriate
consideration of equipment nameplate ratings should be used when
addressing this concern.
E) Reliable Earthing - Reliable earthing of rack-mounted equipment should
be maintained. Particular attention should be given to supply connections
other than direct connections to the branch circuit (e.g. use of power
strips)."
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

HRDP H.264 Rev B DVR User Guide
______________________________________________________________________________________________
Document 800-06801 Rev F 11
02/13
Contents
1Warnings and Safeguards.................................................................................................................5
2Contents ...........................................................................................................................................11
3Introduction......................................................................................................................................16
Product Description........................................................................................................ 16
Features.......................................................................................................................... 17
USB Flash Drive Approved List....................................................................................... 18
PTZ Compatibility List..................................................................................................... 19
Quick Start Instructions .................................................................................................. 20
Logging In for the First Time........................................................................................... 20
4Installation........................................................................................................................................21
Front Panel Controls....................................................................................................... 21
Rear Panel Connectors................................................................................................... 22
HRDP....................................................................................................................... 22
16 Channel ....................................................................................................... 22
8 Channel ......................................................................................................... 23
4 Channel ......................................................................................................... 23
Remote Control............................................................................................................... 24
Connection Guide........................................................................................................... 25
Connecting the Monitor........................................................................................... 25
Video Inputs and Looping Outputs.......................................................................... 25
Connecting to a Network......................................................................................... 25
Connecting Audio.................................................................................................... 25
Connecting a PTZ Camera ...................................................................................... 26
Connecting to a Sensor Input.................................................................................. 26
Connecting to a Relay Output ................................................................................. 26
Installing the Rackmount Kit ........................................................................................... 26
Turning on the DVR ........................................................................................................ 27
Using the Power Button........................................................................................... 27
Setting the Remote Controller ID .................................................................................... 27
5Setup.................................................................................................................................................28

Contents
______________________________________________________________________________________________
12
Setup Menus................................................................................................................... 28
Setup Wizard .................................................................................................................. 29
System............................................................................................................................ 30
System Configuration .............................................................................................. 30
Upgrade Firmware................................................................................................... 31
Disk Configuration ................................................................................................... 32
Format .............................................................................................................. 32
Overwrite .......................................................................................................... 33
Check ............................................................................................................... 33
Auto Data Deletion ........................................................................................... 34
Auto Delete Video............................................................................................. 34
SMART Check .................................................................................................. 35
User Configuration................................................................................................... 36
Adding / Changing a User................................................................................ 37
Setup Dual Login.............................................................................................. 38
Configuration........................................................................................................... 39
Shutdown ................................................................................................................ 39
Camera ........................................................................................................................... 40
Camera Configuration ............................................................................................. 40
Color Setup (Adjust)......................................................................................... 41
PTZ Configuration.................................................................................................... 41
Spot / Sequence Configuration ............................................................................... 42
Monitor Configuration.............................................................................................. 43
Record ............................................................................................................................ 44
Recording Configuration ......................................................................................... 44
Frame ............................................................................................................... 44
Schedule ................................................................................................................. 45
Holiday Setup................................................................................................... 47
Audio ................................................................................................................ 47
Instant Recording ............................................................................................. 48
Using Instant Recording................................................................................... 48
Motion/Event Configuration..................................................................................... 49
Input ................................................................................................................. 49
Setting Up Motion Detection Recording........................................................... 50
Sensor .............................................................................................................. 51
Action ............................................................................................................... 52
Alarm Monitor................................................................................................... 53
Network .......................................................................................................................... 54
Network Configuration............................................................................................. 54
Serial Configuration................................................................................................. 56
E-mail Configuration................................................................................................ 57
Information...................................................................................................................... 58
System Log View ..................................................................................................... 58
Version View ............................................................................................................ 58
Status View .............................................................................................................. 59

HRDP H.264 Rev B DVR User Guide
______________________________________________________________________________________________
Document 800-06801 Rev F 13
02/13
6Operation..........................................................................................................................................62
Login............................................................................................................................... 62
Default Administrator Log In .................................................................................... 62
Live Display Mode .......................................................................................................... 63
Channel Selection ................................................................................................... 63
Icons........................................................................................................................ 64
Mouse-Over Menu ................................................................................................... 65
Popup Menu............................................................................................................ 66
No Signal................................................................................................................. 66
No Permission ......................................................................................................... 66
PTZ .......................................................................................................................... 67
PTZ Popup Menu ............................................................................................. 67
Create PTZ Preset Position ....................................................................... 68
Search ............................................................................................................................ 68
Searching Recorded Data ....................................................................................... 68
Quick Search ........................................................................................................... 69
Graphic Search........................................................................................................ 69
Quick Backup in Search Mode................................................................................ 69
Express Search ....................................................................................................... 70
Jump to First Saved Data ........................................................................................ 70
Jump to Last Saved Data ........................................................................................ 70
Event Search ........................................................................................................... 70
Daylight Savings Search.......................................................................................... 71
Search Popup Menu................................................................................................ 71
Backup (Export).............................................................................................................. 72
Manual Export ......................................................................................................... 72
Search Backup Data................................................................................................ 73
Deinterlacing .................................................................................................... 73
Using the Backup Viewer................................................................................................ 74
Controlling Backup Viewer ...................................................................................... 74
Setup and Save Functions ...................................................................................... 75
Upgrade Firmware at the DVR........................................................................................ 75
Play Back Backup Image................................................................................................ 76
Screen Division Buttons .......................................................................................... 76
Save Settings.................................................................................................................. 77
Save Settings........................................................................................................... 77
Import Settings ........................................................................................................ 77
7Remote Software .............................................................................................................................78
Set up a Remote Connection.......................................................................................... 78
Minimum System Requirements.............................................................................. 78
Recommended System Requirements.................................................................... 78
Configuring the DVR................................................................................................ 79
Creating a DVR Connection with Remote Software................................................. 79
Default Remote Software Log in Information.................................................... 80

Contents
______________________________________________________________________________________________
14
Access Remote Connection ........................................................................................... 80
Connecting Multiple DVRs....................................................................................... 80
Using the Remote Software ............................................................................................ 81
Setting the Time and Date ....................................................................................... 81
Live View Screen ..................................................................................................... 82
Camera View .................................................................................................... 83
Screen Division Buttons ................................................................................... 84
Setup Overview ....................................................................................................... 84
Search Overview...................................................................................................... 85
Play Controls .................................................................................................... 86
Performing a Basic Search............................................................................... 86
Adjust the Brightness of an Image ................................................................... 86
Zooming in on an Image .................................................................................. 86
Zooming in on a Portion of an Image............................................................... 87
Printing an Image ............................................................................................. 87
Save Clip .......................................................................................................... 87
Saving a Video Clip ................................................................................... 88
Status Search .......................................................................................................... 89
Performing a Status Search.............................................................................. 89
PTZ Overview .......................................................................................................... 90
Accessing PTZ Menus...................................................................................... 90
Controlling a PTZ Camera................................................................................ 90
Using the Graphical PTZ Controller.................................................................. 91
Using the On-screen Compass ........................................................................ 92
Web Viewer Overview ..................................................................................................... 93
Connecting to a DVR Using Web Viewer................................................................. 94
Search Video Using Web Viewer............................................................................. 94
Performing a Basic Search............................................................................... 95
Status Search ................................................................................................... 95
Performing a Status Search ...................................................................... 95
Clean Image ..................................................................................................... 95
Print .................................................................................................................. 96
Save ................................................................................................................. 96
Digital Verifier Overview .................................................................................................. 97
Using the Digital Verifier .......................................................................................... 97
FVMS (option) Overview ................................................................................................. 98
Connecting to a recorder using FVMS .................................................................... 98
8Appendix...........................................................................................................................................99
Button Index ................................................................................................................... 99
LED Status Indicators .............................................................................................. 99
Enter / Exit Buttons................................................................................................ 100
Function Buttons ................................................................................................... 100
Numeric Buttons and Rec...................................................................................... 101
Directional and Playback Control Buttons............................................................. 101

HRDP H.264 Rev B DVR User Guide
______________________________________________________________________________________________
Document 800-06801 Rev F 15
02/13
DVR FAQ ...................................................................................................................... 102
General.................................................................................................................. 102
Live Monitoring ...................................................................................................... 102
Recording.............................................................................................................. 103
Searching and Playing Video ................................................................................ 103
Backup .................................................................................................................. 103
Network ................................................................................................................. 103
Miscellaneous........................................................................................................ 103
Troubleshooting............................................................................................................ 104
Specifications (HRDP H.264 Rev B).............................................................................. 105
Notes

Introduction
______________________________________________________________________________________________
16
Introduction
Product Description
Honeywell’s HRDP H.264 Rev B DVR is a powerful, yet affordable, video
management solution designed for easy installation and operation.
Preconfigured for continuous recording, with no additional setup required, the
DVR offers quick search, setup, and backup features.
The Honeywell Embedded DVR comes ready for fast and seamless
integration within your existing IT infrastructure. The HRDP offers unparalleled
stability, security, and ease of use in a 2U chassis. Accordingly, your security
investment has never been easier to maintain. Multiple users may connect
through digital networks such as LANs and WANs for simultaneous live
viewing, and digital search. This powerful software enables users to view live
video, perform searches, and operate PTZ cameras. It also provides system
users and administrators with additional capabilities such as establishing
recording schedules, and creating motion detection zones. With the latest
advancements in the HRDP software, searching and indexing your video
archive has never been easier.

HRDP H.264 Rev B DVR User Guide
______________________________________________________________________________________________
Document 800-06801 Rev F 17
02/13
Features
The HRDP H.264 Rev B DVR includes the following features:
•4/8/16 Composite Video Input Connectors
•4/8/16 Looping Video Outputs
•Compatible with Color (NTSC or PAL) and B&W Video Sources
•Multiple Search Methods (Calendar, Event)
•Records up to 480 NTSC Images Per Second / 400 PAL Images per
Second at CIF resolution (16ch DVR), 240/200 (8ch DVR), 120/100
(4ch DVR)
•Live Real Time Video Display (30 NTSC Images Per Second / 25 PAL
Images Per Second)
•Auto Termination (75 Ohm) on Looping Outputs
•Continuous Recording with Disk Overwrite Mode
•Continuous Recording on Archiving, Transmitting to Remote, and
Playback
•Motion Based Recording Uniquely Configurable for Each Channel
•Customizable Motion Detection Grids Uniquely Configurable for
Each Channel
•Multiple Recording Modes (Manual / Schedule / Event)
•Audio (Mono) Recording (4 channels) and Playback
•4/8/16 Built in Sensor Inputs (Normally Open or Normally Closed)
•4 Built in Relay Outputs (Normally Open or Normally Closed)
•Remote Access via Ethernet and/or Modem
•PTZ Camera Control
•Internal DVD-RW supports CD-RW and DVD-RW media

Introduction
______________________________________________________________________________________________
18
USB Flash Drive Approved List
These USB flash drives have been tested and approved to work with the
HRDP DVR. Other USB flash drives may also work with the HRDP DVR but
have not yet been tested.
Manufacturer Model
SanDisk Cruzer
Talent Flash
Corsair Voyager
Lexar JumpDrive
Kingston Traveler
Note The USB ports on the HRDP H.264 Rev B only provide enough
power for a flash based external device. To use an external hard
disk drive (HDD), then you must use external power or a USB Y
cable to provide sufficient power. Most external HDDs come with an
external power supply or a USB Y cable.

HRDP H.264 Rev B DVR User Guide
______________________________________________________________________________________________
Document 800-06801 Rev F 19
02/13
PTZ Compatibility List
The Honeywell DVRs support a wide selection of PTZ camera protocols:
Honeywell MAXPRO
Honeywell VCL
Honeywell (GC-
655P)
Honeywell (HSD-
250)
Honeywell (HSD-
251)
American Dynamics
Cynix Speed Dome
DynaColor
ERNITech
FastraxII
Ganz-PT
HISHARP
HSDN 251/230
KALATEL
LG (LVC-A70X)
LILIN
OpenEye 500
OpenEye 510
OpenEye – Pelco D
ORX-1000
Pelco-D
Pelco-P
PTC-400C
RS-485 DIRECT
SCC-641
SCC-645A
SDM-100
SJ-3728R1
SK-P
SK-S
SPD-1600
SRX-1008
TBT-DOME
Vison-360
Visiontech
WSD7425D
WV-CS854
YOKO-CCTV

Introduction
______________________________________________________________________________________________
20
Quick Start Instructions
1. Turn on the DVR. See the Turning on the DVR section for more details.
2. Log in -- Use the number buttons to enter the password when prompted
– The default password is <none> – Press ENTER.
3. Complete System Configuration to set up the date, time and system ID.
See the System Configuration section for more details.
4. Complete Disk Configuration to set overwrite options and enable SMART
Check. See the Disk Configuration section for more details.
5. Complete User Configuration to change the Admin password and add
additional users. See the System >User Configuration section for more
details.
6. Complete Camera Configuration for all attached cameras. See the
Camera Configuration section for more detail.
7. Complete PTZ Configuration for any attached Pan / Tilt / Zoom cameras.
See the PTZ Configuration section for more details.
8. Create a recording schedule. See the Record section for more details.
9. Complete Sensor Configuration to enable any external devices
connected to sensor inputs or relay outputs. See the Record >
Motion/Event Configuration section for more details.
10. Complete Motion/Event Configuration to trigger recording on an event:
motion, sensor, video loss. See the Motion/Event Configuration section
for more details.
11. The DVR is now configured to record, search and playback video. See
the Operation section in this manual for more information on using the
DVR.
Logging In for the First Time
The default administrative log in information:
ID: admin
Password: <none>
