Honeywell DR4500A User manual

Honeywell Field Solutions
DR4500A Classic Series Circular Chart
Recorder With or Without Control
Product Manual
Doc. No.: 44-45-25-35
Release: M
Last Revision Date: April 2017

ii DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
Notices and Trademarks
Copyright 2017 by Honeywell
Release M –April 2017
WARRANTY/REMEDY
Honeywell warrants goods of its manufacture as being free of defective materials and faulty
workmanship. Contact your local sales office for warranty information. If warranted goods are
returned to Honeywell during the period of coverage, Honeywell will repair or replace without
charge those items it finds defective. The foregoing is Buyer's sole remedy and is in lieu of all other
warranties, expressed or implied, including those of merchantability and fitness for a particular
purpose. Specifications may change without notice. The information we supply is believed to be
accurate and reliable as of this printing. However, we assume no responsibility for its use.
While we provide application assistance personally, through our literature and the Honeywell web
site, it is up to the customer to determine the suitability of the product in the application.
Honeywell Process Solutions
1250 W Sam Houston Pkwy S
Houston, TX 77042
DR4500 is a trademark of Honeywell
Modbus is a registered trademark of Modicon
Other brand or product names are trademarks of their respective owners.

Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual iii
April 2017
About This Document
Revision Information
Document ID
44-45-25-35
Document Name
DR4500A Classic Series Circular Chart Recorder With or Without Control Product
Manual
Revision #
Publication Date
L
February 2017, (Daughterboard info updated in parts list)
M
April 2017, Range values table (7.2) updated, Aux Output only spare part added
References
The following list identifies all documents that may be sources of reference for material discussed in this
publication.
Document Title
Doc ID
How to Apply Digital Instrumentation in Severe Electrical
Noise Environments
51-52-05-01
Modbus® RTU Serial Communications User Manual
51-52-25-66
Modbus® RTU Serial Communications user Manual
Configuration Interface for DR4500
Supplement to 51-52-25-66
51-52-25-69

iv DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
Support and Contact Information
For Europe, Asia Pacific, North and South America contact details, refer to the back page of this manual or
the appropriate Honeywell Solution Support web site:
Honeywell Corporate: www.honeywellprocess.com
Honeywell Process Solutions: https://www.honeywellprocess.com/*
Honeywell Circular Recorders: https://www.honeywellprocess.com/circular-chart-recorders/
Telephone and Email Contacts
Area
Organization
Phone Number
United States and
Canada
Honeywell Inc.
1-800-343-0228 Customer Service
1-800-423-9883 Global Technical Support
Global Email
Support
Honeywell Process Solutions
[email protected]m

Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual v
April 2017
Symbol Definitions
The following table lists those symbols used in this document to denote certain conditions.
Symbol
Definition
This CAUTION symbol on the equipment refers the user to the Product Manual for
additional information. This symbol appears next to required information in the manual.
WARNING
PERSONAL INJURY: Risk of electrical shock. This symbol warns the user of a
potential shock hazard where HAZARDOUS LIVE voltages greater than 30 Vrms, 42.4
Vpeak, or 60 VDC may be accessible. Failure to comply with these instructions
could result in death or serious injury.
ATTENTION, Electrostatic Discharge (ESD) hazards. Observe precautions for
handling electrostatic sensitive devices
Protective Earth (PE) terminal. Provided for connection of the protective earth (green
or green/yellow) supply system conductor.
Functional earth terminal. Used for non-safety purposes such as noise immunity
improvement. NOTE: This connection shall be bonded to protective earth at the
source of supply in accordance with national local electrical code requirements.
Earth Ground. Functional earth connection. NOTE: This connection shall be bonded to
Protective earth at the source of supply in accordance with national and local electrical
code requirements.
Chassis Ground. Identifies a connection to the chassis or frame of the equipment shall
be bonded to Protective Earth at the source of supply in accordance with national and
local electrical code requirements.

vi DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
Contents
1. Overview............................................................................................1
1.1 Introduction........................................................................................................1
1.2 Operator Interface .............................................................................................3
1.3 Set-up Tasks .....................................................................................................5
2. Installation..........................................................................................7
2.1 Overview............................................................................................................7
2.2 Model Number Interpretation...........................................................................13
2.3 Mounting Considerations and Overall Dimensions .........................................16
2.4 Mounting Methods...........................................................................................17
2.5 Wiring Prerequisites ........................................................................................27
2.6 Input Wiring Procedures..................................................................................29
2.7 Output Wiring Procedures...............................................................................39
2.8 Option Wiring Procedures ...............................................................................45
2.9 Lockout Switch Configuration..........................................................................54
3. Configuration ...................................................................................55
3.1 Overview..........................................................................................................55
3.2 Configuration Prompts.....................................................................................56
3.3 How To Get Started.........................................................................................58
3.4 Configuration Tips ...........................................................................................59
3.5 Configuration Procedure .................................................................................60
3.6 Input Set Up Group..........................................................................................62
3.7 Pen Set Up Group...........................................................................................64
3.8 Chart Set Up Group.........................................................................................65
3.9 Totalizer Set Up Group....................................................................................66
3.10 Control Set Up Group......................................................................................67
3.11 Tuning Parameters Set Up Group...................................................................69
3.12 SP Ramp Set Up Groups ................................................................................70
3.13 Timer Set Up Group ........................................................................................71
3.14 Alarms Set Up Group ......................................................................................72
3.15 Auxiliary Output Set Up Group........................................................................74
3.16 Modbus Communications Set Up Group.........................................................75

Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual vii
April 2017
3.17 Options Set Up Group.....................................................................................76
3.18 Lockout Set Up Group.....................................................................................77
3.19 Configuration Record Sheet............................................................................78
4. Configuration Parameter Definitions................................................81
4.1 Overview..........................................................................................................81
4.2 Input Parameters Set Up Group......................................................................82
4.3 Pen Parameters Set Up Group .......................................................................86
4.4 Chart Parameters Set Up Group.....................................................................88
4.5 Total Parameters Set Up Group......................................................................89
4.6 Control Parameters Set Up Group..................................................................91
4.7 Tuning Parameters Set Up Group.................................................................100
4.8 Setpoint Ramp Set Up Group........................................................................103
4.9 Timer Set Up Group ......................................................................................105
4.10 Alarms Set Up Group ....................................................................................106
4.11 Auxiliary Output Set Up Group......................................................................109
4.12 Modbus Communications Set Up Group.......................................................111
4.13 Options Set Up Group...................................................................................112
4.14 Lockout Parameters Set Up Group...............................................................114
5. Operation.......................................................................................115
5.1 Overview........................................................................................................115
5.2 Preparation....................................................................................................116
5.3 Start-up..........................................................................................................118
5.4 Monitoring Your Recorder .............................................................................121
5.5 Operator Functions........................................................................................128
5.6 Operating Modes...........................................................................................129
5.7 Setpoints........................................................................................................131
5.8 Single Setpoint Ramp....................................................................................133
5.9 Using Two Sets of Tuning Constants (PID Values) ......................................136
5.10 Using Accutune II ..........................................................................................139
5.11 Alarm Setpoints.............................................................................................142
5.12 Digital Input Option (Remote Switching) .......................................................143
5.13 Resetting and Displaying Totalizer Value .....................................................144
5.14 Monitoring the External Event Operation ......................................................146
5.15 Maximizing Pen Life ......................................................................................146
5.16 Routine Maintenance ....................................................................................147

viii DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
5.17 Installing/Replacing Chart .............................................................................148
6. Setpoint Ramp/Soak Programming and Operation........................149
6.1 Overview........................................................................................................149
6.2 Setpoint Program Contents...........................................................................151
6.3 Drawing a Ramp/Soak Profile .......................................................................154
6.4 Entering the Setpoint Program Data .............................................................159
6.5 SP RAMP1 and SP RAMP2 Set Up Group...................................................161
6.6 Setpoint Program Profiles Set Up Group ......................................................163
6.7 Setpoint Program Segments Set Up Group..................................................165
6.8 Setpoint Program Event Set Up Group.........................................................168
6.9 Run/Monitor the Program..............................................................................172
7. Input Calibration.............................................................................175
7.1 Overview........................................................................................................175
7.2 Restoring Factory Calibration........................................................................176
7.3 Minimum and Maximum Range Values.........................................................178
7.4 Preliminary Information .................................................................................180
7.5 Calibration Set Up and Wiring for PV Inputs.................................................182
7.6 Calibration Procedure....................................................................................191
8. Output Calibration..........................................................................194
8.1 Overview........................................................................................................194
8.2 Current Proportional Output/Aux Out 2 and 3 Calibration.............................195
8.3 Position Proportional Output Calibration.......................................................197
8.4 Auxiliary Output Calibration...........................................................................200
9. Troubleshooting / Service ..............................................................202
9.1 Overview........................................................................................................202
9.2 Troubleshooting Aids.....................................................................................204
9.3 Self Diagnostics.............................................................................................206
9.4 Visual Failure Symptoms...............................................................................212
9.5 Troubleshooting Procedures .........................................................................213
9.6 Pen Alignment...............................................................................................219

Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual ix
April 2017
10.Parts List........................................................................................222
10.1 Overview........................................................................................................222
10.2 Exploded Views.............................................................................................223
10.3 Miscellaneous Hardware Kit Contents ..........................................................230
10.4 Internal Cabling Data –Without Options.......................................................232
10.5 Internal Wiring Diagram –Options Only........................................................233
A. Foreign Language Safety Instructions ...........................................235
DA2I-6057 ................................................................................................................236
DU2I-6057 ................................................................................................................237
FI2I-6057 ..................................................................................................................238
FR2I-6057.................................................................................................................238
GE2I-6057 ................................................................................................................240
GR2I-6057................................................................................................................241
IT2I-6057 ..................................................................................................................242
NO2I-6057................................................................................................................243
PO2I-6057 ................................................................................................................244
SP2I-6057.................................................................................................................245
SW2I-6057................................................................................................................246
Index ...................................................................................................247

x DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
Tables
Table 1-1 Function of keys..........................................................................................................................................4
Table 2-1 Operating limits and condensed specifications ...........................................................................................8
Table 2-2 Procedure to access components ...............................................................................................................14
Table 2-3 Mounting flush in a new panel cutout .......................................................................................................18
Table 2-4 Reference data for mounting DR4500A in existing panel cutouts ............................................................19
Table 2-5 Mounting flush in a panel using universal filler kit...................................................................................20
Table 2-6 Mounting flush in a panel using Kent Model 105M cutout.......................................................................21
Table 2-7 Procedure for Mounting Recorder with NEMA4X Door..........................................................................22
Table 2-8 Pipe Mounting Procedure..........................................................................................................................24
Table 2-9 Mounting flush on a surface (of panel or wall) .........................................................................................25
Table 2-10 Permissible wiring bundling....................................................................................................................28
Table 2-11 AC line power wiring..............................................................................................................................31
Table 2-12 Thermocouple, RTD, Radiamatic, mV, or 0–5 Vdc input wiring ...........................................................33
Table 2-13 4-20 mA input wiring..............................................................................................................................35
Table 2-14 0-10 Volt dc input wiring........................................................................................................................37
Table 2-15 4-20 mA control output wiring................................................................................................................39
Table 2-16 Position proportional control output wiring ............................................................................................41
Table 2-17 Relay control output wiring.....................................................................................................................43
Table 2-18 Alarm output or digital input wiring .......................................................................................................45
Table 2-19 Alarm 3 and Alarm 4 output wiring ........................................................................................................47
Table 2-20 Alarm 5 and Alarm 6 output wiring ........................................................................................................48
Table 2-21 RS485 Modbus communications wiring .................................................................................................50
Table 2-22 4-20 mA auxiliary output wiring.............................................................................................................52
Table 3-1 Configuration tips......................................................................................................................................59
Table 3-2 Configuration procedure............................................................................................................................60
Table 3-3 Input group function prompts....................................................................................................................62
Table 3-4 Pen 1 or 2 group function prompts............................................................................................................64
Table 3-5 Chart group function prompts ...................................................................................................................65
Table 3-6 Totalizer group function prompts..............................................................................................................66
Table 3-7 Control 1 or Control 2 group function prompts.........................................................................................67
Table 3-8 Tuning 1 or Tuning 2 group function prompts..........................................................................................69
Table 3-9 SP Ramp 1 or 2 group function prompts...................................................................................................70
Table 3-10 Timer group function prompts ................................................................................................................71
Table 3-11 Priority of functions that operate relays ...................................................................................................72
Table 3-12 Alarms group function prompts...............................................................................................................73
Table 3-13 Auxiliary output group function prompts................................................................................................74
Table 3-14 Modbus communications group function prompts..................................................................................75
Table 3-15 Options group function prompts..............................................................................................................76
Table 3-16 Lockout group function prompts.............................................................................................................77
Table 4-1 Input group definitions..............................................................................................................................82
Table 4-2 Pen 1 or 2 group definitions ......................................................................................................................86
Table 4-3 Chart parameters group definitions ...........................................................................................................88
Table 4-4 Totalizer group definitions........................................................................................................................89
Table 4-5 Control 1 or 2 group definitions................................................................................................................91
Table 4-6 Tuning group prompt definitions.............................................................................................................100
Table 4-7 Setpoint Ramp 1 or 2 group definitions ..................................................................................................103
Table 4-8 Timer group definitions...........................................................................................................................105
Table 4-9 Priority of functions that operate relays ...................................................................................................106
Table 4-10 Alarms group definitions.......................................................................................................................107
Table 4-11 Auxiliary output group definitions........................................................................................................109
Table 4-12 Modbus communications group definitions ..........................................................................................111
Table 4-13 Option group definitions .......................................................................................................................112

Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual xi
April 2017
Table 4-14 Lockout group definitions .....................................................................................................................114
Table 5-1 Install/replace chart .................................................................................................................................116
Table 5-2 Set the chart time line procedure.............................................................................................................118
Table 5-3 Power up diagnostic tests ........................................................................................................................118
Table 5-4 Procedure for testing the displays and keys.............................................................................................119
Table 5-5 Procedure for starting up the recorder .....................................................................................................120
Table 5-6 Meaning of indicators..............................................................................................................................123
Table 5-7 Lower display key parameter prompts ....................................................................................................125
Table 5-8 Error messages ........................................................................................................................................126
Table 5-9 Alarm and tuning messages......................................................................................................................127
Table 5-10 Operating mode definitions...................................................................................................................129
Table 5-11 Changing operating modes....................................................................................................................129
Table 5-12 Procedure for selecting automatic or manual mode ..............................................................................130
Table 5-13 Procedure for selecting the setpoint source ...........................................................................................131
Table 5-14 Procedure for changing the local setpoint .............................................................................................131
Table 5-15 Procedure for switching between setpoints ...........................................................................................132
Table 5-16 Setpoint selection indication .................................................................................................................132
Table 5-17 Procedure for configuring a single setpoint ramp..................................................................................133
Table 5-18 Procedure for running a setpoint ramp ..................................................................................................134
Table 5-19 Procedure for selecting two sets of tuning constants.............................................................................136
Table 5-20 Procedure for setting switchover values................................................................................................137
Table 5-21 Procedure for setting tuning constant values.........................................................................................137
Table 5-22 Procedure for switching PID sets from the keyboard............................................................................138
Table 5-23 Procedure for starting Accutune II .........................................................................................................139
Table 5-24 Procedure for using Accutune for duplex control..................................................................................140
Table 5-25 Procedure for displaying or changing the alarm setpoints......................................................................142
Table 5-26 Digital input option action on contact closure.......................................................................................143
Table 5-27 Procedure for resetting the totalizer ......................................................................................................144
Table 5-28 Procedure for displaying the totalizer value..........................................................................................145
Table 5-29 Maximizing pen life ..............................................................................................................................146
Table 5-30 Changing the ink cartridge ....................................................................................................................147
Table 5-31 Replacing a chart lamp..........................................................................................................................147
Table 6-1 Parameter settings for example 12-step profile........................................................................................155
Table 6-2 Setpoint program data entry procedure ...................................................................................................159
Table 6-3 SP RAMP prompts and available selections ............................................................................................161
Table 6-4 Setpoint program profiles group definitions............................................................................................163
Table 6-5 Setpoint program segments group definitions.........................................................................................165
Table 6-6 Setpoint program event group definitions ...............................................................................................168
Table 6-7 Segment event relay operation requirements............................................................................................169
Table 6-8 Run/Monitor functions ............................................................................................................................172
Table 7-1 Restoring factory calibration...................................................................................................................176
Table 7-2 Voltage and resistance equivalents for 0% and 100% range values........................................................178
Table 7-3 Disconnect the field wiring .....................................................................................................................180
Table 7-4 Equipment needed...................................................................................................................................181
Table 7-5 General set up procedure.........................................................................................................................183
Table 7-6 Set up wiring procedure for Thermocouple inputs using an ice bath ......................................................184
Table 7-7 Set up wiring procedure for Thermocouple inputs using a compensated calibrator method...................185
Table 7-8 Set up wiring procedure for Thermocouple inputs using the ambient temperature method....................186
Table 7-9 Set up wiring procedure for RTD inputs .................................................................................................187
Table 7-10 Set up wiring procedure for Radiamatic, Millivolts, and Volts inputs (except 0-10 Volts) ..................188
Table 7-11 Set up wiring procedure for 0–10 Volt inputs.......................................................................................189
Table 7-12 Set up wiring procedure for 4–20 mA inputs ........................................................................................190
Table 7-13 Calibration procedure sequence ............................................................................................................191
Table 8-1 Set up wiring procedure current proportional output/Aux Out 2 and 3...................................................195
Table 8-2 Current proportional output/Aux Out 2 and 3 calibration procedure ......................................................196

xii DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
Table 8-3 Position proportional output calibration procedure .................................................................................198
Table 8-4 Set up wiring procedure for auxiliary output...........................................................................................200
Table 8-5 Auxiliary output calibration procedure....................................................................................................201
Table 9-1 Procedure for identifying the software version .......................................................................................205
Table 9-2 Power-up tests .........................................................................................................................................206
Table 9-3 Procedure for displaying the device status ..............................................................................................207
Table 9-4 Error message prompts............................................................................................................................208
Table 9-5 Visual failure symptoms..........................................................................................................................212
Table 9-6 Procedure #1—Troubleshooting recorder failure symptoms...................................................................213
Table 9-7 Procedure #2—Troubleshooting pen trace failure symptoms .................................................................214
Table 9-8 Procedure #3—Troubleshooting chart rotation failure symptoms...........................................................214
Table 9-9 Procedure #4—Troubleshooting erratic pen movement symptoms.........................................................215
Table 9-10 Procedure #5—Troubleshooting pen failure symptoms........................................................................215
Table 9-11 Procedure #6—Troubleshooting keyboard and/or display failure symptoms .......................................215
Table 9-12 Procedure #7—Troubleshooting current proportional output failure symptoms...................................216
Table 9-13 Procedure #8—Troubleshooting position proportional output failure symptoms .................................216
Table 9-14 Procedure #9—Troubleshooting relay output failure symptoms...........................................................217
Table 9-15 Procedure #10—Troubleshooting current/time or time/current failure symptoms................................217
Table 9-16 Procedure #11—Troubleshooting the auxiliary output .........................................................................218
Table 9-17 Procedure #12—Troubleshooting external alarm function failure symptoms.......................................218
Table 9-18 Procedure #13—Troubleshooting Modbus communications failure symptoms....................................218
Table 9-19 Pen 1 (purple) and Pen 2 (red) Mechanical Alignment .........................................................................219
Table 9-20 Set the chart time line procedure...........................................................................................................221
Table 10-1 Door assembly parts..............................................................................................................................223
Table 10-2 Chart plate assembly parts.....................................................................................................................225
Table 10-3 Basic recorder parts without options.....................................................................................................227
Table 10-4 Recorder parts associated with options .................................................................................................229
Table 10-5 Miscellaneous hardware kit...................................................................................................................230

Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual xiii
April 2017
Figures
Figure 1-1 Operator interface ......................................................................................................................................3
Figure 1-2 Set-up tasks................................................................................................................................................5
Figure 2-1 Model number interpretation ...................................................................................................................13
Figure 2-2 DR4500A recorder hardware components versus “table” selections.......................................................15
Figure 2-3 Overall dimensions ..................................................................................................................................16
Figure 2-4 How to remove knockouts .......................................................................................................................17
Figure 2-5 Mounting Flush in a New Panel Cutout...................................................................................................18
Figure 2-6 Mounting in a panel using universal filler kit ..........................................................................................20
Figure 2-7 Mounting in a panel using Kent Model 105M cutout ..............................................................................21
Figure 2-8 Panel Mounting Recorder with NEMA4X Door.......................................................................................23
Figure 2-9 Pipe Mounting Brackets...........................................................................................................................24
Figure 2-10 Mounting flush on a surface (of panel or wall)......................................................................................26
Figure 2-11 Ferrite filter locations and shield wiring (CE Mark)..............................................................................30
Figure 2-12 AC line power wiring.............................................................................................................................32
Figure 2-13 Thermocouple, RTD, Radiamatic, mV, or 0–5 Vdc input wiring..........................................................34
Figure 2-14 4-20 mA input wiring.............................................................................................................................36
Figure 2-15 0-10 Volt dc input wiring.......................................................................................................................38
Figure 2-16 4-20 mA control output wiring (or Aux Out #2 and #3 wiring).............................................................40
Figure 2-17 Position proportional control output wiring...........................................................................................42
Figure 2-18 Relay control output wiring ...................................................................................................................44
Figure 2-19 Alarm output or digital input wiring......................................................................................................46
Figure 2-20 Alarm outputs #3, 4, 5, and 6 wiring......................................................................................................49
Figure 2-21 RS485 Modbus communications wiring................................................................................................51
Figure 2-22 4-20 mA auxiliary output wiring............................................................................................................53
Figure 2-23 S1 lockout switch location .....................................................................................................................54
Figure 3-1 DR4500A prompt hierarchy.....................................................................................................................56
Figure 5-1 Basic recording components ..................................................................................................................117
Figure 5-2 Operator interface ..................................................................................................................................122
Figure 5-3 Deviation bargraph.................................................................................................................................124
Figure 6-1 Ramp/Soak profile example....................................................................................................................154
Figure 7-1 Location of the input connections on the input boards ..........................................................................180
Figure 7-2 Location of jumper positions W1/MA and W3 on the input boards ......................................................182
Figure 7-3 Calibration set up diagram for Thermocouple inputs using an ice bath.................................................184
Figure 7-4 Calibration set up diagram for Thermocouple inputs using a compensated calibrator method..............185
Figure 7-5 Calibration set up diagram for Thermocouple inputs using the ambient temperature method...............186
Figure 7-6 Calibration set up diagram for RTD inputs............................................................................................187
Figure 7-7 Calibration set up diagram for Radiamatic, Millivolts, and Volts inputs (except 0-10 Volts)...............188
Figure 7-8 Calibration set up diagram for 0–10 Volt inputs....................................................................................189
Figure 7-9 Calibration set up diagram for 4–20 mA inputs.....................................................................................190
Figure 8-1 Test equipment connections for calibrating current proportional output ...............................................195
Figure 8-2 Test equipment connections for calibrating auxiliary output.................................................................200
Figure 9-1 Mechanical Alignment of Pens..............................................................................................................220
Figure 10-1 Door assembly .....................................................................................................................................223
Figure 10-2 Chart plate assembly............................................................................................................................224
Figure 10-3 Basic recorder components without options ........................................................................................226
Figure 10-4 Recorder components associated with options.....................................................................................228
Figure 10-5 Internal cabling for DR4500A Classic recorder...................................................................................232
Figure 10-6 Internal diagram for DR4500A Classic recorder –options only..........................................................233

xiv DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017

Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual
April 2017
1
1. Overview
1.1 Introduction
Function
The DR4500A Classic Series recorder combines the simplicity of pen drawn analog traces with the
sophistication of microprocessor controlled functions. This combination results in a user configurable
recorder that is easily adapted to meet a variety of application requirements—from blast furnace to
laboratory.
In addition to recording analog traces, the Classic Series recorder continuously displays process variable
values in the selected engineering units.
Both one-pen and two-pen models accept inputs from any one of a variety of sensors or transmitters within
the configurable range limits. Also, models are available with one or two digital controllers to generate
controlled output signals to operate valves, dampers, heating elements, etc. for process control.
CE Conformity (Europe)
Indicated models of this product are in conformity with the protection requirements of the following
European Council Directives: 73/23/EEC, the Low Voltage Directive, and 89/336/EEC, the EMC
Directive. Conformity of this product with any other “CE Mark” Directive(s) shall not be assumed.
Deviation from the installation conditions specified in this manual, and the special conditions for CE
conformity in Section 2.1, may invalidate this product’s conformity with the Low Voltage and EMC
Directives.
ATTENTION
The emission limits of EN 61326 are designed to provide reasonable protection against
harmful interference when this equipment is operated in an industrial environment. Operation
of this equipment in a residential area may cause harmful interference. This equipment
generates, uses, and can radiate radio frequency energy and may cause interference to radio
and television reception when the equipment is used closer than 30 meters (98 feet) to the
antenna(e). In special cases, when highly susceptible apparatus is used in close proximity, the
user may have to employ additional mitigating measures to further reduce the electromagnetic
emissions of this equipment.
Microprocessor controlled recording and printing
Both the chart and the pen are driven by stepper motors which are controlled by the microprocessor with
configurable chart speed through the keyboard.
The microprocessor uses the configured chart range data as well as the input data to determine the proper
pen position.
The stepper motor accurately positions the pen drive without damping, thus eliminating the need for
slidewire feedback gearing and drive cables.
A configurable deviation recording function lets users show graphically the difference between a reference
input and a process variable input.
Users can designate the channel 1 input or enter a deviation setpoint value as the reference input.

Overview
Introduction
2 DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
Digital controller
The DR4500A recorder includes an integral microprocessor-based, PID controller with two loops of
control. A variety of output types, including a duplex variation for heat cool applications, lets you select the
output that is right for your final control element.
You can configure the control action as On-Off, PID-A, PID-B, or PD with manual reset. English language
prompts guide you through the entry of all the controller's configurable parameters.
Construction
The DR4500 recorder is housed in a molded case which can be panel or surface mounted. A glass or acrylic
windowed door protects the internal components while allowing easy access to the chart and operator
interface. An optional external keypad that allows operator selections without opening the door is available.
Circuitry is partitioned on printed circuit boards for ease of service.
Power, input, and output wiring connect to terminations inside the case. Knockouts in the sides and bottom
of the case accept conduit connections for convenient wire entry.

Overview
Operator Interface
Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 3
April 2017
1.2 Operator Interface
Operator interface
Figure 1-1 shows the operator interface and defines the displays and indicators. The function of the keys is
described in Table 1-1.
22074
Control relay
1 or 2 is ON,
when lit.
ALM
CHN
RSP
OUT
12 FC
%RUN
HOLD
MAN
12
Lower Display - eight characters
Normal operation - Displays selectable
operating parameters and values.
Configuration mode - Displays function
group and parameters.
Remote setpoint or
2nd setpoint is
active, when lit.
Blinks when 2nd
setpoint or remote
setpoint is
obtained through
remote switch.
PV displayed is
for channel 1 or 2
Alarm condition
exists for alarm 1
or 2, when lit.
Indicates temperature
units of PV Upper Display - six characters
Normal operation - Displays process
variable (PV) for selected channel.
Configuration mode - Displays selection or
parameter value.
Indicates controller mode:
MAN = Manual
A = Automatic
Bargraph - deviation (±10% of span)
Center green bar indicates PV is within
±1% of control setpoint.
Next small bar will light if PV is between
±1% but less than ±2% in deviation.
If PV is equal to or greater than ±10%
deviation, the green bar plus all ten small
green bars will light.
12
Key Pad/Key Functions
FUNC LOWR
DISP
MAN
AUTO CHART
SET
UP
Figure 1-1 Operator interface

Overview
Operator Interface
4 DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
Key functions
Table 1-1 shows each key on the operator interface and defines its function.
Table 1-1 Function of keys
Key
Function
SET
UP
Places the controller in the Configuration Set Up group select mode. Sequentially
displays Set Up groups and allows the FUNC key to display individual functions in
each Set Up group.
FUNC
Used in conjunction with the SET UP key to select the individual functions of a
selected Configuration Set Up group.
Used to toggle between SP1 and SP2.
Used during field calibration procedure.
LOWR
DISP
Selects an operating parameter to be shown in the lower display:
OUT = Output Value
SP = Local Setpoint 1
SPN = Current setpoint for setpoint rate applications
2SP = Local Setpoint 2
RSP = Remote Setpoint
2IN = Input 2
DEV = Deviation
EU = PV Engineering Units
RH = % RH Value
PIDSETX = Tuning Parameter Set X=1 or 2
RAMP = Minutes remaining in Setpoint Ramp
#RA = Minutes remaining in SP Prog Ramp
#SK = Minutes remaining in SP Prog Soak
RECYC = Number of recycles left in SP Program
= Time remaining in Timer function
= Time elapsed in Timer function
TUNExXXX = Accutune II indicator. x = 1 or 2
ATTENTION
The lower display can be configured to scroll through the operating
parameters.
MAN
AUTO
Alternately selects:
AUTO Lower display automatically displays setpoint value in engineering units.
MAN Lower display automatically indicates output in %.
CHART
Used to stop recording operation and move pen to outer limit for chart change.
RUN
HOLD
Alternate action switch initiates or holds the Setpoint Ramp or Setpoint Program.
In configuration mode, restores the original value or selection if you do not want to
enter a change you are making to a parameter.
▲
Increases the setpoint, output, or configuration values displayed.
Used to step through the items in each function while in configuration mode plus
adjust control variables in the lower display.
▼
Decreases the setpoint, output, or configuration values displayed.
Used to step through the items in each function while in configuration mode plus
adjust control variables in the lower display.

Overview
Set-up Tasks
Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 5
April 2017
1.3 Set-up Tasks
Major set-up tasks
As shown in Figure 1-2, there are four major tasks that you must complete to "Set Up" the DR4500A
recorder for operation. For easy reference the section numbers for each task are shown.
START
Ready for
Operation
1.
2.
4.
3.
Determine your recorder's
hardware components and
software functions
Mount the recorder flush in
a panel, or on the surface
of a panel or a wall
Connect the power and
input/output wiring.
Follow the simple keystroke
sequences and English
language prompts to
"configure" the functional
characteristics of your
recorder.
See Section 2
See Section 2
See Section 2
See Sections 3 & 4
22075
Figure 1-2 Set-up tasks

Overview
Set-up Tasks
6 DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
