Lynx Plus Series Installation and Setup Guide
- 5 -
System Features
The Lynx Plus Series control is a self-contained, rechargeable wireless control/communicator that features
easy installation and usage. A built-in speaker provides voice annunciation of system status along with voice
descriptors of each zone. An internal module (if provided) allows the Lynx Plus Series to communicate with
the Central Station via the Internet.
UL
ULUL
UL
Lynx Plus Series is not intended for UL985 Household Fire applications unless a 24-hour backup battery
(P/N LYNXRCHKIT-HC or LYNXRCHKIT-SHA) is installed.
Powerline Carrier Devices have not been evaluated by UL.
Features
System Features
•Real-time clock display and 2 line by 16
character alpha display
•Message center (for user recorded messages)
•Voice announcement of system and zone status
•Voice chime
•Alarm clock
•Reminder
•X10 scheduling
•Latch key reports
•Automatic stay arming
•Remote phone control
•Speaker phone operation
•“Follow me” reminder and system announcements
•8 User Codes (Installer, Master, 5 Secondary,
Duress)
•3 Panic Functions
Zones and Devices
•1 Hardwire zone
•Up to 24 Wireless zones (5800 Series
transmitters)
•Up to 16 Wireless button zones
•Up to 8 Powerline carrier devices
•Supports wireless keypads
Communication
•Ademco Low Speed
•Sescoa/Radionics
•Ademco Express
•Ademco Contact ID
•Internet central station communication
•GSM cellular central station communication
•Two-way voice communication Supports
AlarmNet remote services
Alarm Output
•Built-in sounder
•Bell output (120mA max.)
•Steady output for burglary/panic
•Temporal pulse output for fire and carbon
monoxide alarms
•Long range radio/audio alarm verification
Programming
•Options stored in EEROM
•Can be downloaded or controlled via IBM-
compatible computer using Compass
downloader software and specified HAYES-
compatible modem or via capable GSM or IP
communications module
•Voice prompt programming mode
Other Features
•Exit error feature (detects difference between an
actual alarm and exit alarm caused by leaving a
door open after the exit delay expires)
•Event log stores up to 84 events
•Macro/ 1-button paging
•RF jam detection
•Compatible with encrypted (high-security)
devices
System Power
•Primary Power: K10145WH or K10145X10 plug-
in transformer, 110VAC to 9VAC, 25VA output
(K10145CN in Canada)
•Backup battery: Rechargeable nickel-metal
hydride battery pack rated at 7.7Vdc.

Lynx Plus Series Installation and Setup Guide
- 6 -
Mounting the Control
Wall Mounting
1. Release the front assembly from the
back case by depressing the two
locking tabs at the top of the unit
with the blade of a medium size
screwdriver.
2. Separate the front and back case
assemblies by rotating the front case
so that it is perpendicular to the
back case and unsnapping
(releasing) the two hooks from the
back case.
3. Feed the field wiring through the
appropriate openings in the back
case. Use tie-wraps to secure the
wiring to the built-in wire loops as
needed.
4. Mount the back case to a sturdy
wall.
5. Attach the front and back cases by
connecting the hooks on the front
case to the attachments on the rear
case. Once attached, the hooks will
support the front case and allow you
to make the wiring connections.
6. After all wiring connections have
been made, snap the front case and
back case closed and ensure that
the control is secured by the locking
tabs.
BACK
CASE
FRONT
CASE
1000-300-009-V1
ROTATE
FRONT CASE
UPWARD
TO RELEASE
HOOKS
MOUNTING
HOOKS
LOCKING TABS
Desktop Mounting
For desktop mounting, the optional
mounting base (model LYNXPLUS-
DM, purchased separately) must be
used.
1. Slide the control panel onto the
mounting base locking tabs.
2. Bring all wiring through the bottom
of the mounting base, using one of
the wire entry locations, before
making connections to the control
panel.
3. Use tie-wraps to secure the wiring to
the built-in wire loops as needed.
4. Use the supplied screws to secure
the control panel to the mounting
base.
BYPASS
NO DELAY
RECORD
TEST
FUNCTION
STATUS
VOLUME PLAY
CODE
LIGHTS ON
LIGHTS OFF CHIME
ESCAPE
ADD
DELETE
SELECT
OFF STAY
132
AWAY AUX
46
5
ARMED READY
79
8
0
1000-300-016-V0

Lynx Plus Series Installation and Setup Guide
- 7 -
Wiring Connections
Wiring Overview
The following summarizes the connections required. Refer to the Wiring Connections paragraph and the
Summary of Connections diagram on the inside back cover when making connections. Ensure that the
battery cable is routed as shown in the figure below.
1000-300-006-V2
LOCAL
SOUNDER
DISABLE
SWITCH
MOUNTING
HOOK
TIE-WRAP
POINT
TELEPHONE
CONNECTION
TERMINAL
STRIP
BATTERY
CABLE
MOUNTING
HOOK
WIRE
ROUTING
TUNNELS
POWERLINE CARRIER
DEVICE CONNECTOR
Wiring Connections
1. Make Earth Ground Connection - The designated earth ground terminal (1) must be terminated in a good earth ground
for the lightning transient protective devices in this product to be effective. The following are examples of good earth
grounds available at most installations:
Metal Cold Water Pipe - Secure a non-corrosive metal strap (copper is recommended) to the pipe that is electrically
connected and secured to which the ground lead is electrically connected and secured.
AC Power Outlet Ground - Available from 3-prong, 120VAC power outlets only. To test the integrity of the ground
terminal, use a three-wire circuit tester with neon lamp indicators, such as the UL Listed Ideal Model 61–035, or
equivalent, available at most electrical supply stores.
a. Connect terminal 1 to a good earth ground.
2. Make Phone Line Connections - For local or full line seizure follow the appropriate steps below.
Local Seizure
a. Connect the incoming phone line to either the 8-position jack or terminals 2 (TIP) and 3 (RING) on the Lynx Plus.
b. Connect the handset phone lines to terminals 4 (TIP) and 5 (RING).
Full Line Seizure: The control must be placed in series with the incoming phone line. Plugging the Direct Connect Cord
directly into the RJ31X jack, allows the control to seize the phone line when an alarm occurs and normal phone line
usage by the premises phones if the plug needs to be removed.
a. Cut the incoming RING and TIP phone lines (typically red and green, respectively) and connect them to RJ31X
terminals 4 (red) and 5 (green).
b. Connect the premises end of the cut RING and TIP wires to RJ31X terminals 1 (grey) and 8 (brown) respectively.

Lynx Plus Series Installation and Setup Guide
- 8 -
Wiring Connections
c. Wire the flying leads of a Direct Connect Cord to the control’s phone terminals as shown in the diagram or plug into
the 8-position jack.
d. Plug the Direct Connect Cord into the RJ31X jack.
RJ31X
1
2
3
45
6
7
8
RING
TIP
INCOMING
PHONE LINE
TO
PREMISES PHONES
TIP RING TIP RING
BROWN
GREY
RED
GREEN
INCOMING
PHONE LINE
TO
PREMISES
PHONES
}
}
GREENRED
GREY BROWN
RING
TIP
DIRECT
CONNECT
CORD
OR
OR
8-POSITION
JACK
01000-008-V0
Full Line Seizure Connections
UL
ULUL
UL The local sounder disable switch must be set to “ON” position.
External sounders and powerline carrier devices have not been evaluated by UL
LOCAL SOUNDER DISABLE: The Master Keypad’s built-in piezo sounder can be disabled by setting the
sounder disable switch to OFF. If disabled, however, no sounding will occur upon AC loss, since the
external sounder does not operate when AC power is lost.
HARDWIRED ZONE: If the EOLR is not at the end of the loop, the zone will not be properly supervised, and the
system may not respond to an open circuit on the zone.
3. Hardwired Zone Connections
Zone 1 is an EOLR supervised zone that supports both open circuit and closed circuit devices and has a response
time of 350msec. Maximum zone resistance: 300 ohms, plus EOLR
Note: The hardwire zone cannot be used as a fire or CO zone.
a. Connect sensors/contacts to the hardwired zone terminals 6 (-) and 7 (+). Refer to the Summary of Connections
diagram.
b. Connect closed circuit devices in series in the high (+) side of the loop. The EOL resistor must be connected in
series with the devices, following the last device.
c. Connect open circuit devices in parallel across the loop. The 2000-ohm EOLR must be connected across the loop
at the last device.
4. Make External Sounder Connections -The control panel a 6-14VDC bell (120mA max.; e.g. ADEMCO WAVE2EX).
a. Connect a bell to terminals 8 (-) and 9 (+).
5. Disable Local Sounder Option - If required, the Master Keypad’s built-in piezo sounder can be disabled.
a. Set the Local Sounder Disable Switch to OFF.
6. Make Powerline Carrier Device Connections -The control panel supports up to 8 Powerline Carrier Devices. If using
these devices, they must be connected to the control via a K10145X10 transformer.
a. Connect the com/data/sync/ lines from the K10145X10 transformer to the Powerline Carrier Device Connector using
the provided cable.
Refer to the ✻
✻✻
✻80 Device Programming Menu Mode section to program the Powerline Carrier Devices.

Lynx Plus Series Installation and Setup Guide
- 9 -
Connecting/Configuring Communication Modules
General
This Lynx Plus Series control supports central station reporting via the internet using wireless (GSM) and
hardwire (IP) communications modules. It also supports upload/download programming capability via the
Internet or a Private local area network (Intranet). This allows site maintenance independent of central
station monitoring, and modification to sites globally via the Internet or through a private LAN. Refer to the
instructions provided with the LRR/IP Communications Device being installed for additional information
regarding its installation, programming, and registration. The control is compatible with the following
AlarmNet Communications Modules:
•7847i-L Internet Communications Module
•GSMVLP GSM Communications Module with 2-Way Voice
Connecting Long Range Radio and Internet Communication Devices
Connect and configure the communications device (refer to the Installation Instructions for device that you
are installing for additional information).
LRR/IP Communications Device 24-Hour Standby Power
If you are installing the AlarmNet 7847i-L, and require 24-hour standby, you must install the Super High
Capacity battery P/N WALYNX-RCHB-SHA in the control.
Configuring Long Range Radio and Internet Communication Devices
1. Enable the communications device in programming field ✼55 and configure alarm reporting and module
supervision in programming field ✼77.
2. Program the device as required using the 7720P programmer (refer to the Installation Instruction for the
device that you are installing). Note that the device address must be set to 3.
The device must be registered before downloading or alarm reporting can take place.
LRR Communications Device Diagnostic Mode
This mode provides a method to verify the LRR signal strength.
1. Enter the Installer Code (4112) + 899. The system will initially display “Entering programming mode”.
2. The LRR Communications Module’s Signal Level (Primary Site Received Signal Strength Indication
[PriRSSI]) will be displayed in dBm. The system will also display GPRS connection and registration
indications (refer to the example that follows).
3. If “FAIL” or “POOR” signal levels are displayed during the test, the control should be relocated to find a
location that provides better signal strength.
If a ‘searching for coverage’ message is displayed or the radio is not connected and no signal indication
is displayed, the installer should check radio programming, panel programming, etc., before entering this
mode again.
Signal strength may vary
4. The Lynx Plus will automatically exit this mode after approximately 1-minute or if any key is pressed.
The system will display “Exiting programming mode” when the test is complete.

Lynx Plus Series Installation and Setup Guide
- 10 -
Connecting/Configuring Communication Modules
Example:
SIGNAL GPRS REG
-86 GOOD Y H
Diagnostic Mode Definitions
SIGNAL = Communications Module’s Signal Level (RSSI) will be displayed in dBm, where:
-01 to -93 GOOD = Good signal level
-94 to -95 POOR = Poor signal level, move unit for better signal level
-96 (and lower) FAIL = Fail signal level, do not install, move unit for better signal level. If “FAIL” condition persists, do
not install
0 or “Searching for Coverage” = Waiting for signal. Try again in a few minutes. If no signal persists, move unit for better
signal level, check all connections and SIM activation.
GPRS = GPRS Service availability where:
Y = GPRS is available
N = GPRS is Not available
REG = Registration status from radio module where
N = Not Registered (contact AlarmNet)
H = Registered Home (functioning normally)
S = Searching (wait or move unit to another location)*
D = Registration Denied (contact AlarmNet)
R = Registered Roaming (no problem)
? = Unknown Registration State (wait or move unit to another location)*
* If the unit is in an area of known cellular coverage for 3 – 5 min and these conditions do not clear contact AlarmNet for
assistance.
