HP Moonshot 1500 Operating and safety instructions

HP Moonshot 1500 Chassis
Setup and Installation Guide
Abstract
This document contains setup, installation, and configuration information for the HP Moonshot System. This document is for th
e person who installs,
administers, and troubleshoots the HP Moonshot System. HP assumes you are qualified in the servicing of computer equipment and trained in
recognizing hazards in products with hazardous energy levels.
Part Number: 711993-004
June 2014
Edition: 4

© Copyright 2013, 2014 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions contained herein.
Microsoft® and Windows® are U.S. registered trademarks of the Microsoft group of companies.

Contents 3
Contents
Planning the installation................................................................................................................. 5
Safety and regulatory compliance..................................................................................................................5
Site requirements..........................................................................................................................................5
Software prerequisites ..................................................................................................................................5
Determine power and cooling configurations ..................................................................................................5
Power requirements............................................................................................................................5
HP Advanced Power Manager ............................................................................................................6
Hot-plug power supply calculations ......................................................................................................6
Compiling the documentation........................................................................................................................6
Warnings and cautions.................................................................................................................................6
Space and airflow requirements ....................................................................................................................7
Temperature requirements .............................................................................................................................8
Grounding requirements ...............................................................................................................................8
Identifying components and LEDs.................................................................................................... 9
HP Moonshot System components..................................................................................................................9
Chassis front panel components...................................................................................................................10
Chassis front panel LEDs and buttons............................................................................................................10
Chassis rear panel components ...................................................................................................................11
Fan bay numbering ..........................................................................................................................12
Fan LED...........................................................................................................................................12
Power supply bay numbering ............................................................................................................12
Power supply LED.............................................................................................................................13
Uplink module bay identification........................................................................................................13
Moonshot-6SFP Uplink Module components ........................................................................................13
Moonshot-6SFP Uplink Module LEDs and buttons.................................................................................14
Moonshot-4QSFP+ Uplink Module components ...................................................................................15
Moonshot-4QSFP+ Uplink Module LEDs and buttons ............................................................................15
HP Moonshot 1500 Chassis Management module components.............................................................16
HP Moonshot 1500 Chassis Management module LEDs and buttons .....................................................17
Chassis internal components........................................................................................................................17
Cartridge slot and switch module bay identification.............................................................................18
Cartridge LEDs and buttons ...............................................................................................................19
Switch module button, sensor, and LEDs .............................................................................................20
Installing the chassis.................................................................................................................... 21
Installation overview...................................................................................................................................21
Unpacking the HP Moonshot System ............................................................................................................21
Determining the chassis rack spacing...........................................................................................................21
Installing the rack rails ................................................................................................................................21
Installing the chassis in the rack ...................................................................................................................21
Installing the blanking panel........................................................................................................................25
Installing HP Moonshot System components ..................................................................................................26
Installing the Moonshot 1500 CM module ..........................................................................................27
Installing a power supply ..................................................................................................................27
Installing the fans .............................................................................................................................28
Installing the cartridge ......................................................................................................................29

Contents 4
Installing network components ...........................................................................................................29
Cabling the HP Moonshot System ................................................................................................. 36
Cabling overview.......................................................................................................................................36
Connecting the Moonshot System to a network..............................................................................................36
Data center management network......................................................................................................36
Data center production network.........................................................................................................37
Connecting power cables and applying power to the chassis .........................................................................38
Power-on events ...............................................................................................................................38
Routing cables on the cable management arm ..............................................................................................38
Configuring the HP Moonshot System............................................................................................ 39
Chassis configuration overview....................................................................................................................39
Configure the chassis........................................................................................................................39
Configure the switch.........................................................................................................................41
Power capping ..........................................................................................................................................44
Power capping modes ......................................................................................................................44
Configuring a power cap..................................................................................................................44
Troubleshooting.......................................................................................................................... 46
Troubleshooting resources ...........................................................................................................................46
Regulatory information ................................................................................................................ 47
Safety and regulatory compliance................................................................................................................47
Belarus Kazakhstan Russia marking..............................................................................................................47
Turkey RoHS material content declaration .....................................................................................................48
Ukraine RoHS material content declaration ...................................................................................................48
Warranty information .................................................................................................................................48
Communications interference.......................................................................................................................48
Electrostatic discharge................................................................................................................. 49
Preventing electrostatic discharge ................................................................................................................49
Grounding methods to prevent electrostatic discharge....................................................................................49
Specifications............................................................................................................................. 50
Chassis environmental specifications............................................................................................................50
Chassis specifications.................................................................................................................................50
Support and other resources ........................................................................................................ 51
Before you contact HP ................................................................................................................................51
HP contact information................................................................................................................................51
Customer Self Repair ..................................................................................................................................51
Acronyms and abbreviations........................................................................................................ 59
Documentation feedback ............................................................................................................. 61
Index......................................................................................................................................... 62

Planning the installation 5
Planning the installation
Safety and regulatory compliance
For safety, environmental, and regulatory information, see Safety and Compliance Information for Server,
Storage, Power, Networking, and Rack Products, available at the HP website
(http://www.hp.com/support/Safety-Compliance-EnterpriseProducts).
Site requirements
Select an installation site that meets the detailed installation site requirements described in the HP Moonshot
System Site Planning Guide in the HP Moonshot Information Library
(http://www.hp.com/go/moonshot/docs).
Software prerequisites
Before setting up and configuring the HP Moonshot System, be prepared to do the following:
•Obtain a supported operating system. For information about operating systems supported by the
Moonshot System, see the operating system support matrices (http://www.hp.com/go/supportos).
•For deployment procedures, see operating system deployment documentation in the HP Moonshot
Information Library (http://www.hp.com/go/moonshot/docs).
•Prepare to update firmware and system software components using HP Moonshot Component Pack.
HP Moonshot Component Pack is a comprehensive firmware solution tested on the HP Moonshot System
and delivered as a compressed file. The compressed file includes all the component files needed to
update a Moonshot System. Users deploy the firmware updates contained in the Moonshot Component
Pack from a command line by using the iLO Chassis Manager CLI or HP Moonshot-45G/180G Switch
Module CLI, or by using the included HP Smart Update Manager. Download the latest pack from the HP
website (http://www.hp.com/go/moonshot/download).
For a complete list of Moonshot System documentation, see the HP Moonshot Information Library
(http://www.hp.com/go/moonshot/docs).
Determine power and cooling configurations
Validate power and cooling requirements based on location and installed components. For more
information, see the HP Moonshot System Configuration and Compatibility Guide in the HP Moonshot
Information Library (http://www.hp.com/go/moonshot/docs).
Power requirements
Installation of this equipment must comply with local and regional electrical regulations governing the
installation of IT equipment by licensed electricians. This equipment is designed to operate in installations

Planning the installation 6
covered by NFPA 70, 1999 Edition (National Electric Code) and NFPA-75, 1992 (code for Protection of
Electronic Computer/Data Processing Equipment). For electrical power ratings on options, refer to the
product rating label or the user documentation supplied with that option.
WARNING: To reduce the risk of personal injury, fire, or damage to the equipment, do not
overload the AC supply branch circuit that provides power to the rack. Consult the electrical
authority having jurisdiction over wiring and installation requirements of your facility.
CAUTION: Protect the chassis from power fluctuations and temporary interruptions with a
regulating UPS. This device protects the hardware from damage caused by power surges and
voltage spikes and keeps the chassis in operation during a power failure.
HP Advanced Power Manager
HP APM is a point of contact for system administration.
To install, configure, and access HP APM, see the HP ProLiant SL Advanced Power Manager User Guide in
the HP Moonshot Information Library (http://www.hp.com/go/moonshot/docs).
Hot-plug power supply calculations
For hot-plug power supply specifications and calculators to determine electrical and heat loading for the HP
Moonshot System, see the HP Power Advisor on the HP website (http://www.hp.com/go/hppoweradvisor).
Compiling the documentation
The documentation, while delivered individually and in various formats, works as a system. Consult these
documents before attempting installation. These documents provide required important safety information
and decision-making steps for configuration.
The HP Moonshot System information can be found in the HP Moonshot Information Library
(http://www.hp.com/go/moonshot/docs):
•Quick Deploy Rail System Installation Instructions
•HP Moonshot System Site Planning Guide
•HP Moonshot iLO Chassis Management CLI User Guide
•Links to all related documentation
•Videos
Warnings and cautions
WARNING: To reduce the risk of personal injury or damage to equipment, heed all warnings
and cautions throughout the installation instructions.

Planning the installation 7
WARNING: To reduce the risk of personal injury or damage to the equipment, be sure that:
•The rack is bolted to the floor using the concrete anchor kit.
•The leveling feet extend to the floor.
•The full weight of the rack rests on the leveling feet.
•The racks are coupled together in multiple rack installations.
•Only one component is extended at a time. If more than one component is extended, a rack
might become unstable.
WARNING: The chassis is very heavy. To reduce the risk of personal injury or damage to the
equipment, do the following:
•Observe local occupational health and safety requirements and guidelines for manual
material handling.
•Get help to lift and stabilize the product during installation or removal, especially when the
product is not fastened to the rails. The chassis weighs more than 81.65 kg (180.00 lb), so at
least four people must lift the chassis into the rack together. An additional person may be
required to help align the chassis if the chassis is installed higher than chest level.
WARNING: To reduce the risk of personal injury or damage to the equipment, you must
adequately support the chassis during installation and removal.
WARNING: Be sure to install the chassis starting from the bottom of the rack, and then work your
way up the rack.
WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the
internal system components to cool before touching them.
WARNING: To reduce the risk of electric shock or damage to the equipment:
•Never reach inside the chassis while the system is powered up.
•Perform service on system components only as instructed in the user documentation.
CAUTION: Always be sure that equipment is properly grounded and that you follow proper
grounding procedures before beginning any installation procedure. Improper grounding can
result in ESD damage to electronic components. For more information, refer to "Electrostatic
discharge (on page 49)."
CAUTION: When performing non-hot-plug operations, you must power down the chassis and/or
the system. However, it may be necessary to leave the chassis powered up when performing other
operations, such as hot-plug installations or troubleshooting.
Space and airflow requirements
To enable servicing and ensure adequate airflow, observe the following spatial requirements when deciding
where to install a rack:
•Leave a minimum clearance of 121.9 cm (48.0 in) in front of the rack.
•Leave a minimum clearance of 76.2 cm (30.0 in) in back of the rack.
•Leave a minimum clearance of 121.9 cm (48.0 in) from the back of the rack to the rear of another rack
or row of racks.

Planning the installation 8
HP rack products draw cool air in through the front and expel warm air through the rear of the enclosure.
Therefore, the front of the rack enclosure must be adequately ventilated to enable ambient room air to enter
the enclosure, and the rear of the enclosure must be adequately ventilated to enable the warm air to escape
from the enclosure.
IMPORTANT: Do not block the ventilation openings.
If the front of the rack is not completely filled with components, the remaining gaps between the components
can cause changes in the airflow, which can adversely affect cooling within the rack. Cover these gaps with
blanking panels.
CAUTION: Always use blanking panels to fill empty vertical spaces in the rack. This arrangement
ensures proper airflow. Using a rack without blanking panels results in improper cooling that can
lead to thermal damage.
Racks provide proper server cooling from flow-through perforations in the front and rear doors that provide
a 65% open area for ventilation.
Temperature requirements
To ensure continued safe and reliable equipment operation, install or position the rack in a well-ventilated,
climate-controlled environment.
The operating temperature inside the rack is always higher than the room temperature and is dependent on
the configuration of equipment in the rack. Check the TMRA for each piece of equipment before installation.
CAUTION: To reduce the risk of damage to the equipment when installing third-party options:
•Do not permit optional equipment to impede airflow around the chassis or to increase the
internal rack temperature beyond the maximum allowable limits.
•Do not exceed the manufacturer’s TMRA.
Grounding requirements
This equipment must be grounded properly for proper operation and safety. In the United States, you must
install the equipment in accordance with NFPA 70, 1999 Edition (National Electric Code), Article 250, as
well as any local and regional building codes.
In Canada, you must install the equipment in accordance with Canadian Standards Association, CSA
C22.1, Canadian Electrical Code.
In all other countries, you must install the equipment in accordance with any regional or national electrical
wiring codes, such as the International Electrotechnical Commission (IEC) Code 364, parts 1 through 7.
Furthermore, you must be sure that all power distribution devices used in the installation, such as branch
wiring and receptacles, are listed or certified grounding-type devices.
Because of the high ground-leakage currents associated with this equipment, HP recommends the use of a
PDU that is either permanently wired to the building’s branch circuit or includes a nondetachable cord that
is wired to an industrial-style plug. NEMA locking-style plugs or those complying with IEC 60309 are
considered suitable for this purpose. Using common power outlet strips to supply power to this equipment is
not recommended.

Identifying components and LEDs 9
Identifying components and LEDs
HP Moonshot System components
Item Description
1 HP Moonshot 1500 Chassis
2 Cartridges*
3
Cartridge blank*
4 Access panel
5 Switch module*
6 Fans (5)
7 Uplink module*
8 Moonshot 1500 CM module
9 Power supplies*
* The quantity depends on the configuration ordered.
The following documents also ship with the Moonshot System:
•Start Here for Important Setup Information
•Safety, Compliance, and Warranty Information

Identifying components and LEDs 10
Chassis front panel components
Item Description
1 Bezel ear
2 Backplane assembly release lever
3 Serial label pull tab
4 Bezel ear
Chassis front panel LEDs and buttons
Item Description LED Status
1 Chassis power LED Flashing Green = The chassis is waiting to power on.
Green = Normal operation
Amber = Standby operation
Off = No power
2 Chassis health LED Green = Normal operation
Flashing Amber = Degraded condition
Flashing Red = Critical condition
Off = No power
3 Chassis UID LED/button Blue = Chassis ID is selected.
Flashing blue = System firmware update is in process.
Off = Chassis ID is not selected.

Identifying components and LEDs 11
Item Description LED Status
4 Cartridge health LEDs Green = Normal operation
Amber = Standby mode
Flashing Amber = Degraded condition
Flashing Amber (All) = Moonshot 1500 CM module is not installed.
Flashing Red = Critical condition
Off = Cartridge is not installed or no power exists.
5 Switch module A health
LED
Green = Normal operation
Flashing Amber = Degraded condition
Flashing Red = Critical condition
Off = Switch module is not installed or no power exists.
6 Switch module B health
LED
Green = Normal operation
Flashing Amber = Degraded condition
Flashing Red = Critical condition
Off = Switch module is not installed or no power exists.
Chassis rear panel components
Item Description
1 Fans (5)
2 Moonshot 1500 CM module
3 Uplink module A
4 Uplink module B (blank installed)
5
Power supplies
6 Power supply blank

Identifying components and LEDs 12
Fan bay numbering
Fan LED
Status Description
Off
The fan is working or the power is off.
Solid amber The fan has failed.
Power supply bay numbering

Identifying components and LEDs 13
Power supply LED
Status Description
Off
•
No AC power to power supply units. Check the AC power cord.
•
AC is present. Standby output is on; output is disabled.
•
Power supply failure (includes overvoltage and overtemperature)
Green AC is present and main 12 V output is enabled.
Uplink module bay identification
Moonshot-6SFP Uplink Module components

Identifying components and LEDs 14
Item Component Description
1 Serial console port For management
2 SFP+ ports X1–X6 1Gb or 10Gb Ethernet
SFP+ ports X1 through X6 support Ethernet traffic only.
SFP+ ports support the following pluggable Ethernet transceiver modules:
•HP 1000BASE-T SFP
•HP 10GBASE-SR SFP+
•HP 10GBASE-DAC SFP+
Any available port can be used to connect to the data center. Ensure the port is populated with supported HP
transceiver modules that are compatible with the data center port type.
Moonshot-6SFP Uplink Module LEDs and buttons
Item Description Status
1 Uplink module UID
LED/button
Solid blue = Switch module ID is selected.
Flashing blue = Switch module firmware
update is in progress.
Off = Switch module ID is not selected.
2 Uplink module health
LED
Green = Normal operation
Flashing amber = Degraded condition
Flashing red = Critical condition
Off = No power
3 Uplink module link
LED
Solid green = Link
Off = No link
4 Uplink module
activity LED
Flashing green = Activity
Off = No activity
5 Reset button Resets the switch module

Identifying components and LEDs 15
Moonshot-4QSFP+ Uplink Module components
Item Component Description
1
Serial console port For management
2 QSFP+ ports Q1–Q4 40Gb Ethernet
QSFP+ ports Q1 through Q4 support Ethernet traffic only.
QSFP+ ports support the following pluggable Ethernet transceiver modules:
•HP 40GBASE QSFP+
•HP 40GBASE QSFP+ SR4
•HP 40GBASE QSFP+ DAC
•HP 40GBASE QSFP+ to 4x10G SFP+
Any available port can be used to connect to the data center. Ensure the port is populated with supported HP
transceiver modules that are compatible with the data center port type.
Moonshot-4QSFP+ Uplink Module LEDs and buttons

Identifying components and LEDs 16
Item Description Status
1 Uplink module UID
LED/button Solid blue = Switch module ID is selected. Flashing blue = Switch module firmware
update is in progress.
Off = Switch module ID is not selected.
2 Uplink module health
LED
Green = Normal operation
Flashing amber = Degraded condition
Flashing red = Critical condition
Off = No power
3 Uplink module link
LED
Solid green = Link
Off = No link
4 Uplink module
activity LED
Flashing green = Activity
Off = No activity
5 Reset button Resets the switch module
HP Moonshot 1500 Chassis Management module components
Item Description Label
1 iLO CM management port iLO/MGMT
2 iLO CM link port (disabled by default) LINK
3 Moonshot 1500 CM module HP APM port RCM
4 Moonshot 1500 CM module diagnostic port DEBUG
5 iLO CM management serial port —
6 Moonshot 1500 CM module USB connector —
7 Moonshot 1500 CM module MicroSD slot —

Identifying components and LEDs 17
HP Moonshot 1500 Chassis Management module LEDs and
buttons
Item Description Label
1 iLO CM management port link LED iLO/MGMT
2 iLO CM management port activity LED iLO/MGMT
3 iLO CM link port link LED LINK
4 iLO CM link port activity LED LINK
5 Moonshot 1500 CM module UID LED/button —
6 Moonshot 1500 CM module health LED —
Chassis internal components
Up to 45 cartridges and two switch modules can be installed in the HP Moonshot 1500 Chassis.

Identifying components and LEDs 18
Cartridge slot and switch module bay identification
The chassis provides 45 cartridge slots (1-45) and two switch module bays (A-B).

Identifying components and LEDs 19
Cartridge LEDs and buttons
Item Description Status
1 Cartridge power
LED/button Green = Normal operation Amber = Standby operation
Off = No power
2 Cartridge health LED Green = Normal operation
Flashing amber = Degraded condition
Flashing red = Critical condition
Off = No power
3 Drive LED* Green = Activity
Off = No activity
4 Cartridge UID LED/button Blue = Cartridge ID is selected.
Flashing blue = Cartridge firmware
update is in progress.
Off = Cartridge ID is not selected.
5 Cartridge link
LED/button**
Flashing white = Cartridges are linked.
Off = Cartridge is not linked to other
cartridges.
* Depending on the cartridge installed, there might be 0, 1, or 2 drive LEDs.
** The cartridge link LED flashes for 10 seconds after the link button is pressed.

Identifying components and LEDs 20
Switch module button, sensor, and LEDs
Item Description Status
1 Switch module power
LED Green = Normal operation Amber = Standby operation
Off = No power
2 Switch module health
LED Green = Normal operation Flashing amber = Degraded condition
Flashing red = Critical condition
Off = No power
3 Switch module uplink
activity LED
Green = Link
Flashing green = Activity
Off = No activity
4 Switch module
downlink activity LED
Green = Link
Flashing green = Activity
Off = No activity
5 Switch module UID
LED/button
Solid blue = Switch module ID is selected.
Flashing blue = Switch module firmware
update is in progress.
Off = Switch module ID is not selected.
6 Access panel sensor Detects the presence of the access panel*
*The fan speed adjusts automatically when the access panel is installed or removed.
