HP ProLiant s6500 User manual

The HP ProLiant s6500 chassis can accommodate up to eight half-width or four full width servers gives you the ability to mix and match
server nodes, and also allows for single node serviceability (SNS)-making it an extremely flexible chassis. This, in other words, means
that you can add or remove compute capacity based on your business needs. The highly efficient multi-node chassis with shared power
and cooling components, including energy efficient fans and optional hot-plug redundant PSU helps reduce power consumption when
compared to previous generation servers.
Front View: Back View:
1. Server Bay 1 1. Fan 8
2. Server Bay 2 2. Fan 7
3. Server Bay 3 3. SL-APM interface
4. Server Bay 4 4. Power supply 4
5. Server Bay 5 5. Fan 4
6. Server Bay 6 6. Fan 3
7. Server Bay 7 7. Fan 1
8. Server Bay 8 8. Fan 2
9. Power Supply 1
10. Power Supply 2
11. Power Supply 3
12. Fan 5
13. Fan 6
What's New
Updating supported options
QuickSpecs
HP ProLiant s6500 Chassis
Overview
DA - 14188 North America — Version 14 — December 13, 2013 Page 1

System Fans Non-redundant model
Redundant model
NOTE: all 8 fan bays must be populated with either redundant or non-redundant fans
NOTE: mixing and matching of fans is not supported
Form Factor HP ProLiant s6500 Chassis - 4U
Warranty This product is covered by a global limited warranty and supported by HP Services and a worldwide
network of HP Authorized Channel Partners. Hardware diagnostic support and repair is available for one
year from date of purchase. Support for software and initial setup is available for 90 days from date of
purchase. Enhancements to warranty services are available through HP Care Pack services or customized
service agreements. Hard drives have either a one year or three year warranty.
NOTE: Server Warranty includes 1 year Parts, 1 year Labor, 1-year on-site support with next business day
response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts.
These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel
and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR
parts are also designed for easy replacement but may involve added complexity. Customers may choose
to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited
warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html .
Factory Express Portfolio
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging, and custom packaging. HP products supported through Factory Express include a wide array of
servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000
servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network
switches.
For more information on Factory Express services for your specific server model please contact your sales
representative or go to: http://www.hp.com/go/factory-express .
QuickSpecs
HP ProLiant s6500 Chassis
Standard Features
DA - 14188 North America — Version 14 — December 13, 2013 Page 2

Service and Support HP Technology Services for Industry Standard Servers and BladeSystem
Capitalizing on HP ProLiant server and HP BladeSystem capabilities requires a service partner who
understands your increasingly complex business technology environment. That's why it makes sense to
team up with the people who know HP infrastructure hardware and software best - the experienced
professionals at HP Services.
What HP ProLiant and BladeSystem Services can do for you
HP ProLiant and BladeSystem Services can help you design, deploy, test, integrate, support, and manage
IT and infrastructure solutions. This way, HP proposes services solutions that include more than just uplift
of base warranty. You can get the support you need by choosing from one of a number of service
packaged solutions we have designed to address wider set of customer support needs.
HP Technology Services meets business challenges with services offered in three packages - Optimized
Care Package, Standard Care Package, and Basic Care Package - available for each product group. Such
packaged solutions enable customers to optimize technology operations, minimize risk and drive better
business outcomes with easy-to-buy, easy-to-use scalable support packages for servers, storage,
networking and software.
Optimized Care Optimized Care Package: Supports maintaining servers at optimum performance availability
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN
HP Installation and Startup for Insight Control Software
Provides for the deployment and basic configuration of HP Insight Control on HP ProLiant ML and DL series
servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP Critical Advantage
Provides end-to-end infrastructure support solution for business critical applications running on
virtualized/x86 infrastructures, enabling the customers to cost effectively build, operate, and
continuously improve their IT environment
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=4AA3-1772ENW
Additional Services : Data Center Transformation Service
QuickSpecs
HP ProLiant s6500 Chassis
Service and Support
DA - 14188 North America — Version 14 — December 13, 2013 Page 3

Standard Care Standard Care Package: Package that maintains high level of server availability
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN
HP Installation and Startup for Insight Control Software
Provides for the deployment and basic configuration of HP Insight Control on HP ProLiant ML and DL series
servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP 6 hour Hardware Support Onsite Call-to-Repair Service
Provides an IT manager with a team of support specialists who will quickly begin troubleshooting the
system to help return the hardware to operating condition within 6 hours of the initial service request to
the HP Global Solution Center
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6636ENN
3-Year , HP 24x7 Software Support for Insight Control
Provides for the deployment and basic configuration of HP Insight Control on HP ProLiant ML and DL series
servers or HP BladeSystem servers
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6645EEE.pdf
Additional Services : Software OS (Microsoft, Linux (SUSE/Red Hat) & VMware Installation & Start Up and
Software Support); Microsoft or Linux or VMware education courses; +60 Proactive Select Credits
Basic Care Basic Care Package: delivers minimum recommended support service level
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN
HP Installation and Startup for Insight Control Software
Provides for the deployment and basic configuration of HP Insight Control on HP ProLiant ML and DL series
servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service
Provides for the deployment and basic configuration of HP Insight Control on HP ProLiant ML and DL series
servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year , HP 24x7 Software Support for Insight Control
Provides for the deployment and basic configuration of HP Insight Control on HP ProLiant ML and DL series
servers or HP BladeSystem servers
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6645EEE.pdf
Additional Services : Software OS (Microsoft, Linux (SUSE/Red Hat) & VMware Installation & Start Up and
QuickSpecs
HP ProLiant s6500 Chassis
Service and Support
DA - 14188 North America — Version 14 — December 13, 2013 Page 4

Software Support); +30 Proactive Select Credits, Factory Express
Insight Remote Support The packages include HP Insight Remote Support that uses proven technology to deliver secure, reliable
24x7 remote monitoring, diagnoses, and problem resolution. It is available at no additional cost to all
warranty, HP Care Pack Service, and service agreement customers.
For more information To learn more on HP ProLiant servers and HP BladeSystem servers, please contact your HP sales
representative or HP Authorized Channel Partner. Or visit: http://www.hp.com/services/proliant
QuickSpecs
HP ProLiant s6500 Chassis
Service and Support
DA - 14188 North America — Version 14 — December 13, 2013 Page 5

s6500 SL Server Support
Server Nodes HP ProLiant SL230s Gen8 1U Left Half Width Tray Configure-to-order Server 650047-B21
HP ProLiant SL230s Gen8 1U Right Half Width Tray Configure-to-order Server 650048-B21
HP ProLiant SL250s Gen8 2U PCIe Gen3 Left Half Width Tray Configure-to-order Server 698723-B21
HP ProLiant SL250s Gen8 2U PCIe Gen3 Right Half Width Tray Configure-to-order Server 698724-B21
HP SL250s Gen8 Ivb Lft Tray Node Server 750349-B21
HP SL250s Gen8 Ivb Rht Tray Node Server 750350-B21
HP ProLiant SL270s Gen8 1U Left Half Width Tray Configure-to-order Server 654947-B21
HP ProLiant SL270s Gen8 1U Right Half Width Tray Configure-to-order Server 654948-B21
HP ProLiant SL270s Gen8 SE 4U Left Tray Configure-to-order Server 739055-B21
HP ProLiant SL270s Gen8 SE 4U Right Tray Configure-to-order Server 739056-B21
Pre-configured Models
HP ProLiant s6500 chassis
HP ProLiant s6500 3/1200
Redundant Fan Chassis
629236-B21
Power Supply (3) 1200W (94% efficient) Platinum Plus Hot Plug Power Supplies
Fans (8) hot plug redundant fans
Form Factor 4U chassis
Tray blank 1 right and 1 left tray blank
Power supply blanks 1 power supply blank
HP ProLiant s6500 2/1200
Non Redundant Fan
Chassis
629235-B21
Power Supply (2) 1200W (94% efficient) Platinum Plus Hot Plug Power Supplies
Fans (8) hot plug non-redundant fans
Form Factor 4U chassis
Tray blank 1 right and 1 left tray blank
Power supply blanks 2 power supply blank
QuickSpecs
HP ProLiant s6500 Chassis
Pre-configured Models
DA - 14188 North America — Version 14 — December 13, 2013 Page 6

S6500 tray mixing support plan
NOTE: s6500 is a 4U chassis and has a left and a right side when using ½ width trays.
NOTE: The picture below show how each half of the chassis can be configured.
NOTE: A full width tray uses the entire width of the chassis
NOTE: Mixing and matching of half width trays is supported.
NOTE: Mixing and Matching of Full width trays is supported
NOTE: Mixing and matching of Full and half width trays is NOT supported.
NOTE: 2U half width tray is NOT supported in middle 2 bays.
1U Full Width
1U ½ Width
1U ½ Width
1U ½ W
1U ½ W
2U ½ W
2U ½ W
1U ½ W
1U ½ W
2U ½ W
2U ½ W
1U ½ W
1U ½ W
4U ½ W
QuickSpecs
HP ProLiant s6500 Chassis
Pre-configured Models
DA - 14188 North America — Version 14 — December 13, 2013 Page 7

NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on
configurable product offerings and requirements.
NOTE: FIO indicates that this option is only available as a factory installable option.
Step 1: Base Configuration (choose one from each list unless otherwise noted)
HP Chassis HP ProLiant s6500 without Fans 4U Configure-to-order Chassis
NOTE: You must choose Power Supplies and fans as the chassis does not include them.
614167-B21
HP Chassis Fans HP s6500 Non Redundant Fan Kit
NOTE: This kit includes only 1 fan
NOTE: This selection must be ordered in quantities of 8.
617858-B21
HP s6500 Redundant Fan Kit
NOTE: This kit includes only 1 fan
NOTE: This selection must be ordered in quantities of 8.
617856-B21
HP Tray Blanks HP s6500 Half Width Node Left Blank Kit
NOTE: Node blank is needed when not completely filling s6500 chassis and when
servicing a node.
688928-B21
HP s6500 Half Width Node Right Blank Kit
NOTE: Node blank is needed when not completely filling s6500 chassis and when
servicing a node.
688930-B21
HP Power Supplies NOTE: Mixing of power supplies in the same chassis is not supported. All power supplies
inside a server must be exactly the same model. Mixing Gold, Platinum, and Platinum
Plus certified power supplies is not supported.
NOTE: Prior to making a power supply selection it is highly recommended that the HP
Power Advisor is run to determine the right size power supply for your server
configuration. The HP Power Advisor is located at: www.hp.com/go/hppoweradvisor .
NOTE: Choose correct power supply from list below depending on generation of server.
HP Common Slot Platinum Plus Power Supply Kits
NOTE: These power supplies support Gen8 servers.
HP 750W Common Slot Platinum Plus Hot Plug Power Supply Kit 656363-B21
HP 1200W Common Slot Platinum Plus Hot Plug Power Supply Kit 656364-B21
HP 1500W Common Slot Platinum Plus Hot Plug Power Supply Kit 684532-B21
HP Common Slot Platinum Power Supplies
NOTE: This Power Supply supports G6 and G7 servers.
HP 1200W Common Slot Platinum Hot Plug Power Supply Kit 578322-B21
HP Common Slot Gold Power Supplies
NOTE: This Power Supply supports G6 and G7 servers.
HP 750W Common Slot Gold Hot Plug Power Supply Kit 512327-B21
HP Common Slot 277VAC Power Supplies
NOTE: 94% efficiency.
HP 1200W Common Slot 277VAC Hot Plug Power Supply Kit
NOTE: The 1200W Common Slot 277VAC Hot Plug Power Supply Kit does not include a
power cord.
717359-B21
QuickSpecs
HP ProLiant s6500 Chassis
Configuration Information - Factory Integrated Models
DA - 14188 North America — Version 14 — December 13, 2013 Page 8

HP Common Slot 380VDC Power Supplies
NOTE: 94% efficiency.
HP 1200W Common Slot 380VDC Hot Plug Power Supply Kit 684539-B21
NOTE: Power Specification and Technical Content for supported power supplies can be
found at:
http://h18000.www1.hp.com/products/quickspecs/14209_na/14209_na.html
Step 2: Choose Additional Options for Factory Integration
NOTE: For additional options, please refer to the "Additional Options" section below.
HP Power Supplies NOTE: Mixing of power supplies in the same chassis is not supported. All power supplies
inside a server must be exactly the same model. Mixing Gold, Platinum, and Platinum
Plus certified power supplies is not supported.
NOTE: Prior to making a power supply selection it is highly recommended that the HP
Power Advisor is run to determine the right size power supply for your server
configuration. The HP Power Advisor is located at: www.hp.com/go/hppoweradvisor .
NOTE: Choose correct power supply from list below depending on generation of server.
HP Common Slot Platinum Plus Power Supply Kits
NOTE: This Power Supply supports Gen8 servers.
HP 750W Common Slot Platinum Plus Hot Plug Power Supply Kit 656363-B21
HP 1200W Common Slot Platinum Plus Hot Plug Power Supply Kit 656364-B21
HP 1500W Common Slot Platinum Plus Hot Plug Power Supply Kit 684532-B21
HP Common Slot Platinum Power Supplies
NOTE: This Power Supply supports G6 and G7 servers.
HP 1200W Common Slot Platinum Hot Plug Power Supply Kit 578322-B21
HP Common Slot Gold Power Supplies
NOTE: This Power Supply supports G6 and G7 servers.
HP 750W Common Slot Gold Hot Plug Power Supply Kit 512327-B21
HP Common Slot 277VAC Power Supplies
NOTE: 94% efficiency.
HP 1200W Common Slot 277VAC Hot Plug Power Supply Kit
NOTE: The 1200W Common Slot 277VAC Hot Plug Power Supply Kit does not include a
power cord.
717359-B21
HP Common Slot 380VDC Power Supplies
NOTE: 94% efficiency.
HP 1200W Common Slot 380VDC Hot Plug Power Supply Kit 684539-B21
NOTE: Power Specification and Technical Content for supported power supplies can be
found at:
http://h18000.www1.hp.com/products/quickspecs/14209_na/14209_na.html
QuickSpecs
HP ProLiant s6500 Chassis
Configuration Information - Factory Integrated Models
DA - 14188 North America — Version 14 — December 13, 2013 Page 9

NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, HP recommends the use of
an HP approved configurator. Contact your local sales representative for additional information.
HP SL Advanced Power
Manager
The SL Advanced Power Manager is an optional rack level solution for the HP ProLiant
SL4540 and SL4545 which enables server-level DC (or hardware) power on and off and
server-level monitoring. In addition, the SL APM will automatically discover SL
hardware components which are connected into the SL APM solution.
The SL APM does not replace rack PDUs, but is designed to enable the utilization of
basic, low cost, rack PDUs while providing the functionality of 'switched' PDUs which
provide hardware power on/off of individual servers by turning off the AC power to the
power supplies of a given server. Because the SL servers share power supplies to
optimize power efficiency, using 'switched' PDUs to turn off the power supplies in the
chassis will result in the loss of all servers in that chassis. The SL APM solves this by
allowing server-level hardware power on/off of the DC power to the individual server
motherboards.
HP SL Advanced Power Manager Kit 538084-B21
HP SL Advanced Power Manager Distribution Module Kit 620002-B21
DC Power Cable Kits HP 1.3M 48V DC Power Cable Kit A5S97A
HP 2.5M 48V DC Power Cable Kit
NOTE: These power cord options are for use with the HP 750W Common Slot -48VDC
Hot Plug Power Supply Kit (636673-B21). A5S98A
A5S98A
HP T-latch Double Ended WW 18AWG DC 2m Jumper Cord
NOTE: This power cord option is for use with the HP 1200W Common Slot 380VDC Hot
Plug Power Supply Kit (684539-B21).
D4J67A
HP Power Cords NOTE: HP ProLiant servers ships with an IEC-IEC power cord used for rack mounting
with Power Distribution Units (PDUs).
HP C13 - C14 WW 250V 10A Gray 0.7m Jumper Cord A0K03A
HP C13 - C14 WW 250V 10A Gray 1.37m Jumper Cord A0K04A
HP C13 - Nema 6-15P US 250V 15A JP 3.6m Power Cord A0N33A
HP C13 - Nema 5-15P TH/PH 250V 10Amp 1.83m Power Cord AF559A
HP C13 - C14 WW 250V 10Amp Flint Gray 2.0m Jumper Cord AF573A
HP Tape Backup NOTE: For the complete range of tape drives, autoloaders, libraries and media see:
http://www.hp.com/go/tape . For hardware and software compatibility of HP tape
backup products see: http://www.hp.com/storage/SPOCK
HP StoreEver LTO-6 Ultrium 6250 Tape Drive in 1U Rack-mount Kit C0L99A
HP 1/8 G2 LTO-6 Ult 6250 FC Autoloader C0H19A
QuickSpecs
HP ProLiant s6500 Chassis
Additional Options
DA - 14188 North America — Version 14 — December 13, 2013 Page 10

HP Tape Storage Systems HP StoreEver MSL6480
HP StoreEver MSL6480 Scalable Base Module QU625A
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/14604_na/14604_na.html
HP Disk Storage Systems Disk Enclosures
HP D2600 w/12 4TB 6G SAS 7.2K LFF Dual Port MDL HDD 48TB Bundle E7W32A
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/13404_na/13404_na.html
HP Uninterruptible Power
Systems
HP Rack-mountable UPS
HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1.5kVA G3 1U NA Uninterruptible Power System AF469A
NOTE: Please see the QuickSpecs for additional information:
http://h18000.www1.hp.com/products/quickspecs/14059_na/14059_na.html
HP R/T3000 G2 Uninterruptible Power System (UPS)
HP R/T3000 G2 2U L530 Low Voltage NA/JP Uninterruptible Power System AF466A
HP R/T3000 G2 2U L620 High Voltage NA/JP Uninterruptible Power System AF467A
NOTE: Please see the QuickSpecs for additional information:
http://h18000.www1.hp.com/products/quickspecs/14058_na/14058_na.html
R5000 Uninterruptible Power System (UPS)
HP R5KVA 3U L630 High Voltage NA/JP Uninterruptible Power System AF460A
NOTE: Please see the QuickSpecs for additional information:
http://h18000.www1.hp.com/products/quickspecs/14109_na/14109_na.html
R7000 Uninterruptible Power System (UPS)
HP R7KVA 4U 50A High Voltage NA/JP Uninterruptible Power System AF462A
NOTE: Please see the QuickSpecs for additional information:
http://h18000.www1.hp.com/products/quickspecs/14110_na/14110_na.html
NOTE: For additional information on sizing your HP UPS, please reference:
http://www.upssizer.com
NOTE: Please see the UPS and PDU cable matrix's on the HP Power Protection and
Management page. Under Power Cords, click on the "HP Power Cord Matrix" link. That
link will list cable descriptions, requirements, and specifications for UPS and PDU units.
Please see the following link: www.hp.com/products/powercords .
NOTE: For additional information on HP Uninterruptible Power Systems please go to:
www.hp.com/servers/rackups .
HP Basic Power
Distribution Units
(bPDU)
HP Basic Power Distribution Unit: 1U/0U Version
HP 1.9kVA 120 Volt 12 Outlet NA/JP Basic Power Distribution Unit H5M54A
HP 3.6kVA 200-240 Volt 12 Outlet WW Basic Power Distribution Unit H5M56A
QuickSpecs
HP ProLiant s6500 Chassis
Additional Options
DA - 14188 North America — Version 14 — December 13, 2013 Page 11

HP Basic Power Distribution Unit: Half Height Version
HP 2.8kVA 120 Volt 18 Outlet NA/JP Basic Power Distribution Unit H5M55A
HP 3.6kVA 200-240 Volt 20 Outlet WW Basic Power Distribution Unit H5M57A
HP 4.9kVA 208 Volt 20 Outlet NA/JP Basic Power Distribution Unit H5M58A
HP 8.6kVA 208 Volt Three Phase 18 Outlet NA/JP Basic Power Distribution Unit H5M61A
HP Basic Power Distribution Unit: Mid Height Version
HP 4.9kVA 208 Volt 30 Outlet NA/JP Basic Power Distribution Unit H5M59A
HP 8.3kVA 208 Volt 36 Outlet NA/JP Basic Power Distribution Unit H5M60A
HP Hardwired 200-240 Volt 36 Outlet WW Basic Power Distribution Unit H5M75A
HP 5.7kVA 208 Volt Three Phase 27 Outlet NA/JP Dual Voltage Basic Power Distribution
Unit
H5M63A
HP 8.6kVA 208 Volt Three Phase 30 Outlet NA/JP Dual Voltage Basic Power Distribution
Unit
H5M64A
HP 8.6kVA 208 Volt Three Phase 30 Outlet NA/JP Basic Power Distribution Unit H5M62A
HP Basic Power Distribution Unit: Full Height Version
HP 11kVA 400 Volt Three Phase 42 Outlet NA Basic Power Distribution Unit H5M67A
HP Basic Power Distribution Unit: 480/277 Volt Version
HP 13.2kVA 480 Volt Three Phase 15 Outlet NA Basic Power Distribution Unit H3X07A
HP 19.9kVA 480 Volt Three Phase 30 Outlet NA Basic Power Distribution Unit H3X08A
HP 800VA - 277V Input / 230V Output NA Rack Mount Transformer H3X09A
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/14557_na/14557_na.html
NOTE: Additional HP Power Distribution Units are available. For a complete list of all HP
PDUs and additional information please visit: www.hp.com/go/rackandpower .
HP Remote Monitoring
Power Distribution Units
(mPDU)
HP Remote Monitored Power Distribution Unit: 1U Version
HP 2.8kVA 120 Volt 12 Outlet NA/JP Monitored Power Distribution Unit D9N43A
HP 3.6kVA 200-240 Volt 12 Outlet WW Monitored Power Distribution Unit D9N46A
HP 4.9kVA 208 Volt 12 Outlet NA/JP Monitored Power Distribution Unit D9N44A
HP Remote Monitored Power Distribution Unit: Half Height Version
HP 3.6kVA 200-240 Volt 16 Outlet WW Monitored Power Distribution Unit D9N45A
HP Remote Monitored Power Distribution Unit: Mid Height Version
HP 4.9kVA 208 Volt 24 Outlet NA/JP Monitored Power Distribution Unit D9N47A
HP 8.6kVA 208 Volt Three Phase 21 Outlet NA/JP Monitored Power Distribution Unit D9N51A
HP 5.7kVA 208 Volt Three Phase 21 Outlet NA/JP Dual Voltage Monitored Power
Distribution Unit
D9N52A
HP 8.6kVA 208 Volt Three Phase 24 Outlet NA/JP Dual Voltage Monitored Power
Distribution Unit
D9N53A
HP Remote Monitored Power Distribution Unit: Full Height Version
HP 8.3kVA 208 Volt 33 Outlet NA Monitored Power Distribution Unit D9N49A
QuickSpecs
HP ProLiant s6500 Chassis
Additional Options
DA - 14188 North America — Version 14 — December 13, 2013 Page 12

HP 14.4kVA 208 Volt Three Phase 24 Outlet NA Monitored Power Distribution Unit D9N58A
HP 16.6kVA 400 Volt Three Phase 33 Outlet NA Monitored Power Distribution Unit D9N61A
HP 17.3kVA 208 Volt Three Phase 27 Outlet NA/JP Monitored Power Distribution Unit D9N54A
HP 17.3kVA 208 Volt Three Phase 24 Outlet NA/JP Monitored Power Distribution Unit D9N59A
HP 16.6kVA 400 Volt Three Phase 24 Outlet NA Monitored Power Distribution Unit D9N62A
HP 19.9kVA 480 Volt Three Phase 30 Outlet NA Monitored Power Distribution Unit D9N63A
HP Environmental Sensor for Remote Monitored PDUs
HP Environmental Sensor for Remote Monitored PDUs E2D53A
NOTE: Please see the QuickSpecs for additional information:
http://h18000.www1.hp.com/products/quickspecs/14669_na/14669_na.html
HP Intelligent Power
Distribution Units (iPDU)
iPDU Core Units
HP 4.9kVA 24A Single Phase NA/JP Core Intelligent Modular Power Distribution Unit AF520A
HP 8.3kVA 40A Single Phase NA/JP Core Intelligent Modular Power Distribution Unit AF521A
HP 8.6kVA 24A Three Phase NA/JP Core Intelligent Modular Power Distribution Unit AF522A
HP 14.4kVA 40A Three Phase NA/JP Intelligent Modular Power Distribution Unit AF533A
HP 17.3kVA 48A Three Phase NA/JP Core Intelligent Modular Power Distribution Unit AF523A
HP 17.3kVA 24A 415V Three Phase L22-30 NA Core Intelligent Power Distribution Unit AF902A
HP 17.3kVA 48A 208V Three Phase 12 Outlet Core NA/JP Intelligent Power Distribution
Unit
AF535A
HP 17.3kVA 24A 415V Three Phase 12 Outlet Core NA/JP Intelligent Power Distribution
Unit
AF537A
iPDU Kits with Standard Extension Bars
HP 4.9kVA 24A Single Phase NA/JP Intelligent Modular Power Distribution Kit AF531A
HP 8.6kVA 24A Three Phase NA/JP Intelligent Modular Power Distribution Kit AF532A
iPDU Extension Bars
HP 5xC13 Intelligent PDU Extension Bar G2 Kit AF547A
HP 5xC13 Outlets Power and UID LEDs Pair Standard Extension Bar AF528A
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/13650_na/13650_na.html
NOTE: Additional HP Power Distribution Units are available. For a complete list of all HP
PDUs and additional information please visit: www.hp.com/go/rackandpower .
HP Rail Kits HP s6500 4U Chassis 598109-B21
QuickSpecs
HP ProLiant s6500 Chassis
Additional Options
DA - 14188 North America — Version 14 — December 13, 2013 Page 13

HP Rack Series HP Intelligent Series Rack
HP 636 1200mm Pallet Intelligent Series Rack BW899A
HP 636 1200mm Shock Intelligent Series Rack BW900A
HP 642 1200mm Pallet Intelligent Series Rack BW907A
HP 642 1200mm Shock Intelligent Series Rack BW908A
HP 647 1200mm Pallet Intelligent Series Rack BW913A
HP 647 1200mm Shock Intelligent Series Rack BW914A
NOTE: Please see the QuickSpecs for Technical Specifications such as height, width,
depth, weight, and color:
http://h18000.www1.hp.com/products/quickspecs/14223_na/14223_na.html
(Worldwide)
NOTE: For additional information regarding Rack Cabinets, please see the following
URL: http://www.hp.com/go/rackandpower .
HP Rack Options HP TFT7600 G2 KVM Console Rackmount Keyboard Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard US Monitor AZ870A
HP TFT7600 G2 KVM Console Rackmount Keyboard UK Monitor AZ871A
HP TFT7600 G2 KVM Console Rackmount Keyboard DE Monitor AZ872A
HP TFT7600 G2 KVM Console Rackmount Keyboard FR Monitor AZ873A
HP TFT7600 G2 KVM Console Rackmount Keyboard IT Monitor AZ874A
HP TFT7600 G2 KVM Console Rackmount Keyboard ES Monitor AZ875A
HP TFT7600 G2 KVM Console Rackmount Keyboard DK Monitor AZ876A
HP TFT7600 G2 KVM Console Rackmount Keyboard NO Monitor AZ877A
HP TFT7600 G2 KVM Console Rackmount Keyboard SE/FI Monitor AZ878A
HP TFT7600 G2 KVM Console Rackmount Keyboard CH Monitor AZ879A
HP TFT7600 G2 KVM Console Rackmount Keyboard PT Monitor AZ880A
HP TFT7600 G2 KVM Console Rackmount Keyboard BE Monitor AZ881A
HP TFT7600 G2 KVM Console Rackmount Keyboard JP Monitor AZ882A
HP TFT7600 G2 KVM Console Rackmount Keyboard RU Monitor AZ883A
HP TFT7600 G2 KVM Console Rackmount Keyboard Intl Monitor AZ884A
HP TFT7600 G2 KVM Console Rackmount Keyboard US TAA Monitor AZ885A
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/13731_na/13731_na.html
(Worldwide)
HP Server Console Switches
HP Server Console 0x2x8 Port Analog Switch AF616A
HP Server Console 0x2x16 Port Analog Switch AF617A
HP TAA 0x2x16xKVM Server Console G2 Switch AF626A
QuickSpecs
HP ProLiant s6500 Chassis
Additional Options
DA - 14188 North America — Version 14 — December 13, 2013 Page 14

NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/11834_na/11834_na.html
(Worldwide)
HP Server Console Switch G2 with Virtual Media & CAC
HP 0x2x16 KVM Server Console Switch G2 with Virtual Media CAC Software AF618A
HP 0x2x32 KVM Server Console Switch G2 with Virtual Media CAC Software AF619A
HP KVM CAT5 1-pack USB Interface Adapter 336047-B21
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/13475_na/13475_na.html
(Worldwide)
HP IP Console Switch G2 with Virtual Media & CAC
HP 1x4 USB/PS2 KVM Console Switch AF611A
HP 1x1Ex8 KVM IP Console Switch G2 with Virtual Media CAC Software AF620A
HP 2x1Ex16 KVM IP Console Switch G2 with Virtual Media CAC Software AF621A
HP 4x1Ex32 KVM IP Console Switch G2 with Virtual Media CAC Software AF622A
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/13474_na/13474_na.html
(Worldwide)
HP Care Pack Services Proactive Care
NOTE: Collaborative Support plus Proactive services delivered by the onshore, local
language Advanced Solution Center (ASC), end-to-end case ownership from a Technical
Solution Specialists and Technical Account Manager who remotely delivers
firmware/software revision management, proactive scans and incident trend reports.
Recommended for customers running a virtualized infrastructure and/or customers
who desire an enhanced call support experience.
HP 3 year Next business day ProLiant s6500 Proactive Care Service U3C66E
HP 3 year 4 hour 24x7 ProLiant s6500 Proactive Care Service U3C72E
Collaborative Support
NOTE: Hardware break/fix plus 24x7 software diagnosis support with collaborative call
management for a broad spectrum of 3rd Party software products including O/S and
hypervisors. Recommended for customers procuring 3rd party SW O/S and hypervisors
from the software vendors directly and deploying them on HP ProLiant servers.
HP 3 year Next business day ProLiant s6500 Collaborative Support U1M46E
HP 3 year 4 hour 24x7 ProLiant s6500 Collaborative Support U1M52E
Installation Services
NOTE: Reduce the time required to get your system up and running and help minimize
disruptions to your business.
HP 3 year Next business day ProLiant s6500 Hardware Support UR398E
HP 3 year 4 hour 24x7 ProLiant s6500 Hardware Support UR402E
QuickSpecs
HP ProLiant s6500 Chassis
Additional Options
DA - 14188 North America — Version 14 — December 13, 2013 Page 15

NOTE: For more information, customer/resellers can contact:
http://www.hp.com/services/carepack
QuickSpecs
HP ProLiant s6500 Chassis
Additional Options
DA - 14188 North America — Version 14 — December 13, 2013 Page 16

System Unit Chassis Dimensions (H x W
x D)
6.96 x 17.638 x 35.236in (17.68 x 44.8 x 89.55cm)
Weight
(approximate)
Maximum
(all hard drives, power
supplies, and processors
installed)
220lb (99.8kg)
Input Requirements
(per power supply)
Rated Line Voltage 90 to 140 VAC
180 to 264 VAC
Rated Input Current 7.31A at 115VAC
3.6A at 230VAC
Rated Input Frequency 47 to 63 Hz
Rated Input Power 855W (at 100 VAC),
840.72W (at 200 VAC)
Power Specifications To review system power requirements, use the HP Power Advisor which is
available via download or online at www.hp.com/go/hppoweradvisor
Power Supply Output
(per power supply)
Rated Steady-State Power 653.10W (at 100 VAC),
653.08W (at 200 VAC)
System Inlet
Temperature
Operating 50° to 95° F (10° to 35° C) at sea level with an
altitude derating of 1.8°F per every 1000 ft (1.0°C
per every 304.8 m) above sea level to a maximum
of 10,000 ft (3048 m), no direct sustained
sunlight. Maximum rate of change is 18°F/hr
(10°C/hr). The upper limit may be limited by the
type and number of options installed.
System performance may be reduced if operating
with a fan fault or above 86°F (30°C).
Non-operating -22° to 140° F (-30° to 60° C)
Maximum rate of change is 36°F/hr (20°C/hr).
Relative Humidity
(non-condensing)
Operating 10% to 90% relative humidity (Rh), 82.4°F (28°C)
maximum wet bulb temperature, non-
condensing.
Non-operating 5% to 95% relative humidity (Rh), 101.7°F
(38.7°C) maximum wet bulb temperature, non-
condensing.
Altitude Operating 10,000 ft (3048 m). This value may be limited by
the type and number of options installed.
Maximum allowable altitude change rate is 1500
ft/min (457 m/min).
Non-operating 30,000 ft (9144 m). Maximum allowable altitude
change rate is 1500 ft/min (457 m/min).
Acoustic Noise Listed are the declared A-Weighted sound power levels (LWAd) and declared
average bystander position A-Weighted sound pressure levels (LpAm) when
the product is operating in a 23°C ambient environment. Noise emissions were
measured in accordance with ISO 7779 (ECMA 74) and declared in accordance
with ISO 9296 (ECMA 109).
Idle
QuickSpecs
HP ProLiant s6500 Chassis
Technical Specifications
DA - 14188 North America — Version 14 — December 13, 2013 Page 17

LWAd 6.4
LpAm 45dBA
Operating
LWAd 6.7
LpAm 51dBA
Emissions Classification
(EMC)
FCC Rating Class A
Normative Standards CISPR 22; EN55022; EN55024; FCC CFR 47, Pt 15;
ICES-003; CNS13438; GB9254; K22;K24; EN
61000-3-2; EN 61000-3-3; EN 60950-1; IEC
60950-1
NOTE: Product conformance to cited product specifications is based on
sample (type) testing, evaluation, or assessment. This product or family of
products is eligible to bear the appropriate compliance logos and statements.
Environment-friendly
Products and Approach
End-of-life Management
and Recycling
Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling
programs in many geographic areas. For trade-in information, please go to:
http://www.hp.com/go/green . To recycle your product, please go to:
http://www.hp.com/go/green or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities.
This information (product disassembly instructions) is posted on the Hewlett
Packard web site at: http://www.hp.com/go/green . These instructions may be
used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
© Copyright 2013 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft and Windows NT are US registered trademarks of Microsoft Corporation. Intel, the Intel logo, Xeon and Xeon Inside are
trademarks of Intel Corporation in the U.S. and other countries.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less.
QuickSpecs
HP ProLiant s6500 Chassis
Technical Specifications
DA - 14188 North America — Version 14 — December 13, 2013 Page 18
