HP Apollo r2800 Installation instructions

EL-MF877-00 Page 1
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Servers
Marketing Name / Model
[List multiple models if applicable.]
HP Apollo r2800 Chassis
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
4
Batteries
All types including standard alkaline and lithium coin
or button style batteries
1
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
0
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Includes background illuminated displays with gas
discharge lamps
0
Cathode Ray Tubes (CRT)
0
Capacitors / condensers (Containing PCB/PCT)
0
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
Depending on power supply model
3
External electrical cables and cords
0
Gas Discharge Lamps
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
0
Components, parts and materials containing
refractory ceramic fibers
0

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Torx Driver
T10
Torx Driver
T15
Torx Driver
T20
Phillips Driver
No.1
Phillips Driver
#2
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. System Megacell -- Remove the top cover and locate the megacell on the system board. Remove the megacell and
dispose properly.
2. Capacitors> 2.5CM -- Remove the power supplys from the system. With #2 Phillips driver remove the screws securing
the top cover and the heatsinks in the power sullpy then locate the capacitors and pry from the PCB and dispose of
properly.
3.
4.
5.
6.
7.
8.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Attachment #1
Attachment #1 Location of Megacell
Attachment #2 ~#8 Capacitor location by model number of power supply

EL-MF877-00 Page 3
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Attachment #2
Attachment #3

EL-MF877-00 Page 4
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Attachment #4
Attachment #5

EL-MF877-00 Page 5
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Attachment #6
Attachment #7

EL-MF877-00 Page 6
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Attachment #8
