HP NetServer
Ultra3 SCSI Hot-Swap
Hard Disk Drive and Tray
User Guide
HP Part Number 5969-5922
Printed in February 2000

ii
Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this
material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. Hewlett-Packard shall not
be liable for errors contained herein or for incidental or consequential damages in
connection with the furnishing, performance, or use of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its software
on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright. All
rights are reserved. No part of this document may be photocopied, reproduced, or
translated to another language without the prior written consent of Hewlett-
Packard Company.
Hewlett-Packard Company
Network Server Division
Technical Communications/MS 45SLE
10955 Tantau Avenue
Cupertino, CA 95014-8059 USA
© Copyright 2000 Hewlett-Packard Company.
Audience Assumptions
The guide is for the person who installs, administers, and troubleshoots LAN
servers. Hewlett-Packard Company assumes you are qualified in the servicing of
computer equipment and trained in recognizing hazards in products with
hazardous energy levels.

iii
Contents
1 Introduction to Ultra3 Drives..........................................................................1
Overview............................................................................................................1
Ultra3 Drives are Low Voltage Devices.........................................................1
Ultra3 Drives Have Two Heights; Drive Cages Have Several Sizes.............1
Filler Panels...................................................................................................1
Disk Spacers .................................................................................................2
Verify Contents .................................................................................................. 2
2 Installation Procedure..................................................................................... 3
Installing the Ultra3 Disk Drive Module..............................................................3
Removing the Ultra3 Disk Drive Module............................................................8
Installing the Ultra3 Drive in a Tray (optional)....................................................9
3 Supported Configurations............................................................................11
4 Warranty and Support...................................................................................13
Hardware Warranty..........................................................................................13
HP Repair and Telephone Support..................................................................13
HP World Wide Web Site................................................................................13
5 Regulatory Information................................................................................. 15
Index.................................................................................................................... 17

1
1 Introduction to Ultra3 Drives
Overview
Ultra3 SCSI hot-swap hard disk drives provide higher I/O bandwidth and can
work with longer cable lengths than Ultra drives. Ultra3 drives operate at SCSI
bus data rates of up to 160 MB per second--double the rate of Ultra2 SCSI. With
Ultra3 drives, HP NetRAID environments and applications will show immediate
increases in performance.
Note: These drives are also backward compatible with Ultra2
controller systems.
Ultra3 Drives are Low Voltage Devices
Ultra3 drives have LVD (low voltage differential) signal levels. The low voltage
requirements allow the integration of the differential drivers and receivers into
drive SCSI controllers. LVD provides the signal quality necessary to run at Ultra3
data rates. LVD also allows for significantly longer SCSI bus cable lengths.
Ultra3 Drives Have Two Heights; Drive Cages Have Several Sizes
Ultra3 disk drive modules come in two heights: the 1-inch (2.5 cm) low profile
drive and the 1.6-inch (4 cm) half-height drive. NetServer drive cages come in
several sizes. There are two types of six-drive cages. The LH3, LH4, and RS-12
cages support a mix-and-match of 1-inch low profile drives and 1.6-inch (4 cm)
half-height drives. Other NetServers with six-drive cages support either 1-inch (2.5
cm) low profile drives or 1.6-inch (4 cm) half-height drives. Refer to your
NetServer manuals for details. Chapter 3 lists the places where the supported
configurations can be found.
Filler Panels
When you have fewer drives than the hot-swap cage supports, filler panels must be
inserted in empty disk locations. Filler panels ensure that the hot-swap cage has
the proper ventilation and air flow. You will remove the filler panel when you
insert a new Ultra3 disk drive module. (Figure 2-1 in the next chapter shows a
filler panel.)

Chapter 1 Introduction to Ultra3 Drives
2
Disk Spacers
When your hot-swap cage holds a mix of low profile and half-height drives, one
drive may require a disk spacer. The disk spacer fills empty space between one
drive and the adjacent drive. Disk spacers can be mounted on 1-inch (2.5 cm) low
profile drives or 1.6-inch (4 cm) half-height drives. (Figure 2-2 in the next chapter
shows a disk spacer.)
Verify Contents
The Ultra3 SCSI Hot-swap Hard Disk Drive and Tray Accessory Kit contains the
following items:
•Ultra3 SCSI hot-swap hard disk drive module
•disk spacer
•Ultra3 SCSI Hot-swap Hard Disk Drive and Tray User Guide
If anything is missing or damaged, call your reseller.

3
2 Installation Procedure
This chapter describes how to install the Ultra3 disk drive module in your
HP NetServer, and provides instructions for removing and storing the disk drive
module. Additionally, this chapter describes how to attach an Ultra3 drive to a hot-
swap tray.
Installing the Ultra3 Disk Drive Module
CAUTION Protect the Ultra3 disk drive module from static electricity by
leaving it in its antistatic bag until you are ready to install it.
Before handling the disk drive module, touch any unpainted
metal surface to discharge static electricity. When you remove
the disk drive module from the antistatic bag, handle it only by
the frame.
Do not touch the electrical components. Place the disk drive
module on the antistatic bag whenever you set it down.
Disk drive modules are very susceptible to mechanical shock
and can be damaged by a drop as short as one-quarter of an
inch (.5 cm). Take care when unpacking and handling the disk
drive module. If the drop would crack an egg, it will damage
the drive.

Chapter 2 Installation Procedure
4
1. If there is a filler panel in the drive location, remove the filler panel as
follows:
• Press the latch and insert your fingers.
• Using your fingers, pull the filler panel straight out.
Figure 2-1 shows a filler panel being removed from a system with a
six-drive hot-swap cage. Your HP NetServer’s enclosure may have a
four-drive cage or a two-drive cage.
Figure 2-1. Removing the Filler Panel

Chapter 2 Installation Procedure
5
2. Disk spacers attach to the disk drive module with four small feet.
To remove a disk spacer from the adjacent disk drive module:
• Slide the disk spacer back, a fraction of an inch (2.5 cm), away from
your body.
• Tilt up the front of the disk spacer to disengage the front two feet.
• Pull the disk spacer forward slightly, to disengage the back two feet and
lift.
Figure 2-2. Removing the Disk Spacer From a Disk Drive Module
To attach a disk spacer to a disk drive module:
• Tilt up the front of the disk spacer and engage the back two feet.
• Press the disk spacer back, a fraction of an inch (2.5 cm), away from
your body.
• Lower the front of the disk spacer into place to engage the front two
feet.

Chapter 2 Installation Procedure
6
3. On the Ultra3 disk drive module, press the blue latch in and pull the lever
out as far as it can go as shown in Figure 2-3. Pulling open the lever
retracts the locking tab on the side of the disk drive module. Be careful not
to use extreme force when pulling the lever.
Figure 2-3. Pulling Open the Lever Retracts the Locking Tab
on the Side of the Drive
4. Slide the Ultra3 disk drive module slowly into the drive location until it
stops. In some systems, drives are inserted horizontally (Figure 2-4); and in
other systems, drives are inserted vertically (Figure 2-5).
Be careful of the light pipes as you insert the drive. The light pipes are
fragile.
CAUTION You must insert the drive slowly and gently. The connector is
designed with some long pins that must make contact before
the short pins. If the disk drive module is inserted too quickly,
the short pins make contact too quickly after the long pins.
The in-rush current can cause the power supply to shut down.
5. Press the lever in, until you hear the latch click into place.

Chapter 2 Installation Procedure
7
Figure 2-4. Installing the Disk Drive Module in the
Horizontal Position
Figure 2-5. Installing the Disk Drive Module in the Vertical Position

Chapter 2 Installation Procedure
8
Removing the Ultra3 Disk Drive Module
CAUTION You must remove the disk drive module slowly to ensure that
the drive heads are parked prior to removal. Be sure to follow
these instructions carefully to prevent handling damage, such
as head slaps or head actuator unlocking.
1. To unlock the Ultra3 disk drive module, push the blue latch in, and then
pull the front lever.
2. Gently pull the disk drive module out, about an inch (2.5 cm), to break the
power connection.
3. Wait about 30 seconds for the hard disk drive to stop spinning and the
drive heads to park.
4. Use your hand to support the bottom of the disk drive module. Slowly pull
the disk drive module straight out. Do not allow the disk drive module to
fall.
5. If your disk drive modules are inserted vertically, turn the disk drive
module slowly to its horizontal storage orientation.
6. Place the disk drive module in an electrostatic protected container. Do not
stack disk drive modules.

Chapter 2 Installation Procedure
9
Figure 2-6. Removing the Disk Drive Module
Installing the Ultra3 Drive in a Tray (optional)
Ultra3 SCSI hot-swap tray accessories have two different sizes: the 1.6-inch
(4 cm) half-height drive uses tray accessory D6127A, and the 1-inch (2.5 cm) low
profile drive uses tray accessory D6128A. (These tray accessories also support
Ultra2 drives.)
CAUTION Handle the drive and tray gently during assembly. Start all
screws prior to tightening. Do not allow the drive or the tray to
drop; dropping the drive or tray will cause drive damage.
If you purchase an Ultra3-SCSI hot-swap tray accessory separately from the Ultra3
drive, refer to Figure 2-7 and follow these steps to attach the tray accessory:
1. Place the Ultra3 drive into the hot-swap tray.

Chapter 2 Installation Procedure
10
2. Plug the SCA extender into the Ultra3 drive.
3. Insert the two screws that hold the SCA extender in place, then tighten
snugly. Do not over tighten.
4. Insert the four screws that attach the Ultra3 drive to the hot-swap tray, then
tighten snugly. Do not over tighten.
2. SCA extender
plugs into drive
1. Drive fits into tray
3. Two screws hold
SCA extender in place
4. Four screws attach the
drive to the tray
Figure 2-7. Ultra3 Drive and Tray Installation

11
3 Supported Configurations
Supported configurations can be found in all of the following sources:
•The Installation Guide (or User Guide) shipped with your HP NetServer.
•The HP NetServer Online Documentation CD-ROM.
•The Installation Guide (or User Guide) for your HP NetServer can be viewed
and printed from the official HP NetServer web site:
http://www.hp.com/go/netserver

13
4 Warranty and Support
The hardware warranty below applies to components purchased as accessories. If
your component was factory installed as part of an HP NetServer model, refer to
the warranty statement provided with your system documentation.
Hardware Warranty
This HP NetServer accessory is covered by a limited hardware warranty for a
period of one year from receipt by the original end-user purchaser.
Once installed in an HP NetServer, this accessory may carry the longer of either a
one-year warranty or the remainder of the warranty period for the HP NetServer in
which it is installed.
This accessory may be serviced through expedited part shipment. In this event, HP
will prepay shipping charges, duty, and taxes; provide telephone assistance on
replacement of the component; and pay shipping charges, duty, and taxes for any
part that HP asks to be returned.
The customer may be required to run HP-supplied configuration and diagnostic
programs before a replacement will be dispatched or an on-site visit is authorized.
Refer to the warranty statement provided with your original HP NetServer system
documentation for the warranty limitations, customer responsibilities, and other
terms and conditions.
HP Repair and Telephone Support
Refer to the HP NetService Warranty and Service/Support Booklet section of your
HP NetServer system documentation for instructions on how to obtain HP repair
and telephone support.
HP World Wide Web Site
Refer to the following World Wide Web (WWW) site for technical specifications
on Hewlett-Packard hard disk drives:
http://www.hp.com:80/netserver/support/news_main.html

15
5 Regulatory Information
DECLARATION OF CONFORMITY
according to ISO/IEC Guide 22 and EN 45014
Manufacturer’s Name: Hewlett-Packard Company
Address: 10955 Tantau Avenue
Cupertino, CA 95014 USA
declares, that the product
Product Name: Ultra3 SCSI Hot-Swap Hard Disk Drives
Model Number(s): D6104A, D6106A, D6107A, D6108A, D7031A, D7174A, D7175A,
D9419A, D1166A, P1216A, P1217A
Product Options: N/A
conforms to the following Product Specifications:
Safety: IEC 60950:1991+A1+A2+A3+A4 / EN 60950:1992+ A1+A2+A3+A4 &
A11 GB4943-1995
EMC: CISPR 22:1993+A1+A2 / EN 55022:1994+A1+A2
EN 50082-1:1992 - Generic Immunity
IEC 801-2:1991, 4 kV CD, 8 kV AD
IEC 801-3:1984, 3V/m
IEC 801-4:1988, 0.5 kV Signal Lines, 1 kV Power Lines
FCC Title 47 CFR, Part 15
Supplementary Information:
1) The product was tested in a typical configuration with Hewlett-Packard peripherals.
2) The product herewith complies with the requirements of the following directives, and
carries the CE-marking accordingly:
o Low Voltage Directive 73/23/EEC
o EMC Directive 89/336/EEC
Cupertino, April 5, 2000
Erin McLaughlin/Quality Manager
North America Contact: Hewlett-Packard Company, Product Regulations Manager, 3000 Hanover Street,
Palo Alto, CA 94304, Phone [phone]. European Contact: Local Hewlett-Packard Sales and Service
Office or Hewlett-Packard GmbH, Herrenberger Straße 130, D-71034 Böblingen (FAX: + 49-7031-14-3143)
